CM Hurricane Mini 360 User manual

192083259 (REV AA) March 2021
Before installing hoist, fill in the information below.
Model Number
Purchase Date
Rated Load
RATED LOADS 1/4 TO 1/2 TONNES
250 KG TO 500 KG
Follow all instructions and warning for inspecting,
maintaining and operating this hoist.
The use of any hoist presents some risk of personal injury
or property damage. That risk is greatly increased if proper
instructions and warnings are not followed. Before using
this hoist, each operator should become thoroughly familiar
with all warnings, instructions and recommendations in this
manual. Retain this manual for future reference and use.
Forward this manual to operator. Failure to operate equipment
as directed in manual may cause injury.
OPERATING, MAINTENANCE
& PARTS MANUAL

2192083259 (REV AA) March 2021
CM HOIST PARTS AND SERVICES ARE AVAILABLE IN THE UNITED STATES AND CANADA
PARTS FOR YOUR HOIST ARE AVAILABLE FROM YOUR LOCAL AUTHORIZED REPAIR STATION.
FOR THE NAME OF THE NEAREST PARTS OR SERVICE CENTER, VISIT OUR WEB SITE
WWW.COLUMBUSMCKINNON.COM OR CALL OUR CUSTOMER SERVICE DEPARTMENT AT 800-888-0985.
AN ELECTRONIC COPY OF THIS MANUAL AND THE CM HOIST PARTS AND SERVICES LIST IS AVAILABLE AT:
WWW.COLUMBUSMCKINNON.COM
Follow all instructions and warnings for inspecting, maintaining, and operating this hoist.

3192083259 (REV AA) March 2021
Improper operation of a hoist can create a potentially
hazardous situation which, if not avoided, could result
in death, or serious injury. To avoid such a potentially
hazardous situation, the operator shall:
1. NOT operate a malfunctioning or unusually performing hoist.
2. NOT operate the hoist until you have thoroughly read and
understood this manual.
3. NOT operate a hoist which has been modied.
4. NOT lift or pull more than rated load for the hoist.
5. NOT use damaged hoist or hoist that is Not working properly.
6. NOT use hoist with twisted, kinked, damaged,
or worn load chain.
7. NOT use the hoist to lift, support, or transport people.
8. NOT lift loads over people and make sure all personnel
remain clear of the supported load.
9. NOT attempt to lengthen the load chain or repair
damaged load chain.
10. Protect the hoists load chain from weld splatter
or other damaging contaminants.
11. NOT use load chain as a sling or wrap load chain around load.
12. NOT apply the load to the tip of the hook or to the hook latch.
13. NOT apply load unless load chain is properly seated in the
chain wheel(s) or sproket(s).
14. NOT apply load if bearing prevents equal loading on all load
supporting chains..
15. NOT operate beyond the limits of the load chain travel
16. NOT leave load supported by the hoist unattended unless
specic precautions have been taken.
17. NOT allow the chain or hook to be used as an electrical or
welding ground.
18. NOT allow the chain or hook to be touched
by a live welding electrode.
19. NOT remove or obscure the warnings on the hoist.
20. NOT operate a hoist which has Not been securely attached
to a suitable support..
21. NOT operate a hoist unless load slings or other approved
single attachments are properly sized and seated in the
hook saddle.
22. NOT operate a hoist when it is restricted from forming a
straight line from hook to hook in the direction of loading.
23. NOT lift loads that are Not balanced and that the holding
action is Not secure, taking up slack carefully.
24. NOT operate a hoist unless all persons are and remain
clear of the supported load.
25. Report malfunctions or unusual performances of a hoist,
after it has been shut down until repaired.
26. NOT operate a hoist on which the safety placards
or decals are missing or illegible.
27. Be familiar with operating controls, procedures and warnings.
Improper operation of a hoist can create a potentially
hazardous situation which, if not avoided, could result
in minor or moderate injury. To avoid such a potentially
hazardous situation, the operator shall:
1. Maintain a rm footing or be otherwise secured when
operating the hoist.
2. Check brake function by tensioning the hoist prior to each
lift or pulling operation.
3. Use hook latches. Latches are to retain slings, chains, etc.
under slack conditions only.
4. Make sure the hook latches are closed and not supporting
any parts of the load.
5. Make sure the load is free to move and will clear
all obstructions.
6. Avoid swinging the load or hook.
7. Inspect the hoist regularly, replace damaged or worn parts,
and keep appropriate records of maintenance.
8. Use Columbus McKinnon parts when repairing the unit.
9. Lubricate load chain as recommended in this manual.
10. NOT operate except with manual power.
11. NOT permit more than one operator to pull on hand chain
at the same time. More than one operator is likely to cause
hoist overload.
12. NOT allow your attention to be diverted from operating
the hoist.
13. NOT allow the hoist to be subjected to sharp contact
with other hoists, structures, or objects through misuse.
14. NOT adjust or repair the hoist unless qualied to perform
such adjustments or repairs.
The hoists are intended for general industrial use
for moving loads within their load ratings. Prior
to installation and operation, the user should
review the application for abnormal environmental
or handling conditions.
GENERAL SAFETY INFORMATION
ADVERSE ENVIRONMENTAL CONDITIONS
Do not use the hoists in areas containing ammable vapors,
liquids, gasses or any combustible dust or bers. Do not use
the hoist in highly corrosive, abrasive, wet environments or in
applications involving exposure to temperatures below -10ºF
or above 130ºF.
MOVING HAZARDOUS LOADS
The hoists are not recommended for lifting materials that
could cause widespread damage if dropped. The lifting
or moving of materials that could explode or cause
chemical or radioactive contamination requires fail-safe,
redundant supporting devices that are not incorporated
into these hoists.

4192083259 (REV AA) March 2021
HOIST SAFETY IS UP TO YOU...
CHOOSE THE RIGHT HOIST FOR
THE JOB...
Choose a hoist with the capacity for the job.
Know the capacities of your hoists and the
weight of your loads.
Then match them.
The application, the size and type of load,
the attachments to be used and the period
of use must also be taken into consideration
in selecting the right hoist for the job.
Remember, the hoist was designed to ease
our burden and carelessness not only endangers
the operator, but in many cases, a valuable load.
INSPECT
All hoists should be visually inspected
before use, in addition to regular, periodic
maintenance inspections.
Inspect hoists for operations warning notices
and legibility.
Deciencies should be noted and brought to the
attention of supervisors. Be sure defective hoists are
tagged and taken out of service until repairs are made.
Under no circumstances should you operate a malfunctioning hoist.
Check for gouged, twisted, distorted links and foreign material.
Do not operate hoists with twisted, kinked,
or damaged chain links.
Load chain should be properly lubricated.
Hooks that are bent, worn, or whose
openings are enlarged beyond normal throat
opening should not be used. If latch does not
engage throat opening of hook, hoist should
be taken out of service.
Chains should be checked for deposits of
foreign material which may be carried into
the hoist mechanism.
Check brake for evidence of slippage
under load.
DO NOT LIFT MORE THAN RATED LOAD.
DO OPERATE WITH MANUAL POWER ONLY (ONE OPERATOR)
DO NOT OPERATE DAMAGED OR MALFUNCTIONING HOIST.
DO NOT OPERATE WITH TWISTED, KINKED, OR DAMAGED CHAIN.
DO NOT PULL AT AN ANGLE. BE SURE HOIST AND LOAD ARE
IN A STRAIGHT LINE.
DO NOT USE LOAD CHAIN AS A SLING.
USE HOIST PROPERLY
Be sure hoist is solidly held in the uppermost
part of the support hook arc.
Be sure hoist and load are in a straight line.
Do not pull at an angle.
Be sure load is hooked securely. Do not tip load
the hook. Do not load hook latch. Hook latch
is to prevent detachment of load under slack
chain conditions only.
Do not operate with hoist head resting against
any object. Lift the load gently. Do not jerk it.
PRACTICE CAUTION ALWAYS
Do not lift co-workers with a hoist.
Make sure everyone is clear of the load when you lift.
Do not remove or obscure operational warning notices.
OPERATOR SERVICE
CLEANING
Hoists should be kept clean and free of dust, dirt, moisture, etc.,
which will in any way affect the operation or safety of the equipment.
LUBRICATION
Chain should be properly lubricated.
AFTER REPAIRS
Carefully operate the hoist before returning it to full service.
DO NOT LIFT PEOPLE OR LOADS OVER PEOPLE
VIOLATIONS OF ANY OF THE WARNINGS LISTED MAY RESULT IN SERIOUS PERSONAL INJURY TO THE OPERATOR
OR NEARBY PERSONNEL BY NATURE OF RELEASED LOAD OR BROKEN HOIST COMPONENTS.

5192083259 (REV AA) March 2021
FOREWORD
This manual contains important information to help you properly install, operate and maintain your hoist for maximum performance, economy
and safety.
Please study its contents thoroughly before putting your hoist into operation. By practicing correct operating procedures and by carrying out
the recommended preventive maintenance suggestions, you will experience long, dependable and safe service. After you have completely
familiarized yourself with the contents of this manual, we recommend that you carefully le it for future reference.
The information herein is directed to the proper installation, use, care and maintenance of the hoist and does not comprise a handbook on
the broad subject of rigging.
Rigging can be dened as the process of lifting and moving heavy loads using hoists and other mechanical equipment. Skill acquired through
specialized experience and study is essential to safe rigging operations. For rigging information, we recommend consulting a standard
textbook on the subject.
TABLE OF CONTENTS
SAFETY PRECAUTIONS ............................................................................................................................................................... 4
FOREWORD ................................................................................................................................................................................. 5
GENERAL INFORMATION
Application .................................................................................................................................................................................................... 6
Features and Advantages .............................................................................................................................................................................. 6
Precaution ...................................................................................................................................................................................................... 6
Maintenance................................................................................................................................................................................................... 6
DATA SHEET ................................................................................................................................................................................ 7
WARRANTY ................................................................................................................................................................................ 11

6192083259 (REV AA) March 2021
APPLICATION
With compacted design and enclosed body, this hoist is made of
Aluminum, has very light weight, easy to carry and widely be used
in home, factory, eld construction, agriculture, warehouse and so
on for lifting and small equipment installation purpose. It is also
widely used in chemical industry and marine industry where
anti-corrosion properity required.
FEATURES AND ADVANTAGES
1. Compacted design, light weight, easy to carry.
2. Made of Aluminum alloy, safe and reliable with
strong metallic visual sense.
3. Two-stage carburizing and quenching gear, high mechanical
transmission efciency and durability.
4. Double pawl brake system providing more safety.
5. Special heat treated exible hook, can be stretched,
but will never break
6. Zinc-Plated load chain and hand chain with high brightness.
7. Hand chain can be pulled in 360 degree, and wider
range of application.
PRECAUTION
1. Do not pull chain inclinedly
2. Do not operate hoist over the rated load
3. Do not pull hoist other than manpower
4. Before use, check hoist and be sure no damage, gears and
load chain are well lubricated, no load operation works well.
5. Before lift, check and be sure the hoist has been well hooked
and connected with the object to move, hook latch be well
closed, chain is vertical, no twisted link, no kinked links
6. Operator should stand on hand wheel side, pull the chain to
rotate wheel clockwise for lift purpose. Change the direction
to down loads slowly
7. Never lift people or load over people to avoid personal injury
8. Pull the chain uniform and gentle, do not give too much force
to avoid chain link jump or block
9. Stop operation if pulling effort is much larger than rated force
to avoid inside structure damage that may lead to loads falling
10. Detach hoist hook only when loads down to oor safely
11. After use, handle hoist gently, lubricated and keep in dry,
ventilate area
12. When removing ball bearings from hand wheel cover, it is
recommended to use a degreaser spray or similar to ensure
the ball bearings can be lled easily into the hand chain cover
upon re-assembly. Ball bearings should then be re-greased.
MAINTENANCE
1. Clean hoist after each use, keep in dry area to avoid rust and
corrosion
2. Properly clean and lubricate the gear and bearing according to
the usage frequency
3. When assembly hoist, be sure the "O"mark on small gears well
aligned and on same line
4. When assembly brake system, be sure the ratchet gear teeth
well engaged with pawl spring tip. Pawl spring can control pawl
sensitively. After put on hand wheel, rotate wheel clockwise
and press ratchet gear and brake pad tightly on the brake disc.
Rotate the hand wheel anticlockwise, there should be small gap
between wheel, ratchet gear and brake pad.
5. Never disassemble hoist by unqualied person
6. After each clean and maintenance, the hoist should be tested
under no load and under rated load for any new operation
purpose.
7. During lubrication or operation, the brake disc should keep clean
and check frequently to be sure the brake system works well

7192083259 (REV AA) March 2021
DATA SHEET
Model MHU-0.25 MHU-0.50
Capacity t 0.25 0.5
Standard Lift ft. / m 10 / 3.05 10 / 3.05
Running Test Load lbf / kN 843 / 3.75 1686 / 7.5
Effort Required to Lift Rated Load lbf / N 36 / 160 45 / 200
Diameter of Load Chain in. / mm .118 / 3 .16 / 4
Strands of Load Chain 1 1
Dimensions in. / mm
A3.43 / 87 3.86 / 98
B3.31 / 84 4.06 / 103
C9.65 / 245 11.22 / 285
D.83 / 21 .91/ 23
E1.26 / 32 1.38 / 35
Net Weight lbs / kg 5.70 / 2.59 8.73 / 3.96
Extra weight per ft. / m of extra lift lbs / kg 1.37 / .62 1.65 / .75

8192083259 (REV AA) March 2021
PARTS LIST
Reference No. Description
CMCO Part Number
Qty
0.25 t .50 t
14, 15, 27, 28, 29, 31 Upper Hook Kit
(includes Latch Kit assembled, Upper Hook Pin loose) MHU-0121 MHU-0122 1
25, 39
Ball Set
(Contains 77 Balls & 1 Plug) MHU-0010 - 1 kit
Ball Set
(Contains 69 Balls & 1 Plug) - MHU-0011 1 kit
27, 28, 29, 31 Safety Latch Kit
(includes latch, spring, screw, and nut) MHU-0123 MHU-0124 2
26, 27, 28, 29, 30, 31, 32 Bottom Hook Kit
(includes Latch Kit assembled, Lower Hook Pin & Nut loose) MHU-0131 MHU-0132 1
33 Load Chain 85830 051316 As Req'd
38 Hand Chain N04300019 As Req'd
37 End Link Pin MHU-0020 MHU-0021 1

9192083259 (REV AA) March 2021
NOTES

10 192083259 (REV AA) March 2021
NOTES

11 192083259 (REV AA) March 2021
INDEMNIFICATION AND SAFE OPERATION
Buyer shall comply with and require its employees to comply with directions
set forth in instructions and manuals furnished by Seller and shall use and
require its employees to follow such instructions and manuals and to use
reasonable care in the use and maintenance of the goods. Buyer shall not
remove or permit anyone to remove any warning or instruction signs on the
goods. In the event of personal injury or damage to property or business
arising from the use of the goods, Buyer shall within 48 hours thereafter
give Seller written notice of such injury or damage. Buyer shall cooperate
with Seller in investigating any such injury or damage and in the defense of
any claims arising therefrom.
If Buyer fails to comply with this section or if any injury or damage is
caused, in whole or in part, by Buyer’s failure to comply with applicable
federal or state safety requirements, Buyer shall indemnify and hold Seller
harmless against any claims, loss or expense for injury or damage arising
from the use of the goods.
CMCO Warranty (HOISTS)
A. Columbus McKinnon Corporation (“Seller”) warrants to the original end
user (“Buyer”) that: (a) for a period of one (1) year from the date of Seller’s
delivery of the goods (collectively, the “Goods”) to the carrier, the electrical
components of the Goods will be free from defects in workmanship and
materials; and (b) for the life of the Goods, the mechanical components of
the Goods will be free from defects in workmanship and materials.
B. IN THE EVENT OF ANY BREACH OF SUCH WARRANTY, SELLER’S SOLE
OBLIGATION SHALL BE EXCLUSIVELY LIMITED TO, AT THE OPTION
OF SELLER, REPAIR OR REPLACEMENT, F.O.B. SELLER’S POINT OF
SHIPMENT, OF ANY GOODS THAT SELLER DETERMINES TO HAVE
BEEN DEFECTIVE OR, IF SELLER DETERMINES THAT SUCH REPAIR OR
REPLACEMENT IS NOT FEASIBLE, TO A REFUND OF THE PURCHASE
PRICE UPON RETURN OF THE GOODS TO SELLER. NO CLAIM AGAINST
SELLER FOR ANY BREACH OF (i) SUCH WARRANTY WITH RESPECT
TO THE ELECTRICAL COMPONENTS OF ANY GOOD SHALL BE VALID
OR ENFORCEABLE UNLESS BUYER’S WRITTEN NOTICE THEREOF
IS RECEIVED BY SELLER WITHIN ONE (1) YEAR FROM THE DATE OF
SELLER’S DELIVERY TO THE CARRIER AND (ii) SUCH WARRANTY
WITH RESPECT TO THE MECHANICAL COMPONENTS OF ANY GOOD
SHALL BE VALID OR ENFORCEABLE UNLESS BUYER’S WRITTEN
NOTICE THEREOF IS RECEIVED BY SELLER WITHIN ONE (1) YEAR
FROM THE DATE THE DATE ANY ALLEGED CLAIM ACCRUES. EXCEPT
FOR THE WARRANTY SET FORTH ABOVE, SELLER MAKES NO OTHER
WARRANTIES WITH RESPECT TO THE GOODS, WHETHER EXPRESSED
OR IMPLIED, INCLUDING ANY WARRANTIES OF MERCHANTABILITY,
FITNESS FOR A PARTICULAR PURPOSE, QUALITY AND/OR THOSE
ARISING BY STATUTE OR OTHERWISE BY LAW OR FROM ANY
COURSE OF DEALING OR USE OF TRADE, ALL OF WHICH ARE HEREBY
EXPRESSLY DISCLAIMED.
C. IN NO EVENT SHALL SELLER BE LIABLE TO BUYER OR ANY THIRD
PARTY WITH RESPECT TO ANY GOOD, WHETHER IN CONTRACT,
TORT OR OTHER THEORY OF LAW, FOR LOSS OF PROFITS OR LOSS
OF USE, OR FOR ANY INCIDENTAL, CONSEQUENTIAL, SPECIAL,
DIRECT OR INDIRECT DAMAGES, HOWSOEVER CAUSED. SELLER’S
MAXIMUM LIABILITY TO BUYER WITH RESPECT TO THE GOODS
SHALL IN NO EVENT EXCEED THE PRICE PAID BY BUYER FOR THE
GOODS THAT ARE THE SUBJECT OF THE APPLICABLE CLAIM.
D. Seller shall not be liable for any damage, injury or loss arising out of the
use of the Goods if, prior to such damage, injury or loss, such Goods are:
(1) damaged or misused following Seller’s delivery to the carrier; (2) not
maintained, inspected, or used in compliance with applicable law and
Seller’s written instructions and recommendations; or (3) installed, repaired,
altered or modied without compliance with such laws, instructions or
recommendations.
E. This warranty is limited and provided only to the original end user.
Each Good must be registered within sixty (60) days of receipt
of each product to establish eligibility. Please register at
www.columbusmckinnon.com/en-us/warranty-registration/
or submit registration card via US mail.
F. Any action against Seller for breach of warranty, negligence or otherwise
in connection with the electrical components of any Good must be
commenced by Buyer within one (1) year after: (a) the date any alleged
claim accrues; or (b) the date of delivery of the Goods to Buyer,
whichever is earlier. Any action against Seller for breach of warranty,
negligence or otherwise in connection with the mechanical components
of any Good must be commenced by Buyer within one (1) year after the
date any alleged claim accrues.
Alterations or modifications of equipment and use of non-factory
repair parts can lead to dangerous operation and injury.
TO AVOID INJURY:
• Do not alter or modify equipment.
• Do use only factory replacement parts.
WARRANTY
LIMITATION OF WARRANTIES, REMEDIES AND DAMAGES

© 2020 Columbus McKinnon Corporation. All Rights Reserved.
