Comeup CWG-30151 User manual

Electric Winch
Model: CWG-30151
PN: 152085 380V50Hz 157258 415V50Hz
159685 415V50Hz
Introduction
Feature
Lifting capacity: 500 kg wire rope top layer
Lifting height: 58 m
Lifting speed: 12-18 m/min at 50Hz
Brake: Electromagnetic spring-applied failsafe brake
Control: Pendant switch powers the winch
Unpacking
．Winch assembly 1pc
．Wire rope 9 mm x 60 m w/weight hook CHW-0005 1pc
．Low voltage control ass’y LV-320 for PN:152085 157258 1pc
．Low voltage control ass’y LV-360 for PN:159685 1pc
．Pendant switch PB-306 w/cord 1.25 mm2
x 3C x 3 m 1pc
Read this manual carefully
You should carefully read and understand this manual carefully before
operating it. Careless winch operation may result in personal injury hazards
or property damage.
Information requesting or parts ordering
Please specify the followings information:
．Winch PN
．Serial number
．Part description
．Replacement part number
．Quantity for each part
Installation
Before using the winch, make sure all electrical components have no
corrosion or damaged; the environment should be clear and dry.
Performance
Wiring Diagram
Winch Model CWG-30151
Motor kw x p 1.5 x 4
Recommend
Wire Rope Size(mm) 9
Breaking (kg) 3,750
1st
Layer
Rated Load
(kg) 50Hz 742
2nd
Layer
Rated Load
(kg) 50Hz 662
3rd
Layer
Rated Load
(kg) 50Hz 597
Speed
(m/min) 50Hz 12 Speed (m/min) 50Hz 13.3 Speed (m/min) 50Hz 14.8
Rope-Winding Cumulating
Sum
(
m
)
12 Rope-Winding Cumulating
Sum
(
m
)
26 Rope-Winding
Cumulatin
g
Sum
(
m
)
40
4th
Layer
Rated Load
(kg) 50Hz 544
5th
Layer
Rated Load
(kg) 50Hz 500
Speed
(m/min) 50Hz 16.2 Speed (m/min) 50Hz 18
Rope-Winding Cumulating
Sum
(
m
)
57 Rope-Winding Cumulating
Sum
(
m
)
60

Warning
．The winch is not intended to be used in any manner for the movement or
lifting of personnel.
．The lifting capacity shown is based on the top layer of rope on the drum.
．The rope winding on the drum shall remain 5 wraps from the drum.
Parts List
Item No. Description Part No. Qty
1 Induction motor kit ,380V 880827 1
Induction motor kit ,415V 880828 1
2 Low voltage control ass’y LV-320 for PN:152085 881714 1Low voltage control ass’y LV-320 for PN:157258 881716
Low voltage control ass’y LV-360 for PN:159685 881717
2-1 Remote control, PB-306 for PN:152085 881710 1
Remote control, PB-306 881048
3 Motor support rack kit 880806 1
4 Drum kit 880807 1
5 Connect shaft kit 880808 1
6 Gearbox support rack kit 880809 1
7 2nd stage carrier kit 881663 1
8 1st stage carrier kit 881664 1
9 Gear box kit 880814 1
10 1st shaft kit 880815 1
11 Gearbox rear cover kit 880816 1
12 Brake base 880817 1
13 Brake disc 880818 1
14 Brake panel 880819 1
15 Brake kit DC200V 882220 1
15-1 Brake disc 882046 1
15-2 Brake coil DC200V 882221 1
17 Brake cover kit 880822 1
18 Wire rope w/weight hook 880823 1
19 Base plate kit for PN:152085 881719 1Base plate kit for PN:157258 881720
Base plate kit for PN:159685 881721
Winch Assembly
