Comeup DHC-3000 User manual

Heavy Duty Hoist
Model: DHC
-
3
0
0
0
PN: 751516 12V DC
751680 24V DC
Introduction
XFeature
Line lifting: 1,361 kg / 3,000 lb wire rope first layer
Wire rope: 8.3 mm × 22.9 m (21/64" × 75′) galvanized aircraft A7 × 19
Brake: Patented cone brake holds full load PLUS auxiliary inverted
current brake for a 100% & instant braking
Control: Handheld pendant switch powers the hoist
XUnpacking
．Hoist assembly…………………………………………………………… 1 pc
．Detachable control box………………………………………................ 1 pc
．Remote control…………………………………………………………… 1 pc
．Wire rope with hook……………………………………………………… 1 pc
XRead this manual carefully
You should carefully read and understand this manual before operating it.
Careless hoist operation may result in personal injury hazards or property
damage.
XInformation requesting or parts ordering
Please specify the following information:
．Hoist PN ．Part description
．Serial number ．Replacement part number
．Quantity for each part
Installation
Before using the hoist, make sure all electrical components have no corrosion
or damaged; the environment should be clear and dry.
Attach fix plates to the foot of motor/gearbox support racks securely.

XWire Rope Replacement
．Feed the end of the wire rope into No. 1 anchor hole in the
drum and wind about 1/4 wrap of rope on the drum. Insert
the wire rope into No. 2 hole and tighten the set screw
securely.
．Make sure the first layer of wire rope is tight and maintain
a freeboard at least 1.5 x rope diameter.
．Wire rope shall be wound in an under-wound orientation
only.
．To compensate for uneven spooling and the decrease in
line pull capacity as the drum fills up, use as short a wire
rope as practical.
XWiring Diagram
Attach the black lead firmly to the negative (–)battery terminal and red lead to
the positive (+) battery terminal. The voltage drop for the hoist motor must not
exceed 10% of the nominal voltage of 12/24V DC.
．Recommended battery: 650 CCA minimum for hoisting
Performance Data
Lifting Load
kg / lb
Line Speed
mpm/fpm
Amp. Draw
12/24V
Percentage Duty
Cycle %ED
No load 11.7 / 38.4 80 / 50 25%
454 / 1,000 7.6 / 24.9 165 / 100 20%
907 / 2,000 5.6 / 18.4 210 / 140 15%
1,361 / 3,000 4.3 / 14.1 250 / 170 13%

Warning
．The operator shall always work in compliance with the operating instructions.
．Overload shall be forbidden and overload protection shall be required.
．Ban on transporting persons and excessive inching shall be avoided.
．Don’t try to move obstructed loads and side-pull of load is not allowed
．The rope winding on the drum shall remain 5 wraps from the drum.
Parts List
Ver:3
Item No. Description Part No. Qty
Motor 12V 880043
1 Motor 24V 880044 1
2 Tie bar kit 881431 2
3 Motor support rack 880046 1
4 Motor coupling 880047 1
5 Drum bushing 880048 2
6 Drum kit 881439 1
7 Gearbox support rack 880050 1
8 Grounding lead 880085 1
9 Wire rope w/hook 881150 1
10 1st shaft 881433 1
11 3rd ring gear kit 880054 1
12 3rd stage carrier 880055 1
13 2nd stage carrier 880104 1
14 1st stage carrier 880107 1
15 Retaining ring 880058 1
16 1st & 2nd ring gear 880059 1
17 1st pinion kit 880060 1
18 Tap screw 881423 1
19 Gear box kit 880062 1
20 Brake base 880063 1
21 Cone brake disc kit 880021 1
22 Brake cover kit 880065 1
23 Remote control 880025 1
Detachable control box 12V 881153
24 Detachable control box 24V 881154 1
24-1 Remote socket kit 881426 1
Detachable control pack 12V 881424
24-2 Detachable control pack 24V 881425 1
25 Brake clutch base 881434 1
26 Tie bar kit 881437 2

Hoist Assembly
