Cognex In-Sight 3400 User manual

Installing the In-Sight 3400®Vision Sensor
Copyright, Trademarks, Patents
The software described in this document is furnished under license, and may be used or copied only in
accordance with the terms of such license and with the inclusion of the copyright notice shown on this
page. The software, this document, nor any copies thereof may be provided to or otherwise made
available to anyone other than the licensee. Title to and ownership of this software remains with Cognex
Corporation or its licensor. Cognex Corporation assumes no responsibility for the use or reliability of its
software on equipment that is not supplied by Cognex Corporation. Cognex Corporation makes no
warranties, either express or implied, regarding the described software, its merchantability or its fitness for
any particular purpose.
The information in this document is subject to change without notice and should not be construed as a
commitment by Cognex Corporation. Cognex Corporation is not responsible for any errors that may be
present in either this document or the associated software.
This document may not be copied in whole or in part, nor transferred to any other media or language,
without the written permission of Cognex Corporation.
Cognex P/N 597-0025-02
Copyright © 2003-2005 Cognex Corporation. All Rights Reserved.
The hardware and portions of the software described in this document may be covered by one or more of
the following U.S. patents (other U.S. and foreign patents are pending):
Hardware 4,972,359; 5,526,050; 5,657,403; 5,793,899
Vision Tools 5,495,537; 5,548,326; 5,583,954; 5,602,937; 5,640,200; 5,717,785; 5,742,037; 5,751,853;
5,768,443; 5,796,868; 5,818,443; 5,825,483; 5,825,913; 5,845,007; 5,859,466; 5,872,870;
5,909,504
The following are registered trademarks of Cognex Corporation:
Cognex
Cognex, Vision for Industry
In-Sight "crosshair" logo
In-Sight
The following are trademarks of Cognex Corporation:
The Cognex logo
VAN (Vision Area Network)
Other product and company names mentioned herein are the trademarks, or registered trademarks, of
their respective owners.
i

Regulations/Compliance
Regulations/Compliance
Declaration of Conformity
Manufacturer Cognex Corporation
One Vision Drive
Natick, MA 01760 USA
Declares this -marked product
Product Number In-Sight®3400
Complies With 89/336/EEC Electromagnetic Compatibility Directive
Compliance Standards EN 55011 Class A
EN 61000-3-2
EN 61000-3-3
EN 61000-6-2
(EN 6100-4-2/-3/-4/-5/-6/-8/-11)
Certificate Number CE-058
European Representative Cognex France
Immeuble le Patio
104 avenue Albert 1er
92563 Rueil Malmaison
France
Safety
LISTED
(UL 508:Standard for
Industrial Control
Equipment)
CUL Certification marks are present on products
FCC Part 15, Class A
ii

Installing the In-Sight 3400®Vision Sensor
Precautions
Observe these precautions when installing the In-Sight 3400 sensor to reduce the risk of injury or
equipment damage:
 Do not connect the In-Sight 3400 sensor to a power source other than 24VDC. Any other voltage
creates a risk of fire or shock and can damage In-Sight components. Always observe the proper
polarity.
 Do not connect or disconnect In-Sight components to any equipment while connected to a power
source. Installing or removing “live” equipment can damage In-Sight 3400 components.
 Do not connect any camera other than the In-Sight cameras specified in this document; this may
damage the remote head camera, the In-Sight sensor, or both.
 Do not install the In-Sight 3400 sensor where it is directly exposed to environmental hazards
such as excessive heat, dust, moisture, humidity, impact, vibration, corrosive substances,
flammable substances, or static electricity.
 Do not route In-Sight cables and wires near high-voltage power sources. Route cables and wires
away from high-voltage power sources to reduce the risk of damage or malfunction.
 Do not open the In-Sight 3400 sensor or remote head camera. These devices do not contain
user-serviceable parts.
 Do not make electrical or mechanical modifications to In-Sight components. Unauthorized
modifications may violate your warranty.
iii

Precautions
iv

Installing the In-Sight 3400®Vision Sensor
Table of Contents
1Introduction...........................................................................................................................1
1.1 In-Sight 3400 Vision Sensor Overview ........................................................................1
1.2 In-Sight Support ...........................................................................................................1
1.3 In-Sight 3400 Components ..........................................................................................2
1.4 In-Sight 3400 Sensor Configurations ...........................................................................3
1.4.1 Standalone (No Network) Configuration..........................................................4
1.4.2 Adding an In-Sight Network to a Factory Network ..........................................6
2In-Sight 3400 Installation .....................................................................................................7
2.1 Connecting the In-Sight 3400 Vision Sensor ...............................................................7
2.1.1 Connecting the In-Sight 3400 Components.....................................................9
2.1.2 Verifying the Standard Connections..............................................................11
2.2 Connecting the Model 1350 Breakout Module...........................................................12
2.3 Connecting the Model 1460 I/O Expansion Module ..................................................13
2.4 Connecting the Model 1450 I/O Expansion Module ..................................................15
2.5 Adding the Sensor to a Network Using the In-Sight 3400 GUI..................................17
2.5.1 Installing to a DHCP Network ........................................................................17
2.5.2 Installing to a Non-DHCP Network ................................................................18
2.5.3 Verifying the In-Sight 3400 Sensor Network Connection ..............................22
2.6 Installing the In-Sight Software on a Windows PC ....................................................24
2.7 Adding the Sensor to a Network Using In-Sight Explorer..........................................25
2.7.1 Installing to a DHCP Network ........................................................................25
2.7.2 Installing to a Non-DHCP Network ................................................................26
2.7.3 Logging On to the In-Sight 3400 Sensor .......................................................31
2.7.4 Modifying the In-Sight 3400 Sensor Network Settings..................................32
3Using the Control Pad........................................................................................................35
3.1 Direction Buttons........................................................................................................35
3.1.1 Trigger Button ................................................................................................36
3.1.2 View Button....................................................................................................36
3.2 Action Buttons ............................................................................................................36
4Specifications .....................................................................................................................37
4.1 General Specifications ...............................................................................................37
4.1.1 In-Sight 3400 Sensor Specifications..............................................................38
v

Table of Contents
4.1.2 In-Sight 3400 Remote Head Camera Specifications..................................... 39
4.1.3 Remote Head Camera Enclosure Specifications ..........................................40
4.2 Detailed I/O Specifications.........................................................................................40
4.2.1 Acquisition Trigger Input................................................................................ 40
4.2.2 High-Speed Outputs ......................................................................................41
4.2.3 Control Pad and Connector Specifications....................................................44
4.2.4 24VDC Breakout Connector and Cable Specifications .................................45
4.2.5 I/O Module Cable...........................................................................................46
4.2.6 Network Cable Specifications........................................................................47
4.2.7 Camera Cable Specifications ........................................................................48
4.2.8 VGA Connector Specifications ......................................................................49
4.3 Dimensional Drawings ...............................................................................................50
4.3.1 Sensor Dimensions........................................................................................50
4.3.2 Remote Head Camera Dimensions...............................................................51
4.3.3 Remote Head Camera Enclosure Dimensions..............................................52
4.3.4 Remote Head Camera Mount Dimensions....................................................53
4.3.5 Control Pad Dimensions................................................................................54
Appendix A................................................................................................................................55
A.1 Configuring Microsoft Windows Network Settings..................................................... 55
A.1.1 Configuring the IP Address and Subnet Mask..............................................55
Appendix B................................................................................................................................57
B.1 Configuring the In-Sight Sensor’s I/O Settings Using In-Sight Explorer.................... 57
B.1.1 Configuring the I/O Expansion Module .........................................................57
B.1.2 Enabling Hardware Handshaking..................................................................59
Appendix C................................................................................................................................61
C.1 Configuring the In-Sight Sensor Using In-Sight PC Host...........................................61
C.1.1 Adding the In-Sight 3400 Sensor to a Network .............................................61
C.1.2 Logging On to the In-Sight 3400 Sensor .......................................................65
C.1.3 Modifying the In-Sight 3400 Sensor’s Network Settings ...............................66
C.1.4 Configuring the In-Sight Sensor’s I/O Settings.............................................. 69
Appendix D................................................................................................................................75
D.1 Installing the Remote Head Camera Mount...............................................................75
Appendix E ................................................................................................................................77
E.1 System Recovery Using Safe Mode ..........................................................................77
vi

Installing the In-Sight 3400®Vision Sensor
List of Figures
Figure 1-1: Standard In-Sight 3400 Components.........................................................................2
Figure 1-2: In-Sight 3400 Standalone Configuration ....................................................................4
Figure 1-3: Standalone In-Sight Network with Switch/Router.......................................................5
Figure 1-4: In-Sight Network on the Factory Network...................................................................6
Figure 2-1: Control Pad Connection .............................................................................................9
Figure 2-2: VGA Connection.........................................................................................................9
Figure 2-3: CAM Connection ......................................................................................................10
Figure 2-4: Power Connections ..................................................................................................10
Figure 2-5: Breakout Module Connections .................................................................................12
Figure 2-6: Connecting I/O Wires ...............................................................................................13
Figure 2-7: Connecting the I/O Cable and Serial Cable .............................................................14
Figure 2-8: Connecting the Expansion Module to In-Sight .........................................................14
Figure 2-9: Connecting +24VDC and Ground Wires ..................................................................15
Figure 2-10: Model 1450 I/O Expansion Module Connections ...................................................16
Figure 2-11: System and Settings Menus...................................................................................18
Figure 2-12: Network Dialog .......................................................................................................19
Figure 2-13: Logon Dialog ..........................................................................................................23
Figure 2-14: In-Sight Connection Manager.................................................................................26
Figure 2-15: User Name and Password......................................................................................27
Figure 2-16: MAC Address .........................................................................................................28
Figure 2-17: Set Network Configuration Dialog ..........................................................................29
Figure 2-18: Enter IP Address ....................................................................................................30
Figure 2-19: Network Settings Dialog .........................................................................................32
Figure 3-1: Control Pad...............................................................................................................35
Figure 4-1: Acquisition Trigger Input Schematic.........................................................................41
Figure 4-2: High-Speed Output Connection Example 1 .............................................................42
Figure 4-3: High-Speed Output Connection Example 2 .............................................................42
Figure 4-4: High-Speed Output Connection Example 3 .............................................................43
Figure 4-5: In-Sight 3400 Sensor Dimensions............................................................................50
Figure 4-6: Remote Head Camera Dimensions..........................................................................51
Figure 4-7: Remote Head Camera Enclosure Dimensions.........................................................52
Figure 4-8: Remote Head Camera Mount Dimensions...............................................................53
vii

List of Figures
Figure 4-9: Control Pad Dimensions...........................................................................................54
Figure A-1: Local Area Connection Properties Dialog................................................................55
Figure A-2: Select Network Protocol Dialog ...............................................................................56
Figure B-1: Accessing the Discrete Output Settings...................................................................57
Figure B-2: Discrete Output Settings Dialog............................................................................... 58
Figure B-3: Accessing the Serial Port Settings...........................................................................59
Figure B-4: Serial Port Settings Dialog ....................................................................................... 60
Figure C-1: System Menu...........................................................................................................62
Figure C-2: Logon Dialog............................................................................................................63
Figure C-3: New Host Configuration...........................................................................................63
Figure C-4: IP Configuration Message Box ................................................................................64
Figure C-5: IP Configuration Successful Message Box..............................................................64
Figure C-6: System Menu...........................................................................................................65
Figure C-7: Logon Dialog........................................................................................................... 66
Figure C-8: System Menu...........................................................................................................67
Figure C-9: Settings Menu..........................................................................................................67
Figure C-10: Network Dialog.......................................................................................................68
Figure C-11: System Menu.........................................................................................................69
Figure C-12: Settings Menu........................................................................................................70
Figure C-13: Discrete Output Dialog, Default Settings ...............................................................70
Figure C-14: Discrete Output Dialog, I/O Expansion Configuration ........................................... 71
Figure C-15: System Menu.........................................................................................................72
Figure C-16: Settings Menu........................................................................................................73
Figure C-17: Serial Port Dialog................................................................................................... 73
Figure C-18: Serial Port Dialog, Hardware Handshaking Enabled.............................................74
Figure D-1: Remote Head Camera Installation Diagram............................................................75
viii

Installing the In-Sight 3400®Vision Sensor
List of Tables
Table 1-1: In-Sight 3400 Standard Component Descriptions .......................................................3
Table 2-1: In-Sight 3400 Vision Sensor Connections and Indicators ...........................................8
Table 2-2: IP Address Schemes .................................................................................................20
Table 2-3: Subnet Mask Formats................................................................................................20
Table 4-1: In-Sight 3400 Sensor, General Specifications...........................................................38
Table 4-2: In-Sight 3400 Remote Head Camera, General Specifications..................................39
Table 4-3: Remote Head Camera Enclosure Specifications ......................................................40
Table 4-4: Acquisition Trigger Input Specifications.....................................................................40
Table 4-5: High-Speed Output Specifications Table...................................................................41
Table 4-6: Control Pad Port Pin Numbers and Assignments......................................................44
Table 4-7: 24VDC Breakout Connector Cable Pin-Out ..............................................................45
Table 4-8: I/O Module Cable Pin-Out..........................................................................................46
Table 4-9: Network Cable Pin-Out..............................................................................................47
Table 4-10: Camera Cable Pin-Out ............................................................................................48
Table 4-11: VGA Connector Pin-Out ..........................................................................................49
ix

List of Tables
x

1 Introduction
In this Section…
1.1 In-Sight 3400 Vision Sensor Overview.............................................1
1.2 In-Sight Support...............................................................................1
1.3 In-Sight 3400 Components ..............................................................2
1.4 In-Sight 3400 Sensor Configurations...............................................3
1.1 In-Sight 3400 Vision Sensor Overview
The In-Sight®3400 sensor is a compact, network-ready machine vision sensor for automated
inspection, measurement, identification, alignment and robot guidance applications on the factory
floor. The In-Sight 3400 sensor provides an intuitive spreadsheet interface for configuring and
monitoring any In-Sight sensor without using a PC. Use the In-Sight 3400 sensor to configure
other sensors on a factory network, or remotely from another part of the factory or enterprise
network. The spreadsheet also allows local or remote monitoring of the In-Sight sensor’s
operation during runtime without using a PC.
This manual describes how to install the In-Sight 3400 sensor.
1.2 In-Sight Support
Other resources with information about the In-Sight 3400 sensor and its spreadsheet interface
include:
 Getting Started with In-Sight, Cognex P/N 590-6368 (English), 590-6368F (French),
590-6368J (Japanese), or 590-6368G (German)
 In-Sight®Explorer Help, an on-line HTML Help file provided on the In-Sight CD-ROM
(for In-Sight Explorer software).
 In-Sight®Guide & Reference, an on-line HTML Help file provided on the In-Sight
CD-ROM (for In-Sight PC Host software version 2.51 through version 2.80).
 In-Sight computer-based tutorials provided on CD-ROM with In-Sight starter
accessories kits.
 The In-Sight Online Support and Learning Center:
www.cognex.com/support/In-Sight.asp.
1

Introduction
1.3 In-Sight 3400 Components
The In-Sight 3400 sensor is shipped with the components shown in Figure 1-1. Component part
numbers and descriptions are listed in Table 1-1.
Figure 1-1: Standard In-Sight 3400 Components
2

Installing the In-Sight®3400 Vision Sensor
Table 1-1: In-Sight 3400 Standard Component Descriptions
COMPONENT DESCRIPTION
Sensor
(P/N 800-5809-1)
Provides image display, vision processing, serial and
Ethernet connectivity and discrete I/O.
Remote Head Camera
(P/N 800-5808-1)
Acquires and sends images to the In-Sight 3400 sensor.
Camera Cable
2M (P/N 185-0085)
5M (P/N 185-0086)
10M (P/N 185-0087)
15M (P/N 185-0088)
Connects the In-Sight 3400 remote head camera to the
sensor. This cable can be identified by its M12 connectors
at both ends.
Breakout Cable1
2M (P/N 185-0095)
5M (P/N 185-0096)
10M (P/N 185-0093)
15M (P/N 185-0094)
Connects the In-Sight 3400 sensor to an external power
supply, an acquisition trigger source, output devices and a
remote serial device. This cable can be identified by its
M12 connector on one end, and eight wires on the other.
When an I/O Expansion Module or Breakout Module is
used, the I/O Cable supplied with the module replaces the
Breakout Cable.
Network Cable1
5M (P/N 185-0084)
10M (P/N 185-0092)
15M (P/N 185-0097)
30M (P/N 185-0089)
Connects the In-Sight 3400 sensor to the factory network.
This cable is a CAT5/5e standard, straight-pinned
Ethernet cable, and can be identified by its M12 connector
on one end and standard RJ-45 connector on the other.
Crossover Coupler
(P/N 185-0080)
Attaches to the RJ-45 connector of the network cable to
provide crossover CAT5/5e cable functionality when
connecting the In-Sight 3400 sensor directly to a PC or
other In-Sight sensor.
Control Pad
(P/N 800-5746-1)
Used to navigate and configure the In-Sight spreadsheet
user interface. Attaches to the In-Sight 3400 sensor via
DB15 male connector.
Remote Head
Accessory Kit
(P/N 800-5813-1)
Includes remote head camera mounting hardware and a
5mm extension ring (for use with C-mount lenses).
1. When you receive a Breakout cable or Network cable from Cognex, the cable bag is labeled
with a CCB-84909-xxxx-xx product number and a Cognex 185-xxxx part number. The cable
is tagged with an 84909-xxxx cable number.
1.4 In-Sight 3400 Sensor Configurations
The In-Sight 3400 sensor can operate as a standalone sensor, or as a host sensor on a factory
network. For the purposes of the instructions in this manual, a network is an In-Sight 3400 sensor
connected over Ethernet to at least one other In-Sight sensor or PC running In-Sight software.
These configurations may require additional components, such as an Ethernet switch or VGA
display. Many optional components may be purchased directly from Cognex. A complete catalog
of In-Sight products and accessories is available on the Cognex web sight at:
www.cognex.com/pdf/downloads/In-Sight-brochure.pdf.
3

Introduction
Several basic In-Sight 3400 configurations are described in the following sections.
1.4.1 Standalone (No Network) Configuration
A standalone In-Sight 3400 configuration does not include a connection to any other network
device or In-Sight sensor. Figure 1-2 shows the standalone configuration.
The standalone configuration requires a local VGA display to configure applications and monitor
the In-Sight 3400 sensor’s runtime operation. In this configuration, the jobs that can be stored are
limited to the amount of local storage available on the In-Sight 3400 sensor. A remote serial
device must be used for storing image files or for additional job storage.
Control Pad VGA Display
Power, I/O, Serial
Communications
Remote Head
Camera
Figure 1-2: In-Sight 3400 Standalone Configuration
4

Installing the In-Sight®3400 Vision Sensor
Configurations Using Switches/Routers
An In-Sight network may be extended to include more than two In-Sight sensors by using a
network router or Ethernet switch. The only limit on the size of this type of network is the number
of routers or switches connected, and the number of connections they provide.
The standalone In-Sight network shown in Figure 1-3 includes an In-Sight 3400 sensor, two
In-Sight 5000 series sensors and a PC running In-Sight Explorer, connected by a switch/router.
In this configuration, any In-Sight sensor on the network can be configured using either the
In-Sight 3400 GUI or the In-Sight Explorer software. In-Sight Explorer also provides additional job
storage, and image and data archiving, for all three In-Sight sensors on the network. The network
switch/router may also connect to another network switch/router, which in turn could have a
similar complement of network sensors.
NOTE In this configuration, the Network cable connecting the In-Sight 3400 sensor to the
switch/router does not use the Crossover Coupler.
Figure 1-3: Standalone In-Sight Network with Switch/Router
5

Introduction
1.4.2 Adding an In-Sight Network to a Factory Network
Multiple In-Sight networks may be connected to the larger, factory network, combining to create
an In-Sight network of virtually unlimited size. Connecting an In-Sight network to the factory
network allows real-time production data to be accessed remotely from any PC workstation with
network access. For networks that cover large physical areas, an In-Sight 3400 sensor located
on each In-Sight network provides local job configuration and image display for all In-Sight
sensors, without a PC.
As in the example in the previous section, the In-Sight network shown below includes an In-Sight
3400 sensor, two In-Sight 5000 series sensors and a PC running In-Sight Explorer, connected to
the same network switch/router. However, the switch/router for the In-Sight network is now
connected to the factory network through another switch/router, which in turn may host
connections to additional In-Sight networks.
Figure 1-4: In-Sight Network on the Factory Network
6

2 In-Sight 3400 Installation
In This Section…
2.1 Connecting the In-Sight 3400 Vision Sensor ...................................7
2.2 Connecting the Model 1350 Breakout Module...............................12
2.3 Connecting the Model 1460 I/O Expansion Module.......................13
2.4 Connecting the Model 1450 I/O Expansion Module.......................15
2.5 Adding the Sensor to a Network Using the In-Sight 3400 GUI.......17
2.6 Installing the In-Sight Software on a Windows PC.........................24
2.7 Adding the Sensor to a Network Using In-Sight Explorer ..............25
2.1 Connecting the In-Sight 3400 Vision Sensor
This section describes the connection of the In-Sight 3400 to its standard components and
optional I/O modules. For a complete list of options and accessories, contact your Cognex sales
representative.
7

In-Sight 3400 Installation
Table 2-1: In-Sight 3400 Vision Sensor Connections and Indicators
CONNECTOR/
INDICATOR FUNCTION
CONTROL
PAD Connector
Connects the In-Sight Control Pad, which is used to navigate the spreadsheet user
interface. The Control Pad is not required when the In-Sight 3400 sensor is
accessed remotely from a PC running In-Sight software.
PWR LED This PWR LED indicates the power status of the In-Sight 3400 sensor. The LED is
red when the sensor is receiving power during initialization, momentarily switches
from green to orange during the LED start-up test, and then switches back to green
after initialization is completed. If initialization fails, the LED remains red. The LED
blinks red if the power supply is overloaded, causing the power to cycle. If the
sensor is rebooting, the PWR LED is orange.
ENET LED The ENET LED is orange during the LED start-up test, momentarily switches to
green when a network connection is established, and then blinks green and orange
when network traffic is detected. If a network connection cannot be established, the
LED is not lit.
24VDC
Connector
Connects the In-Sight Breakout Cable, which provides connections to an external
power supply, the acquisition trigger input, high-speed outputs and RS-232 serial
communications. Alternatively, this connector is used to attach the I/O Cable to an
optional In-Sight I/O Expansion Module, which adds general-purpose discrete I/O
and light control functionality. Refer to Table 4-7 and Table 4-8, pages 45 and 46.
ENET
Connector
Connects the In-Sight sensor to a network. The ENET connector provides the
Ethernet connection to external network devices. Refer to Table 4-9, page 47.
CAM
Connector
The CAM connector attaches the remote head camera to the In-Sight 3400 sensor.
Refer to Table 4-10, page 48.
CAM LED The CAM LED indicates the status of the remote head camera. The LED is orange
during the LED start-up test and then switches to green when the camera is
connected to the sensor and the synchronization signal is established. The LED is
orange when the camera is acquiring an image and blinks red if the camera loses
sync. If the camera does not sync-lock during initialization, the LED is solid red.
HSOUT 0/1
LEDs
These LEDs indicate the status of the two High-Speed outputs. The applicable LED
is green when active.
USER 0/1
LEDs
The User 0 LED lights green; User 1 lights red when triggered by a user-definable
event. Refer to the “WriteDiscrete” topic in the In-Sight®Explorer Help file for
information on configuring the behavior of User 0/1 LEDs.
VGA
Connector
Connects a standard VGA or flat panel display. A display is not needed when
configuring or monitoring an In-Sight 3400 sensor from a remote PC location.
Refer to Table 4-11, page 49.
8
