CLiC-iT IMN PU-V6 Instructions for use

1
&
INSTRUCTIONS AND MAINTENANCE MANUAL
CONTINUOUS BELAY SYSTEM
Ed16 17-09-21
&

2
&
INDEX
ANNEX B
Control and Maintenance sheet..........46
ANNEX A
Use and safety infographic...............45
1. CLiC -iT Pulley.......................................................................................................................................3
1.1. Funconality................................... .................................................................................................................................. 4
1.2. Carabiner Connecon....................................................................................................................................................... 5
1.3. Lanyard Connecon................................... ....................................................................................................................... 6
1.4. Safetyline anchorages compability................................................................................................................................. 7
2. Anchor............................................. ......................................................................................................8
3. Traceability and Marking.......... ..........................................................................................................9
3.1. Traceability and Marking. CLiC-iT Pulley...................... ..................................................................................................... 9
3.2. Traceability and Marking. Anchor.................. ................................................................................................................... 9
4. Anchor Wedge ........................... .........................................................................................................10
5. Other IMN & CLiC-iT CBS components .............................................................................................10
5.1. Arculated arms. Types and connecons ........................................................................................................................11
5.2. Non-Returns. Types and connecons ..............................................................................................................................12
5.3. Posioners. Types and connecons .......................................................................................................................14
5.4. Cable Connector. .............................................................................................................................................................14
5.5. Route Swapper. ...............................................................................................................................................................15
6. Assemblies.............................
.............................................................................................................16
6.1.
8.1.
Anchor and Anchor Wedge..
Icons for CBS schemes..........
................................
................................
................................
................................
................................
................................
................................
................................
............
............
16
22
6.2.
8.2.
Anchor and Inverter...............
CBS Path examples.................
................................
................................
................................
................................
................................
................................
................................
................................
..........
..........
17
23
6.3.
Anchor and Arculated Arm........ .....................................................................................................................................18
6.4.
Anchor Plate for Trees and Vercal Posioner..................... ............................................................................................18
6.5.
Arculated Arm on trees using Liing Sling. ....................................................................................................................19
6.6.
Anchor Plate for Trees using ratchet tape......... ...............................................................................................................19
7. IMN & CLiC-iT Continuous Belay System Height. ...........................................................................20
8. IMN & CLiC-iT Continuous Belay System Path ................................................................................21
9. IMN&CLiC-iT Continuous Belay System. Specifications......... ........................................................ 33
9.1. Installaon according to different inclinaon cases.. .......................................................................................................33
9.2. Ziplines.. ..........................................................................................................................................................................34
9.3. Installaon according to different structural anchoring cases.........................................................................................35
9.4. Requirements for CBS anchorages installaon. .............................................................................................................. 36
9.5. Safety line cable installaon ........................................................................................................................................... 37
10. RESPONSABILITY & GENERAL RECOMENDATIONS.. ...................................................................39
10.1. Further informaons. ..................................................................................................................................................... 40
10.2. Cauon. ..........................................................................................................................................................................40
10.3. Training of the staff. ....................................................................................................................................................... 40
10.4. Supervision. ....................................................................................................................................................................40
11. Usage precautions. ............................................................................................................................ 41
12.
13.
Product life cycle and warranty.
Product references .....................
................................
................................
................................
................................
................................
................................
.......
.......
43
44

3
&
CLiC-iT Pulley is designed for the use jointly with OK carabiner from PETZ with
triple locking, to be considered a Class E safety category regarding EN 17109:2020.
Other carabiners with similar characteristics are allowed with IMN & CLiC-iT as a
self-locking device (see section 1.2).
ŸAm'D PIN-LOCK. Petz
To ensure the correct condition of the product, please refer to the control points
before and after use. Only official replacements of B, C and D parts are allowed.
Components
x1
x2 x4 x6 x1 x2 x2
x2 x2 x1
x1
x1
x1
J
D E F G H I
K L M
A
A
F K
B G L
C H M
D I
EJ
B
C
Body
Reference: PU-V6
Torx Screw
DIN 965 M5x14 Spacer Ring Ø7
Spacer Ring Ø8
Magnet
Locking part rod
Sheave shaft
Central shaft
S e t s c r e w
DIN 914 M5x8
Plate
Locking cam
Sheave
Bearing 608 2RS
CLiC-iT Pulley is an MCD (mobile connection device) designed to prevent from fall risk
and operate along an IMN&CLiC-iT safetyline regarding the recommendation of the PPE
2016/425. Its main functions are to assure the user to the lifeline and to provide a continuous
movement through it.
It´s not necessary for the user to perform any manipulation in CLiC-iT Pulley until get out of the
lifeline.This product is a Personal Protection Equipment designed for leisure activities at heights
(high rope adventure parks) as per standard EN17109:2020.
Description
1
Material
Aluminum
20 kN
Max. Vertical Load
Dimensions
120x123x36(mm)
Dimensions
120x123x36(mm)
600g
Weight
Controled by:
APAVE SUD EUROPE
CS 60193 - 13322
MARSEILLE CEDEX 16,
France
CE number 0082
The UE conformity
check is avalable
for download at:
www.clic-it.eu 18mm
Aperture in unlocking position
8mm
Aperture in locking position
CLiC-iT Pulley

4
&
The sheaves adapt Sheaves of CLiC-iT Pulley to the cable and Anchor dimensions. are
designed to provide fluid movement during play activity and to reduce noise during use. To
do this each of them incorporate two 608 2RS1 bearings and components that fit them in
the right position. Bearings and sheaves must be replaced when it is detected that the
movement is not correct.
When the MCD is in working condition it remains in
contact with the body thanks to the magnetic force exerted
by the magnet.
The geometry of the carabiner prevents the opening of the
MCD locking system, avoiding risks of disconnection due
to system failures.
The housing where the carabiner is inserted is designed to
avoid any unfavorable position during the activity.
ŸEN 17109:2020. “ Mountaineering equipment. Individual safety systems for rope
courses. Safety requirements and test methods”.
ŸEN- 15567-1:2015. “ Sports and recreational facilities - Ropes courses - Part 1:
Construction and safety requirements. ”
ŸDon´t clean the pMCD with soap or water.
ŸAvoid long exposure of the product in saline environments.
ŸTo remove dirt from the MCD use air or a damp cloth.
ŸThe MCD doesn´t need to be lubricated.
ŸAfter use, store the MCD in a dry place.
Movement system
Placing on the safety line Locking system
Standards applied
Storage and cleaning recommendations
The open area of the channel where the
cable is hosted in CLiC-iT Pulley is 8mm
between parallel faces of parts B (Plate)
and C (locking cam).
Part C, locking cam, should be inspected at
intervals of one week or after use by 1000
users.
8mm
Wear
indicator
Please contact the Technical Service to
request a replacement.
Both parts should be replaced when you
cannot clearly see any wear indicator.
B and C parts incorporate a 0.5mm depth
slot to control the wear produced with use.
Wear Inspection
Before connecting the MCD to the safetyline you must have your landyard properly connected to the
harness and your carabiner properly connected to the landyard too (see point 1.3 in the manual).
Make sure you are in a safe position on the floor and disconnect the carabiner from CLiC-iT Pulley in
case it is connected.
Move the Locking Cam until it magnetically locks and insert the carabiner according to the
orientation shown in the next page.
Unlock CLiC-iT Pulley by pressing with both thumbs on the bottom of the Locking Cam (part C).
Insert the MCD on a straight portion of compatible cable. Be sure to orient CLiC-iT Pulley with the
face marked looking at the anchors.
Regulate the length of the landyard according to the indications of point 1.3 and move the MCD
along the cable to check the correct operation.
1
22
23
24
25
26
Functionality
1.1
1
CLiC-iT Pulley

5
&
CLiC-iT Pulley is designed to
support both carabiner positions.
It´s recommended the position
shown in the image to reduce the
risk of collision in the MCD when
passing through the safety line
anchors.
Below are the dimensions of the MCD hole for
carabiners:
Tensile strength (Rm): It´s the longitudinal load that a carabiner supports
until it breaks.
A carabiner with a minimum tensile strength (Rm) of
22kN is required to meet safety requirements
Consult your carabiner technical specifications
to check compatibility with CLiC-iT Pulley.
13,25mm
16,45mm
13,25mm
19,75mm
13,10mm
Allowed carabiners
Recommended carabiner
Safety Class E Safety Class B (risk of openning)
OK TriactLock
Petzl
Rm: 25kN lengthwise
Rm: 24kN lengthwise
CT
Pillar TG
Fixe
Symmetric
automatc 3
Rm: 22kN lengthwise
Petzl
Am'D Pin-Lock
Rm: 27kN lengthwise
To ensure system safety, use only Pin
Lock-type carabiners as recommended
below in conjunction with CLiC-iT Pulley.
Carabiner connection
1.2
1
CLiC-iT Pulley

6
&
An adjustable lanyard is used to connect the carabiner with the user´s harness. Use only harness that
comply with EN 12277+A1. The lanyards recommended by the manufacturer are shown below:
Adjustable lanyard regulation
Regardless of the height at which IMN&CLiC-iT CBS is installed,
the adjustable lanyard must be adjusted in the user´s harness
with an approximate drop of 10cm.
The correct harness and lanyard length must be chosen
individually to each participant correctly. Harness must be put on
properly and double checked. Adjustments to the harness leg
loops are necessary to prevent the harness clip-in point from
sliding upwards in the case of a fall. This harness rise should be
taken into consideration and planned for.
The user should be instructed on proper harness t and to ask a
guide if something feels wrong. It should be forbidden for
participants to put on the harness on their own.
5cm Ex. 180cm
Lower
Height
5cm
≈ ≈
See your lanyard instructions for
connecting to carabiner.
See your lanyard instructions for
connecting to carabiner.
from PETZ Connect Adjust instructions: from PETZ Connect Adjust instructions:
from: PETZ Connect Vario instructions:
from: PETZ Connect Vario instructions:
A type Lark´s head / Cow
hitch knot connection is
recommended.
Connection with the carabiner
of the MCD.
Connection with the carabiner
of the MCD
Connection with harness.
Connection with harness.
Dual Connect Vario
PETZL
Connect Adjust
PETZL
Possibility 1
Possibility 2
Lanyard connection.
1.3
1
CLiC-iT Pulley

7
&
Structural anchorages compatible with the CLiC-iT Pulley must meet the requirements of the UNE EN 795:2012
standard to ensure user safety.
Below are the dimensional requirements that an anchorage must meet to be considered compatible with the CLiC-iT
Pulley:
ŸThe anchorage must be inclined 35º with the vertical axis to ensure correct movement of the MCD, correct stability
and avoid collisions in the system.
Ø20mm
max. thickness:
5mm
min. neck length:
20mm
80mm min.
70mm min.
Safetyline anchorages compatibility.
1.4
1
CLiC-iT Pulley

8
&
Anchor Components
Reference: LAN-V2
x1
x3
x4
x3
x3 x3
A
C
D
B
E F
A C E
B D F
Anchor Body Fix screw.
DIN 933 M10x40 Thin nut.
DIN 936 M10
Anchor Screw.
DIN 912 M8x35 Self-Locking nut. DIN 985 M8
Fastening part
The Anchor installation and maintenance requires the use of a calibrated
torque wrench.
The installation of the Anchor on the Anchor Wedge is carried out using
the components D and F according to the assembly procedure of this
Follow the torque specifications described in this manual for each
installation case.
Anchor allows a continuous
movement for CLiC-iT Pulley along
the entire game course. Its function is
to guide the IMN&CliC-iT Safety Line
cable and keeping it fixed at a certain
point. To do this, 3 gripping pieces
press the cable and prevent any
movement.
Description
2
Usage Specications
Required tools:
Manual or Digital Torque Wrench
Ex: Irimo
Supported safety cable diameter
12 < ø < 13 (mm)
17mm Hexagonal head
or
17mm Hexagonal socket
! The use of an impact wrench is
not allowed.
! Ignoring these indications can
lead to anchor fracture.
! Never exceed the indicated
torque.
To fix the safety cable,
you must exe r t a
torque of 40 N / m on
each M10 screw.
A torque wrench must
be used to not exceed
this value.
Finally, manually tighten the nuts of each screw.
ŸAvoid long exposure of the product in saline environments.
ŸDon´t clean Anchor with soap or water.
ŸTo remove dirt from Anchor use air or a damp cloth.
Cleaning Recommendations
40 N/m
40 N/m
40 N/m
Anchor

9
&
Traceability and Marking
Essential Technical Specications.
EN 17109:2020
Anchorage designed for safety lines
equipped with 12 mm diameter steel
cable.
Essential instructions for product use
described in the manual.
Code respective to the
production batch and
correlative to the part
version.
Standard for personal protective
equipment against falls in height.
It establishes the technical requirements
necessary to cover the possible health
and safety risks associated with the use
of the product.
Compliance with European Directive
89/686/EEC: Personal protective
equipment (PPE).
This document specifies safety requirements
and test methods for components of an
individual safety system for protection against
a fall from height used in permanent and
mobile rope courses as defined in EN 15567-1.
Mountaineering equipment. Individual
safety systems for rope courses. Safety
requirements and test methods.
Individual identification code.
(A):part denomination.
(XXXX): unique numeric code.
Limit load capacity established by the
manufacturer for use in the indicated
direction.
A0854
A0854
3
1
1
2
2
2
2
2
2
8
2
3
4
5
6
7
9
8
9
2
3
7
4
5
6
12 < Ø < 13 mm
20 kN SN: XXXX.MM.YY
EN 17109:2020
PU-V6 - DAS436
0082
APAVE SUDEUROPE SAS (0082)
Manufacturers.
Compilance with EU Regulation 2016/425 .
Notified body involved in the CE type examination and
incharge of equipment certification:
Cs60193 - 13322 Marseille Cedex 16 France.
20kN. Static resistance of the product, guaranteed at the
time of production and validated during UE check. With a
safety factor of 1.3 over the requirements of standard EN
17109:2020.
Safety line compatibility. Diameter range of the cable.
Individual product identification number:
SN: XXXX.MM.YY
XXXX: unique identifier number.
MM: manufacturing month.
YY: manufacturing year.
IMN reference: PU-V6
CLiC-iT reference: DAS-436
Carefully read the notice before using the product.
Reference of the product:
This product in conjunction with a Pin Lock type
carabiner belongs to category E (device that is
permanently attached during operation and can
only be opened with a tool) which is determined
by the standard.
Use the product with Pin Lock carabiners as
recommended in the section 1.2 of this manual.
&
CLiC-iT Pulley Anchor
3.1 3.2

10
&
Articulated arms
Other IMN & CLiC-iT
CBS components
Anchor Plate for Trees
Positioner
Inverter
References:
References:
Reference: AP-V2
Simple articulated Arm (Left side)
Simple articulated Arm (Right side)
Double articulated arm (Left side)
Double articulated arm (Right side)
Reference: IN-V3
SAL-V1
BAL-V1
BAR-V1
SAR-V1
Anchor Plate for Trees is used in adventure
parks installed on trees. On this are
mounted the necessary elements to drive
the IMN & CLiC-iT CBS in the desired
direction. The installation system prevents
damage to the natural environment.
This element inverts the positioning of the
anchorage and allows to adjust the inclination
of this to adapt to a certain trajectory of IMN &
CLiC-iT CBS.
Vertical Positioner Horizontal Positioner.
VP-V1 VH-V1
5
Anchor Wedge
Reference: LDV-C-ED3
Anchor Wedge is a piece of cast
steel whose function is to provide
the ideal inclination of 35º for
Anchor. This is the standard
connecting element for attaching
the Anchors to the structural poles
of an adventure park.
Description
4
Positioners are auxiliary
anchors wich are located
at points where high
structural strength is not
required required.
More info in page 14

11
&
Articulated arms. Types and connections
Simple articulated Arm (Left side)
Simple articulated Arm (Right side)
Double articulated arm (Left side)
Double articulated arm (Right side)
SAL-V1
BAL-V1
BAR-V1
SAR-V1
Arm connection
in structural parks
Arm connection
in tree parks
The arm is installed with one
or two 5/8 (inch) shackles
depending on the case.
For horizontal structural
c o n n e c t i o n s , t w o
shackles are required.
For vertical structural
conn e c t ions, o n e
shackle is required.
For tree sling connections,
one shackle are required.
5.1
Other IMN & CLiC-iT CBS components
5

12
&
For Anchor Wedge
Reference: NR1-V1 Reference: NR2-V1
For Vertical Positioner Reference: NR3-V1
For Inverter
Structural
connection
Non-Return devices are used to stop and prevent the MCD move back at certain points in the path. It
is useful in inclined sections, in entrances or exits of the park or to control the flow of users in ziplines.
Depending on the type of anchorage, there are different types of Non-Returns.
Non-Return are independent components that can be added to Anchor Wedge (Type A), Vertical
Positioner (Type B), Inverter (Type C) or be placed in elemets for adventure park to prevent falls
(Type D).
Non-Returns Type A, B and C consist of a folded sheet metal for each of the cases and a piece of
silicone, which is valid for any system:
Vertical
Positioner
Anchor + Anchor Wedge
Assembly
Inverter
TYPE A TYPE B TYPE C
DIN 7380 Screw
M8x20 (min.)
A2
DIN 933 Self-Locking nut
M8
8.8
x2
x2
Non-Returns. Types and connections
5.2
Other IMN & CLiC-iT CBS components
5

13
&
Reference: NR4-V1
Structural Non-Return
TYPE D
Hexagonal crimping die K18
Manual hydraulic crimping tool
Ex:CEMBRE Model 1350-C
The cable crimping must be done with a crimping tool capable of
exerting a force of 130 KN. The crimp die used must be of type K18
according to DIN 48083.
x2 crimpings must be
made on each side.
It must be entered during
the installation of the
rope course section.
Its function is to stop the MCD and prevent it from sliding backwards in an inclined
section of element for adventure parks. It´s used as a structural component to
prevent falls. We recommend its installation in games with a slope higher than 6º.
The Non-Return Type D is an obstacle to the pulley wich must be passed through by
turning the MCD 35º.
Non-Return devices are used to stop and prevent the MDC move back at certain
points in the path. It is useful in inclined sections, in entrances or exits of the park or
to control the flow of users in ziplines.
How to install it?
Forbidden to install this
component as a
Cable Connector
35º
160
56
10
AISI 304
Non-Returns. Types and connections
5.2
Other IMN & CLiC-iT CBS components
5

14
&
The cable crimping must be done with a crimping tool capable of
exerting a force of 130 KN. The crimp die used must be of type K18
according to DIN 48083.
A total of 8 crimpings
must be made on the
crimp sleeve.
AISI 304
Hexagonal crimping die K18
Manual hydraulic crimping tool
Ex:CEMBRE Model 1350-C
At times during installation there may be a need to connect two
ends of the safety line cable.
Positioners are an economical option to guide the safety
line cable at points where the structural strength
provided by an Anchor is not required.
Positioner Tube installed on Inverter is also
used when it needs to be placed in the
opposite direction. In places where great
structural resistance is not needed, such as
stairs or the beginning and end of a safety line.
Ex: Vertical Positioner
installed on Anchor
Plate for Trees
Ex: Horizontal Positioner
installed on structural
pole.
There are two types of Positioners, depending on
whether a vertical or horizontal installation is required.
This devices can rotate to accommodate the path
inclination required by the safety line.
Vertical Positioner.
Positioner Tube.
Horizontal Positioner.
Reference: HP-V1Reference: VP-V1
Reference: PT-V1
DIN 7380 Screw
M8x20 (min.)
A2
DIN 7380 Set Screw
M5x5
A2
DIN 933 Self-Locking nut
M8
8.8 x1
x1
x2
Positioners fixes
cable using two
M5x5 set screws.
20,7
250
12,7
20,7
250
12,7
Positioners. Types and connections Cable Connector
5.3 5.4
Other IMN & CLiC-iT CBS components
5
Reference: CC-V1

15
&
Reference: RS-V1
Misuse of the product:
The cable crimping must be done with a crimping tool capable of
exerting a force of 130 KN. The crimp die used must be of type K18
according to DIN 48083.
A total of 4 crimpings must be
made on each cable connection.
Inclination of the product with respect to the vertical axis:
Hexagonal crimping die K18
Manual hydraulic crimping tool
Ex:CEMBRE Model 1350-C
How to install it?
Where to install it?
Primary route procedure
It is not necessary to handle the MCD
if the product has been installed at 35º
respect to the vertical axis.
Forbidden to install this
component in ziplines and
rope course games
Only install on a
stable platform
Secondary route procedure
Wrong
turning direction
145º
Correct
turning direction
Route Swapper must be installed in a position where the user is stable and with enough room to
maneuver the MCD
Route Swapper is a device designed to alternate between safety line routes in an high rope course. It
should be installed at a comfortable height where the user will have to manipulate CLiC-iT Pulley.
It works by turning the MCD to orient it towards the alternative route or by maintaining original orientation
to continue on the route.
35º
145º
Route Swapper
5.5
Other IMN & CLiC-iT CBS components
5

16
&
Anchor Screws
DIN 912 M8x35
Anchor Wedge Screws
DIN 933 M8x35 Assembly order
Anchor
Anchor Wedge
Self-Locking nuts
DIN 985 M8 Anchor
Wedge
x4x4
x4
x8 1st Step
1st Step 2nd Step
2nd Step
Required tools:
Hex Key - 6mm (7/32'') Required tools:
Spanner - ISO/DIN13mm
Anchor and Anchor Wedge
6.1
Assemblies
6

17
&
Anchor Screws
DIN 912 M8x35
Inver ter Sc rew s
DIN 933 M8x35(min)
Inverter
Structural post Assembled
CBS Anchor
CBS Wedge
Self-Locking nuts
DIN 985 M8
x4
x2
x2
Self-Locking nuts
DIN 985 M8
x4
Anchor
Assembly order
2nd Step
1st Step
CBS Anchor and Inverter Arm
6.2
Assemblies
6

18
&
Anchor Screws
DIN 912 M8x35
Flat Washer
DIN 125 M8
x4x4
x4x4
x4x4
x3
Anchor
Anchor Plate for Trees
Articulated Arm
Self-Locking nuts
DIN 985 M8
Vertical Positioner Screw
DIN 7380 M8x20
Vertical Positioner
Parts
x3
Self-Locking nuts
DIN 985 M8
Required tools:
Spanner - ISO/DIN13mm
Hex Key - 6mm (7/32'')
Required tools:
Spanner - ISO/DIN13mm
Hex Key - 6mm (7/32'')
Anchor and Articulated Arms
6.3
Assemblies
6
Anchor Plate for Trees and Vertical Positioner
6.4

19
&
Ratchet Tape
1.500Kg x (?)m.
Width 35mm Plastic Tube.
Ratchet tape protector
D32mm x L160mm
Wood Plank.
Tree protector
x2
x1
x2
5/8 (inch) Shackle
10-15cm Ø Tree +
+
2.000Kg
Lifting Sling
Lark´s head
Anchor
Articulated Arm
The remaining length after the knot should
protrude between 10 and 15 cm.
To install an Articulated Arm on a tree a 2000 Kg
lifting sling is required.
Be sure to measure the diameter of the tree at
the height where the installation will be made.
The ratchet tape must be
located in an inaccessible
position to the user.
Slings are measured end to end
Required items:
Assemblies
6
Anchor Plate for Trees using ratchet tape.
6.6
Articulated Arm on trees using lifting sling
6.5

20
&
IMN & CLiC-iT Continuous Belay System height
Two safety cables can overlap in the
same path if they maintain a certain
vertical and horizontal distance.
Standard distance between
a safety cable and wall.
Minimum horizontal distance
between safety cables.
Minimum vertical distance
between safety cables.
aa
>19cm
>6cm
>20cm
b
b
c
c
Parallel Safety Line
CBS example
in a park with
two heigh levels
pte 30%
pte 30%
1,7 < x < 2 (m)
1,7 < x < 2 (m)1,7 < x < 2 (m)
1,6m
x>6º
x<6º
1,7 < x < 2 (m)
Safety cable height.
170 to 200 cm above platform
Beginning.
aprox 160cm above floor
The safety cable can be
installed at heights lower
than those shown in the
diagram
Non-Return Type D
for cable slope > 6º
7
