Cosel PCA Series User manual

PCA-1
Feature
Low profile (41mm, 1.61 inch = meet to 1U height)
Universal input 85 - 264VAC
(Refer to “Derating”, when using at 85 - 90VAC)
DC input 88 - 370VDC possible : Excluding PCA1000F
(Refer to “Derating”, when using at 88 - 110VDC)
For medical electric equipment
(ANSI/AAMI ES60601-1, EN60601-1 3rd)
Medical Isolation Grade 2MOPP
With AUX output 12V 0.1A (Voltage variable range 5 - 12V)
Constant current regulation
Output voltage can be varied to near 0V (Refer to item 2.6)
With various alarms
Parallel Operation / N+1 Parallel Redundancy Operation possible
Monitoring function by communication and various setting
values can be changed (Refer to item 2.11)
Safety agency approval
-UL62368-1, C-UL (CSA62368-1), EN62368-1,
ANSI/AAMI ES60601-1, EN60601-1 3rd
Up to 5-year warranty (Refer to Instruction Manual)
CE marking
Low Voltage Directive
RoHS Directive
EMI
-PCA300F, PCA600F
Complies with FCC-B, CISPR32-B, EN55011-B, EN55032-B,
VCCI-B
-PCA1000F
Complies with FCC-A, CISPR32-A, EN55011-A, EN55032-A,
VCCI-A
EMS Compliance : EN61204-3, EN61000-6-2
IEC60601-1-2 (2014), EN60601-1-2 (2015)
EN61000-4-2
EN61000-4-3
EN61000-4-4
EN61000-4-5
EN61000-4-6
EN61000-4-8
EN61000-4-11
AC-DC Power Supplies Enclosed Type
Power
Factor
Correction
World wide Safety
Approvals
EMI Inrush
current
limiting
OCP OVP Remote
ON/OFF
Parallel
Operation
1U
PCA-series
Medical
electric
equipment
PCA1000FPCA300F PCA600F
July 16, 2020

PCA-2
PCA300F
AC-DC Power Supplies Enclosed Type
PC A 300 F -5 -O
Ordering information
1Series name
2Single output
3Output wattage
4Universal input
5Output voltage
6Optional *7
C :with Coating
G : Low leakage current
T : T
erminal Block Style
I :with PMBus interface
F2 : Reverse air exhaust type
P3 : Master-slave Operation
W1 :Alarm function
For option details, refer to
instruction manual 6.1.
R
1 2 3 4 5 6
Example recommended EMI/EMC filter
NAC-06-472
High voltage pulse noise type : NAP series
Low leakage current type : NAM series
* A higher current rating EMI/EMC filter
may be recommended in view of the
other devices that could be connected
in parallel with the power supply.
*Make sure necessary tests will be carried out on your end equipment with the power supply installed in accordance with any required EMC/EMI regulations.
Terminal Block Style
2MOPP
MODEL PCA300F-5 PCA300F-12 PCA300F-15 PCA300F-24 PCA300F-32 PCA300F-48
MAX OUTPUT WATTAGE[W] 300 324 330 336 320 336
DC OUTPUT 5V 60A 12V 27A 15V 22A 24V 14A 32V 10A 48V 7A
SPECIFICATIONS
MODEL PCA300F-5 PCA300F-12 PCA300F-15 PCA300F-24 PCA300F-32 PCA300F-48
INPUT
VOLTAGE [VAC] 85 - 264 1f
[VDC]
*1
88 - 370
CURRENT[A]
ACIN 100V 3.8typ
ACIN 230V 1.6typ
FREQUENCY[Hz] 50/60 (45 - 66)
EFFICIENCY[%]
ACIN 100V
(Io=50%) 86typ 87typ 87typ 88typ 88typ 88typ
(Io=100%) 87typ 88typ 88typ 89typ 89typ 89typ
ACIN 230V
(Io=50%) 87typ 88typ 88typ 89typ 89typ 89typ
(Io=100%) 89typ 90typ 90typ 91typ 91typ 91typ
POWER FACTOR
ACIN 100V 0.98typ (Io=100%)
ACIN 230V 0.95typ (Io=100%)
INRUSH CURRENT[A]
ACIN 100V
*2
20/40 typ (Io=100%) (Primary inrush current / Secondary inrush current) (More than 3 sec. to re-start)
ACIN 230V
*2
40/40 typ (Io=100%) (Primary inrush current / Secondary inrush current) (More than 3 sec. to re-start)
LEAKAGE CURRENT[mA] 0.5max (ACIN 240V 60Hz, Io=100%, According to IEC60601-1)
OUTPUT
VOLTAGE[V] 5 12 15 24 32 48
CURRENT[A] 60 27 22 14 10 7
LINE REGULATION[mV] 20max 48max 60max 96max 128max 192max
LOAD REGULATION[mV] 40max 100max 120max 150max 150max 480max
RIPPLE[mVp-p]
0 to +50C
*3*4
160max 240max 240max 240max 320max 480max
-20 to 0C
*3
280max 320max 320max 320max 420max 640max
RIPPLE NOISE[mVp-p]
0 to +50C
*3*4
240max 300max 300max 300max 400max 600max
-20 to 0C
*3
320max 360max 360max 360max 480max 720max
TEMPERATURE REGULATION[mV]
0 to +50C
*4
50max 120max 150max 240max 320max 480max
-20 to +50C
*4
75max 180max 180max 290max 400max 600max
DRIFT[mV]
* 5
20max 48max 60max 96max 128max 192max
START-UP TIME[ms] 700typ (ACIN 100/230V Io=100%)
HOLD-UP TIME[ms] 20typ (ACIN 230V Io=80%) / 16typ (ACIN 230V Io=100%)
OUTPUT VOLTAGE ADJUSTMENT RANGE[V] 3.00 to 6.00 7.20 to 14.40 9.00 to 18.00 14.40 to 28.80 19.20 to 38.40 28.80 to 57.60
OUTPUT VOLTAGE SETTING[V] 5.00 to 5.05 12.00 to 12.12 15.00 to 15.15 24.00 to 24.24 32.00 to 32.32 48.00 to 48.48
PROTECTION
CIRCUIT AND
OTHERS
OVERCURRENT PROTECTION Works over 105% of rating (Recovers automatically, Hiccup overcurrent)
OVERVOLTAGE PROTECTION[V] 6.25 to 7.00 15.00 to 16.80 18.75 to 21.00 30.00 to 33.60 40.00 to 44.80 60.00 to 67.20
REMOTE SENSING Provided
REMOTE ON/OFF (RC) Provided
DC_OK LAMP LED (Blue)
ALARM LAMP LED (Orange)
COMMUNICATION FUNCTION Provided (Extended UART)
ISOLATION
INPUT-OUTPUT AC4,000V 1minute, Cutoff current = 10mA, DC500V 50MΩmin (At Room Temperature) 2MOPP
INPUT-FG AC2,000V 1minute, Cutoff current = 10mA, DC500V 50MΩmin (At Room Temperature) 1MOPP
OUTPUT-FG AC500V 1minute, Cutoff current = 100mA, DC500V 50MΩmin (At Room Temperature)
OUTPUT - AUX-RC-PG-INFO-DS-ADDR0-ADDR1-ADDR2 AC500V 1minute, Cutoff current = 100mA, DC500V 50MΩmin (At Room Temperature)
ENVIRONMENT
OPERATING TEMP.,HUMIDITY.AND ALTITUDE -20 to +70C, 20 - 90%RH (Non condensing)
STORAGE TEMP.,HUMIDITY.AND ALTITUDE -20 to +75C, 20 - 90%RH (Non condensing)
VIBRATION 10 - 55Hz 19.6m/s2(2G) 3minutes period, 60minutes each along X, Y and Z axis
IMPACT 196.1m/s2(20G) 11ms, once each X, Y and Z axis
SAFETY
AND NOISE
REGULATIONS
AGENCY APPROVALS
UL62368-1, EN62368-1, C-UL (equivalent to CAN/CSA-C22.2 No.62368-1), ANSI/AAMI ES60601-1, EN60601-1 3rd,
C-UL (equivalent to CAN/CSA-C22.2 No.60601-1), Complies with IEC60601-1-2 4th Ed.
CONDUCTED NOISE Complies with FCC Part15 classB, VCCI-B, CISPR32-B, EN55011-B, EN55032-B
HARMONIC ATTENUATOR
* 6
Complies with IEC61000-3-2 (class A)
July 16, 2020

PCA-3
Block diagram
PCA300F
Features
- Low profile (41mm, 1.61 inch = meet to 1U height)
- Universal input 85 - 264VAC
- DC input 88 - 370VDC possible
- For medical electric equipment (ANSI/AAMI ES60601-1,
EN60601-1 3rd, IEC60601-1-2 4th Ed.)
- Medical Isolation Grade 2MOPP
- With AUX output 12V 0.1A (Voltage variable range 5 - 12V)
- Constant current regulation
- Output voltage can be varied to near 0V
(Refer to Instruction Manual item 2.6)
- With various alarms
- Parallel Operation / N+1 Parallel Redundancy Operation
possible
- Monitoring function by communication and various
setting values can be changed
(Refer to Instruction Manual item 2.11)
- Complies with SEMI F47 (Refer to Instruction Manual item2.1)
DC OUT
INRUSH
CURRENT
LIMIT
NOISE
FILTER
REGULATOR
SWITCHING
DEVICE
CONTROL
CONTROL
CONTROL
RECTIFIER
AND
FILTER
CURRENT
SENSING
THERMAL
PROTECTION
INVERTER
RECTIFIER
AND
FILTER
FAN
CURRENT
SENSING
FG
250V10A
AC(L)
250V10A
AC(N)
FUSE
AC IN
85 - 264V
±S
(Remote sensing)
PG
(Alarm)
CB
(Current balance)
DS
(Data Shared signal)
VTRM
(Adjustment of output voltage)
ITRM
(Adjustment of output current)
INFO
(Extended UART)
RC
(Remote ON/OFF)
OVER
VOLTAGE
PROTECTION
RECTIFIER
AUX
(12V0.1A)
INTERNAL
REGULATOR
TRANSFORMER
TRANSFORMER
Photocoupler
Photocoupler
Photocoupler
Photocoupler
SPECIFICATIONS
OTHERS CASE SIZE/WEIGHT 89X41X152mm [3.50X1.61X5.98 inches] (without terminal block and screw) (WXHXD) / 840g max
COOLING METHOD Forced cooling (internal fan)
*1DC input safety agency approvals deleted.
*2
The value is primary surge. The current of input surge to a built-in EMI/EMS Filter(0.2ms or
less) is excluded.
*3
Measured by 20MHz oscilloscope or Ripple-Noise meter (equivalent to KEISOKU-
GIKEN:RM103). Please refer to the instruction manual 1.2.
*4
5V output product, the maximum temperature of 40C.
*5
Drift is the change in DC output for an eight hours period after a half-hour warm-up at 25C.
*6
Please contact us about another class.
*7
The listed options may affect the published standard specifications. Please contact us for
detailed product specifications and safety approvals.
*
A sound may occur from power supply at pulse loading.
July 16, 2020

PCA-4
AC(L)
AC(N)
CN1
LED(Alarm) Orange
LED(DC OK) Blue
Output voltage
adjustable
potentiometer
Output
terminal(+)
Output
terminal(-)
CN3
CN4
CN2
FG
12.85
33.6
[1.32]
[0.51]
10.3
[0.41]
10
[0.39]
57.5
[2.26]
2-M4 (Depth:6mm max)
Mounting Hole
[0.51]
13
[0.63]
16
[0.57]
14.5
[0.57]
14.5
[0.28]
7
[0.28]
7
[0.81]
20.5
[0.28]
[2.99]
76±0.5
[1.54]
39
7
2-M3
[0.33]
2-f8.5
2-M4 (Depth:6mm max)
Mounting Hole
[0.16]
4
[0.16]
4
[1.61]
41
[0.81]
20.5
[0.94]
24
[0.94]
24
[2.99]
76±0.5
[1.54]
39
M4
M4
Terminal cover Name plate 2-M4 (Depth:6mm max)
Mounting Hole (Bottom side)
[0.10]
[3.50]
89
[1.75]
44.5
[2.54]
64.5
[0.65]
16.5
[2.31]
58.75
[0.61]
15.5
2.5
[0.34]
8.6
[0.79]
20max
[5.98]
152
[3.43]
87±0.5
[1.38]
35
[1.28]
32.5
[0.57]
14.5
[0.35]
9
AIR FLOW
External view
PCA300F
<PCA300F-O(Bus Bar Style) >
¶Tolerance : ±1 [±0.04]
¶Weight : 840g max
¶PCB Material / thickness : FR-4 / 1.6mm [0.06]
¶Chassis Material : Aluminum
¶Fan cover Material : PBT
¶Dimensions in mm, [ ] = inches
¶Mounting torque : 1.2N-m max
¶Input and output terminal screw tightening torque
M3 0.6N-m max
M4 1.6N-m max
¶Please connect safety ground to FG terminal on the unit.
