COMPOUND CCB-MSB-K81 User manual

.
Owner’s Manual
CCB-MSB-K81
Caliber BLK –Magnetic Spin Bike
Zwift & Kinomap
with 18.5” HD Screen

2

3
ATTENTION:
Read instructions carefully, failure to do so may cause permanent damage to your body.
Please verify that all parts associated with this product are in good condition and accounted for.
During the assembly process please be sure to follow each step accordingly as it has been
explained within the manual.

4
SAFETY INFORMATION:
1. Keep children and pets away from this equipment at all times. DO NOT leave them
unsupervised in the room where the machine is kept.
2. If you experience dizziness, nausea, chest pains or any other symptom while using
this machine STOP the exercise. SEEK IMMEDIATE MEDICALATTENTION!
3. Keep your hands away from any of the joints and moving parts.
4. Wear clothing suitable for doing exercise. Do not wear baggy clothing that might get
caught in the machine. Always wear athletic shoes when using the machine and tie
the laces securely.
5. This machine must only be used for the purposes described in this manual. DO NOT
use accessories that are not recommended.
6. Do not place sharp objects near the machine.
7. Any person with physical or coordination limitations should not use the machine
without the assistance of a qualified per son or doctor.
8. Do not use the machine if it is not working correctly.
9. Before using the machine, thoroughly inspect the equipment for proper assembly.
10. Use only authorized and trained technicians if a repair is needed.
11. Use only the tools provided to assemble this machine.
12. This machine can only be used by one person at a time.
13. The moving pedals can cause injury.
Caution: Consult your doctor before beginning to use the machine or any exercise
program. Read all of the instructions before using any exercise equipment.
KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.

5
CAUTION: During assembly it is recommended that all bolts be tightened by hand,
upon completing assembly, bolts should then be properly secured using the wrench. To
avoid injury, check bolts carefully before use.
Assembly Drawing
STEP 1
Attach the front foot tube (35) first by lifting
up the front of the frame and sliding the front
foot tube (35) under the frame. Align the
holes of the foot tube and frame then insert
bolt (30) from below, Secure the bolt with
washer (28) and nut (27) by the wrench.
Make sure it is fixed securely.
Use the same procedure to install the rear
foot tube (31).
