Craftex CX series User manual

MODEL CX06BTSC
6" BENCHTOP JOINTER
w / SPIRAL CUTTERHEAD
USER MANUAL
1

2
TABLE OF CONTENTS
General Safety Instructions........................................................................................................... 3
Specic Safety Instructions........................................................................................................... 4
Features.........................................................................................................................................5
Identication...................................................................................................................................7
Components and Controls..............................................................................................................8
Plug and Grounding Requirements...............................................................................................10
Unpacking.....................................................................................................................................12
Inventory List.................................................................................................................................13
Cleaning Up Your Machine...........................................................................................................14
Bench Mounting & Assembly........................................................................................................15
Test Run........................................................................................................................................17
General Operation.........................................................................................................................18
Material Inspection........................................................................................................................19
Setting the Fence Stops................................................................................................................20
Adjusting and Setting Depth of Cut...............................................................................................23
Maintenance..................................................................................................................................28
Lubrication.....................................................................................................................................29
Trouble Shooting............................................................................................................................34
6 Jointer with Spiral Parts List.........................................................................................................36
Warranty...........................................................................................................................................41

ALWAYS read and understand the user man-
ual before operating the machine.
CONNECT your machine ONLY to the matched
and specic power source.
ALWAYS wear safet y glass es respirators,
hearing protection and safety shoes, when op-
erating your machine.
DO NOT wear loose clothing or
jewelry when operating your machine.
A SAFE ENVIRONMENT is important. Keep the
area free of dust, dirt and other debris in the
immediate vicinity of your machine.
BE ALERT! DO NOT use prescription or other
drugs that may affect your ability or judgment
to safely use your machine.
DISCONNECT the power source when chang-
ing drill bits, hollow chisels router bits, shaper
heads, blades, knives or making other adjust-
ments or repairs.
NEVER leave a tool unattended while it is in
operation.
NEVER reach over the table when the tool is
in operation.
ALWAYS keep blades, knives and bits
sharpened and properly aligned.
ALL OPERATIONS MUST BE performed
with gaurds in place to ensure safety.
ALWAYS use push sticks and feather
boards to safely feed your work through
the machine.
ALWAYS make sure that any tools used for adjust-
ments or installation are removed before operating
the machine.
ALWAYS keep bystanders safely away while
the machine is in operation.
3
Extreme caution should be used when operating all power tools. Know your power tool, be familiar
with its operation, read through the owner’s manual and practice safe usage procedures at all times
WARNING!
The safety instructions given above can not be complete because the environment in
every shop is different. Always consider safety rst as it applies to your individual
working conditions.
GENERAL SAFETY INSTRUCTIONS

ALWAYS make sure the machine is level be-
fore operating.
IF YOU ARE NOT FAMILIAR with the opera-
tions of a jointer, you should obtain the
advice and/or instructions from a qualied pro-
fessional.
ALWAYS use push blocks when jointing
stock.
NEVER make cuts deeper that 1/8” in a
single pass to prevent overloading the
machine and to prevent kickback.
MAKE SURE before servicing or making any ad-
justments, the power switch is in the “OFF” position
and the cord is un-plugged from the power source
to avoid any injury from accidental starting.
ALWAYS KEEP the edge of the out-feed table
aligned with the top dead center of the knife to pre-
vent kickback.
ALL OPERATIONS MUST be performed with
the guards in place to ensure safety.
MAINTAIN AND SERVICE your jointer regularly
as instructed in the user manual.
DO NOT force the work-piece into the cutter-
head. Feed the stock smoothly using push
blocks
ALWAYS inspect your stock before feeding
over the cutter head.
NEVER back your work-piece into the
spinning cutter head.
NEVER allow your hands to pass di-
rectly over the cutter head.
ALWAYS operate jointer with a proper dust collec-
tion system.
ALWAYS make sure that the exposed cutter head
behind the fence is guarded particularly when joint-
ing near the leading edge such as in rabbetting.
NEVER LEAVE the jointer unattended while
it is running. Unplug the cord from the power
outlet when not in use.
MAKE SURE you have read and understand
all the safety instructions in this user manual
and that you are familiar with jointer before op-
erating. If you fail to do so, serious injury could
occur.
WARNING!
The safety instructions given above cannot be complete because the environment in
every shop is different. Always consider safety rst as it applies to your individual
working conditions.
4
JOINTER SPECIFIC SAFETY INSTRUCTIONS

5
MODEL CX06BTSC 6”
BENCHTOP JOINTER WITH SPIRAL CUTTERHEAD
Main Specications:
Jointer Size:………………….....................……….………………….………….......……………..6”
Maximum Cut Width:…………………………………………......................….....….......…….…..6”
Minimum Material Thickness:………………………………......................…..............……….. 1/2”
Minimum Material Length: …………...…………….......................……………………………......8”
Bevel Jointing:............................................................................................0°- 45°Left And Right
Cuts Per Minute:……………....................................................…………….………………24, 000
Electrical Specications:
Hydro Requirement:………......................……………….…………...…120V Single Phase 60 Hz
Minimum Circuit Size:…………......................…………….………….......................................15A
Full Load Current:…………….................................................…………………………….……12A
Connection Type:……………...................................…………………………….6ft Cord and Plug
Power Cord Gauge:….....……......................................................………………………...16AWG
Plug Type:……..…………………......................………………………......................…………5-15
Switch Type:……..……....………......................……….….Paddle Switch with Yellow Safety Key
Motor Specications:
Type:……………….......................……….........……………..............................……......Universal
Horsepower:……………………………………………...........................…......................……...1.5
Amps:…………………………………………….......................………………………............….12A
Speed:………………………………………........................................……...…………20,000 RPM
Power Transfer:………………………..…………….......................…………………….…Belt Drive
Bearings:………......……….........………….......................……Shielded Permanently Lubricated
Cutter Head and Cutter Inserts Specications
Type of Cutter Head:…......……………...............................……….………....Spiral

6
Cutter Head Diameter:…………………........................………………..............…………….1-7/8”
Cutter Spirals:………………………………..........…........................………………………………3
Indexable Cutter Inserts:…………....…………...................................……………………...…...18
Cutter Head Speed:……………….............................................................................. 8000 RPM
Insert Type:…………………….........................................................................Indexable Carbide
Insert Dimensions:…………….................……............................……........….......15mm x 15mm
Insert Thickness:…………………………………….....................................................…….2.5mm
Jointer Fence Specications
Length:………………...…………………....................................................................…….22-1/2”
Width:………………………….....................................................…………………………….13/16”
Height:………………………….......................................................................................... 4-5/16”
Thicknes.…………………………….................................................................................……...1”
Set Fence Stops:.................................................................................……… 45°, 90°, and 135°
Machine Construction
Table:………………………………….……….............................................………….….Aluminum
Body:……………………………….....................…............................………...…Pre-formed Steel
Cutter Head:………………………..............................................................………………….Steel
Guard:……………………………….........................………………........................….....Aluminum
Fence:………………………………...............……………........................……Extruded Aluminum
Paint:…………………………………...………………….........................……………..Powder Coat
Other Specications
Country of Origin:………........................……………….............………………….…........….China
Warranty:………………........................……................................……………………….…3 Years
Serial Number Location:……........................………………..............………………….….ID Label
Sound Rating:…………...………………………................................................................….95db
ISO 9001 Factory:……..……………............................................................……………..……Yes
Certied By a National Recognized Laboratory (NRTL):.........................................…………..No
Dust Collection Ports:……………………………………...…………….............................………..1
Dust Collection Port Size:……………................................................................................ 2-1/2”

7
Identication
WARNING!
Read instruction manual before operating jointer for your own safety.
1, Always wear proper personal protection equipment such as hearing and eye protection.
2, Always keep all safety guards in place while operating machine.
3, Always use provided push blocks while jointing materials narrower then 3” or surface planing
material thinner than 3”.
4, Never joint any material less than 8” in length.

A. Main On/Off Switch: Turns motor on when
in the up position and turns motor off when
in the down position.
B. Main Switch Safety Key: Disables the switch
when yellow key is removed rendering the
machine disabled.
C. Infeed Table: Supports the material before
it passes over the cutterhead. The depth of
cut is determined by the height of the
infeed table.
D. Fence: Supports material laterally as it
passes over the cutterhead. The angle of
the fence determines angle of cut when
edge or bevel joining.
E. Infeed Table Height Adjustment: Allows you
to adjust the height of the infeed table, which
will determine the depth of cut.
F. Outfeed Table: Supports the material after
it passes over the cutterhead. Forsafestoperation
and best results the outfeed table should
be set even with the highest point or top dead
centre of cutterhead inserts.
8
Components and Controls:

9
G. Cutterhead Spring Guard: This sits overtop
the cutterhead and moves out of the way
when material pushes against it as it passes
over the cutterhead during operation. Once
material has passed over the cutterhead
the guar d springs back into place over
the cutterhead.
K. Fence Tilt Locking Lever: Firmly secures
the tilt angle of the fence. By using and
setting the fence stops on the bracket
assembly, the fence can be quickly set
at 90°, 45°outward, and 45° inward.
L. Limit Block: Adjusts and sets the angle of
the fence carriage to 90° using indents.
M. Limit Plate: Locks into indents in the limit
block at the factory set fence angles to
give a starting angle before precision
adjustments.
N. Dust Port: Expells the sawdust from
machine into supplied dust collection bag
or can be connected to a shop vacuum
or dust collector using the appropriate
connectors.
H. 45° Outward (135°) Fence Stop: Stops
fence at 45° outward (135°) position for
bevel cuts. Fence locks must be tight
ened even when fence is resting on stops
before operation of machine.
I. 45° inward Fence Stop: Stops fence at a
45° inward angle for bevel cuts.
J. Fence Carriage Locking Lever: Locks the
fence securely in place. You must loosen
the fence carriage lock in order to make
lateral adjustments to the fence to
accommodate the width of the material
being cut.

AVAILABILITY OF POWER
Before Installation of this machine you will
need to consider the proximity of your power
supply circuit. If available circuits do not meet
the requirements for this machine you will
have to get a new circuit installed by a licensed
electrician. Use of a licensed electrician will
minimize the risks of re, electrocution, dam-
age to equipment, and will insure everything
is wired in accordance to the applicable codes
and standards.
FULL LOAD CURRENT RATING
This is the amount of Amps a machine draws
under 100% of the rated output power.
FULL LOAD RATING FOR 120V 12AMPS
The full load current is not the maximum
amount of amps the machine will draw. The
machine has potential to draw current beyond
the full load rating if it is overloaded. Over-
loading of the machine for an extended period
of time can cause damage, overheating, or
even re. The risk is higher if the machine is
on an undersized circuit. To help avoid
these issues ensure you are connected
to a circuit in which meets the specied circuit
requirements for this piece of machinery.
CIRCUIT REQUIREMENTS FOR CX06BTSC
6” BENCHTOP JOINTER
The CX06BTSC has been prewired at the factory
for operation on an electrical circuit that has a veri-
ed ground and meets the below requirements:
Voltage:..................................................110V – 120V
Cycle: ............................................................60Hertz
Phase: ..............................................................Single
Circuit Breaker Size: ...................................15Amps
Please Note:
1. An electrical circuit includes all electrical
equipment between the breaker panel
and the machine. This is why it is
important to have the proper circuit size
so it can safely accommodate this
machine under full load for an extended
period of time.
2. The circuit requirements laid out in this
manual are for a dedicated circuit in
w h i c h o n l y o n e m a c h i n e w i l l b e
operational or installed at a time.
3. If you choose to connect to a shared
circuit where more than one machine
may be running at a time please consult
with a qualied electrician to ensure the
circuit is properly sized for safe operation.
10
POWER SUPPLY

PLUG AND GROUNDING
REQUIREMENTS
This machine must be grounded so that in
the event of certain malfunctions it will reduce
the chances of electrical shock by providing
a path of lesser resistance for the electric
current to travel through. For this reason
the CX06BTSC comes with a cord equipped
with an equipment grounding wire that leads
in to the grounding prong on the plug.
USE WITH EXTENSION CORDS
If you absolutely must require the use of an
extension cord with your machine do so, on
a temporary short term basis only.
NOTE
The three prong plug is only to be
plugged in to the matching receptacle
that is properly installed according to
the local electrical codes and standards.
Under no circumstances should you modify
the plug to make it fit in a receptacle
that is not meant for this configuration.
If there is an improper connection of
a machine grounding wire it may result
in a heightened risk of electric shock. If
repair or replacement of the power cord
is necessary in the future please consult
a licensed electrician.
NOTE
1. We recommend that you do not use an
extension cord with this machine. Also
the longer the extension cord the greater
the possibility of voltage drop causing
the motor to work harder under powered
which in turn will cause it to draw more
amps. Thi s may cau se the th ermal
overload to trip or even the breaker in
your electrical panel. It may also cause
the extension cord to heat up which
can be a potential fire hazard.
2. If an extension cord is used with this
machine it must have a groun d wi re
with a plug that matches the one cur-
rently installed on your machine. The
extension cord m u s t a l s o m e e t t h e
following specifications below:
Minimum Wire Gauge: 14 AWG
Maximum Cord Length: 50 ft.
NOTE
If ever you notice damage or wear to ei-
ther the cord or plug disconnect it imme-
diately from the power supply and have
it replaced by a licensed electrician or
service tech before any further use of
the machine.
11

UNPACKING OF THE CX06BTSC
This machine has been carefully packed in
order to protect it during transport. While un-
packing thoroughly go through the box and
separate all items from the materials used
for packaging. It is always wise to inspect
all items for shipping damage. In the event
of any damaged items please call Busy Bee
Tools customer service at 905-738-5115X6506
NOTE
Please keep all material used in
pa ckagi ng until you are satisfied with
your machine and have rectified any
issues between Busy Bee Tools or the
agent of shipping. (Ex: Shipping
damage claim)
12
UNPACKING

INVENTORY LIST
The following is an itemized list of the items
that come with your new machine. Before
you begin following the procedures for setup
of the machine lay out everything and check
that it matches the inventory list.
A. Jointer……………………...........….x1
B. Fence………………………………...x1
C. Fence Carriage Lock Lever….…….x1
D. Fence Tilt Lock Lever……………...x1
E. Carriage Assembly………….…...…x1
F. Carriage Mounting Bracket…..……x1
G. Fence Pivot Assembly………..…….x1
H. Locking Pin Plate……….…………..x1
I. Limit Block…………….……………..x1
J. Beveled Washers 10 x 3.5mm....….x2
K. Infeed/Outfeed Handles……….......x2
L. Dust Port……………….…………....x1
M. Dust Collection bag………………...x1
N. Dust Collection Bag Clamp….…….x1
O. Push Blocks……………….……...…x2
P. Replacement Inserts……….……....x5
Q. Hex Wrenches 5mm
and 6mm............................…x1 each
R. T-handle Torx Wrench T25……..….x1
Included Hardware
Flat Washers 8mm…….......……………….x2
Flat Washers 6mm…….......…………….…x2
Lock Washers 8mm………......……………x2
Lock Washers 6mm………….......………...x6
Flat Head Screws M5-.8x10…......……...x10
Cap Screws M8-1.25x30……......……...…x4
Cap Screws M6-1x20………......……….…x6
Large components
Small components
NOTICE
If item on list can not be found check
around machine as well as inside and
packaging materials. Sometimes items
get lost in packaging or are pre-installed
at the factory.
13

Your machine has unpainted surfaces that
have been covered with a heavy coat of
packing grease and rust preventatives to
prevent any corrosion during storage or
shipment of this machine. Although the
grease and rust preventatives work well you
will need to be patient and clean it off the
unpainted surfaces. This process will take
a little time.
There are multiple methods that can be utilized
for this process however we recommend the
following steps:
CLEANING ESSENTIALS
Degreaser (WD40 Specialist Machine
& Engine Degreaser Foaming Spray
or even regular WD40)
Plastic Scrapper ( a metal scrapper
may damage or mar the surface you
are degreasing)
Eye protection
Rubber Gloves
Rags
NOTE
We do recommend that this process is
done in a well ventilated place to minimize
any exposure to toxic fumes that may be
harmful to your health.
NOTE
You may need to repeat steps 3 and 4 until
all the rust preventative is able to be re-
moved leaving a clean surface.
NOTE
Avoid using acetone or chlorine based solvents
as they will damage painted surfaces.
CLEANING UP
YOUR MACHINE
RUST PREVENTATIVE REMOVAL STEPS
1. Make sure that you are setup for rust
preventative removal in a well ventilated
area.
2. Put on all required safety equipment. (Eye
protection and rubber gloves).
3. Spray surface with a generous amount of
the degreasing agent and let it soak in and
break down the grease for 10 minutes. This
will allow the degreaser time to work.
4. Now you can wipe the excess degreaser
off of the surface. If your degreaser
was effective the rust preventative should
have started to breakdown and come off.
Try using the plastic scrapper to remove
most of the preventative. After scrapping
wipe down the surface again.
14

On the base of the machine are mounting
holes that allow for the machine to be fas-
tened to a workbench to prevent machine
from moving during operation
The strongest method is a through mount
where holes are made all the way through
the work bench and hex bolts, washers, lock
washers, and hex nuts are used to securely
fasten the machine to mounting surface.
The Machine must be completely assembled
before operation. Before you begin the pro-
cess of assembly make sure to thoroughly
clean all parts that are coated in packing
grease or rust preventative.
1. To attach the carriage support to the
jointer you will need (2) M8-1.25x10
cap screws, (2) 8mm flat washers, as
well as (2) 8mm Lock washers. See
picture below:
2. Place the locking plate assembly
into the carriage support so that the
locking plate pins are against bottom
edge of carriage support. Now attach
the fence carriage lock lever and 10
x 3.5mm beveled washer on locking
plate. Assemble as shown in pictures
below: (DO NOT FULLY TIGHTEN YET)
3. Push down on the limit plate tab on
the carriage assembly then place the
limit block with notched side facing up.
BENCH MOUNTING
ASSEMBLY
15

4. To attach the fence bracket assembly
you will require (2) M6-1 x 20 cap screws
and (2) 6mm lock washers.
6. To install the fence tilt lock thread the
handle shaft into the bracket assembly.
7. Push the fence forward until it makes
contact with the cutterhead safety
guard. Th e c ut t er h ea d s ho ul d b e
completely covered by the cutterhead
safety guard.
5. Carefully s l i d e t h e f e n c e b r a c k e t
assembly onto dovetail supports and
locking plate assembly.
16
Plate

8. To lock the fence into place you must
tighten the fence carriage locking lever.
9. To attach the handles to the infeed/
outfeed tables you will require (2) M6-1
x 20 cap screws, (2) 6mm lock washers,
and (2) 6mm flat washers.
Now that you have completed the assembly
of your machine it is time for the test run.
The test run is to confirm that everything is
functioning as it should.
The test run is used to conrm the following:
1. That the motor energizes and
ru ns properly.
2. That the main switch with the safety
key function as intended.
1. Remove the existing dust bag and
hose cl a m p from t h e 2-1/ 2 ” d ust
co llection port.
2. Slide a 2-1/2” piece of hose on the
dusts port and fasten it in place using
the appropriate hose clamp.
3. Make sure that the hose is secured
tightly and the seal between the hose
and dust port is air tight in order to
prevent loss of suction and ensure
proper performance.
OPTIONAL: HOOK UP
TO DUST COLLECTOR
TEST RUN
NOTE
If you do happen to encounter any unusual
issues or problems stop the machine
immediately and disconnect it from the
power supply. The issues must be fixed
before operation of the machine. The trouble
shooting section is located in the service
and maintenance part of the manual it may
be of help.
17

HOW TO TEST RUN
THE MACHINE
TENSIONING DRIVE BELT
GENERAL OPERATION
1. Please make sure that you have read
and understand all safety instructions
located at the start of the manual.
2. Make sure that the machine was set
up properly in accordance with the
instruction manual.
3. Clear the area of all tools and objects
used in the assembly stage as well
as any other items that may be in
the area.
4. Plug the machine in to the power source.
5. Turn the main switch on to confirm
that motor is operational, and then
turn the machine off. Motor should run
smoothly without any unusual noises
or issues.
6. Remove the yellow safety key from
the centre of the main switch.
The last step in the setup of your jointer is
tensioning the drive belt. This should be
done after approximately the first 16 hours
of use. During that time the belt will become
properly seated in the grooves of the pulley
causing it to stretch making re-tensioning of
the drive belt necessary for optimal perfor-
mance.
This is a gen eral ov ervie w to help t he
beginner machine operator develop a basic
understanding of how the machine is to be
used during operation. This will help make
the controls and components discussed later
in this manual easier to understand.
7. Now that the safety key has been
removed from the main switch try and
start the machine. If the machine does
not start the safety key feature is working
as intended.
NOTE
Do Not try to adjust the tension after
extended use or operation as the pulley
and belt may be hot to the touch. Allow
them to cool down before making
your adjustments.
NOTE
This should only be considered as a
general overview and it is not intended
to be an instructional guide. For more
in depth learning on specific operations
please seek additional training.
18

To complete a basic
operation, the operator
will do the following:
MATERIAL INSPECTION
Not all work materials are suitable for use.
Before jointing check all material and follow
the rules below:
Jointing/planing should always be done
with the grain as it is safer for the opera-
tor and it provides a better finish. Jointing
or planing against the grain increases the
risk of kickback and tear-out. When cutting
with the grain on your material it should be
pointing down and towards the feed table.
Remove foreign objects from the material.
Look for defects in the material and things
like nails, staples, imbedded gravel, and
other impurities.
Make sure material is adequately dried. Do
not use wood that has higher moisture content
then 20% like wood that has been exposed to
rain or snow as it is hard on the machine and
will cut poorly and could cause excessive wear
to the machine as well. Too much exposure to
moisture may cause rust and corrosion of your
machine and related components.
1. Put on all required safety equipment
like safety glasses, ear plugs,
and respirator.
2. Check that material is suitable and
safe for jointing.
3. Adjust fence laterally to accommodate
the width of material being jointed
then lock the fence into place.
4. Tilt and adjust fence if required.
5. Adjust the infeed table height in order
to set the depth of cut for each pass.
6. Turn the jointer on by putting the main
switch in the upward position.
7. Hold the material securely against
the fence and infeed table using the
supplied push blocks. Feed the material
o ve r t h e c u t t e r h e a d a t a s t e a d y
and consistent rate until the full length
of the material has passed over the
cutterhead completely onto the outfeed
table. Repeat this step until you have
achieved the desired result.
8. Turn the jointer off by returning the
main switch to the downward position.
19

Do not surface plane material containing
big or loose knots. Knots when loose run the
risk of dislodging and coming out during the
jointing/planing process causing kickbacks,
damage to the machine or even injury.
Only put materials consisting of natural
wood ber through your jointer. Only
natural wood material is meant for use with
this machine. Use of any other material like
tile, glass, or stone may cause machine dam-
age or even result in serious injury.
Clean all Materials of glue before jointing.
Remove glue with a scrapper before jointing
material to avoid coating the cutterhead in-
serts in glue. If not removed you may experi-
ence poor results and dulling of the cutterhead
inserts.
Setting Fence Stop 90°
1. Make sure that the machine has been
disconnected from its power source.
2. Now you will have to loosen the fence
tilt lock lever and push the limit plate
tab forward into rear slot of limit block.
3. Take 90° machinists square and
adjust the fence until it sits flush
with square. Once fence is at 90°
tighten the fence tilt lock lever.
Fe nce sho uld sto p at 90° wh en it
ma kes contact with the limit block.
NOTE
Materials must be a minimum of
10”Length x 1/4” Width x 3/4” Height
or larger for edge jointing and
10”Length x 1”Width x 1/2” Height
for surface planing to reduce risk
of material breaking or kicking back
during operation causing serious injury.
SETTING THE FENCE STOPS
20
Limit
Plate
Limit
Block
