CM 602 Series User manual

Part Number: 02805 Rev AA February 2017
HAND OPERATED LEVER HOIST
POLIPASTO MANUAL DE PALANCA
PALAN MANUEL À LEVIER
OPERATING, MAINTENANCE
& PARTS MANUAL
MANUAL DE FUNCIONAMIENTO,
MANTENIMIENTO Y PIEZAS
MANUEL D'ENTRETIEN,
D'OPÉRATION ET DE PIÈCES
Before installing hoist, fill in the information below.
Antes de instalar el polipasto, rellene los datos siguientes.
Enregistrez les informations suivantes avant de faire l'installation.
Rated Load / Carga Nominal / Charge nominale
Serial No. / N° de Serie / No. de Ser.
Purchase Date / Fecha de Compra / Date d'achat
CAPACITIES:
SERIES 602:
550 LBS (250 KG.)
SERIES 603:
1100 LBS (500 KG.)
Follow all instructions and warnings
for inspecting, maintaining and
operating this hoist.
The use of any hoist presents some risk
of personal injury or property damage. That
risk is greatly increased if proper instructions
and warnings are not followed. Before using
this hoist, each operator should become
thoroughly familiar with all warnings,
instructions and recommendations
in this manual. Retain this manual for
future reference and use.
Forward this manual to operator.
Failure to operate equipment as
directed in manual may cause injury.
CAPACIDADES DE CARGA:
SERIES 602:
550 LBS (250 KG.)
SERIES 603:
1100 LBS (500 KG.)
Siga todas las instrucciones y
advertencias para inspeccionar,
mantener y operar este polipasto.
El uso de cualquier polipasto presenta
algunos riesgos de daños a las personas o a
las cosas. Este riesgo se ve incrementado si
no se siguen correctamente las instrucciones
y advertencias. Antes de usar el polipasto
el operario debería estar familiarizado con
todas las advertencias, instrucciones y
recomendaciones de este manual. Guarde
este manual para futuras consultas.
Entregue este manual al operario. Si el
equipo no se maneja tal y como se
recomienda en el presente manual, es
posible que se produzcan situaciones
de peligro que pueden resultar en
daños personales.
CHARGES NOMINALES:
SERIES 602:
550 LBS (250 KG.)
SERIES 603:
1100 LBS (500 KG.)
Veuillez vous conformer à toutes les
instructions et avertissements d'inspection,
d'entretien et d'opération de ce palan.
L'utilisation de tout appareil de levage
comporte des risques de blessures ou
de dégâts matériels. Ces risques sont
de beaucoup accrus si les instructions
et avertissements ne sont pas suivis.
Tours les opérateurs devraient se
familiariser complètement avec toutes
les recommandations instructions et
avertissements de ce manuel avant d'utiliser
ce palan. Conservez ce manuel pour
utilisation et référence future.
Remettre ce manuel à l'opérateur.
L'utilisation de cet équipement contrairement
aux directives de ce manuel peut causer
des blessures.
SERIES 602/603
OPERATING, MAINTENANCE
& PARTS MANUAL
SERIES 602 SERIES 603

3Part Number: 02805 Rev AA February 2017
CM HOIST PARTS AND SERVICES ARE AVAILABLE
IN THE UNITED STATES AND IN CANADA
As a CM Hoist and Trolley user you are assured of reliable repair and parts services through a network of Master Parts Depots and Service Centers
that are strategically located in the United States and Canada. These facilities have been selected on the basis of their demonstrated ability to handle
all parts and repair requirements promptly and efciently. To quickly obtain the name of the Master Parts Depot or Service Center located nearest you,
call [phone]. Fax: [phone].
LAS PIEZAS Y REPARACIONES DE LOS POLIPASTOS DE CM ESTÁN
ASEGURADAS EN ESTADOS UNIDOS Y CANADÁ
Como usuario de un polipasto y carro de CM le aseguramos cualquier reparación o la disponibilidad de cualquier pieza de repuesto a través de una
red de almacenes de piezas de repuesto y centros de servicio situados estratégicamente en Estados Unidos y Canadá. Estas instalaciones se han
seleccionado en base a su capacidad demostrada en la reparación de equipos y suminstro de piezas de repuesto de forma rápida y ecaz. Para obtener
la dirección del almacén de piezas de repuesto o del centro de servicio más cercano, llame al teléfono [phone]. Fax: [phone] (sólo en
Estados Unidos y Canadá).
LE SERVICE DE RÉPARATION ET DE PIÈCES POUR PALANS CM EST
DISPONIBLE AUX ÉTATS-UNIS ET AU CANADA
Soyez assurés qu'en temps d'utilisateur de palan et treuil CM, d'un service de réparation et de pièces able par l'entremise d'un réseau de Centres de
service et de Dépôts de pièces maîtresses qui sont stratégiquement situés aux États-Unis et au Canada. Ces établissements ont été sélectionnés sur
une base de leur habileté démontrée à s'occuper promptement et efcacement des besoins de réparation de pièces. Composez le [phone],
télécopieur: [phone] pour obtenir rapidement le nom du dépôt de pièces maîtresses ou du centre de service situé le plus près.

4Part Number: 02805 Rev AA February 2017
SAFETY PRECAUTIONS
Each Series 602/603 Manually Operated Lever Hoist is built in accordance with the specifications contained herein and at the time of
manufacture complies with our interpretation of applicable sections of *ASME B30.21, *ANSI/ASME HST-3M and the Occupational Safety
and Health Act-1970.
The safety laws for elevators and for dumbwaiters specify construction details that are not incorporated in CM industrial hoists. We
recommend the use of equipment that meets state and national safety codes for such use. Columbus McKinnon Corporation cannot be
responsible for applications other than those for which CM equipment is recommended.
THIS SYMBOL POINTS OUT IMPORTANT SAFETY INSTRUCTIONS WHICH IF NOT FOLLOWED COULD ENDANGER THE PERSONAL SAFETY AND/OR
PROPERTY OF YOURSELF AND OTHERS. READ AND FOLLOW ALL INSTRUCTIONS IN THIS MANUAL AND ANY PROVIDED WITH THE EQUIPMENT
BEFORE ATTEMPTING TO OPERATE YOUR SERIES 602/603 LEVER HOIST.
*Copies of this standard can be obtained from ASME Order Department, 22 Law Drive, Box 2300, Fairfield, NJ 07007-2300, U.S.A.
Improper operation of a hoist can create a potentially hazardous situation which,
if NOT avoided, could result in death or serious injury. To avoid such a potentially
hazardous situation, the operator shall:
1. NOT operate a malfunctioning or unusually performing hoist.
2. NOT operate the hoist until you have thoroughly read and understood this
manual.
3. NOT operate a hoist which has been modified without the manufacturer’s
approval or certification to be in conformity with applicable oSHA
regulations.
4. NOT lift or pull more than rated load for the hoist.
5. NOT use damaged hoist or hoist that is NOT working properly.
6. NOT use hoist with twisted, kinked, damaged, or worn load chain.
7. NOT operate with any lever extension (cheater bar).
8. NOT attempt to “free chain” the hoist while a load is applied.
9. NOT use the hoist to lift, support, or transport people.
10. NOT lift loads over people and make sure all personnel remain clear of
supported load.
11. NOT attempt to lengthen the load chain or repair damaged load chain.
12. Protect the hoists load chain from weld splatter or other damaging
contaminants.
13. NOT operate a hoist when it is restricted from forming a straight line from
hook to hook in the direction of loading.
14. NOT use load chain as a sling or wrap load chain around load.
15. NOT apply the load to the tip of the hook or to the hook latch.
16. NOT apply load unless load chain is properly seated in the chain wheel(s) or
sprocket(s).
17. NOT apply load if bearing prevents equal loading on all load supporting
chains.
18. NOT operate beyond the limits of the load chain travel.
19. NOT leave load supported by the hoist unattended unless specific
precautions have been taken.
20. NOT allow the chain or hook to be used as an electrical or welding ground.
21. NOT allow the chain or hook to be touched zby a live welding electrode.
22. NOT remove or obscure the warnings on the hoist.
23. NOT operate a hoist which has NOT been securely attached to a suitable
support.
24. NOT operate a hoist unless load slings or other approved single
attachments are properly sized and seated in the hook saddle.
25. NOT lift loads that are NOT balanced and the holding action is NOT secure,
taking up slack carefully.
26. NOT operate a hoist unless all persons are and remain clear of the
supported load.
27. Report malfunctions or unusual performances of a hoist, after it has
been shut down until repaired.
28. NOT operate a hoist on which the safety placards or decals are
missing or illegible.
29. Be favmiliar with operating controls, procedures and warnings.
Improper operation of a hoist can create a potentially hazardous situation
which, if not avoided, could result in minor or moderate injury. To avoid
such a potentially hazardous situation, the operator shall:
1. Maintain a firm footing or be otherwise secured when operating the
hoist.
2. Check brake function by tensioning the hoist prior to each
lift operation.
3. Use hook latches. Latches are to retain slings, chains, etc. under
slack conditions only.
4. Make sure the hook latches are closed and not supporting any parts
of the load.
5. Make sure the load is free to move and will clear
all obstructions.
6. Avoid swinging the load or hook.
7. Make sure hook travel is in the same direction as shown
on the controls.
8. Inspect the hoist regularly, replace damaged or worn parts, and keep
appropriate records of maintenance.
9. Use the hoist manufacturer’s recommended parts
when repairing the unit.
10. Lubricate load chain per hoist manufacturer’s recommendations.
11. NOT use the hoist load limiting or warning device
to measure load.
12. NOT use limit switches as routine operating stops unless allowed by
manufacturer. They are emergency devices only.
13. NOT allow your attention to be diverted from operating
the hoist.
14. NOT allow the hoist to be subjected to sharp contact with other
hoists, structures, or objects through misuse.
15. NOT adjust or repair the hoist unless qualified to perform such
adjustments or repairs.
The hoists are intended for general industrial use for moving loads
within their load ratings. prior to installation and operation, the user
should review the application for abnormal environmental or handling
conditions.
GENERAL SAFETY INFORMATION
ADVERSE ENVIRONMENTAL CONDITIONS
Do not use the hoists in areas containing flammable vapors, liquids,
gasses or any combustible dust or fibers. Do not use the hoist
in highly corrosive, abrasive, wet environments or in applications
involving exposure to temperatures below -10ºF or above 130ºF.
MOVING HAZARDOUS LOADS
The hoists are not recommended for lifting materials that could
cause widespread damage if dropped. The lifting or moving of
materials that could explode or cause chemical or radioactive
contamination requires fail-safe, redundant supporting devices
that are not incorporated into these hoists.

5Part Number: 02805 Rev AA February 2017
INSTALLATION
1. Read and understand the safety precautions on page 7 of this
manual.
2. Estimate the load that is to be lifted or moved and make sure it
does not exceed the hoist’s rated capacity (550 lbs. / 250 Kg.
for the Series 602 and 1100 lbs. / 500 Kg. for the Series 603).
3. Make sure that the support to which the upper hook is attached
is strong enough to hold several times the weight of the load.
Be sure the hoist is solidly held in in the uppermost part of the
upper hook, the latch is closed and the latch does not contact
the support.
4. Make sure that the hoist is rigged so that the upper and lower
hooks will form a straight line when the hoist is operated and
the frame is free to swivel and will not come in contact with any
object.
5. Spanish and French Warning labels for the loose end ring are
packed separately. If needed, attach these to the loose end ring
at installation.
Failure to use as directed herein may cause injury to you or others
and could result in property damage.
• DO NOT exceed the 550 lbs. (250 Kg.) capacity of the hoist or
58 lbs. (26 Kg.) handle pull on the Series 602, or 1100 lbs. (500
Kg.) capacity of the hoist or 56 lbs. (25 Kg.) handle pull on the
Series 603 when lifting or pulling.
• DO NOT use the hoist to lift people or loads over people.
• DO NOT use a damaged or malfunctioning hoist.
• DO NOT use if the load chain is twisted, kinked, worn,
stretched or damaged.
• DO NOT use unless the hoist’s frame and chain form a straight
line between hooks.
• DO NOT use if the hoist’s frame is in contact with any object.
• DO NOT leave a suspended load or hoist under
tension unattended.
• DO NOT use an extension on the handle. Operate using
hand power only.
• DO NOT apply loads to the tip of the hooks or to the
hook latches.
• DO NOT remove warning labels and tags from the hoist.
OPERATION
Before using the Series 602/603 Lever Hoist, familiarize yourself with
main parts (See Fig. 1). Always check the hoist for proper operation
before use and under no circumstance should you attempt to use a
malfunctioning hoist. To reduce the risk of injury, the user must read
and understand this manual.
FIGURE 1
SERIES 602 LEVER HOIST
SERIES 603 LEVER HOIST
Model
Number
Max,
Capacity
Standard
Lift
Chain
Size
Minimum
Distance
Between
Hooks
Pull on
Handle to
Lift Max.
Capacity
Net
Weight
Shipping
Weight
TB602 550 lbs.
(250 kg.)
5 ft.
(1.5 m)
4 x 12
mm
9-7/16"
(240 mm)
58 lbs.
(26 kg.)
5 lbs.
(2.3 kg.)
6 lbs.
(2.7 kg.)
TB603 1100 lbs.
(500 kg.)
5 ft.
(1.5 m)
4 x 12
mm
11-1/8"
(282 mm)
56 lbs.
(25 kg.)
6 lbs.
(2.7 kg.)
7 lbs.
(3.2 kg.)

6Part Number: 02805 Rev AA February 2017
FREE CHAINING
In this mode, the load can be pulled through the hoist in either
direction by hand for quick attachment to the load. To set the hoist
to free chaining mode:
1. With no load on the hoist, move the directional lever to the
center (neutral) position.
2. *Pull the load chain, in either direction, to its desired length so
that the lower hook can be attached to the load. Note that the
chain must feed into the hoist freely. If it does not, check for
twisted chain. A twisted chain may become damaged by the
chain guide rollers or liftwheel and result in chain damage.
*Pull the chain slowly and be careful: HANDLE MAY SPIN.
OPERATING THE LEVER HOIST
The Series 602/603 Lever Hoist can be used in any position as long
as it is rigged to pull in a straight line from hook to hook and the
frame is free to swivel on the upper hook.
If the hoist is not rigged in a straight line hook to hook manner or
if the frame is not free to swivel on the upper hook, handle pull
may break the frame, bend upper hook and/or break the chain
and cause physical injury or loss of load.
TO AVOID INJURY:
Always rig the hoist in a straight line hook to hook manner and do
not allow the frame to touch the load or any object when in use.
When operating in limited spaces, use attachments or slings to make
sure the frame is free to swivel on the upper hook and that there are
no obstructions that would prevent you from operating the hoist.
1. Suspend or attach the hoist from an adequate support (see
INSTALLATION).
2. Following the instruction for FREE CHAINING, take up the slack
chain and attach the lower hook to load to be lifted or moved.
Make sure that the load will be applied to the bowl of the lower
hook and that it will not be applied to the latch or tip of the hook.
3. To lift or pull load, set the directional lever to () LOAD position and
slowly pull chain in either direction by hand to ensure the hoist is out
of the free chaining mode. Be careful: HANDLE MAY SPIN. Then
operate the handle up and down to tension the load only enough to
check that the brake is engaged and that the attachments to hooks
and load are firmly seated. Then repeatedly operate the handle up
and down to lift or pull the load. DO NOT OVERLOAD! A handle pull
of 58 pounds (26 Kg.) results in applying the maximum capacity of
550 pounds (250 Kg.) to the Series 602 hoist, and a handle pull of
56 lbs. (25 Kg.) results in applying the maximum capacity of 1100
lbs. (500 Kg.) to a Series 603 hoist.
4. To lower or loosen the load, move the directional lever to the ()
UNLOAD position and operate the handle up and down repeatedly.
With no load on the hoist and when the directional lever is in the
() LOAD or () UNLOAD position, pulling sharply on either end
of the chain will cause the handle to spin rapidly.
TO AVOID INJURY:
Never pull sharply on either end of the chain when the directional
lever is in the () LOAD or () UNLOAD position.
If directional lever is forced out of engagement with a load
applied, load will be released.
TO AVOID INJURY:
With a load applied to the hoist, do not force the directional lever
into the center (neutral) position.
LOCKED BRAKE
If a hoist under load is suddenly relieved of the load by removing
the load from the hoist by some other means, the brake will remain
locked. The brake could also lock if the lower hook block is run
tightly against the frame. To unlock the brake, move the directional
lever to the () UNLOAD position and pull sharply on the handle, or
reapply the load and operate the hoist in the normal manner.
MAINTENANCE/INSPECTION
The Series 602/603 Lever Hoist normally requires very little
maintenance, other than the frequent and periodic inspection listed
in the chart on page 5. However, if the hoist is disassembled for
inspection, the following should be observed when reassembling.
1. The pawl must engage the teeth of the ratchet as shown in Figure 2.
2. The check washer must be positioned on the ratchet hub as
shown in Figure 2.
3. When installing the chain, it must be fed through the chain guide
rollers with the welds away from the liftwheel, the lower hook must
be directly below the upper hook and the loose end ring must be
positioned and oriented at the end of the chain as shown in Figure 3.
4. A rivet is used to attach the latch to the hook. To remove the
latch grind off the head of the rivet. When installing the latch,
only peen over the end of the rivet enough to secure it.
FIGURE 2
PAWL
1/8"
RATCHET
PAWL
RATCHET
CHECK
WASHER
FIGURE 3
CHAIN GUIDE
ROLLER CHAIN GUIDE
ROLLER
STRIPPER
LOAD CHAIN
WELDS AWAY
FROM LIFTWHEEL
LOWER HOOK
BLOCK
LOOSE END RING-
POSITION AS SHOWN
FIGURE 4 FIGURE 5
.149" (3.8mm)
STOCK DIAMETER
.496" (12.6mm)
MAXIMUM PITCH
0.91" (23.1 mm)
MAXIMUM
THROAT OPENING
.71" (18mm)
MINIMUM SEAT

7Part Number: 02805 Rev AA February 2017
FREQUENT & PERIODIC INSPECTION CHART
Item
Frequency
WHAT TO
CHECK
Inspection
Method Acceptance Level
Dainy
(Frequent)
EVERY 6
MONTHS
(PERIODIC)
LABELING &
TAGS X X
Nameplate,
capacity label
warning labels &
free chaining tag
Visually These items must be legible and securely fastened to the hoist. Replace if
necessary.
OPERATION
X X General
Operation
Lift & lower
a light load
1. Chain must feed into and out of the hoist freely.
2. Brake must hold the load when handle is released.
— X Overload test
Lift & lower a 688
lb. (312 Kg.) load
for the 602 or a
1378 lb. (625 Kg.)
for the 603 one
foot (300 mm)
1. Pull on handle should be about 73# (33Kg.)
2. Brake should operate smoothly while lowering.
X X Directional Lever Movement Lever must move smoothly.
X X Free Chaining Movement In free chaining mode, chain should feed into and out of the hoist freely when
pulled by hand.
HOOK
ASSEMBLIES
X X Hook opening &
bowl wear
Measure opening
and bowl wear See Figure 4.
X X Hook latch
Operation,
engagement &
damage
1. Latch must not be damaged.
2. Latch must operate smoothly with sufficient pressure
to engage the tip of the hook tightly.
X X Hook deformation Visually Hook must not be bent more than 10 degrees from the plane of the unbent hook.
X X
Hook chain
screw, upper
hook pin, hook
collars and hook
collars hardware
Visually There must be no damage, corrosion, excessive wear or looseness.
X X
Hooks, chemical
damage, cracks,
gouges
Visually There must be no excessive cracks,
Chain
X X Lubrication Visually Chain should be frequently lubricated using Frisk Bros. Lubriplate 10-R, or equal.
X X Corrosion, Pitting,
Gouges Visually There must be no excessive corrosion, pitting or gouges on the chain.
X X Wear &
Contamination
Measure chain
for wear & stretch See figure 5.
X X Deformation &
Twists Visually Chain must be free of twists.
Brake Disc — X Wear &
Contamination
Measure
thickness &
visually
Take the hoist out of service if the thickness is less than 0.094” (2.4 mm)
or if the friction surfaces are glazed, oily or contaminated.
Hoist Head
— X Side plate &
Covers Visually Frame and covers should not be damaged or corroded.
X X Handle Visually Handle must not be bent or corroded. Grip should not be damaged.
— X Stripper Visually Stripper must not be bent, corroded or worn.
X X Hardware Visually All nuts must not be corroded and must be securely tightened.
— X Pawl & Ratchet Visually There should be no excessive wear of the ratchet teeth and the tip of the pawl.
The pawl spring should not be corroded or stretched.
*Daily or before each use.

8Part Number: 02805 Rev AA February 2017
REPAIR PARTS LIST
Using “Commercial” or other manufacturer’s parts to repair the CM
Hoists may cause load loss.
TO AVOID INJURY:
Use only CM supplied replacement parts. Parts may look alike but
CM parts are made of specific materials or processed to achieve
specific properties.
ORDERING INSTRUCTIONS
The following information must accompany all correspondence
orders for replacement parts:
1. Hoist Model Number from identification plate.
2. Serial number of the hoist stamped below identification plate.
3. Length of lift.
4. Part number of part from parts list.
5. Number of parts required.
6. Part name from parts list.
Parts for your hoist are available from your local authorized
repair station. For the name of the nearest parts or service
center, visit our website www.cmworks.com or call the
Columbus McKinnon customer service department at
[phone].
SERIES 602/603 LEVER HOIST
PARTS LIST
Description
Part Number
602 603
CHAIN STOP ASSEMBLY 00230260
LOAD CHAIN (PER FOOT CODE) XFT04012 02100009
HOOK LATCH KITS (2 INCLUDED) 00230168 00400449

9Part Number: 02805 Rev AA February 2017
THE WARRANTY STATED BELOW IS GIVEN IN PLACE OF
ALL OTHER WARRANTIES, EXPRESS OR IMPLIED, OF
MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE,
OR OTHERWISE, NO PROMISE OR AFFIRMATION OF FACT
MADE BY ANY AGENT OR REPRESENTATIVE OF SELLER SHALL
CONSTITUTE AWARRANTY BY SELLER OR GIVE RISE TO ANY
LIABILITY OR OBLIGATION.
Seller warrants that on the date of delivery to carrier the goods are
free from defects in workmanship and materials.
SELLER’S SOLE OBLIGATION IN THE EVENT OF BREACH
OF WARRANTY OR CONTRACT OR FOR NEGLIGENCE OR
OTHERWISE WITH RESPECT TO GOODS SOLD SHALL BE
EXCLUSIVELY LIMITED TO REPAIR OR REPLACEMENT, F.O.B.
SELLER’S POINT OF SHIPMENT, OF ANY PARTS WHICH SELLER
DETERMINES TO HAVE BEEN DEFECTIVE or if Seller determines
that such repair or replacement is not feasible, to a refund of the
purchase price upon return of the goods to Seller.
Any action against Seller for breach of warranty, negligence or
otherwise, must be commenced within one year after such cause of
action occurs.
NO CLAIM AGAINST SELLER FOR ANY DEFECT IN THE GOODS
SHALL BE VALID OR ENFORCEABLE UNLESS BUYER’S WRITTEN
NOTICE THEREOF IS RECEIVED BY SELLER WITHIN ONE YEAR
FROM THE DATE OF SHIPMENT. Seller shall not be liable for any
damage, injury or loss arising out of the use of the goods if, prior
to such damage, injury or loss, such goods are (1) damaged or
misused following Seller’s delivery to carrier; (2) not maintained,
inspected, or used in compliance with applicable law and Seller’s
written instructions and recommendations; or (3) installed, repaired,
altered or modified without compliance with such law, instructions or
recommendations.
UNDER NO CIRCUMSTANCES SHALL SELLER BE LIABLE
FOR INCIDENTAL OR CONSEQUENTIAL DAMAGES AS THOSE
TERMS ARE DEFINED IN SECTION 2-715 OF THE UNIFORM
COMMERCIAL CODE.
INDEMNIFICATION AND SAFE OPERATION
Buyer shall comply with and require its employees to comply with
directions set forth in instructions and manuals furnished by Seller
and shall use and require its employees to follow such instructions
and manuals and to use reasonable care in the use and maintenance
of the goods. Buyer shall not remove or permit anyone to remove any
warning or instruction signs on the goods. In the event of personal
injury or damage to property or business arising from the use of
the goods, Buyer shall within 48 hours thereafter give Seller written
notice of such injury or damage. Buyer shall cooperate with Seller
in investigating any such injury or damage and in the defense of any
claims arising therefrom.
If Buyer fails to comply with this section or if any injury or damage
is caused, in whole or in part, by Buyer’s failure to comply with
applicable federal or state safety requirements, Buyer shall indemnify
and hold Seller harmless against any claims, loss or expense for
injury or damage arising from the use of the goods.
CMCO Warranty (HOISTS)
A. Columbus McKinnon Corporation (“Seller”) warrants to the original
end user (“Buyer”) that: (a) for a period of one (1) year from the
date of Seller’s delivery of the goods (collectively, the “Goods”)
to the carrier, the electrical components of the Goods will be free
from defects in workmanship and materials; and (b) for the life of
the Goods, the mechanical components of the Goods will be free
from defects in workmanship and materials.
B. IN THE EVENT OF ANY BREACH OF SUCH WARRANTY,
SELLER’S SOLE OBLIGATION SHALL BE EXCLUSIVELY LIMITED
TO, AT THE OPTION OF SELLER, REPAIR OR REPLACEMENT,
F.O.B. SELLER’S POINT OF SHIPMENT, OF ANY GOODS THAT
SELLER DETERMINES TO HAVE BEEN DEFECTIVE OR, IF
SELLER DETERMINES THAT SUCH REPAIR OR REPLACEMENT
IS NOT FEASIBLE, TO A REFUND OF THE PURCHASE PRICE
UPON RETURN OF THE GOODS TO SELLER. NO CLAIM
AGAINST SELLER FOR ANY BREACH OF (i) SUCH WARRANTY
WITH RESPECT TO THE ELECTRICAL COMPONENTS OF ANY
GOOD SHALL BE VALID OR ENFORCEABLE UNLESS BUYER’S
WRITTEN NOTICE THEREOF IS RECEIVED BY SELLER WITHIN
ONE (1) YEAR FROM THE DATE OF SELLER’S DELIVERY TO
THE CARRIER AND (ii) SUCH WARRANTY WITH RESPECT TO
THE MECHANICAL COMPONENTS OF ANY GOOD SHALL BE
VALID OR ENFORCEABLE UNLESS BUYER’S WRITTEN NOTICE
THEREOF IS RECEIVED BY SELLER WITHIN ONE (1) YEAR
FROM THE DATE THE DATE ANY ALLEGED CLAIM ACCRUES.
EXCEPT FOR THE WARRANTY SET FORTH ABOVE, SELLER
MAKES NO OTHER WARRANTIES WITH RESPECT TO THE
GOODS, WHETHER EXPRESSED OR IMPLIED, INCLUDING
ANY WARRANTIES OF MERCHANTABILITY, FITNESS FOR A
PARTICULAR PURPOSE, QUALITY AND/OR THOSE ARISING
BY STATUTE OR OTHERWISE BY LAW OR FROM ANY COURSE
OF DEALING OR USE OF TRADE, ALL OF WHICH ARE HEREBY
EXPRESSLY DISCLAIMED.
C. IN NO EVENT SHALL SELLER BE LIABLE TO BUYER OR ANY
THIRD PARTY WITH RESPECT TO ANY GOOD, WHETHER IN
CONTRACT, TORT OR OTHER THEORY OF LAW, FOR LOSS
OF PROFITS OR LOSS OF USE, OR FOR ANY INCIDENTAL,
CONSEQUENTIAL, SPECIAL, DIRECT OR INDIRECT DAMAGES,
HOWSOEVER CAUSED. SELLER’S MAXIMUM LIABILITY TO
BUYER WITH RESPECT TO THE GOODS SHALL IN NO EVENT
EXCEED THE PRICE PAID BY BUYER FOR THE GOODS THAT
ARE THE SUBJECT OF THE APPLICABLE CLAIM.
D. Seller shall not be liable for any damage, injury or loss arising
out of the use of the Goods if, prior to such damage, injury or
loss, such Goods are: (1) damaged or misused following Seller’s
delivery to the carrier; (2) not maintained, inspected, or used in
compliance with applicable law and Seller’s written instructions
and recommendations; or (3) installed, repaired, altered or
modified without compliance with such laws, instructions or
recommendations.
E. This warranty is limited and provided only to the original end user.
Each Good must be registered within sixty (60) days of receipt
of each product to establish eligibility. Please register at www.
cmworks.com/hoist-warrantyregistration or submit registration
card via US mail.
F. Any action against Seller for breach of warranty, negligence or
otherwise in connection with the electrical components of any
Good must be commenced by Buyer within one (1) year after: (a)
the date any alleged claim accrues; or (b) the date of delivery of
the Goods to Buyer, whichever is earlier. Any action against Seller
for breach of warranty, negligence or otherwise in connection with
the mechanical components of any Good must be commenced by
Buyer within one (1) year after the date any alleged claim accrues.
Alterations or modifications of equipment and use of nonfactory
repair parts can lead to dangerous operation and injury.
TO AVOID INJURY:
• Do not alter or modify equipment.
• Do use only factory replacement parts
WARRANTY
LIMITATION OF WARRANTIES, REMEDIES AND DAMAGES

10 Part Number: 02805 Rev AA February 2017
NOTES

11 Part Number: 02805 Rev AA February 2017
NOTES

© 2016 Columbus McKinnon Corporation. All Rights Reserved.
USA: Ph: [phone] •[phone] •Fax: [phone] •www.cmworks.com
CANADA: Ph: [phone] •Fax: [phone] •www.cmworks.com
