Comeup CP-750T Quick start guide

Electric Winch
Model: CP-750T
PN: 157555 380V50Hz 157730 400V50Hz
157688 415V50Hz 157690 415V50Hz
Introduction
Feature
Lifting capacity: 750 kg wire rope top layer
Lifting height: 58 m
Lifting speed: 10-15 m/min at 50Hz
Brake: Electromagnetic spring-applied failsafe brake
Control: Pendant switch powers the winch
Unpacking
．Winch assembly 1pc
．Wire rope 9 mm x 60 m w/hook 1pc
．Low voltage control ass’y LV-320 1pc
．Pendant switch PB-306 w/cord 1.25 mm2
x 3C x 3 m 1pc
Read this manual carefully
You should carefully read and understand this manual before operating it.
Careless winch operation may result in personal injury hazards or property
damage.
Information requesting or parts ordering
Please specify the followings information:
．Winch PN
．Serial number
．Part description
．Replacement part number
．Quantity for each part
Installation
Before using the winch, make sure all electrical components have no
corrosion or damaged; the environment should be clear and dry.
Performance
Wiring Diagram
Winch Model CP-750T
Motor kw x p 2.2 x 4
Recommend
Wire Rope Size (mm) 9
Breaking (kg) 3,750
1st
Layer
Rated Load
(kg) 50Hz 1,188
2nd
Layer
Rated Load
(kg) 50Hz 1,036
3rd
Layer
Rated Load
(kg) 50Hz 920
Speed
(m/min) 50Hz 10 Speed (m/min) 50Hz 11.0 Speed (m/min) 50Hz 12.4
Rope-Winding Cumulating
Sum (m) 9.9 Rope-Winding
Cumulating Sum (m) 21.3 Rope-Winding
Cumulating Sum (m) 34.2
4th
Layer
Rated Load
(kg) 50Hz 826
5th
Layer
Rated Load
(kg) 50Hz 750
Speed
(m/min) 50Hz 13.8 Speed (m/min) 50Hz 15
Rope-Winding Cumulating
Sum (m) 48.5 Rope-Winding Cumulating Sum (m) 60

Warning
．The winch is not intended to be used in any manner for the movement or
lifting of personnel.
．The lifting capacity shown is based on the top layer of rope on the drum.
．The rope winding on the drum shall remain 5 wraps from the drum.
Parts List
Item No. Description Part No. Qty
1 Induction motor kit 380V 880917 1Induction motor kit 400V 882267
Induction motor kit 415V 880918
2 Motor support rack kit 881031 1
3 Drum kit 881032 1
4 Connect shaft kit 881033 1
5 Tie bar kit 881034 2
6 Gearbox support rack kit 881035 1
7 2nd stage carrier kit 880907 1
8 1st stage carrier kit 880909 1
9 Gear box kit 880910 1
10 1st shaft kit 880911 1
11 Gearbox rear cover kit 880912 1
12 Brake kit 380V 881257 1Brake kit 400V 882268
Brake kit 415V 881258
12-1 Brake disc 880919 1
12-2 Brake coil 380V 880924 1
Brake coil 400V 882269
Brake coil 415V 880925
13 Brake rear cover kit 881130 1
14 Wire rope w/hook 9 mm x 60 m 881131 1
15 Low voltage control ass’y LV-320,380V 881821 1 Low voltage control ass’y LV-320,400V 881822
Low voltage control ass’y LV-320,415V 881823
15-1 Remote control, PB-306 881048 1
16 Base plate kit 880914 1
Winch Assembly
