Craftex CT188 User manual

CT188
6" BUFFER
User Manual
Version 1.0

2
TABLE OF CONTENTS
General Safety Instructions..................................................................................... 3
Specific Safety Instructions..................................................................................... 4
CT188 Features...................................................................................................... 5
Physical Features ................................................................................................... 6
Unpacking............................................................................................................... 7
Proper Grounding ................................................................................................... 7
Mounting on A Workbench...................................................................................... 8
Installing Buffing Wheels......................................................................................... 9
Test Run................................................................................................................. 9
Operation................................................................................................................10
Buffing Tips.............................................................................................................10
Maintenance ...........................................................................................................11
Cleaning..................................................................................................................11
Parts Diagram.........................................................................................................12
Parts List.................................................................................................................13
Warranty.................................................................................................................14

3
GENERAL SAFETY INSTRUCTIONS
FOR MACHINES
Extreme caution should be used when operating all power tools. Know your power
tool, be familiar with its operation, read through the user manual and practice safe
usage procedures at all times.
ALWAYS read and understand the
user manual before operating the
machine.
CONNECT your machine ONLY to the
matched and specific power source.
ALWAYS wear safety glasses
respirators, hearing protection and
safety shoes, when operating your
machine.
DO NOT wear loose clothing or
jewelry when operating your machine.
A SAFE ENVIRONMENT is
important. Keep the area free of dust,
dirt and other debris in the immediate
vicinity of your machine.
BE ALERT! DO NOT use prescription
or other drugs that may affect your
ability or judgment to safely use your
machine.
DISCONNECT the power source when
changing drill bits, hollow chisels,
router bits, shaper heads, blades,
knives or making other adjustments or
repairs.
NEVER leave a tool unattended while it
is in operation.
NEVER reach over the table when the
tool is in operation.
ALWAYS keep blades, knives and bits
sharpened and properly aligned.
ALL OPERATIONS MUST BE
performed with the guards in place to
ensure safety.
ALWAYS use push sticks and feather
boards to safely feed your work through
the machine and clamp the work-piece
(when necessary) to prevent the work-
piece from any unexpected movement.
ALWAYS make sure that any tools used
for adjustments are removed before
operating the machine.
ALWAYS keep the bystanders safely
away while the machine is in operation.
NEVER attempt to remove jammed
cutoff pieces until the saw blade has
come to a full stop.

4
Read and follow all the instructions
and safety precautions in the user
manual before setup or use.
For the protection of your eyes, always
wear safety glasses, goggles or face
shield while operating the buffer.
Make sure to secure the buffer
properly to a workbench. An
unsecured buffer may become out of
control while operation.
If you can not hold small work-pieces
securely while buffing, use clamps or
other tools to hold them.
Do not stand directly in front of the
buffer while turning it ON or while
buffing. Do not buff the work-piece at
the rear of the buffer.
Do not wear loose clothing, neckties,
jewelry or gloves that can get caught
in moving parts. Confine long hair and
keep sleeves above the elbow.
Make sure before making any
adjustments, the switch is in the “OFF”
position and the cord is un-plugged
from the power source.
Always inspect the work-piece before
buffing. Do not buff pieces with loose
knots, large splinters, sharp edges,
knives or other potentially dangerous
objects that may be grabbed by the
buffing wheel and thrown at the
operator.
Always allow the buffer to reach full
speed before feeding the work-piece.
Slowly feed the work-piece into the
buffing wheel, holding it in front of and
slightly below the wheel center. Do not
position the work-piece on the top or
sides of the buffing wheel and do not
place an edge or corner of the work-
piece against the buffing wheel.
Do not touch the buffing wheel while
operation. Abrasive accessories can
remove skin very fast. Hold the work-
piece securely and position your fingers
at a safe distance from the buffing
wheel. Do not wear gloves, it may get
caught in the wheel.
Make sure you have read and
understood all the safety instructions in
the manual and you are familiar with
your buffer, before operating it. If you fail
to do so, serious injury could occur.
CT188 – BUFFER
SPECIFIC SAFETY INSTRUCTIONS
WARNING!
The safety instructions given above can not be complete because the environment in
every shop is different. Always consider safety first as it applies to your individual
working conditions.

5
MODEL CT188 - 6" BUFFER
As part of the growing line of Craftex woodworking equipment, we are proud to offer the CT188
a 6" Buffer. By following the instructions and procedures laid out in this user manual, you will
receive years of excellent service and satisfaction. The CT188 is a professional tool and like all
power tools, proper care and safety procedures should be adhered to.
Motor......................................................................................3/4 HP
Voltage...................................................................................120
Amperage...............................................................................4.8
Hertz.......................................................................................60
Phase.....................................................................................Single
RPM.......................................................................................3450
Wheel Diameter .....................................................................6"
Bore........................................................................................1/2"
Direction of Rotation of the Wheel (from left side)..................Clockwise
Weight....................................................................................9 Kgs
CT188 – 6" BUFFER
FEATURES

6
PHYSICAL FEATURES
Right
Buffing Wheel
Outer
Wheel Flange
ON/OFF
Switch
Left
Buffing Wheel
Mounting
Hole
Spacer
Inner
Wheel Flange
Arbor Nut
Base
Shaft

7
UNPACKING
The machine is properly packaged and
shipped in a carton for safe transportation.
When unpacking, carefully inspect the
carton and ensure that it has not been
damaged during transit. Open the carton
and check that the machine and the parts
are in good condition.
PROPER GROUNDING
Grounding provides a path of least
resistance for electric current to reduce the
risk of electric shock.
Make sure the cord is plugged into a
properly installed and grounded power
outlet. To prevent electrical hazards, have a
qualified electrician ensure that the line is
properly wired.
Make sure that the buffer is connected to
an outlet having the same configuration as
the plug. If an adaptor plug is used, it must
be attached to the metal screw of the
receptacle.
Figure-1 120-volts outlet for CT188
It is recommended not to use extension
cords with your CT188. Always try to
position your machine close to the power
source so that you do not need to use
extension cords.
WARNING!
Improper connection of the equipment-
grounding conductor can result in a risk
of electric shock. Check with a qualified
electrician if you are in doubt as to
whether the outlet is properly grounded.

8
MOUNTING ON A
WORKBENCH
The CT188 features two pre-drilled holes
on its base which allow mounting the buffer
to the workbench.
There are two ways to mount the buffer
onto the workbench; through mount and
direct mount.
"Through Mount" is the strongest mounting
option where the holes are drilled all the
way through the workbench. Hex bolts,
washers and hex nuts are used to secure
the buffer to the workbench. See figure-2.
Figure-2 Through Mount
"Direct Mount" is to simply secure the buffer
to the workbench using lag screws. See
figure-3.
Figure-3 Direct Mount

9
INSTALLING BUFFING
WHEELS
To install the buffing wheels on the CT188:
Make sure the cord is disconnected from
the power source.
Remove the arbor nut.
Install spacers on the shaft (spacers are not
needed when mounting several wheels on
the shaft).
Slide the inner wheel flange onto the shaft.
Slide the buffing wheel on to the shaft and
butt it against the inner wheel flange.
Slide the outer wheel flange and butt the
flat side of the flange against the buffing
wheel.
Tighten the arbor nut on to the shaft. Make
sure the buffing wheel is firmly held in place
and the hex nut is snug against the outer
wheel flange. Use additional spacers (not
supplied) if required.
Figure-4 Installing the buffing wheel
Install the second buffing wheel on the
other side of the buffer in the same manner.
TEST RUN
Once you have mounted your machine, it is
then time for a test run to make sure that
the machine works properly and is ready for
operation.
During the test run if there is any unusual
noise coming from the machine or the
machine vibrates excessively, shut off the
machine immediately and disconnect the
cord from the power source. Check all the
parts you have assembled, once again and
investigate to find out the problem.
To test run the machine:
Make sure you have read and understood
the safety instructions given in this manual.
Connect the cord to the power source and
turn ON the machine.
The machine should star with little or no
vibration.
Let the machine run for a few minutes and
turn it OFF.
WARNING!
Do not make any adjustments while the
machine is running. Failure to do so
could result in serious personal injury.

10
OPERATION
The buffing operation will vary depending
on the type of buffing wheel used and the
type of material to be buffed.
To operate the buffer:
Wear safety glasses for the protection of
your eyes.
Stand to the side of the buffer (out of the
way of the buffing wheels).
Turn ON the buffer and let it reach full
speed.
Select the proper polishing compound
needed for the operation and apply to the
surface of the rotating wheel.
Hold the work-piece with two hands or use
a jig if the work-piece is too small. Slowly
position the work-piece onto the buffing
wheel. Do not push a sharp edge or corner
into the buffing wheel, which could grab the
work-piece.
Move the work-piece lightly and evenly
back and forth on the edge of the buffing
wheel.
Figure-5 Area on the buffing wheel where
the work-piece should contact
BUFFING TIPS
1. Always wear safety equipments when
buffing. Wearing safety glasses for the
protection of your eyes, dust mask to
protect your lungs from microscopic
particles and leather apron.
2. Clean the work-piece thoroughly before
buffing. If the dirt on the work-piece is
cleaned using chemical or water, make
sure to dry if off using a rag before
buffing.
3. Buffing compounds should be applied in
small amounts with a wand or directly to
the work-piece. When using wax-based
polishing stick-type compounds, press it
on the wheel for a few of seconds while
the machine is running.
4. When buffing, make sure to use the
area on the wheel shown in figure-5. If
the work-piece comes in contact with
the buffing wheel outside the indicated
area, the work-piece may flip out of your
hands.
5. Do not mix two different compounds on
the same buffing wheel.
6. Keep the buffing wheels free from build-
ups. Clean the wheels with light
pressure, using a wheel rake to remove
built-up compounds and metal particles.

11
MAINTENANCE
During the life of your machine, you will
need to practice some regular maintenance
to keep your buffer in peak performance
condition.
CHECK THE BUFFER DAILY FOR:
Loose mounting bolts
Worn or damaged power cord
Loose or damaged buffing wheels.
Any other unsafe condition
CHECK THE BUFFER MONTHLY FOR:
Worn or damaged shaft bearings
Worn of damaged cord
Worn switch
CLEANING
Vacuum excess wood chips, sawdust, or
metal shavings and wipe off the remaining
dust with a dry cloth. Use a resin dissolving
cleaner if there is a resin built up.
WARNING!
Make sure the machine is turned OFF
and the cord is disconnected from the
power source before servicing and
removing/replacing any components on
the machine.

12
CT188 PARTS DIAGRAM

13
ITEM DESCRIPTION QTY
1 HEX NUT I TYPE M12 LEFT 1
2 WHEEL FLANGE 4
3 SOFT BUFFING WHEEL 1
4 SPACER 2
5 HEX NUT M5 2
6 END BELL 2
7 WAVE ELASTIC COLLAR D35 1
8 BEARING 2
9 POWER CORD & PLUG 1
10 CORD CLIP BOTTOM PLATE 1
11 PHILIPS SCREW M5X8 4
12 CORD CLIPS 1
13 SPIRAL SEWN BUFFING WHEEL 1
14 ROTOR 1
15 HEX NUT I TYPE M12 RIGHT 1
16 STATOR 1
17 PHILIPS SCREW + FLAT WASHER M5X200 2
18 TOOTHED LOCKING WASHER D4 1
19 PHILIPS SCREW + SPRING WASHER + FLAT
WASHER M4X8 2
20 POWER CORD BUSHING 1
21 SWITCH 1
22 SWITCH PLATE 1
23 BASE 1
24 HEX NUT I TYPE M8 1
25 CAPACITOR SUPPORT 1
26 CAPACITOR 1
27 PHILIPS SCREW + SPRING WASHER M6X20 2
28 BASE BOTTOM PLATE 1
29 RUBBER FOOT 4
30 PHILIPS SCREW + FLAT WASHER M4X20 4
CT188 PARTS LIST

14
WARRANTY
Craftex warrants every product to be free from defects in materials and agrees to correct such defects where
applicable. This warranty covers two years for parts and 90 days for labour (unless specified otherwise), to the
original purchaser from the date of purchase but does not apply to malfunctions arising directly or indirectly from
misuse, abuse, improper installation or assembly, negligence, accidents, repairs or alterations or lack of
maintenance. Proof of purchase is necessary.
All warranty claims are subject to inspection of such products or part thereof and Craftex reserves the right to
inspect any returned item before a refund or replacement may be issued.
This warranty shall not apply to consumable products such as blades, bits, belts, cutters, chisels, punches
etceteras.
Craftex shall in no event be liable for injuries, accidental or otherwise, death to persons or damage to property or
for incidental contingent, special or consequential damages arising from the use of our products.
RETURNS, REPAIRS AND REPLACEMENTS
To return, repair, or replace a Craftex product, you must visit the appropriate Busy Bee Tools showroom or call 1-
800-461-BUSY. Craftex is a brand of equipment that is exclusive to Busy Bee Tools.
For replacement parts directly from Busy Bee Tools, for this machine, please call 1-800-461-BUSY (2879), and
have your credit card and part number handy.
All returned merchandise will be subject to a minimum charge of 15% for re-stocking and handling with the
following qualifications.
Returns must be pre-authorized by us in writing.
We do not accept collect shipments.
Items returned for warranty purposes must be insured and shipped pre-paid to the nearest warehouse
Returns must be accompanied with a copy of your original invoice as proof of purchase. Returns must be in
an un-used condition and shipped in their original packaging a letter explaining your reason for the return.
Incurred shipping and handling charges are not refundable.
Busy Bee will repair or replace the item at our discretion and subject to our inspection.
Repaired or replaced items will be returned to you pre-paid by our choice of carriers.
Busy Bee reserves the right to refuse reimbursement or repairs or replacement if a third party without our
prior authorization has carried out repairs to the item.
Repairs made by Busy Bee are warranted for 30 days on parts and labour.
Any unforeseen repair charges will be reported to you for acceptance prior to making the repairs.
The Busy Bee Parts & Service Departments are fully equipped to do repairs on all products purchased from us
with the exception of some products that require the return to their authorized repair depots. A Busy Bee
representative will provide you with the necessary information to have this done.
For faster service it is advisable to contact the nearest Busy Bee location for parts availability prior to
bringing your product in for repairs.
CRAFTEX 2 YEARS LIMITED WARRANTY
