Craftex CX12HC User manual

MODEL CX12HC
12" JOINTER WITH
HELICAL CUTTERHEAD
USER MANUAL
Version 1.0

2
TABLE OF CONTENTS
General Safety Instructions....................................................... 3
Specific Safety Instructions ....................................................... 4
CX12HC.................................................................................... 5
Physical Features...................................................................... 6
Set Up ....................................................................................... 7
Unpacking ................................................................................. 7
Proper Grounding...................................................................... 8
Assembly................................................................................... 9
Basic Controls ...........................................................................10
Test Run....................................................................................10
Fence Adjustment......................................................................11
Infeed Table Adjustment............................................................12
Outfeed Table Adjustment.........................................................13
Winding the Cutterhead Guard..................................................14
Work-piece Inspection...............................................................14
Connecting to a Dust Collector..................................................15
Surface Planing.........................................................................15
Bevel Cutting.............................................................................16
Edge Jointing.............................................................................16
Maintenance..............................................................................17
Lubrication.................................................................................17
Inspecting the Cutterhead Knives..............................................17
Adjusting/Replacing Cutterhead Knives ....................................17
Replacing and Tensioning V-Belts.............................................18
Parts Breakdown & Parts List.............................................. 19-27
Warranty....................................................................................28

3
GENERAL SAFETY INSTRUCTIONS
Extreme caution should be used when operating all power tools. Know your power
tool, be familiar with its operation, read through the owner’s manual and practice
safe usage procedures at all times.
ALWAYS read and understand the
user manual before operating the
machine.
CONNECT your machine ONLY to the
matched and specific power source.
ALWAYS wear safety glasses
respirators, hearing protection and
safety shoes, when operating your
machine.
DO NOT wear loose clothing or
jewelry when operating your machine.
A SAFE ENVIRONMENT is
important. Keep the area free of dust,
dirt and other debris in the immediate
vicinity of your machine.
BE ALERT! DO NOT use prescription
or other drugs that may affect your
ability or judgment to safely use your
machine.
DISCONNECT the power source when
changing drill bits, hollow chisels,
router bits, shaper heads, blades,
knives or making other adjustments or
repairs.
NEVER leave a tool unattended while
it is in operation.
NEVER reach over the table when the
tool is in operation.
ALWAYS keep blades, knives and bits
sharpened and properly aligned.
ALL OPERATIONS MUST BE
performed with the guards in place to
ensure safety.
ALWAYS use push sticks and feather
boards to safely feed your work
through the machine.
ALWAYS make sure that any tools
used for adjustments or installation is
removed before operating the
machine.
ALWAYS keep the bystanders safely
away while the machine is in
operation.

4
ALWAYS lock the mobile base before
operating the machine.
IF YOU ARE NOT FAMILIAR with the
operations of a jointer, you should
obtain the advice and/or instructions
from a qualified professional.
ALWAYS use push blocks when jointing
stock that does not provide a
reasonable distance of safety for your
hands.
NEVER make cuts deeper that 1/8” in a
single pass to prevent overloading the
machine and to prevent dangerous
kickback.
MAKE SURE before servicing or
making any adjustments, the power
switch is in the “OFF” position and the
cord is un-plugged from the power
source to avoid any injury from
accidental starting.
MAINTAIN the proper relationship of in-
feed and out-feed table surfaces and the
cutter-head knife path.
ALL OPERATIONS MUST be
performed with the guards in place to
ensure safety.
ALWAYS inspect your stock before
feeding over the cutter head.
NEVER back your work-piece into the
spinning cutter head.
NEVER allow your hands to pass
directly over the cutter head.
ALWAYS operate the jointer with a
proper dust collection system.
ALWAYS make sure that the exposed
cutter head behind the fence is guarded
particularly when jointing near the
leading edge such as in rabbetting.
NEVER LEAVE the jointer unattended
while it is running. Unplug the cord from
the power outlet when not in use.
MAINTAIN AND SERVICE your jointer
regularly as instructed in the user
manual.
MAKE SURE you have read and
understood all the safety instructions in
this user manual and you are familiar
with jointer before operating the
CX12HC. If you fail to do so, serious
injury could occur.
CX12HC SPECIFIC SAFETY INSTRUCTIONS
WARNING!
The safety instructions given above can not be complete because the environment in
every shop is different. Always consider safety first as it applies to your individual
working conditions.

5
MODEL CX12HC - 12” JOINTER WITH HELICAL CUTTERHEAD
As part of the growing line of Craftex woodworking equipment, we are proud to offer the
CX012HC, an 12” Jointer with Helical Cutterhead. By following the instructions and procedures
laid out in this user manual, you will receive years of excellent service and satisfaction. The
CX12HC is a professional tool and like all power tools, proper care and safety procedures
should be adhered to.
Motor: 3 HP, 220 Volts, Single Phase, 15 Amps
3 ‘V’ Belts Drive.
Max. Depth of Cut – 1/8”
Max. Width of Cut – 8”
Cutter-Head Type: Helical
Cutter Head Speed: 5,350 RPM
Number of Carbide Inserts: 40
Cuts per Minute – 21,400
Table Size: 8” Width, 76-3/8” Length and Height (from floor) 32-5/8”
Fence Size: 1 1/4” Width, 36” Length, 5” Height, 45°, 90° and 135° Stops
Die Cast Metal Cutter-Head Guard
All Ball Bearing and Cast-Iron Construction
Shielded and Lubricated Ball Bearings
Precision Ground Cast Iron In-feed and Out-feed
Parallelogram Beds
Mobile Base with Locking Foot Pedal
4” Dust Hood is included
First Carton Size: 81 1/2” L x 25 1/2” W x 12 1/2” H
Second Carton Size: 38” L x 18” W x 27 1/2” H
Net Weight: 510 lbs
Warranty – 3 YEARS
CX12HC JOINTER
FEATURES

CX12HC PHYSICAL FEATURES
Outfeed
Table
Fence
Fence Tilt
Lock Lever
Fence Tilt
Handle ON/OFF Switch
In-feed
Table
Fence
Lock Lever
Cutterhead
Guard
Depth
Scale
Infeed
Table
Lock
4” Dust
Hood
Outfeed Table
Adjustment Lever
Outfeed
Table
Lock
Infeed Table
Adjustment Lever
Fence
Adjustment
Knob

7
SETUP
Before starting setting up the machine you
need to read and understand this user
manual completely. For the protection of
your eyes you should wear safety glasses.
The unpainted surfaces of the jointer are
coated with rust prevention waxy oil and
you will want to remove this before you
begin assembly. Use a solvent cleaner that
will not damage painted surfaces.
UNPACKING
The machine is properly packaged in a
carton for safe transportation. When
unpacking, carefully inspect the crate and
ensure that nothing has been damaged
during transit. Open the crate and check
that the machine is in good condition. The
machine is heavy and you should use a fork
truck or get assistance to move the
machine for safe moving method. You
should also clean the cutter-head, in-feed
and out-feed tables, and the fence before
assembly and operation.
The hardware (screws, washers & etc)
might be shipped in a plastic bag. After the
machine has been un-packed, check that
all loose parts and hardware are present.
WARNING!
CX12HC is a heavy machine. Do not
over-exert yourself. Use fork truck or
other devices for safe moving.
IMPORTANT!
When setting up your machine, you will
want to find an ideal spot where your
jointer will most likely be positioned most
of the time. Consider your complete work
environment as well as working
comfortable with the jointer before
placing your machine in the ideal spot.

8
PROPER GROUNDING
Grounding provides a path of least
resistance for electric current to reduce the
risk of electric shock.
CX12HC is for use on a normal 110 volt
circuit. Make sure that the machine is
connected to an outlet having the same
configuration as the plug. If an adaptor plug
is used, it must be attached to the metal
screw of the receptacle. To prevent
electrical hazards, have a qualified
electrician ensure that the line is properly
wired.
The sander should be wired with a plug
having 3 prongs to fit a 3 prong grounded
receptacle as shown in figure-1. Do not
remove the grounding prong to fit it into a 2
pronged outlet.
Figure-1 220 volts outlet for CX12HC
It is strongly recommended not to use
extension cords with your CX12HC. Always
try to position your machine close to the
power source so that you do not need to
use extension cords.
In case if you really find it necessary to use
an extension cord, make sure the extension
cord does not exceed 50-feet in length and
the cord is 14-gauge to prevent motor
damage.
WARNING!
Improper connection of the equipment-
grounding conductor can result in a risk
of electric shock. Check with a qualified
electrician if you are in doubt as to
whether the outlet is properly grounded.

9
ASSEMBLY
Make sure the cord is disconnected from
the power source.
Install the fence assembly to the rear of the
cabinet by aligning the fence mounting
holes with the holes on the cabinet and
tighten the cap screws to secure the fence
in position. See figure-2.
Figure-2 Installing the fence
The jointer comes with the switch bracket
installed upside down for shipping
purposes.
Loosen and remove the two screws
securing the switch bracket to the cabinet.
Now, attach the switch bracket to the
cabinet upright and secure it using the
screws removed. See figure-3.
Figure-3 Installing the switch bracket
Insert the cutterhead guard shaft and use
the set screws to tight it. See figure-10.
Figure-4 Installing the cutterhead guard
Attach the dust hood to the cabinet and
secure it using screws provided.
Figure-5 Installing the dust hood

10
BASIC CONTROLS
The basic controls of the jointer are shown
in the figure below. Use this figure and read
the text to know what the basic controls of
your machine are.
Figure-6 Basic Controls
A. ON/OFF SWITCH: Starts and stops the
jointer.
B. FENCE ADJUSTMENT KNOB: Moves
the fence forward or backward.
C. TABLE ADJUSTMENT LEVERS: Move
the table forward and backward.
D. TABLE LOCKS: Lock the tables to the
position desired position.
TEST RUN
Once you have assembled your machine
completely, it is then time for a test run to
make sure that the machine works properly
and is ready for operation.
TO TEST RUN THE MACHINE:
Make sure you have read and understood
the safety instructions given in the manual.
Connect the machine to correct power
source.
Make sure all the tools and objects used
during setup are cleared away from the
machine.
Turn the machine ON and let the machine
run for a few seconds.
Press stop button to turn OFF the machine
and restart the jointer.
Listen and watch the machine for any
unusual noises. The machine should run
smoothly with little or no vibration.
During the test run if there is any unusual
noise coming from the machine or the
machine vibrates, immediately shut off the
machine and investigate to find out the
problem with your machine.
WARNING!
Before starting the jointer please make
sure that you have read and understood
the manual and you are familiar with the
functions and safety features on this
machine. Failure to do this may cause
serious personal injury.

11
FENCE ADJUSTMENT
Make sure the cord is disconnected from
the power source before making any
adjustments.
FORWARD & BACKWARD
MOVEMENT
The fence can be positioned anywhere
across the table by loosening the lock lever
and rotating the star knob shown in figure-
7.
Figure-7 Fence controls for forward and
backward movements
Once the fence is moved to the desired
position, retighten the lock lever.
TILTING THE FENCE
To tilt the fence outward or inward, loosen
the lock lever and tilt the fence to the
desired angle. Retighten the lock lever to
secure the fence in the desired angle. See
figure-8.
When tilting the fence outward, the stop
plate must be rotated to the up position
allowing the fence to go past it. See figure-
8.
Figure-8 Fence tilt controls
FENCE POSITIVE STOPS
The CX12HC fence is equipped with
positive stops at the most common fence
positions (90° and 45° right left).
Loosen the lock lever.
Position the fence at 90° to the table
making sure the tip of the stop bolt shown
in figure-9 is against the stop plate. then
tighten the lock handle.
Figure-9 90° positive stop
Using a square, check to see if the fence is
at 90° with the table..
If the fence is not at 90° to the table, loosen
the lock lever and lock nut on the stop bolt.
Turn the stop bolt until it is tip contacts the
stop plate. Make sure the table is now at
90° with the table and tighten the lock lever.

12
Tilt the fence inward as far as possible and
use a combination square to check if the
fence is tilted 45° inward to the table.
If an adjustment is necessary, loosen the
lock nuts and adjust the bolts shown in
figure-10 until tip of the bolts contact the
brackets.
Figure-10 45° inward positive stop
Now, rotate the tilt stop plate to up position
and tilt the fence outward as far as
possible. Use a combination square and to
check if the fence is tilted 45° outward.
If an adjustment is necessary, loosen the
lock nut and adjust the bolt shown in figure-
11 until head of the bolt contacts back of
the fence.
Figure-11 45° outward positive stop
Tighten the lock lever to secure the fence in
position.
INFEED TABLE
ADJUSTMENTS
To raise or lower the infeed table, loosen
the table lock lever. See figure-12.
Move the table height lever up or down until
the table is at the desired position and
tighten table lock lever. See figure-12.
Figure-12 Infeed table height controls
The depth of cut depends on the position of
the infeed table in relationship with the
cutterhead and it can be read on the pointer
and scale. See figure-13.
Figure-13 Infeed table height adjustment
Positive stops are provided on the jointer to
limit the height and depth of the infeed
table. To adjust the stops, loosen two
locknuts and shown in figure-14. Turn the
two adjustment bolts as necessary.

13
Figure-14 Infeed table positive stop bolts
Retighten locknuts.
We recommend that the height of the infeed
table to be adjusted so that the table at its
highest point will be 1/2mm below the
highest point of the cutter inserts. This is an
important feature of your jointer which
enables you to rapidly position the infeed
table for a finish or final cut.
OUTFEED TABLE
ADJUSTMENT
For most jointing operations the outfeed
table must be exactly level with the cutter
inserts at their highest point of revolution.
To move the outfeed table, loosen lock
lever shown in figure figure-15 and move
the table height lever up or down until the
table is level with the cutter inserts.
Figure-15 Outfeed table height adjustment
It may be necessary to adjust the positive
stops. Loosen the two locknuts shown in
figure-16 when moving the table up or
down.
Figure-16 Outfeed table positive stops
Turn the bolts and when the table is exactly
level with the cutter inserts at the highest
point of revolution, retighten the lock nuts.

14
WINDING THE
CUTTERHEAD GUARD
The cutterhead guar must be checked to
see if it works properly.
Pull the guard and let it go. The guard
should spring back over the cutterhead.
If the guard drags across the table, loosen
the set screws on the guard, raise it slightly
then tighten the set screws.
If the guard does not spring back over the
cutterhead, loosen the set screws. Hold the
guard over the cutterhead and wind the
shaft collar clockwise. Tighten the set
screws and check to see if the guard works
properly.
Figure- 17 Cutterhead gaurd
WORKPIECE INSPECTION
Before cutting any wood, make sure to
inspect the workpiece for the nails, staples,
small pieces of stone or metal and any
other object which is dangerous to come on
contact with the blade.
If the wood contains any of these objects
and it come in contact with the blade, either
the object might fly and hit the operator or
seriously damage the blade. For a safe
cutting method always inspect your work-
piece carefully before cut.
Some of the woods with excessive twisting,
wrapping or large knots are unstable while
jointing. While jointing operation the work-
piece can move un-expectedly, this will
either damage the blade or hurt the
operator.
Do not joint or surface plane against the
grain direction. Cutting against the grain
increases the chance of kickback as well as
tear out on the stock.
Always joint the stock with the grain so that
the grain is pointing down and towards you
as viewed on the edge of the stock.
In case the grain changes direction along
the edge of the board, decrease the cutting
depth and make additional cuts.
Make sure all the stock is sufficiently dried
before jointing. Wet stock causes
unnecessary wear on the knives and poor
cutting results.

15
CONNECTING TO A
DUST COLLECTOR
CX12HC features a 4” diameter dust ports
to connect to a dust collector. When
connecting to a dust collector, use a proper
sized hose and make sure all the
connections are sealed tightly.
SURFACE PLANING
When surface planing on a jointer, set the
cutting depth to 1/32” and make sure the
fence is set to 90°. Place the concave face
of the stock flat on the in-feed table and run
the jointer. Push the stock over the cutter
head with the help of push blocks as shown
in figure-18.
Figure-18 Surface planing
Never plane stock against the grain
direction of the wood. It can cause a kick
back or there is a possibility of tear-out on
the wood.
WARNING!
The fine particles of saw dust produced
by the machines in your work shop can
go into your lungs and cause serious
health problems. Make sure your
machines are connected to a proper dust
collection system while operation.
WARNING!
To save your hands, always use push
blocks when surface planing on the
jointer. Failure to do so, your hands can
come in contact with the cutter head and
serious injury can occur.

16
BEVEL CUTTING
Bevel cutting is the cutting operation to cut
a desired angle on the edge of the work
piece.
To perform bevel cutting operation on a
jointer it is recommended to set the cutting
depth between 1/16” and 1/8”.
Now, set the fence to your desired angle
and start the jointer. Use push blocks to
push the stock over the cutter-head. If the
stock is cupped, make sure to put the
concave face of the stock flat on the in-feed
table. See figure 19.
Figure-19 Bevel cutting
EDGE JOINTING
Edge jointing is to make the edge of the
stock flat and suitable for joinery or
finishing. To edge joint on the jointer set the
cutting depth to 1/16” & 1/8” and make sure
the fence is set to 90 degrees. Place the
concave face of the stock flat on the in-feed
table and run the jointer. Use push blocks
to push the stock over the cutter head.
Repeat the same procedure until the edge
of the stock is flat.
Figure-20 Edge jointing

17
MAINTENANCE
During the life of your machine, you will
need to practice some regular maintenance
to keep your jointer in peak performance
condition.
Check the machine for any loose mounting
bolts, dull or damaged inserts, worn or
damaged wires or any other unsafe
condition daily before use.
Regularly vacuum all sawdust from the
machine.
The unpainted surfaces such as the
precision ground cast iron table top should
be protected with a light coat of paste wax
and then buffed dry.
Check the V-belts for wear and correct
tension on a regular basis.
LUBRICATION
Since all the bearings are sealed and
permanently lubricated on the CX12HC,
you do not need to lubricated them.
INSPECTING THE
CUTTERHEAD KNIVES
The cutterhead knives are supposed to be
at the same height with each other and with
the outfeed table. If one of the carbide
inserts is higher than the others, you will get
a poor result while doing any cutting
operation.
To inspect the cutter-heads disconnect the
jointer from the power source and remove
the cutterhead guard so that you can have
access to the cutter-head.
Now, take a straight edge and put it on the
outfeed table so that it hangs over the
cutterhead. Rotate the cutter head body
and check the height of each carbide insert
with the out-feed table. The inserts should
just touch the bottom of the straight edge. If
the inserts are set too high or too low then
they should be adjusted.
ADJUSTING/ REPLACING
CUTTERHEAD KNIVES
The carbide inserts get dull after sometimes
and need to be adjusted or replaced
occasionally.
To adjust or replace the carbide inserts,
disconnect the machine from the power
source and remove the cutter head guard to
expose the cutter head with the carbide
inserts.
Now, take a hex key and loosen the screws
on the carbide inserts that hold each
carbide insert to the cutter head body. See
figure-21.
WARNING!
Make sure the switch is turned OFF and
the cord is disconnected from the power
source when installing, removing any
parts or servicing the machine.

18
Figure-21 Removing the carbide inserts
Clean all the dust and debris on the cutter-
head body and on the insert and replace it
with a new one.
The carbide insert has a square shape and
thus it has four cutting edges. When one
edge of the carbide insert gets dull, simply
rotate it 90 degrees and you will get a new
and fresh cutting edge. When all four edges
of the carbide insert are used replace it with
a new one.
Figure-22 Rotating carbide insert 90°
REPLACING AND
TENSIONING V-BELTS
The jointer comes with two V-belts installed
and properly tensioned.
TO REPLACE THE V-BELTS:
Disconnect the cord from the power source.
Loosen the knob and pull the latch
upwards. Open the rear cabinet door to
access the V-belts.
Loosen the lock nuts shown in figure-23 to
loosen tension on the V-belts.
Figure-23 V-belt tensioning lock nuts
Remove the V-belts from the motor pulley
and the cutterhead pulley.
Install the new V-belts and make sure both
are setting properly into the grooves of the
pulleys.
TO TENSION THE V-BELTS:
Push the motor down with one hand and
tighten the upper lock nut shown in figure-
24 first and then the lower one with the
other hand.
There is approximately 1/2" deflection in the
center span of the V-belts using light finger
pressure.
Close the cabinet door.
WARNING!
Remember if the dust and debris on the
cutter-head body is not cleaned, it will
make the insert out of height alignment
and may result in poor cutting
performance.

19
FENCE
PARTS BREAKDOWN

20
REF DESCRIPTION QTY
301 LOCK HANDLE 1
302 FLAT WASHER 1
303 HEX HD SCR 1
304 FLAT WASHER 1
305 HEX SOC SET SCR 1
306 GUID BLOCK 1
307 HEX SOC HD SCR 1
308 HAND WHEEL 1
309 HEX SOC SET SCR 1
310 ADAPTER 1
311 BRACKET 1
312 GEAR SHAFT 1
313 GEAR COLUMN 1
314 HEX SOC HD SCR 2
315 LOCK WASHER 2
316 FLAT WASHER 2
317 FENCE SUPPORT 1
318 FLAT WASHER 2
319 HEX SOC HD SCR 2
320 LOCK WASHER 2
321 HEX SOC HD SCR 2
322 LOCK WASHER 2
323 FLAT WASHER 2
324 GUARD 1
324A LOCK WASHER 2
325 HEX SOC PAN SCR 2
326 HEX HD SCR 1
327 HEX NUT 1
328 FENCE BRACKET 1
329 BLOCK 1
330 FLAT WASHER 1
331 HEX HD SCR 1
332 SLEEVE 1
333 LEFT BRACKET 1
334 SPRING PIN 1
335 HEX NUT 1
336 HEX HD SCR 2
337 HEX NUT 2
338 PIN 6
339 SUPPORT 1
340 KNOB 1
341 HANDLE ROD 1
342 HEX NUT 1
343 FENCE 1
344 REAR CLAMP 2
345 HANDLE 1
346 FLAT WASHER 1
347 SHAFT 2
348 HEX SOX HD SCR 4
349 RIGHT BRACKET 1
350 HEX NUT 1
351 HEX HD SCR 1
352 HEX SOC HD SCR 2
353 COLUMN COVER 1
FENCE
PARTS LIST
