Craftex CX902 User manual

CX902 (T-50)
AIR STAPLER
User Manual

2
TABLE OF CONTENTS
General Safety Instructions for Pneumatic Tools ................................................... 3
CX902 Specific Safety Instructions ........................................................................ 4
CX902 Features..................................................................................................... 5
Unpacking .............................................................................................................. 6
Inventory................................................................................................................. 6
Safety Nose Mechanism ........................................................................................ 6
Oiling the Stapler.................................................................................................... 7
Loading the Stapler................................................................................................ 7
Operating the Stapler ............................................................................................. 7
Removing the Jammed Nails.................................................................................. 8
Cleaning................................................................................................................. 8
Parts Diagram ........................................................................................................ 9
Parts List.................................................................................................................10
Warranty.................................................................................................................12

3
GENERAL SAFETY INSTRUCTIONS
FOR PNEUMATIC TOOLS
Extreme caution should be used when operating all pneumatic tools. Know your tool,
be familiar with its operation, read through the user manual and practice safe usage
procedures at all times.
Keep all guards and safety devices in
place and in working order.
Always make sure to remove all the
keys and wrenches before operation.
Always keep your work area clean and
well lighted.
Do not use the pneumatic tools in
damp or wet locations, or where
flammable or noxious fumes may
exist.
Always keep bystanders away or at a
safe distance from your work area.
Disconnect the power source when
changing drill bits, hollow chisels,
router bits, shaper heads, blades,
knives or making other adjustments or
repairs.
Never leave a tool unattended while it
is in operation.
Do not force the tool. It will do a better
and safer job at the rate for which it is
designed.
Always use the right tool. Do not attach
any part to the tool for which it is not
designed.
Always check the hose for any damage
before using the pneumatic tool.
Disconnect the tool before servicing,
changing accessories, or moving to
another location.
Always check the tool for damaged or
broken parts, loosen screws or bolts or
any other unsafe condition that may
affect the tool operation. Repair the
damaged parts before operation.
Do not overreach. Always keep proper
footing and balance.
Always use safety glasses and a dust
mask while operation.
Always keep your tool lubricated and
clean for best and safest performance.
Be alert! Do not use prescription or
other drugs that may affect your ability
or judgment to safely use your tool.

4
Read and follow all the instructions
and safety precautions in the user
manual before operation.
For the protection of your eyes, always
wear safety glasses, goggles or face
shield while operating this tool.
Do not connect the stapler to
compressed air that exceeds 120 PSI.
Never point the stapler at others.
Always carry the stapler by handle.
Make sure the air hose is good
condition and long enough to read
your work area without stretching.
Always keep bystanders away at a
safe distance while operation.
Make sure not to drive one staple on
the top of the other. The staple may
deflect and cause injury.
Do not drive fasteners close to the
edge of the work-piece as the wood
may split, allowing the fastener to be
deflected possibly causing injury.
Always disconnect the air hose before
installing staples, clearing a jam,
moving to another work area,
performing maintenance or when the
tool is not in use.
Do not use a check valve or any other
fitting that allows air to remain in the
tool. If used, the tool can remain
charged with air after disconnecting
and this will be able to drive a fastener
even after the air hose is
disconnected, possibly causing injury.
Do not connect the stapler to
pressurized oxygen or other
combustible gases as a power source.
Only use regulated compressed air.
Do not use gasoline or any other
flammable liquids to clean the stapler,
vapors in the stapler will ignite by a
spark and cause it to explode.
Always use the fasteners for which the
tool is designed.
If the stapler is leaking air, damaged or
not working properly, do not use it
before repairing.
Do not use the stapler, if you are not
sure about its indented operation.
Make sure you have read and
understood all the safety instructions
in the manual and you are familiar with
your shaper, before operating it. If you
fail to do so, serious injury could occur.
CX902 – AIR STAPLER
SPECIFIC SAFETY INSTRUCTIONS
WARNING!
The safety instructions given above can not be complete because the environment in
every shop is different. Always consider safety first as it applies to your individual
working conditions.

5
MODEL CX902 (T-50) – AIR STAPLER
As part of the new line of Craftex CX-Series Pneumatic Tools, we are proud to offer the CX902
(T-50) Air Stapler. By following the instructions and procedures laid out in this user manual,
you will receive years of excellent service and satisfaction. The CX902 is a professional tool
and like all pneumatic tools, proper care and safety procedures should be adhered to.
TOOL AIR FITTING
This tool uses a 1/4" NPT male plug
OPERATING PRESSURE
60 to 100 PSI (MAX. 120 PSI)
AIR CONSUMPTION
0.98 SCFM @ 90 PSI
STAPLER DIMENSIONS
9.5" (24cm) x 6.5" (17cm) x 2.5 (6cm)
FASTENER SIZE
Uses Arrow T-50 Staples and Similar
Gauge: 20
Length: 1/4" (6mm) x 5/8" (16mm)
Capacity: 100 pieces
TOOL WEIGHT
Weight: 3.8 lbs
CX902 (T-50) – AIR STAPLER
FEATURES

6
UNPACKING
The tool is properly packaged and shipped
in a box. When unpacking, carefully inspect
that the stapler has not been damaged
during transit.
INVENTORY
A. Air Stapler ------------------------------------ 1
B. Carrying Case --------------------------------1
C. Safety Goggles------------------------------ 1
D. Bottle for Oil---------------------------------- 1
E. Hex Wrenches--------------------------------2
Figure-1 Inventory
SAFETY NOSE
MECHANISM
The CX902 features safety nose
mechanism which protects against
accidental firing. When the trigger is
pressed, the stapler will not fire until the
safety nose mechanism is depressed.
Before using the stapler for the first time,
check the safety nose mechanism to
ensure proper function and safe use.
To check the safety nose mechanism:
Make sure the stapler is disconnected from
the air supply.
Make sure the magazine is empty.
Make sure the trigger and the safety nose
mechanism move up and down without
sticking.
Connect the stapler to the air supply.
Without pressing the trigger, depress the
safety nose mechanism against a scrap
piece of wood that is clean and free of any
knots, nails, staples or other foreign
objects.
If the stapler does not fire, the safety
nose mechanism is working.
If the stapler does fire, the safety
nose mechanism is not working.
Disconnect the air supply to the
stapler and do not use the stapler
until the safety nose mechanism is
fixed.
Keep the stapler with its nose mechanism
on the scrap wood and now, pull the trigger
and the stapler should fire.

7
OILING THE STAPLER
The CX902 Air Stapler needs to be
lubricated before every use. Place three to
four drops of pneumatic tool oil (provided)
in the stapler air inlet every two hours of
continuous use. See figure-2.
Figure-2 Lubricating the stapler
LOADING THE STAPLER
Disconnect the stapler form the air supply.
The CX902 accepts staplers with the
following specifications:
Use arrow T-50 Staples or similar.
Gauge: 20
Length: 1/4" (6mm) to 5/8" (16mm)
Capacity: 100 pieces
Depress and hold the magazine cover lock
while pulling the magazine cover back all
the way.
Slide a strip of staples, pointed-end down
into the magazine.
Push the magazine cover forward until it is
locked in its place.
OPERATING THE
STAPLER
Before operating the stapler, make sure you
have read and understood the instructions
given in this manual.
Always use the stapler first on a piece of
scrap wood; thick enough for the length of
the staples, loaded in the magazine, before
using it on the actual work-piece.
To operate the stapler:
Connect the air supply hose to the stapler.
Check the work-piece and make sure it is
free of knots, metals, or any other foreign
objects that will cause deflection.
Hold the stapler perpendicular to the
surface of the work-piece. Depress the
safety nose mechanism against the wood
and make sure your other hand and body
parts are positioned out of the way of the
potential of the staple in case of deflection.
Pull the trigger and drive the stapler into the
work-piece. Remove the stapler and check
the staple for proper depth.
If the staple is shot too deep into the wood,
slightly decrease the air pressure.
If the depth is too shallow, slightly increase
the air pressure.
WARNING!
Lubricate the stapler with a few drops of
oil as instructed in the manual, before
operating it. Failure to do so could result
in internal damage to the stapler and will
void the warranty.

8
REMOVING JAMMED
STAPLES
Sometimes the staple gets jammed.
Jammed staple must be removed before
using the stapler again.
To clear the jammed staple:
Disconnect the air supply to the stapler.
Push and hold the magazine lock, pull the
magazine loader all the way back.
Now, use needle nose pliers to remove the
jammed staple.
If the jammed staple can not be removed,
remove the cap screws securing the driver
guide cover to the nose assembly.
Now, the jammed staple should be visible.
Remove it with a pair of needle nose pliers.
Re-install the driver guide cover, and load a
new staples stick.
Check the safety nose mechanism, before
using the stapler again.
CLEANING
Always keep the stapler clean from dust,
chips, sand and etc, in the air connectors or
into the body.
Use a good solvent to clean the nose
assembly of the stapler and make sure the
stapler is dry before using it again.
WARNING!
Do not use gasoline or flammable liquids
to clean this tool. Vapours in the tool may
ignite, causing the tool to explode.
Failure to do so could result in serious
personal injury or death.

9

10

11

12
WARRANTY
Craftex warrants every product to be free from defects in materials and agrees to correct such defects where
applicable. This warranty covers three years for parts and 90 days for labour (unless specified otherwise), to the
original purchaser from the date of purchase but does not apply to malfunctions arising directly or indirectly from
misuse, abuse, improper installation or assembly, negligence, accidents, repairs or alterations or lack of
maintenance. Proof of purchase is necessary.
All warranty claims are subject to inspection of such products or part thereof and Craftex reserves the right to
inspect any returned item before a refund or replacement may be issued.
This warranty shall not apply to consumable products such as blades, bits, belts, cutters, chisels, punches
etceteras.
Craftex shall in no event be liable for injuries, accidental or otherwise, death to persons or damage to property or
for incidental contingent, special or consequential damages arising from the use of our products.
RETURNS, REPAIRS AND REPLACEMENTS
To return, repair, or replace a Craftex product, you must visit the appropriate Busy Bee Tools showroom or call 1-
800-461-BUSY. Craftex is a brand of equipment that is exclusive to Busy Bee Tools.
For replacement parts directly from Busy Bee Tools, for this machine, please call 1-800-461-BUSY (2879), and
have your credit card and part number handy.
All returned merchandise will be subject to a minimum charge of 15% for re-stocking and handling with the
following qualifications.
Returns must be pre-authorized by us in writing.
We do not accept collect shipments.
Items returned for warranty purposes must be insured and shipped pre-paid to the nearest warehouse
Returns must be accompanied with a copy of your original invoice as proof of purchase. Returns must be in
an un-used condition and shipped in their original packaging a letter explaining your reason for the return.
Incurred shipping and handling charges are not refundable.
Busy Bee will repair or replace the item at our discretion and subject to our inspection.
Repaired or replaced items will be returned to you pre-paid by our choice of carriers.
Busy Bee reserves the right to refuse reimbursement or repairs or replacement if a third party without our
prior authorization has carried out repairs to the item.
Repairs made by Busy Bee are warranted for 30 days on parts and labour.
Any unforeseen repair charges will be reported to you for acceptance prior to making the repairs.
The Busy Bee Parts & Service Departments are fully equipped to do repairs on all products purchased from us
with the exception of some products that require the return to their authorized repair depots. A Busy Bee
representative will provide you with the necessary information to have this done.
For faster service it is advisable to contact the nearest Busy Bee location for parts availability prior to
bringing your product in for repairs.
CRAFTEX 3 YEARS LIMITED WARRANTY
