CombiSteel 7534 Series User manual

Planetary Mixer
7534 Series
User Manual
Gebruikershandleiding
Gebrauchsanweisung
Le mode d’emploi

2
www.combisteel.com
CONTENT
ENGLISH
1. Attention Owners and Operators........................................................................................................................ 4
2. Specifications ......................................................................................................................................................5
3. Key Components of the Mixer ............................................................................................................................5
4. Installation .......................................................................................................................................................... 6
4.1 Unpack ..........................................................................................................................................................6
4.2 Installation .................................................................................................................................................... 6
4.3 Connecting the power supply.......................................................................................................................6
5. Operating instructions ........................................................................................................................................ 7
5.1 About the bowl guard...................................................................................................................................7
5.2 Attaching the bowl to the mixer ................................................................................................................... 7
5.3 Attach agitator to mixer (i.e., Beater, Hook, Whip)....................................................................................... 8
5.4 Mixing ingredients ........................................................................................................................................8
5.5 Setting and Changing speed by digital control panel....................................................................................8
5.6 Preset speed by digital control panel............................................................................................................9
5.7 Using mixer’s digital controls and timer .......................................................................................................9
5.8 Digital control instructions.......................................................................................................................... 10
6. Speed data table............................................................................................................................................... 11
7. Cleaning Instructions ........................................................................................................................................ 12
8. Important points............................................................................................................................................... 12
8.1 Dust hazard .................................................................................................................................................12
8.2 Maintenance...............................................................................................................................................13
9. Troubleshooting................................................................................................................................................ 13
NEDERLANDS
1. Aandachtspunten voor eigenaars en gebruikers ..............................................................................................15
2. Specificaties ...................................................................................................................................................... 16
3. Belangrijkste onderdelen van de mixer ............................................................................................................16
4. Installatie .......................................................................................................................................................... 17
4.1 Uitpakken.................................................................................................................................................... 17
4.2 Installatie ....................................................................................................................................................17
4.3 De voeding aansluiten ................................................................................................................................17
5. Gebruiksaanwijzing...........................................................................................................................................18
5.1 Over het spatscherm...................................................................................................................................18
5.2 De kom aan de mixer bevestigen................................................................................................................18
5.3 Roerwerk aan mixer bevestigen (bv. klopper, garde, haak) ........................................................................ 19
5.4 Ingrediënten mengen ................................................................................................................................. 19
5.5 Snelheid instellen en wijzigen via digitaal bedieningspaneel .....................................................................20
5.6 Vooraf ingestelde snelheid door digitaal bedieningspaneel.......................................................................20
5.7 De digitale bedieningselementen en timer van de mixer gebruiken .......................................................... 21
5.8 Digitale bedieningsinstructies.....................................................................................................................22
6. Tabel met snelheidsgegevens ...........................................................................................................................23
7. Reinigingsinstructies .........................................................................................................................................24
8. Belangrijke punten............................................................................................................................................25
8.1 Stofgevaar ................................................................................................................................................... 25
8.2 Onderhoud.................................................................................................................................................. 25
9. Problemen oplossen ......................................................................................................................................... 25

3
www.combisteel.com
DEUTSCH
1. Achtung: an Eigentümer und Betreiber ............................................................................................................ 27
2. Technische Daten.............................................................................................................................................. 28
3. Hauptkomponenten des Mixers .......................................................................................................................28
4. Montage............................................................................................................................................................29
4.1 Auspacken................................................................................................................................................... 29
4.2 Montage...................................................................................................................................................... 29
4.3 Anschluss des Netzteils............................................................................................................................... 29
5. Betriebsanleitung.............................................................................................................................................. 30
5.1 Über den Schüsselschutz ............................................................................................................................30
5.2 Befestigen der Schüssel am Mixer ..............................................................................................................30
5.3 Anbringen des Rührwerks am Mixer (z. B. Schläger, Haken, Quirl).............................................................31
5.4 Mischen der Zutaten................................................................................................................................... 31
5.5 Einstellen und Ändern der Geschwindigkeit über das digitale Bedienfeld .................................................32
5.6 Voreingestellte Geschwindigkeit über das digitale Bedienfeld...................................................................32
5.7 Verwendung der digitalen Bedienelemente und des Timers des Mixers.................................................... 33
5.8 Anweisungen zur digitalen Steuerung ........................................................................................................34
6. Tabelle der Geschwindigkeitsdaten ..................................................................................................................35
7. Anweisungen zur Reinigung..............................................................................................................................36
8. Wichtige Punkte................................................................................................................................................ 37
8.1 Gefahr durch Staub..................................................................................................................................... 37
8.2 Wartung ......................................................................................................................................................37
9. Fehlersuche....................................................................................................................................................... 37
FRANÇAIS
1. À l'attention des propriétaires et des opérateurs............................................................................................. 39
2. Spécifications ....................................................................................................................................................39
3. Principaux éléments du mixeur ........................................................................................................................40
4. Installation ........................................................................................................................................................ 41
4.1 Déballage ....................................................................................................................................................41
4.2 Installation .................................................................................................................................................. 41
4.3 Raccordement de l'alimentation électrique ............................................................................................... 41
5. Instructions d'utilisation ...................................................................................................................................42
5.1 À propos du protège-bol............................................................................................................................. 42
5.2 Fixation du bol au mixeur ........................................................................................................................... 42
5.3 Fixer l'agitateur au mixeur (par exemple, le batteur, le crochet, le fouet).................................................. 43
5.4 Mélange d'ingrédients ................................................................................................................................43
5.5 Réglage et modification de la vitesse par le panneau de commande numérique......................................44
5.6 Vitesse préréglée par le panneau de commande numérique..................................................................... 44
5.7 Utilisation des commandes numériques et de la minuterie du mixeur...................................................... 45
5.8 Instructions de contrôle numérique ...........................................................................................................46
6. Tableau des données de vitesse .......................................................................................................................48
7. Instructions de nettoyage .................................................................................................................................48
8. Points importants .............................................................................................................................................49
8.1 Risque lié à la poussière.............................................................................................................................. 49
8.2 Maintenance...............................................................................................................................................49
9. Dépannage........................................................................................................................................................ 50

4
www.combisteel.com
- IMPORTANT SAFETY NOTICE –
This manual contains important safety instructions which must be strictly followed
when using this equipment.
Maintain and use this manual as a reference for training.
1. Attention Owners and Operators
Equipment provides safe and efficient food processing as long as the equipment is used in accordance with the
instructions in this manual and is properly maintained. Serious injury may occur unless operating personnel are
adequately trained and supervised. The owner of this equipment is responsible for ensuring that this equipment
is used correctly and safely and that it strictly follows all instructions in this manual and local, state and/or federal
legal requirements.
The owner should not allow anyone to have access to this equipment unless they are 18 years of age or older,
have been properly trained and supervised, and have read and understood this manual. Owners should also
ensure that no customers, visitors, or other unauthorized persons come into contact with this equipment. Please
keep in mind that cannot predict the conditions or circumstances in which its equipment will be operated. It is
the owner and operator's responsibility to be alert to any hazards presented by the function of this equipment.
If you are in doubt about a task or the proper way to operate this equipment, ask your supervisor.
This manual contains precautions to help promote the safe use of this equipment. Throughout the manual, you
will see additional warnings to help alert you to potential hazards.
Warnings label affecting your personal safety are indicated by:
Warnings label related to possible damage to the equipment are indicated by:
Puts several warning labels in English on its mixers. If warning labels and/or manuals are misplaced, damaged or
illegible, or if you need additional copies, please contact your nearest representative or dealer directly to request
these items free of charge.
Remember that neither a manual nor a warning label can replace the need to be vigilant, to properly train and
supervise operators, and to use common sense when using this equipment.

5
www.combisteel.com
2. Specifications
Model Transmission Bowl
capacity (L)
Maximum
kneading
capacity (KG)
Maximum
flour (KG)
Power
(kW)
Voltage
(V)
Frequency
(Hz)
7534.0005
Belt + VFD
10
3,75
2,5
0,75
230
50/60
7534.0010
Belt + VFD
20
7,5
5
1
230
50/60
7534.0015
Belt + VFD
30
10,5
7
1,5
230
50/60
7534.0020
Belt + VFD
40
13,5
9
1,5
230
50/60
*VFD: Variable Frequency Drive
3. Key Components of the Mixer
7534.0005 7534.0015 7534.0005/0010
7534.0010 7534.0020 7534.0015/0020

6
www.combisteel.com
4. Installation
4.1 Unpack
Unpack the blender as soon as you receive it. If you find that the machine is damaged, please save the packing
materials, and contact the carrier within fifteen (15) days of delivery. Contact your equipment source now.
To avoid serious personal injury.
•Always install the equipment in a work area with adequate light and space.
•Only operate the mixer only on a solid, flat, non-slip, non-flammable surface.
•Never bypass, alter or modify the original condition of this device in any way. Doing so is dangerous and will
avoid the warranty.
•Never operate the mixer without all warnings installed.
•DO NOT attempt to lift the mixer by itself.
4.2 Installation
1. Read this manual carefully before installation and operation. If you have questions or do not understand
everything in this manual, do not proceed with the installation and operation. Contact your local representative.
2. Remove the straps from the box and remove the corrugated box from the chute. NOTE: The mixers are shipped
in wooden box; only the bolts on the bottom of the box (all four sides) need to be removed.
3. Carefully remove the mixer from the chute using an 11/16'' or 3/4'' wrench.
4. Choose a location for the mixer, keeping in mind the following.
-The floor or counter must be level.
-Easy access for maintenance and repair.
-Clearance for operating controls, mounting and removing the mixer, bowl or accessories.
-Sufficient space for adding ingredients during mixing.
-Ensure that the rear vent of the mixer is not blocked.
5. At least two people are required to tilt the unit and install rubber feet.
6. Check the mixer to ensure that all parts are provided (i.e. bowl, mixer, stirrer and dough hook).
7. Read the electrical information on the nameplate on the back of the machine. The input power must match
the rating on the nameplate.
4.3 Connecting the power supply
Electrical connection device: While the machine is equipped with a three-phase, The receptacle to which this
plug is connected must be properly grounded. If the receptacle has an incorrect type of grounding, contact an
electrician. Do not under any circumstances cut or remove the third grounding pin on the power cord or use the
adapter plug. Do not use extension cords. Low power may damage the mixer and/or cause a fire.
If the equipment needs to be hardwired, have a licensed electrician connect the equipment to the power source.
8.Clean the mixer before use. Refer to the Cleaning Instructions section of this manual.
NOTE: It is normal for the factory to apply a large amount of grease to the inside of the machine and to the
machine. Excess grease (brown) will be applied to all metal surfaces (i.e. top of drum guard, speed control,
locking drum, drum lift will and accessory wheel hub wing screws). Excess High Pressure Grease (brown-black)
can also be found on the planetary shafts and some droplets can be found in the bucket.

7
www.combisteel.com
5. Operating instructions
To avoid serious personal injury.
-Do not operate the mixer until you have first read the instruction manual.
-Always disconnect or unplug power before cleaning, servicing or adjusting parts or accessories.
-Always keep hands, hair and clothing away from moving parts.
5.1 About the bowl guard
NOTE: The mixer will not operate when the bowl guard is open or not properly installed.
NOTE: Rotate the bowl guard clockwise (open) and counterclockwise (closed) to attach the mixer.
Open/rotating bowl guard.
Rotate the bowl guard clockwise (open) and counterclockwise (close) to allow the operator to easily add
ingredients and properly remove the mixer and bucket from the mixer.
1. When the separate handles are aligned and firmly pushed to the right side of the mixer, the bowl guard is in
the locked position and ready for operation (Figure 7-1)
2. To rotate the bowl cover to its open position, grasp the separate handles on the
bowl cover and bring them together, moving clockwise to open/rotate the bowl
cover. To close the bowl cover, grasp the separate handles and move them together
as a unit, moving counterclockwise to close/rotate the bowl cover back to the
locked position.
5.2 Attaching the bowl to the mixer
NOTE: Install the bowl before attaching the mixer.
1. Lower the bowl by pulling the bowl lift lever forward and down to its resting position. For the 60 liter and 80
liter mixer, press the arrow (green button) to lower the bowl until it stops (Fig. 7-2).
2. Lift the bowl by the bowl handle and:
a. Slowly position the locking pin (located at the rear of the bowl) into the hole in the middle rear of the holder
(Fig. 7-3).
b. Lower the bowl onto the pins located on the sides of the bowl holder.
3. After placing the bowl on the stand, pull each bowl clip forward to secure the bowl until the bowl locks into
place (Fig. 7-4)

8
www.combisteel.com
5.3 Attach agitator to mixer (i.e., Beater, Hook, Whip)
NOTE: It is easier to install the mixer before adding the ingredients to the bowl.
1. Turn the bowl cover to the left so that it stays in the open position (Fig. 8-1).
Excessive force to open and close the bowl hood may damage the spring lock and
bowl cover microswitch will void the warranty.
2. Slowly slide the mixer upwards onto the planetary shaft and insert the shaft pin
through the slot in the agitator (Fig. 8-2).
3. Turn the agitator clockwise to secure it to the planetary shaft.
5.4 Mixing ingredients
Agitators of 7534.0005, 7534.0010, 7534.0015 and 7534.0020 must always rotate in clockwise direction around
the bowl. If the agitator of 7534.0005, 7534.0010, 7534.0015 and 7534.0020 moves counterclockwise, contact a
licensed electrician immediately to remedy incorrect wiring.
1. Add the appropriate mixing ingredients to the bowl.
2. Rotate bowl lift lever up until the bowl locks into position. For BX60,
and BX80, press the arrow (green button) to lift up the bowl until it
stops. (Fig.8-3)
3. Rotate bowl guard to the right until it locks into the closed position
(Fig. 8-4). You will hear it ‘di’ into place.
NOTE: Mixer will not start if bowl guard is open or bowl is in the lowered
position.
5.5 Setting and Changing speed by digital control panel
1. Select the appropriate speed setting by rotating speed button, clockwise to raise speed, counterclockwise to
lower speed.
NOTE: ALL models have 10 variable speeds under each agitator.
Agitator: Product Type/Ingredient recommendation:
Hook: Raised Donut Dough (65% AR), Pasta, Basic Egg Noodle, Heavy Bread Dough (55% AR), Bread and Roll
Dough (60% AR), Pizza Dough (40% AR)
Flat Beater: Waffle or Hotcake Batter, Mashed Potatoes, Fondant Icing, Cake Flat, Pie Dough
Wire Whip Light: whipping cream, egg whites, meringue
2. Press the green START button to begin mixing.
3. To change the speed while mixing, NO STOP or PAUSE button, by rotating speed button, clockwise to raise
speed, counterclockwise to lower speed.
4. When the ingredients have been thoroughly mixed, press the red STOP button to stop the mixer.
NOTE: If the timer was used, mixer will automatically stop when time has expired.

9
www.combisteel.com
5. Lower bowl by pulling bowl lift lever forward and down to its resting position. For models 7534.0005,
7534.0010, 7534.0015 and 7534.0020 rotate bowl lift wheel counterclockwise until it stops.
6. Rotate bowl guard to the left so it is in the open position.
7. Remove the agitator from the planetary shaft by lifting it upwards, then rotating it counterclockwise until it is
unlocked. Lower the agitator and remove from the planetary shaft.
8. Push each bowl clamp backwards to unlock the bowl from the bowl cradle.
9. Lift up slightly on bowl so it clears pins on the bowl cradle.
5.6 Preset speed by digital control panel
NOTE: Each agitator is available to preset speed.
Preset Speed Operation:
Speed on mixer can be set from 1 to 10. Before preset speed operating mode, verify that bowl guard and bowl
lift are closed and locked into position.
1. Set desired speed. Press and continuously hold the speed button 3 seconds, The display will illuminate a small
dot of light in the lower right-hand corner of the seconds speed display. After 3 seconds, no small dot is displayed.
NOTE: Press and continuously hold the SPEED buttons to counterclockwise and clockwise the desired minutes.
2. Once the desired speed is set, check that bowl guard and bowl lift are closed and locked into position, and
then press START.
Un-preset Speed Operation:
For simple on/off mixing operation in an un-preset speed operating mode, verify that bowl guard and bowl lift
are closed and locked into position.
1.The display should read 00:00 to operate in each agitator. Rotating the SPEED button rotate to counterclockwise
until speed back to zero, press and continuously hold the speed button 3 seconds, until no flash dot.
2.Press START button to begin mixing. The display will scroll zeros across the display from left to right while mixing.
NOTE: To change the speed while mixing, NO STOP or PAUSE button, by rotating speed button, clockwise to raise
speed, counterclockwise to lower speed.
5.7 Using mixer’s digital controls and timer
Read through this section and continue to section 5.8 for further operating instructions for use of the digital
controls on your mixer.
Mixer is equipped with a digital timer display, minutes and speed buttons (to adjust the timed operations) and
Start / Pause and Stop buttons. Mixer can function in either timed operation or untimed operation.
Untimed Operation: For simple on/off mixing operation in an untimed operating mode, verify that bowl guard
and bowl lift are closed and locked into position.
1. The display should read 00:00 to operate in untimed mode. Pressing the SPEED button rotate to counter-
clockwise until timer back to zero.
2. Press START button to begin mixing. The display will scroll zeros across the display from left to right while
mixing. Press STOP button once the desired mixing is complete.
Timed Operation: Timer on mixer can be set from 1 minute to 99 minutes.
1. Set desired time. Minutes advance by one and seconds advance by fives before rolling over to zero.
NOTE: Press and continuously hold the SPEED buttons to counterclockwise and clockwise the desired minutes.

10
www.combisteel.com
2. Once the desired time is set, check that bowl guard and bowl lift are closed and locked into position, and then
press START.
3. Wait for the timed cycle to end or press PAUSE to pause the mixing cycle.
a) Pressing the PUASE button stops the mixer and pauses the timer during operation.
b) Pressing the STOP button once while the mixer is not in operation will reset the timer to zero (00:00).
NOTE: If a cycle is interrupted by the bowl guard being opened or by lowering the bowl lift lever, the mixer will
stop. After bowl guard and bowl lift are closed and locked into position, START button can be pressed to continue
the programmed time.
To add additional minutes or seconds to a mix time, PAUSE mixer and adjust the cycle mixing time.
4. Once a timed cycle ends, mixer will beep for 20 seconds and indicating the timed cycle is complete.
Preset speed mode instructions and controls for the BX Models.
NOTE: Make sure bowl is up and bowl guard is closed. Mixer will not start if bowl and bowl guard are not
in the proper operating position.
Preset Speed Operation MODE
1. To begin operation of mixer in preset speed, select appropriate agitator, set the desired speed, press and hold
speed button. The display will illuminate a small dot of light in the lower right-hand corner of the speed display.
After 3 seconds, the desired speed will be illuminated on the display.
NOTE: Mixer will not start if bowl is not all the way up. Additionally, the bowl guard must be completely closed.
2. Press START button to begin mixing. Press PAUSE to discontinue mixing.
NOTE: Under preset speed mode, each start time of agitator will begin from the desired speed. Preset speed
always reset back the desired speed no Whether if power is lost or stop to mixer.
Un-preset Speed Operation MODE
1. To cancel preset speed operation mode, select preset speed agitator.
2. Rotating the SPEED button rotate to counterclockwise until speed
back to zero, press and continuously hold the speed button 3 seconds,
until small dot of right no flash. The display should read 00:00 to
operate in each agitator.
5.8 Digital control instructions
Untimed / Manual Mode instructions and controls for the BX Models.
Mixer must be OFF before installing attachments. Do NOT use attachments while mixing.
NOTE: Make sure bowl is up and bowl guard is closed. Mixer will not start if bowl and bowl guard are not
in the proper operating position.
Press BOWL “Up” arrow to activate the power bowl lift. Set the speed control to the desired speed.
Untimed - manual mode
1. To begin operation of mixer in Manual Mode, press and Hold SPEED button counterclockwise until
timer back to zero. The display will illuminate a small dot of light in the lower right-hand corner of the
seconds timer display.
NOTE: Mixer will not start if bowl is not all the way up. Additionally, the bowl guard must be completely
closed.
Set the speed control to the desired speed by rotating the
speed button clockwise to raise the speed, counterclockwise
to lower the speed.

11
www.combisteel.com
2. Press START button to begin mixing. Press PAUSE to discontinue mixing.
NOTE: The timer does not work in Manual Mode. To use the timer feature, follow the Timer Mode
instructions.
Timer mode
1. To begin operating the mixer in TIMER mode, press and hold SPEED button
2. Press and continuously hold the SPEED buttons to counterclockwise and clockwise the desired minutes.
3. Once the desired mix time has been set on the timer, press the START button to begin mixing.
4. Once the START button is pressed, mixer timer numbers will begin to descend.
The timer and mixer can be interrupted at any time by pressing the PAUSE OR STOP button. If the timer cycle is
interrupted and the mixer has not yet finished its set mixing time, the mixing cycle can be continued from where
it left off by pressing the START button.
NOTE: If a cycle is interrupted by the bowl guard being opened or the speed of the mixer being changed, mixer
will stop. After bowl guard and bowl lift are closed and locked into position, START button can be pressed to
continue the programmed time.
To add additional minutes to a mix time, PAUSE mixer, press and continuously hold the SPEED buttons to
counterclockwise and clockwise adjust the cycle mixing time. Press START button to begin mixing once again.
5. At the end of a timed mixing cycle the timer will count down to “00” minutes, mixer will stop, and the timer
will return to displaying the last mix cycle time that was entered.
6. To begin another mix cycle with the same set time as the previous mix, press the START button.
If the mix cycle time needs to be adjusted, set the new desired time and then press START button to begin mixing.
If power is lost to mixer, the mixing time will need to be reset to the desired time.
6. Speed data table
Model 1st 2nd 3rd 4th 5th 6th 7th 8th 9th 10th
7534.0005 52 71 90 113 135 155 177 197 219 242
7534.0010 60 73 93 113 137 157 177 197 220 240
7534.0015 52 70 91 112 131 152 170 192 213 231
7534.0020 52 70 91 112 131 152 170 192 213 231
Model 1st 2nd 3rd 4th 5th 6th 7th 8th 9th 10th
7534.0005 52 94 126 152 181 210 239 265 294 323
7534.0010 60 90 120 147 177 207 237 267 293 320
7534.0015 55 85 116 143 170 201 228 255 283 310
7534.0020 55 85 116 143 170 201 228 255 283 310
Model 1st 2nd 3rd 4th 5th 6th 7th 8th 9th 10th
7534.0005 52 103 152 203 252 303 352 400 452 500
7534.0010 60 103 153 203 253 303 353 403 453 503
7534.0015 55 94 143 192 240 286 334 383 432 480
7534.0020 55 94 143 192 240 286 334 383 432 480

12
www.combisteel.com
7. Cleaning Instructions
a) Dilute detergent according to the supplier’s instruction.
b) DO NOT hose down or pressure wash the mixer.
c) NEVER use a scrubber pad, steel wool, or abrasive material to clean the mixer.
d) NEVER use bleach (sodium hypochlorite) or bleach-based cleaner.
e) ALWAYS remove the agitator after each batch as the agitator can become stuck on the shaft and become
difficult to remove.
The entire mixer, including removable parts, must be thoroughly cleaned and sanitized using the
procedures identified by your local health department and the ServSafe Essentials published by the
National Restaurant Association Educational Foundation (NRAEF). Visit www.servsafe.com for more
details.
It is extremely important to sanitize mixer and to follow the instructions on the quaternary sanitizer
container to make sure proper sanitation is achieved.
ALWAYS DISCONNECT OR UNPLUG ELECTRICAL POWER FROM THE MIXER BEFORE CLEANING.
7.1 Recommended cleaning
PART REQUITED ACTION FREQUENCY
Agitators Hand-wash using mild soap and water; rinse, dry and sanitize. Clean after each use
Bowl guard Hand-wash using mild soap and water; rinse, dry and sanitize. Clean after each use
Bowl
Using a sponge or cloth, mild soap and water, apply pressure
to make sure the bowl is clean; rinse, dry, and sanitize.
The bowl can also be placed in a dishwasher.
Clean after each use
Rear splash guard Hand-wash using mild soap and water; rinse, dry and sanitize. Clean after each use
Bowl cradle Hand-wash using mild soap and water; rinse, dry and sanitize. Daily
Planetary shaft Wipe with clean damp cloth; dry and sanitize. Clean after each use
Exterior
Hand-wash using mild soap and water; rinse, dry, and
sanitize. DO NOT use a water hose.
Daily
Hub interior Wipe with clean damp cloth; dry, and sanitize. Daily
8. Important points
8.1 Dust hazard
•When mixing ingredients care must be taken to avoid the inhalation of dust particles e.g. flour.
•Ingredients such as flour must be added carefully to minimize air-borne dust particles.
•Carefully slit the bag while holding it in the lower part of the bowl. When mixing dry ingredients use the
lowest speed and a splash cover to minimize dust emission. Mix the ingredients in the bowl using the lowest
speed until the risk of producing any dust is eliminated. Fit suitable dust extraction equipment.

13
www.combisteel.com
8.2 Maintenance
PART REQUITED ACTION FREQUENCY
Bowl slide rods
Apply mineral oil on bowl slide rods. Raise and lower bowl
to distribute the oil onto the rods.
If bowl becomes difficult
to raise or lower.
9. Troubleshooting
Digital code Code explanation Possible causes Action required
E1 Bowl guard switch off
Bowl guard not in
closed position.
Rotate guard to the right until fully
closed.
Switch loosened. Tighten the switch in the right position.
E2 Bowl lift switch off
Bowl not raised. Raise bowl to highest position.
Switch loosened. Tighten the switch in the right position.
E3 Bowl lock switch off
Bowl not seated
correctly or clamps
not in place.
Make sure bowl is seated into bowl cradle
correctly and bowl clamps are locked into
place.
Switch loosened. Tighten the switch in the right position.
E4
Emergency stop switch
is on.
Emergency stop
switch is on.
Rotate the button to switch it off.
E7 Motor failure Motor failure Contact a technician to replace part.
E8 Motor temperature is
too high.
Exceeded maximum
mixing load.
Reduce the batch size by 30%.
The running time is
too long.
Wait 10 minutes. Then press START to
restart the mixer.
Damaged or broken
mechanical parts.
Rotate the motor blade to check whether
it can easily turn. If it can’t, contact after-
sales service.
E9 Machine is overloaded. Exceeded maximum
mixing load.
Reduce the batch size by 30%.
Wait 10 minutes. Then press START to
restart the mixer.
No display No power to unit Check power.

14
www.combisteel.com
Problem Possible causes Action required
Mixer is noisy
Mixer is not installed on level
surface.
Adjust surface or relocate the mixer.
Make sure rubber feet are installed.
Bowl not seated correctly or clamps
not in place.
Make sure bowl is seated into bowl
cradle correctly and bowl clamps are
locked into place.
Agitator not fitted properly.
Remove and attach agitator into
position correctly.
Overloading bowl.
Reduce batch size. Refer to Capacity
Chart section.
Damaged or worn part. Contact a technician to replace part.
Safety guard seized
(will not move freely)
Clean and lubricate slide sheath.
Technician must drop down planetary
assembly to access mat and sheath.
Agitators won’t go onto
the planetary shaft easily
Lack of lubrication and/or cleaning of
the planetary shaft.
Wipe planetary shaft with a clean damp
cloth and lubricate the shaft with
mineral oil or food quality grease.
Mixing time is too long
Batch size is too small. Increase batch size.
Incorrect recipe portions or
temperatures.
Follow portions and temperatures per
recipe instructions.
Bowl lift sticking or not
operational Lack of lubrication on bowl slides.
Lubricate bowl slides with mineral oil or
food quality grease.
Sticking, technician must clean bowl lift
mechanism.
Mixer will not mix
medium or heavy loads Belt slipping
Tighten the belt
Call a technician to replace the belt.
Motor is running, but
agitator doesn’t run
Belt broken Call a technician to replace the belt.
Agitators touching
bottom or sides of the
bowl
Defective or dented bowl Remove dents or replace the bowl
Defective agitator Replace agitator
Broken whip wires
Batch size too large for mixer. Adjust
recipe.
Reduce batch size. Refer to Capacity
Chart section. Mixture too firm, speed
too high. Reduce speed.
Hand utensil dropped into bowl
while mixing.
Stop mixer.
Broken flat beater
Ingredients too cold or too large (e.g.
frozen butter, cream cheese cut in
chunks).
Wait for ingredients to reach room
temperature before mixing. Reduce
chunk size.
Broken dough hook
Batch size too large for mixer.
Reduce batch size. Refer to Capacity
Chart section. Adjust recipe.
Ingredients too cold or too large.
Wait for ingredients to reach room
temperature before mixing. Reduce
chunk size.

15
www.combisteel.com
- BELANGRIJKE VEILIGHEIDSINSTRUCTIES -
Deze handleiding bevat belangrijke veiligheidsinstructies die strikt moeten worden
opgevolgd bij gebruik van dit apparaat.
Bewaar en gebruik deze handleiding voor toekomstige referentie.
1. Aandachtspunten voor eigenaars en gebruikers
Het apparaat zorgt voor een veilige en efficiënte voedselverwerking zolang het apparaat wordt gebruikt volgens
de instructies in deze handleiding en goed wordt onderhouden. Ernstig letsel kan zich voordoen tenzij het
bedienend personeel voldoende is opgeleid en onder toezicht staat. De eigenaar van dit apparaat is er
verantwoordelijk voor dat dit apparaat correct en veilig wordt gebruikt en dat alle instructies in deze handleiding
en lokale, staats- en/of federale wettelijke vereisten strikt worden opgevolgd.
De eigenaar mag niemand toegang geven tot dit apparaat tenzij ze 18 jaar of ouder zijn, goed zijn opgeleid en
onder toezicht staan en deze handleiding bovendien hebben gelezen en begrepen. De eigenaar moet er ook voor
zorgen dat er geen klanten, bezoekers of andere onbevoegde personen in contact komen met dit apparaat. Houd
er rekening mee dat niet kan worden voorspeld onder welke omstandigheden het apparaat zal worden gebruikt.
Het is de verantwoordelijkheid van de eigenaar en gebruiker om alert te zijn op eventuele gevaren die dit
apparaat met zich meebrengt. Als u twijfelt over een taak of de juiste manier om dit apparaat te bedienen, vraag
dan raad aan uw leidinggevende.
Deze handleiding bevat voorzorgsmaatregelen voor een veilig gebruik van dit apparaat. In de handleiding vindt
u aanvullende waarschuwingen die u op mogelijke gevaren wijzen.
Waarschuwingen die van invloed zijn op uw persoonlijke veiligheid worden aangegeven door:
Waarschuwingen met betrekking tot mogelijke schade aan het apparaat worden aangegeven door:
Op de mixers zijn verschillende waarschuwing labels in het Engels geplaatst. Als waarschuwing labels en/of
handleidingen zoekraken, beschadigd of onleesbaar zijn of als u extra exemplaren nodig hebt, neem dan
rechtstreeks contact op met uw dichtstbijzijnde vertegenwoordiger of dealer om deze items gratis aan te vragen.
Onthoud dat noch een handleiding noch een waarschuwingslabel de noodzaak kan vervangen om waakzaam te
zijn, gebruikers goed op te leiden en toezicht te houden en gezond verstand te gebruiken bij het gebruik van dit
apparaat.

16
www.combisteel.com
2. Specificaties
Model Transmissie Inhoud
kom (L)
Maximale
kneedcapaciteit
(KG)
Maximaal
meel (KG)
Vermogen
(kW)
Spanning
(V)
Frequentie
(Hz)
7534.0005
Riem + VFD
10
3,75
2,5
0,75
230
50/60
7534.0010
Riem + VFD
20
7,5
5
1
230
50/60
7534.0015
Riem + VFD
30
10,5
7
1,5
230
50/60
7534.0020
Riem + VFD
40
13,5
9
1,5
230
50/60
*VFD: Aandrijving met variabele frequentie (Variable Frequency Drive)
3. Belangrijkste onderdelen van de mixer
7534.0005 7534.0015 7534.0005/0010
7534.0010 7534.0020 7534.0015/0020
Hoofdschakelaar:
Hendel voor het optillen van de kom:

17
www.combisteel.com
4. Installatie
4.1 Uitpakken
Pak de mixer uit zodra u deze ontvangt. Als u merkt dat het apparaat beschadigd is, bewaar dan het
verpakkingsmateriaal en neem binnen vijftien (15) dagen na levering contact op met de vervoerder en neem nu
contact op met uw leverancier.
Om ernstig persoonlijk letsel te voorkomen.
•Installeer het apparaat altijd in een werkomgeving met voldoende licht en ruimte.
•Gebruik de mixer alleen op een stevige, vlakke, antislip, niet-brandbare ondergrond.
•Omzeil nooit de originele staat van dit apparaat en breng geen wijzigingen aan.
Dit is gevaarlijk en leidt tot het vervallen van de garantie.
•Gebruik de mixer nooit zonder dat alle waarschuwing labels geïnstalleerd zijn.
•Probeer de mixer NIET zelf op te tillen.
4.2 Installatie
1. Lees deze handleiding zorgvuldig door voordat u tot installatie en bediening overgaat. Als u vragen hebt of niet
alles in deze handleiding begrijpt, ga dan niet verder met de installatie en bediening. Neem contact op met uw
plaatselijke vertegenwoordiger.
2. Verwijder de banden van de doos en haal het golfkarton van de koker. OPMERKING: De mixers worden
verzonden in een houten doos; alleen de bouten aan de onderkant van de doos (alle vier de zijkanten) moeten
worden verwijderd.
3. Verwijder de mixer voorzichtig uit de koker met behulp van een 11/16” of 3/4”-sleutel.
4. Kies een locatie voor de mixer en houd daarbij rekening met het volgende:
-De vloer of het aanrecht moet vlak zijn.
-Gemakkelijke toegang voor onderhoud en reparatie.
-Vrije ruimte voor de bediening, montage en demontage van de mixer, kom of accessoires.
-Voldoende ruimte om ingrediënten toe te voegen tijdens het mixen.
-Zorg ervoor dat de ontluchting aan de achterkant van de mixer niet geblokkeerd is.
5. Er zijn minstens twee personen nodig om het apparaat te kantelen en de rubberen voetjes te installeren.
6. Controleer de mixer om er zeker van te zijn dat alle onderdelen aanwezig zijn (d.w.z. kom, mixer, roerstaaf en
deeghaak).
7. Lees de elektrische informatie op het typeplaatje aan de achterkant van het apparaat. Het ingangsvermogen
moet overeenkomen met de nominale waarde op het typeplaatje.
4.3 De voeding aansluiten
Elektrische aansluiting: Hoewel het apparaat is uitgerust met een driefasige aansluiting moet het stopcontact
waarop deze stekker wordt aangesloten, geaard zijn. Neem contact op met een elektricien als het stopcontact
een onjuist type aarding heeft. Snijd de derde aardpen van het netsnoer in geen geval door en verwijder deze
niet. Gebruik geen verlengsnoeren. Te weinig stroom kan de mixer beschadigen en/of brand veroorzaken.
Als het apparaat bedraad moet worden, laat dan een elektricien het apparaat aansluiten op de stroombron.

18
www.combisteel.com
8. Reinig de mixer vóór gebruik. Zie het hoofdstuk Reinigingsinstructies in deze handleiding.
OPMERKING: Het is normaal dat de fabriek een grote hoeveelheid vet aanbrengt aan de binnenkant en op het
apparaat. Overtollig vet (bruin) zal worden aangebracht op alle metalen oppervlakken (d.w.z. bovenkant van
trommelbeschermer, snelheidsregeling, vergrendeltrommel, trommelhefmechanisme en vleugelschroeven).
Overtollig hogedrukvet (bruinzwart) kan ook worden aangetroffen op de planetaire assen en sommige druppels
kunnen in de kom worden aangetroffen.
5. Gebruiksaanwijzing
Om ernstig persoonlijk letsel te voorkomen.
-Gebruik de mixer pas nadat u eerst de gebruikshandleiding hebt gelezen.
-Trek altijd de stekker uit het stopcontact voordat u onderdelen of accessoires reinigt, onderhoudt of aanpast.
-Houd handen, haar en kleding altijd uit de buurt van bewegende delen.
5.1 Over het spatscherm
OPMERKING: De mixer werkt niet als het spatscherm open of niet goed geïnstalleerd is.
OPMERKING: Draai het spatscherm met de klok mee (open) en tegen de klok in (gesloten) om de mixer te
bevestigen.
Open/draaiend spatscherm.
Draai het spatscherm met de klok mee (open) en tegen de klok in (dicht) zodat de gebruiker gemakkelijk
ingrediënten kan toevoegen en de klopper en kom op de juiste manier uit de mixer kan halen.
1. Wanneer de afzonderlijke handgrepen op één lijn staan en stevig naar de rechterkant van de mixer zijn geduwd,
is het spatscherm in de vergrendelde positie en klaar voor gebruik (Figuur 7-1).
2. Om het spatscherm in de open stand te plaatsen, pakt u de afzonderlijke hendels
op het spatscherm vast en brengt u ze samen, waarbij u ze met de wijzers van de
klok mee beweegt om het spatscherm te openen/draaien. Om het spatscherm te
sluiten, pakt u de afzonderlijke handgrepen vast en brengt u ze samen, waarbij u ze
tegen de wijzers van de klok in beweegt om het spatscherm terug te sluiten/draaien
naar de vergrendelde positie.
5.2 De kom aan de mixer bevestigen
OPMERKING: Installeer de kom voordat u de mixer bevestigt.
1. Laat de kom zakken door de hendel van de mengkom naar voren en naar beneden te trekken tot de rustpositie.
Voor de 60 liter en 80 liter mixer drukt u op de pijl (groene knop) om de kom te laten zakken tot deze stopt (Fig.
7-2).
2. Til de kom op met de hendel en:
a. Plaats de borgpen (die zich aan de achterkant van de kom bevindt) langzaam in het gat middenachter in de
houder (Fig. 7-3).
b. Laat de kom zakken op de pinnen aan de zijkanten van de komhouder.
3. Nadat u de kom op de standaard hebt gezet, trekt u elke klem naar voren om de kom vast te zetten totdat de
kom vastklikt (Fig. 7-4).

19
www.combisteel.com
5.3 Roerwerk aan mixer bevestigen (bv. klopper, garde, haak)
OPMERKING: Het is gemakkelijker om de mixer te installeren voordat u de
ingrediënten in de kom doet.
1. Draai het spatscherm naar links zodat het in de open stand blijft staan (Fig. 8-1).
Overmatige kracht bij het openen en sluiten van het spatscherm kan de
veersluiting en de microschakelaar van het spatscherm beschadigen, waardoor de
garantie vervalt.
2. Schuif de mixer langzaam omhoog op de planetaire as en steek de asbout door
de gleuf in het roerwerk (Fig. 8-2).
3. Draai het roerwerk met de klok mee om het vast te zetten op de planetaire as.
5.4 Ingrediënten mengen
Roerwerken van 7534.0005, 7534.0010, 7534.0015 en 7534.0020 moeten altijd met de klok mee draaien in de
kom. Als het roerwerk van 7534.0005, 7534.0010, 7534.0015 en 7534.0020 linksom draait, neem dan
onmiddellijk contact op met een erkende elektricien om onjuiste bedrading te verhelpen.
1. Voeg de juiste ingrediënten toe aan de kom.
2. Draai de hendel van de kom omhoog tot de kom vastklikt. Druk voor de BX60 en BX80 op de pijl (groene knop)
om de kom omhoog te tillen tot hij stopt. (Fig. 8-3)
3. Draai het spatscherm naar rechts tot hij vastklikt in de gesloten positie (Fig. 8-4). U hoort het op zijn plaats
klikken.
OPMERKING: De mixer start niet als het spatscherm open is of als de kom in de onderste stand staat.

20
www.combisteel.com
5.5 Snelheid instellen en wijzigen via digitaal bedieningspaneel
1. Selecteer de juiste snelheidsinstelling door de snelheidsknop te draaien, met de klok mee om de snelheid te
verhogen, tegen de klok in om de snelheid te verlagen.
OPMERKING: ALLE modellen hebben 10 variabele snelheden.
Roerwerk: Product type/Ingrediënt aanbeveling:
Haak: Gerezen donutdeeg (65% AR), pasta, basis eiernoedels, zwaar brooddeeg (55% AR), brooddeeg (60% AR),
pizzadeeg (40% AR)
Platte klopper: Wafel- of cakebeslag, aardappelpuree, fondantglazuur, platte cake, taartdeeg
Garde licht: slagroom, eiwitten, meringue
2. Druk op de groene STARTKNOP om te beginnen met mengen.
3. Om de snelheid tijdens het mengen te veranderen, druk op de PAUZE-knop en draai aan de snelheidsknop,
met de klok mee om de snelheid te verhogen, tegen de klok in om de snelheid te verlagen.
4. Als de ingrediënten goed gemengd zijn, druk dan op de rode STOPKNOP om de mixer te stoppen.
OPMERKING: Als de timer is gebruikt, stopt de mixer automatisch als de tijd is verstreken.
5. Laat de kom zakken door de hendel naar voren en omlaag te trekken tot de rustpositie. Voor de modellen
7534.0005, 7534.0010, 7534.0015 en 7534.0020 draait u het wiel voor het optillen van de kom linksom tot het
stopt.
6. Draai het spatscherm naar links zodat deze in de open positie staat.
7. Verwijder het roerwerk van de planetaire as door het omhoog te tillen en tegen de klok in te draaien totdat
het ontgrendeld is. Laat het roerwerk zakken en verwijder het van de planetaire as.
8. Duw elke komklem naar achteren om de kom te ontgrendelen van de komhouder.
9. Til de kom iets op zodat deze de pinnen op de komhouder passeert.
5.6 Vooraf ingestelde snelheid door digitaal bedieningspaneel
OPMERKING: Elk roerwerk is beschikbaar met een vooraf ingestelde snelheid.
Werking met vooraf ingestelde snelheid:
De snelheid op de mixer kan worden ingesteld van 1 tot 10. Voordat u de snelheidsmodus instelt, moet u
controleren of het spatscherm en de kom gesloten en vergrendeld zijn.
1. Stel de gewenste snelheid in. Houd de snelheidsknop 3 seconden lang ingedrukt. Op het paneel verschijnt een
lichtje in de rechterbenedenhoek van de snelheidsweergave. Na 3 seconden brandt er geen lichtje meer.
OPMERKING: Houd de SNELHEIDSKNOP ingedrukt om de gewenste minuten in te stellen.
2. Zodra de gewenste snelheid is ingesteld, controleert u of het spatscherm en de kom gesloten en vergrendeld
zijn en drukt u op START.
Werking zonder vooraf ingestelde snelheid:
Voor eenvoudig mengen zonder vooraf ingestelde snelheid moet u controleren of het spatscherm en de kom
gesloten en vergrendeld zijn.
1. Het paneel moet 00:00 weergeven om met elk roerwerk te kunnen werken. 2. Draai de SNELHEIDSKNOP tegen
de klok in tot de snelheid terug is op nul, druk op de snelheidsknop en houd deze 3 seconden ingedrukt, totdat
er geen knipperend lichtje meer is.
