Craftex CX series User manual

MODEL CX06HC
6” HELICAL JOINTER USER MANUAL
Version 1

2
TABLE OF CONTENTS
General Safety Instructions................................................................................................... 3
Machine Specifications ......................................................................................................... 4
Identification………………………………………….…………………………..………............... 5
Power Supply……………………………………………………………………..………………… 6
Plug and Grounding Requirements…………………………………………..…………………... 7
Set Up……………………………………………………………………………..…………………. 8
Inventory………………………………………………………………………..……………………. 9
Locking Foot Pedal & Mounting the Jointer……………………..……………………...……….9 & 10
V –Belt……………………………………………………………………..…………………………11
Carriage Mounting Bracket……………………………………………….……………………….. 12
Assembling the Fence………………………………………………..…………………………….. 13
Cutterhead Guard………………………………………………………..…………………………..14
Power Switch Install……………………………………………..…………………………………...15
Table Control Installation……………………………………..…………………………………….. 16
Replacing Carbide Inserts……………………………………..…………………………………… 17
Operations…………………………………………………………..………………………………... 19
Stock Inspection………………………………………………………………………………………. 20
Squaring Stock & Surfacing Planing ……………………………………………………..………… 21
Edge Jointing……………………..…………………………………………………………………… 22
Bevel Cutting & Rabbet Cutting………………………….…………………………………………23 & 24
Maintenance & Service……………………………………………………………………………….. 25
Setting the Fence Stops…………………………………………………………………..……………26
Adjusting the Gibs……………………………………………………….…………..……………....... 27
Table Parts Breakdown.............................................................................................................. 32
Parts Breakdown & Parts List…….............................................................................................. 33
Warranty…….............................................................................................................................. 38

3
GENERAL SAFETY INSTRUCTIONS
Extreme caution should be used when operating all power tools. Know your power tool, be familiar with
its operation, read through the owner’s manual and practice safe usage procedures at all times
ALWAYS read and understand the
user manual before operating the
machine.
CONNECT your machine ONLY to the
matched and specific power source.
ALWAYS wear safety glasses
respirators, hearing protection and
safety shoes, when operating your
machine.
DO NOT wear loose clothing or
jewelry when operating your machine.
A SAFE ENVIRONMENT is
important. Keep the area free of dust,
dirt and other debris in the immediate
vicinity of your machine.
BE ALERT! DO NOT use prescription
or other drugs that may affect your
ability or judgment to safely use your
machine.
DISCONNECT the power source when
changing drill bits, hollow chisels,
router bits, shaper heads, blades, knives
or making other adjustments or repairs.
NEVER leave a tool unattended
while it is in operation.
NEVER reach over the table when
the tool is in operation.
ALWAYS keep blades, knives and
bits sharpened and properly aligned.
ALL OPERATIONS MUST BE
performed with the guards in place to
ensure safety.
ALWAYS use push sticks and
feather boards to safely feed your work
through the machine.
ALWAYS make sure that any tools
used for adjustments are removed
before operating the machine.
ALWAYS keep bystanders safely
away while the machine is in operation.
WARNING!
The safety instructions given above cannot be complete because the environment in every shop
is different. Always consider safety first as it applies to your individual working conditions.
The safety instructions given above can not be complete because the environment in
every shop is different. Always consider safety first as it applies to your individual
working conditions.

4
CX06HC
MACHINE SPECIFICATIONS
Table Size……………………………………….….………………………………………………………6” W x 46” L
Table Height...........................................................................................................32-1/2”
Overall length……………………………….….…………………….………………………………………………..46”
Overall Width……………………………..………………….………………………………………………….27-1/2”
Shipping weight……………….………….……………….……………………………………………………….80 kg
Net Weight………………………………….……………….……………………………………………………….74 kg
Box 1 Size…………………………….…….………………….………………………………….48-1/2” x 21” x15”
Box 2 Size………………………………….….……………….……………………20-1/2” x 15-3/4” x 28-3/4”
Foot Print…………………………………..…………………….……………………………………….18” x 13-1/2”
Maximum Depth of cut…………………..…………………………………………………………….………..1/8”
Maximum Width of Cut……………………..………………………………………............……………………6”
Cutterhead Diameter…………………………..………………………………………………………………2-1/2”
Cutterhead Speed……………………………………………………………………...………………….4800 RPM
Cuts Per Minute……………………………………………………………………………………………………14400
Tables……………………………..…………Independently Adjustable, Precision Ground Cast Iron
Stand……………………………………………………………………………………………………Preformed Steel
Ways………………………………………………………………………………………….Dovetailed, Adjustable
Fence Assembly………………………………….………………………………………………………….. Cast Iron
Body Assembly…………………………………………..…………………………………………………… Cast iron
Base……………………………………………….…………………………………………One Piece Steel Cabinet
Cutterhead…………………..………………………………………………………………………………..……Helical
Number of Inserts………………………………………………………………………………………………………32
Guard……………………………………………………………………………………………………..Die Cast Metal
Bearings……………………………………………………………………….Sealed Permanently Lubricated
Motor:TypeTEFC…………………………………………………………….TEFC Capacitor Start Induction
Phase / Voltage…………………………………………………………………………………… Single –110Volt
Amps……………………………………………………………………………………………………………………….14A
Cycle / RPM…………………………………………………………………………………..60 Hertz / 3450 RPM
Power Transfer………………………………………………………………………………………….. V-Belt Drive
Bearings…………………………………………………………………….Sealed & Lubricated Ball Bearings
Fence…………………………………………….Center Mounted, Positive Stops at 45 Deg & 90 Deg
Table Movement………………………………… Hand wheel/Lever and infeed & Outfeed tables
½” Rebating Capacity Built-In
Specifications, while deemed accurate, are not guaranteed.

5
Identification
A. Outfeed table
B. Fence
C. Cutterhead Guard
D. Fence Lock
E. Fence Adjustment Knob
F. Fence Tilt Handle
G. Control Panel
H. Infeed Table
I. Infeed Table Lever
J. Locking Foot Pedal
K. Depth Scale
L. Dust Port
M. Outfeed Table Handwheel

6
POWER SUPPLY
AVAILABILITY OF POWER
Before Installation of this machine you
will need to consider the proximity of
your power supply circuit. If available
circuits do not meet the requirements for
this machine you will have to get a new
circuit installed by a licensed electrician.
Use of a licensed electrician will
minimize the risks of fire, electrocution,
damage to equipment, and will insure
everything is wired in accordance to the
applicable codes and standards.
FULL LOAD CURRENT RATING
This is the amount of Amps a machine
draws under 100% of the rated output
power.
FULL LOAD RATING FOR 120V
15AMPS
The full load current is not the maximum
amount of amps the machine will draw.
The machine has potential to draw
current beyond the full load rating if it is
overloaded. Overloading of the machine
for an extended period of time can
cause damage, overheating, or even
fire. The risk is higher if the machine is
on an undersized circuit. To help avoid
these issues insure you are connected
to a circuit that meets the specified
circuit requirements for this piece of
machinery.
WARNING!!!
Do not connect machine to power
before setup has been fully
completed to avoid risk of personal
injury or property damage.
CIRCUIT REQUIREMENTS FOR
CX06HC JOINTERS
The CX06HC has been prewired at the
factory for operation on an electrical
circuit that has a verified ground and
meets the below requirements:
Voltage: 110V –120V
Cycle: 60Hertz
Phase: Single
Circuit Breaker Size: 20Amps
Please Note:
1. An electrical circuit includes all
electrical equipment between the
breaker panel and the machine. This
is why it is important to have the
proper circuit size so it can safely
accommodate this machine under
full load for an extended period of
time.
2. The circuit requirements laid out in
this manual are for a dedicated
circuit in which only one machine will
be operational or installed at a time.

7
3. If you choose to connect to a shared
circuit where more than one
machine may be running at a time
please consult with a qualified
electrician to insure the circuit is
properly sized for safe operation.
PLUG AND GROUNDING
REQUIREMENTS
This machine must be grounded so that
in the event of certain malfunctions it will
reduce the chances of electrical shock
by providing a path of least resistance
for the electric current to travel through.
For this reason the CX06HC comes with
a cord with an equipment grounding
wire that leads in to the grounding prong
on the plug.
NOTE:
The three prong plug is only to be
plugged in to the matching receptacle
that is properly installed according to the
local electrical codes and standards.
Under no circumstances should you
modify the plug to make it fit in a
receptacle that it is not meant for this
configuration. ( see figure 1)
Figure 1
If there is an improper connection of a
machine grounding wire it may result in
a heightened risk of electric shock. If
repair or replacement of the power cord
is necessary in the future please consult
a licensed electrician.
NOTE:
If ever you notice damage or wear to
either the cord or plug disconnect it
immediately from the power supply and
have it replaced by a licensed electrician
or service tech before any further use of
the machine.
USE WITH EXTENSION CORDS
If you absolutely must require the use of
an extension cord with your machine do
so, on a temporary short term basis
only.

8
NOTE:
1. We recommend that you do not use
an extension cord with this machine.
Also the longer the extension cord the
greater the possibility of voltage drop
causing the motor to work harder under
powered which in turn will cause it to
draw more amps. This may cause the
thermal overload to trip or even the
breaker in your electrical panel. It may
also cause the extension cord to heat up
which can be a potential fire hazard.
2. If an extension cord is used with this
machine it must have a ground wire with
a plug that matches the one currently
installed on your machine. The
extension cord must also meet the
following specifications below:
Minimum Wire Gauge: 14 AWG
Maximum Cord Length: 50 ft.
SETUP
WARNING!
This machine presents a serious injury
hazard to untrained users. Read through
this entire manual to become familiar with
controls and operations before starting the
machine!
WARNING!
Always wear safety glasses during the
setup and operation of this machine!
WARNING!
This Machine weighs 80kg. DO NOT
overexert yourself while unpacking or
moving your machine. GET ASSISTANCE!
Tools Required for Setup
The tools listed below are not included with
your machine
48” Straightedge…………………………..1
Safety glasses………………………….…...1
Dust Collection System (optional)…1
4” Dust Hose (optional)…………….….1
4” Hose Clamp (optional)………….….1
Phillips Head Screwdriver……………..1
13mm Wrench………………………….…..1
17mm Wrench……………………….……..1
19mm Wrench……………………….……..1
17mm Socket Wrench……………….….1
Level……………………………………….…….1
Unpacking
This machine has been carefully packed
prior to leaving our warehouse. If you
discover the machine has been damaged
after you have signed for delivery, please
immediately call Customer Service or your
local Busy Bee Outlet.
Save all containers and packing materials
for possible inspection by the carrier or its
agent.
When completely satisfied with your
shipment you should inventory the
contents.

9
INVENTORY
Inventory
Check for the following items packed in the
two boxes you received. In the event that
any nonproprietary parts are missing (e.g. a
nut or a washer), we will replace them, or
for the sake of expediency, replacements
can be obtained at your local hardware
store.
Box 1: (Fig. A)
Qty
A. Table Assembly 1
B. Fence Carriage Assembly 1
C. Carriage Mounting Bracket 1
D. Infeed table Lever 1
E. Fence Tilt Handles 2
F. Cutterhead Guard 1
G. Push Blocks 2
H. Outfeed Table Handwheel 1
I. Fence Assembly 1
J. Knife Setting Gauge 1
Hardware & Tools
Qty
Wrenches 8/10mm & 12/14mm
1 each
Hex Keys 2.5, 3, 4, 6, & 8mm 1
each
Cap Screws M10-1.5 x 20 3
Cap Screws M10-1.5 x 25 2
Hex Bolts M10-1.5 x 55 2
Lock washers 10mm 5
Flat washers 10mm 7
Hex Nuts M10-1.5 2
Hex Bolt M8-1.25 x 50 1
Cap Screws M8-1.25 x 60 4
Cap Screws M8-1.28 x 25 4
Cap Screws M8-1.25 x 20 2
Lock Washers 8mm 8
Flat Washers 11
Phillips Head Screws M5-.8 x 15 5
Flat Washers M5 5
Figure A
Box 2: (Fig.B)
Qty
A. Cabinet 1
B. Power Switch & Support Arm 1
C. V-Belt 1
D. Locking Foot Pedal 1
E. Dust Port 1
Figure B
Locking Foot Pedal
Components & Hardware Required:
Qty
Cabinet 1
Locking Foot Pedal 1
Hex Bolts M10-1.5 x 55 2
Flat Washers 10mm 4

10
Hex Nuts M10-1.5 2
Hex Bolt M8-1.25 x 50 1
Qty
Flat Washer 8mm 1
Tools Required
Qty
17mm Wrench 1
17mm Socket Wrench 1
13mm Wrench 1
Level 1
Installing the locking foot pedal:
1. Lay the cabinet on its side as shown in
(Fig.C). Notice the 3 hole in the cross
brace.
Figure C
2. Place the locking foot pedal onto the
cross brace. See Fig D.
3. Using the 13mm wrench, install the M8-
1.28 x 50mm Hex Bolt and washer as
shown in (Fig.D) (Install the hex bolt
from the inside) from top to bottom so
it threads into the foot pedal though
the indicated holes in Fig. C.
Figure D
4. Install the two M10-1.5 x 55 Hex Bolts,
flat washers and nuts through the front
of the locking foot pedal assembly as
shown in (Fig. E)
Figure E
5. Raise the cabinet to its upright position
6. Lift the foot pedal so machine remains
stationary and can’t roll.
7. Level the cabinet front-to-back and
side-to-side by adjusting the leveling
feet.
Mounting the Jointer
Components & Hardware Required: Qty
Table Assembly 1
Cabinet 1
Cap Screws M10-1.5 x 20 3
Lock Washers 10mm 3
Flat Washers 3

11
Tools required: Qty
8mm Hex Key 1
Extra Person for Lifting Help 1
CAUTION!
The jointer is heavy. Get assistance when
lifting it in place onto the cabinet.
Mounting the jointer:
1. Remove the back cabinet cover
2. With the help of an assistant, lift the
jointer onto the cabinet
3. Align the three bolt holes on the
jointer to the three holes on the
cabinet (Fig. F)
Figure F
4. With the 8mm Hex Key, secure the
jointer to the cabinet with the M10-
1.5 x 20 cap screws, flat washers and
lock washers.
Note:
Reach through the dust vent for access to
the forward mounting hole as in (Fig. G)
Figure G
V-Belt
Components & Hardware Required:
Qty
V-Belt 1
Tools required: Qty
13mm Wrench or Socket 1
6mm Hex Key 1
Installing the V-Belt
1. With the 13mm wrench, loosen but
DO NOT remove the motor mount
bolts
2. Lift the motor upward far enough to
allow the V-belt to be placed around
the cutterhead pulley and the motor
pulley (Fig. H) and install V belt.

12
Figure H
3. Carefully allow the motor to slide
downward, tensioning the V-belt with
the weight of the motor.
4. Looking from the top, sight down the V-
belt and pulleys and check that the
pulleys are parallel and aligned with
each other. (Fig. I )
If the pulleys are aligned,
retighten the motor mount
bolts and proceed to step 7
If the pulleys are NOT aligned,
proceed to steps 5 & 6.
5. Remove the V-belt, loosen the set
screws in the motor pulley and then
align the motor pulley with the
cutterhead pulley. If needed the motor
can be loosened and moved backward
and forward slightly to bring the pulleys
into alignment.
6. Tighten the set screws and replace the
V-belt. Repeat step 4 to check the
pulley alignment, they should be
perfectly aligned (Fig. I).
7. Now replace the back access cover on
the cabinet then tighten motor
mounting bolts.
Figure I
Carriage Mounting Bracket
Components & Hardware Required:
Qty
Carriage Mounting Bracket 1
Cap Screws M8-1.25 x 60 4
Lock Washers 8mm 4
Flat Washers 4
Tools required:
Qty
6mm Hex Key 1
1. Align the locating pins on the back of
the carriage mounting bracket with the
sockets on the jointer table as shown in
(Fig. J)
Figure J

13
2. Tighten the carriage mounting
bracket to the jointer table with the
cap screws, lock washers & flat
washers supplied. (Fig. K)
Figure K
Assembling the Fence Carriage
Components & Hardware Required:
Qty
Fence Carriage Assembly 1
Cap Screws M8-1.25 x 20 2
Lock Washers 8mm 2
Flat Washers 2
Tools required:
Qty
6mm Hex Key
1
1. With the fasteners listed above,
secure the fence carriage to the
carriage mounting bracket as in (Fig.
L)
Figure L
Assembling the Fence
Components & Hardware Required:
Qty
Fence Assembly 1
Cap Screws M8-1.25 x 25 2
Lock Washers 8mm 2
Flat Washers 2
Fence Tilting Handles 2
I. Fasten the fence assembly to the
fence carriage using the M8-1.25 x
25 cap screws and washers supplied
as in (Fig. M)
Figure M
II. Thread the fence tilting handle into
the fence assembly as in (Fig. N)

14
Figure N
Cutterhead Guard
CAUTION!
The cutterhead guard is a critical safety feature
on this jointer and care must be taken in
installation. The guard has a torsion spring
mounted within it to allow it to return to its
proper position after a jointing operation. The
spring must have spring pressure during the
installation to operate correctly.
Components & Hardware Required:
Qty
Cutterhead Guard 1
Tools required:
Qty
2.5mm Hex Key 1
1. Remove the set screw from the bottom of
the cutterhead guard shaft. Fig O
Figure O
2. Place the cutter head guard into the
mounting hole on the casting of the infeed
table. Fig P. Ensuring that the cutterhead
guard shaft fits over the pin that is inside
the grey spring knob barrel (hidden from
View).
Figure P
3. Slightly raise the cutterhead guard until it is
free of the pin inside the barrel.
4. While holding the cutter guard with one
hand, turn the grey spring knob clockwise
to increase spring tension.
5. Lower the cutter head guard ensuring that
it seat over the pin in the barrel.
6. Test the return of the cutterhead guard to
ensure that it returns to it home position
and completely covers the cutterhead.
7. If the guard does not properly return to it
home position repeat from step 3 until the
guard returns to its home position and
covers the cutterhead completely.

15
Figure Q
Dust Port Installation
Components & Hardware Required:
Qty
Dust Port 1
Phillips Head Screws M5-.8 x 15 4
Flat Washers 5mm 4
Tools required:
Qty
Phillips Head Screwdriver 1
Note:
If you do not choose to use a dust collector, do
not install the dust port. Chips will build up
within the cabinet and clog.
I. Place the dust hood over the dust
vent on the cabinet and with the
four screws & washers secure it to
the cabinet (Fig. R). Then attach to
the dust collection system.
Figure R
Power Switch Install
Components & Hardware Required:
Qty
Power Switch and Support Arm 1
Cap Screws M8-1.25 x 25 2
Flat Washers 8mm 2
Tools required:
Qty
6mm Hex Key 1
I. With the M8-1.25 x 25 cap screws,
mount and secure the support arm as in
(Fig. S)
Figure S
II. Plug the power cord from the switch
box into the cord coming from the
cabinet of the jointer leading to the

16
motor. Then secure the loose cords
with the hold downs shown in (Fig. T)
Figure T
Table Controls Installation
Components & Hardware Required:
Qty
Outfeed Table Handwheel 1
Infeed Table Lever 1
Phillips Head Screws M5-.8 x 15 1
Flat Washers 5mm 1
Tools required: Qty
Phillips Head Screwdriver 1
19mm Wrench 1
1. Remove the screw & flat washer
already mounted in the outfeed
handle shaft.
2. Mount & secure the handwheel to
handwheel shaft as in (Fig.U)
Figure U
3. Thread the infeed lever into the hole as
shown in (Fig.V) then tighten the
locknut with the 19mm wrench
Figure V
Outfeed Table Height Setting
Setting Outfeed Table Height
The outfeed table height MUST be level
with the carbide inserts when they are at
top-dead-center. If the outfeed table is set
too low, the workpiece will be tapered from
front to back. If the outfeed table is set too
high, the workpiece will hit the edge of the
outfeed table during operation, increasing
the chance of kickback.

17
To set the outfeed table height:
1. DISCONNECT JOINTER FROM POWER
SUPPLY!
2. Move the cutterhead guard out of the
way or remove it, and open the rear
access panel.
3. Place a straightedge on the outfeed
table so it extends over the cutterhead
and rotate the cutterhead pulley until
one of the carbide inserts is at top-
dead-center (TDC), as shown in Figure
W.
Figure W Cutterhead insert at top-dead-
center
4. When correctly set, the carbide insert will
just touch the straightedge when the insert
is at its highest point of rotation (Figure X).
Figure X. Using a straightedge to align the
outfeed table height with insert at TDC.
—If your outfeed table is correctly set, no
adjustments are necessary.—If the insert
lifts the straightedge off the table or the
insert is below the straightedge, loosen the
outfeed table lock and adjust the outfeed
table height with the handwheel until the
straightedge just touches an insert at its
highest point of rotation.
5. Lock the outfeed table, re-install the
cutterhead guard, and close the rear access
panel.
Replacing Carbide Inserts
Tools Needed: Qty
L-Wrench Torx w/T20 Torx
Driver....................................... 1
The cutterhead is equipped with 32
indexable carbide inserts. Each insert can be
rotated to reveal any one of its four cutting
edges. Therefore, if one cutting edge
becomes dull or damaged, simply rotate it
90˚ to reveal a fresh cutting edge (Figure Y)
Figure Y
In addition, each insert has a reference dot
on one corner. As the insert is rotated, the
reference dot location can be used as an
indicator of which edges are used and
which are new. When the reference dot
revolves back around to its starting
position, the insert should be replaced.

18
To rotate or change a carbide insert:
1. Disconnect JOINTER from power!
2. Move the cutterhead guard out of the
way, or remove it.
3. Remove any sawdust from the head of
the carbide insert Torx screw.
4. Remove the Torx screw and carbide
insert.
5. Clean all dust and dirt off of the insert
and the cutterhead pocket from which
the insert was removed, and replace the
insert so a fresh, sharp edge is facing
outward. Make sure the insert is seated
in the pocket on the cutterhead.
Note:
Proper cleaning is critical to achieving a
smooth finish. Dirt or dust trapped between
the insert and cutterhead will slightly raise
the insert, and make noticeable marks on
your workpieces the next time you cut.
6. Lubricate the Torx screw threads with
light machine oil, wipe the excess oil
off the threads, and torque the Torx
screw to 48-50 inch/pounds.
Note:
Excess oil may squeeze between the insert
and cutterhead or at the bottom of the
screw hole, causing hydrostatic lock and
preventing the screw from fully tightening,
thereby lifting the insert or screw slightly
and affecting workpiece finishes. Make sure
to carefully clean off any excess oil to
prevent this from happening.
Test Run
WARNING!
Long hair, loose clothing and jewelry can
get caught up in the moving parts of
machinery and result in serious injury.
Keep Long hair and loose clothing tied up
and away from the machine. Remove
jewelry prior to use.
WARNING!
Chips and pieces of stock may be thrown
from the machine. This can cause eye
injuries, wear safety glasses at all times.
1. Before starting the machine, read
the instruction manual in its
entirety.
2. Check that the cutterhead guard has
been installed correctly
3. Remove all tools and foreign objects
from the machine.
4. Review the section Circuit
Requirements and connect to the
power source
5. Press the START button to turn on
the machine.
The jointer should run smoothly with no
vibration. Immediately stop the machine if
you suspect any problems and refer to the
trouble shooting section of this manual
before re-starting.
Recommended Adjustments
Your machine has been factory preset so
very little if any adjustments should be
necessary, however due to any unforeseen

19
problems in the shipping process we
recommend that you verify the following to
ensure the best possible results from your
machine.
I. Depth Scale calibration
II. Fence Stop Accuracy
Step by step instructions for these
adjustments can be found in the SERVICE
section of this manual
OPERATIONS
Operation Safety
WARNING!
Always wear safety glasses, a respirator,
and hearing protection when operating
this machine, damage to your eyes, lungs,
and ears may result without the proper
protective gear.
WARNING!
Long hair, loose clothing and jewelry can
get caught up in the moving parts of
machinery and result in serious injury.
Keep Long hair and loose clothing tied up
and away from the machine. Remove
jewelry prior to use.
NOTICE:
For your own safety and experience we
recommend that you seek additional
training outside of this manual. Books and
magazines are also good source materials to
gain more experience.
Infeed Table Adjustment
Before any cut the proper infeed table
adjustment must be made to safely and
efficiently use this jointer. DO NOT set the
infeed table depth greater than 1/16” on
your first pass and never greater than 1/8”
when rabbeting.
WARNING!
Beware of kickback when excessive depths
of cut are made. Limit a single pass from
1/16” to 1/8”. Serious injury could occur in
the event of kickback.
1. Loosen the infeed table lock (Fig.Z)
Figure Z
Figure AA
2. Use the infeed table lever to raise or
lower the table (Fig.AA)
3. Set the infeed table to the desired
depth of cut on the depth of cut scale
and lock the table in position

20
Note:
Adjust the infeed table stops to return the
table height to the same height every time
by loosening the lock nuts and adjusting the
set screws.
Stock Inspection
DO NOT joint or surface plane stock
that contains knots. If a knot becomes
dislodged during the cutting operation
it could cause injury to the operator and
even damage the workpiece.
Jointing or surface planing with the
grain will give a superior finish and is
safer for the operator, or feeding the
stock on the table so the grain points
down and toward you as viewed on the
edge of the stock. (See Fig.BB). Note: If
the grain changes direction along the
edge, decrease the cutting depth and
make additional passes.
Figure BB
Your jointer is designed only to cut
natural wood fiber products. DO NOT
joint MDF, particle board, plywood,
laminates or other synthetically made
materials.
Scrape all glue off the workpiece
before jointing. Glue deposits, either
hard or soft will gum up the inserts,
produce poor results and may cause
kickback.
Remove foreign objects from the
workpiece. Always check your
workpiece for foreign objects such as
nails and staples. Ensure that your
workpiece is free of dirt that may
damage the inserts. NOTE: Wood
stacked on dirt or concrete may have
small pieces of concrete or stone
embedded into the surface.
Use only dry wood when jointing or
planing. Wood with a moisture content
of over 20% can cause unnecessary
wear to the inserts, produce poor
cutting results and increase the risk of
kickback.
CAUTION:
Your workpiece must exceed the minimum
dimensions of stock shown in (Fig.31 & 32)
when edge jointing or surface planing.
Stock of smaller dimensions may break or
kickback during operations.
Figure CC
Figure DD
