COMPOUND PLATINUM Series User manual

SKU: CPL-CHP-1092
ASSEMBLY INSTRUCTIONS
CHEST PRESS PIN LOADED MACHINE
PLATINUM SERIES
COMPOUND.
FITNESS EQUIPMENT
CAUTION: Read all precautions and instructions before
using this equipment. Save this manual for future reference.
OWNER’S MANUAL
CAUTION: Read all precautions and instructions before using
this equipment. Save this manual for future reference.
CPL-CHP-1092
CHEST PRESS PIN LOADED

01
CONTENTS
02 General warnings and maintenance advice
10 snoitcurtsnIylbmessA03-
Explained as a series of steps,with each step containing:
Pictures,descriptions and quantities of the parts required
Notes
Diagram showing how the parts fit together
tsiLtraP11
●
●
●

Assembly Instructions
02
This exercise equipment is built for optimum safety. Be sure to read the entire
manual before you assemble or operate your equipment. Please note the
following safety precautions:
1. Keep children and pets away from the equipment at all times. Do not leave
children unattended in the same room with the equipment.
2. Only one person at a time should use the equipment.
3. If the user experiences dizziness, nausea, chest pain, or any other abnormal
symptoms STOP the workout at once CONSULT A PHYSICIAN IMMEDIATELY.
4. Position the equipment on a clear, level surface. DO NOT use the equipment
near water or outdoors.
5. Keep hands away from all moving parts.
6. Always wear appropriate workout clothing when exercising. DO NOT wear
robes or other clothing that could become caught in the equipment.
7. Use the equipment only for its intended use as described in this manual.
DO NOT use attachments not recommended by the manufacturer.
8. Before using the equipment, always do stretching exercises to properly
warm up.
9. Never operate the equipment if the equipment is not functioning properly.
Before Your Begin

03
STEP 1
SC10-24
W10
1 42 3SC10-18
W10
SC10-18
W10
SC10-14
W10
5
SC10-24
W10
INFORMATION
We recommend you have someone assist you in lifting and assembling your gym. Follow these steps carefully and it will make it easier to assemble your gym.
● ●

04
STEP 2
B
A
The Dimension B is longer
than the Dimension A.
6
SC6-4
W6
SC8-6
7
8
9
10
11
12
13
14 15
NOTE 1:
NOTE 2: If the movement of the weight stack is not smooth during exercising,
please lubricate the guide rods.
please clean the weight plates Before sticking the weight labels , and
avoid touching the adhesive of the sticker.

05
STEP 3
16
17
18
CH5-4
SC10-4
W10

06
STEP 4
19
19
FN12
21
4050mm
22
19
20
FN12
11

07
STEP 5
SC10-9
W10 SC10-9
W10
SC10-8
W10
19 19 20
FN12
SC10-10
W10
N10
W10
22
FN12
21
A10-9
W10
19

08
STEP 6
SC8-6
W8
SC8-6
W8
23
24
25
26

09
STEP 7
H6-4
W6
C5-4
C5-4
H6-4
W6
27
28
29
30
31
32
NOTE: After assembling the equipment, please check and tighten all the fasteners including the screws on the handle.

10
PREASSEMBLED STEP
1
33
34
35
37
SC8-3
W8
A10-4
H10-4
H6-4
W6
4
11
12
13
14
16
44
17
18
CH5-4
H10-4
36
23
40
39
CH5-4
A10-4
W10
S5-1
36
38
23 41
H8-4
42
43
37 45
46
8
48
49
50
51
52
54
47
53

11
PARTS LIST
PART DESCRIPTION QTY PART DESCRIPTION QTY
1 Weight Stack Frame
Bottom Connection Tube
L Support Tube
Seat Frame
L Connection Tube
U Plate
Rod Retainer
Retaining Ring D25
Guide Rod
Weight Pin
Top Weight Plate
Weight Plate 5 Kg
Weight Plate 7.5 Kg
Weight Label
Rubber Ring
Back Rest Frame
Swinging Arm
Seat
Pulley D114
Joint Bearing
Cable 4050mm
Pulley D89
Hole Cap D25
Head Pad
Back Pad
Seat Pad
Back Lower Shield
Front Lower Shield 1
Front Lower Shield 2
Front Upper Shield
Back Upper Shield
Back Lower Shield
FE Tube Cap 50×100
Clamp Plate
Plate 8×50×100
L Rubber Foot
1
1
1
1
1
4
2
4
2
1
1
1
14
1
2
1
1
1
5
1
1
1
9
1
1
1
1
1
1
1
1
1
6
1
4
Rubber Pad 50×100
Upper Lateral Tube
Pull Pin
Spring
Knob
Outer Tube Bushing
Inner Tube Bushing
FE Tube Cap 40 × 80
Shaft D25 × 380
Bearing 6205
Weight Plate Bushing
2
1
1
1
1
3
1
3
1
2
30
1
48 Hand Grip
FE Tube Cap 40 × 70
Retaining Ring D32
Aluminium Bushing
Elastic Pin
C Ring
Rubber Ring
2
2
2
4
2
1
2
2 49
3 50
4 51
5 52
6 53
7 54
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
S5-1 Socket Set Screw M5X4 4
S8-6 Socket Set Screw M8X30 4
C5-4 Countersunk Head Screw M5X10 2
A10-4 Allen Bolt M10X20 4
A10-9 Allen Bolt M10X45 1
SC8-6 Socket Cap Screw M8X30 9
SC8-3 Socket Cap Screw M8X15 4
SC10-4 Socket Cap Screw M10X20 6
SC10-8 Socket Cap Screw M10X40 1
SC10-9 Socket Cap Screw M10X45 4
SC10-10 Socket Cap Screw M10X50 1
SC10-14 Socket Cap Screw M10X70 2
SC10-18 Socket Cap Screw M10X90 4
SC10-24 Socket Cap Screw M10X120 6
FN12 Flange Nut M12 2
H6-4 Hex Head Bolt M6X10 28
H8-4 Hex Head Bolt M10X25 2
W6 Washer Φ6 20
W6B Big Washer 6 9
W8 Washer 8 13
W10 Washer 10 41
N10 Nut M 10 19
