Crestron TPMC-3SM & TPMC-3SMD
Isys®2.8” Wall Mount & Designer
Touch Screens
Configuration Guide

This document was prepared and written by the Technical Documentation department at:
Crestron Electronics, Inc.
15 Volvo Drive
Rockleigh, NJ 07647
1-888-CRESTRON
Crestron, the Crestron logo, Crestron Toolbox, Fusion RV and Isys are either trademarks or registered trademarks of Crestron Electronics,
Inc. in the United States and/or other countries. Other trademarks and trade names may be used in this document to refer to either the
entities claiming the marks and names or their products. Crestron disclaims any proprietary interest in the marks and names of others.
©2011 Crestron Electronics, Inc.

Crestron TPMC-3SM & TPMC-3SMD Wall Mount & Designer Touch Screens
Contents
Isys®2.8” Wall Mount & Designer Touch Screens: TPMC-3SM & TPMC-3SMD 1
Access the Setup Screens........................................................................................................... 1
Configure the TPMC-3SM or TPMC-3SMD ............................................................................4
Ethernet Setup .............................................................................................................4
Standby Setup..............................................................................................................7
Display Settings...........................................................................................................8
System Messages Disabled/Enabled..........................................................................10
About.........................................................................................................................10
Diagnostics ................................................................................................................11
User Project Mode Off/On ........................................................................................13
Save & Exit ...............................................................................................................13
Configuration Guide – DOC. 7269A Contents •i

Crestron TPMC-3SM & TPMC-3SMD Wall Mount & Designer Touch Screens
Isys®2.8” Wall Mount & Designer
Touch Screens: TPMC-3SM &
TPMC-3SMD
Access the Setup Screens
The setup screens are the starting point for configuring the TPMC-3SM and
TPMC-3SMD.
NOTE: If no project has been loaded or if an invalid project has been loaded, the
TPMC-3SM and TPMC-3SMD default to the setup menu screen.
The setup screens allow basic configuration procedures prior to regular operation of
the TPMC-3SM and TPMC-3SMD.
When power is applied for the first time, the screen shown in the following
illustration appears.
Initial Screen
Configuration Guide – DOC. 7269A Isys®2.8” Touch Screens: TPMC-3SM & TPMC-3SMD •1

Wall Mount & Designer Touch Screens Crestron TPMC-3SM & TPMC-3SMD
NOTE: Most screens on the TPMC-3SM and TPMC-3SMD are identical. The few
instances where they differ will be noted in the text.
Touch the screen to display the “Panel Setup Options” screen, shown in the
illustration below.
TPMC-3SM “Panel Setup Options” Screen
TPMC-3SMD “Panel Setup Options” Screen
During regular operation of the touch screen, there are two ways to activate the setup
functions:
1. Place a button on the project main page and assign the reserved join number
(17242) that activates setup.
2. Press hard keys 1, 2, 3 and 4, under the touch screen display, in sequence
twice (i.e. press 1, 2, 3, 4, 1, 2, 3, 4) within a five second period.
2 •Isys®2.8” Touch Screens: TPMC-3SM & TPMC-3SMD Configuration Guide – DOC. 7269A

Crestron TPMC-3SM & TPMC-3SMD Wall Mount & Designer Touch Screens
1234
The “Panel Setup Options” screen is comprised of buttons for Ethernet Setup,
Standby Setup, Display Settings and Diagnostics. In addition, there are buttons
that enable/disable system messages, that provide information About the touch
screen and (on the TPMC-3SM only), that select whether User Project mode is on or
off. There is also a Save & Exit button. The functions of each are detailed in the next
section of this guide.
Configuration Guide – DOC. 7269A Isys®2.8” Touch Screens: TPMC-3SM & TPMC-3SMD •3

Wall Mount & Designer Touch Screens Crestron TPMC-3SM & TPMC-3SMD
Configure the TPMC-3SM or TPMC-3SMD
Ethernet Setup
On the “Panel Setup Options” screen, touch Ethernet Setup to display the “Ethernet
Setup” screen, shown in the following illustration.
“Ethernet Setup” Screen
The “Ethernet Setup” screen displays information about your Link Status, Control
Connection, Mac and IP addresses. There is a button to enable/disable Ethernet Auto
Discovery and buttons that provide access to Control System Settings and IP
Address Settings.
Touch Control System Settings to display the “Control Systems” screen, shown in
the following illustration.
“Control Systems” Screen
4 •Isys®2.8” Touch Screens: TPMC-3SM & TPMC-3SMD Configuration Guide – DOC. 7269A

Crestron TPMC-3SM & TPMC-3SMD Wall Mount & Designer Touch Screens
The “Control Systems” screen provides information about IP addresses, CIP ID,
Device ID and Port for up to four entries.
NOTE: The TPMC-3SM and TPMC-3SMD can communicate with up to 16 control
systems but only the first four entries will be visible on the screen. Other entries will
be visible with Crestron Toolbox™ software.
Touch Add Entry to display the “Edit Control System Settings” screen (shown in
the following illustration), where IP Address / Hostname, Port, CIP ID and Device
ID can be accessed.
“Edit Control System Settings” Screen
Touch the IP Address / Hostname, Port, CIP ID and Device ID fields to make each
entry. Each will open an on-screen keyboard appropriate for the field. For example,
touching the IP Address / Hostname field will open the keyboard shown in the
following illustration.
On-Screen Keyboard for IP Address / Hostname
Configuration Guide – DOC. 7269A Isys®2.8” Touch Screens: TPMC-3SM & TPMC-3SMD •5

Wall Mount & Designer Touch Screens Crestron TPMC-3SM & TPMC-3SMD
After making the entry, touch OK to add it or CANCEL to cancel it. After making
all the appropriate entries, when you are returned to the “Edit Control System
Settings” screen, touch Save to keep the new settings or Cancel to cancel them.
Touch Back on the “Control Systems” screen to return to the “Ethernet Setup”
screen.
On the TPMC-3SM and TPMC-3SMD, DHCP is enabled by default. To switch to a
static IP address, touch IP Address Settings on the “Ethernet Setup” screen, to
display the “Edit IP Settings” screen, shown in the following illustration.
“Edit IP Settings” Screen
Touch the Enabled/Disabled button to toggle between DHCP enabled and disabled.
Then touch the field for the Static IP Address, Static Subnet Mask or Static Default
Gateway you wish to enter. The on-screen keyboard will appear. After entering the
addresses, touch Save to add the entries or Cancel to cancel them.
On the “Edit IP Settings” screen, touch Edit DNS Servers >> to display the screen
for editing these addresses, which is shown in the illustration below.
“Edit IP Settings” Screen (DNS Servers)
6 •Isys®2.8” Touch Screens: TPMC-3SM & TPMC-3SMD Configuration Guide – DOC. 7269A

Crestron TPMC-3SM & TPMC-3SMD Wall Mount & Designer Touch Screens
Touch Save to keep new settings or Cancel to cancel them. Touch Back on the
“Ethernet Setup” screen to return to the “Panel Setup Options” screen.
Standby Setup
On the “Panel Setup Options” screen, touch Standby Setup to display the “Standby
Timeout” screen, shown in the following illustration.
“Standby Timeout” Screen
The “Standby Timeout” screen provides controls to adjust Standby Timeout from 0
to 120 minutes. Touch Back to return to the “Panel Setup Options” screen or touch
Key Wake Options to display the “Key Wake Options” screen, shown in the
following illustration.
“Key Wake Options” Screen
This screen provides controls for turning the Hardkey press wakes the LCD from
STANDBY and Key backlight state when in STANDBY functions ON or OFF. Touch
Back to return to the “Standby Timeout” screen, then touch Back to return to the
“Panel Setup Options” screen.
Configuration Guide – DOC. 7269A Isys®2.8” Touch Screens: TPMC-3SM & TPMC-3SMD •7

Wall Mount & Designer Touch Screens Crestron TPMC-3SM & TPMC-3SMD
Display Settings
On the “Panel Setup Options” screen, touch Display Settings to display the “Display
Settings” screen. The “Display Settings” screens on the TPMC-3SM and
TPMC-3SMD are different, as noted below.
TPMC-3SM On the TPMC-3SM, the “Display Settings” screen, shown in the illustration below,
provides controls to adjust LCD Brightness and a Key Backlight Settings button to
access the “Key Backlight Settings” screen.
TPMC-3SM “Display Settings” Screen
TPMC-3SM “Key Backlight Settings” Screen
The “Key Backlight Settings” screen provides controls for Red LED Brightness and
Green LED Brightness. There is also a Key Wake Options button for accessing the
“Key Wake Options” screen, shown at the bottom of page 7 and a Key Color
Selection button for accessing the TPMC-3SM’s “LED Color Settings” screen,
shown in the illustration at the top of the following page.
8 •Isys®2.8” Touch Screens: TPMC-3SM & TPMC-3SMD Configuration Guide – DOC. 7269A

Crestron TPMC-3SM & TPMC-3SMD Wall Mount & Designer Touch Screens
TPMC-3SM “LED Color Settings” Screen
The TPMC-3SM’s “LED Color Settings” screen provides control for selection of
Left Key LED Color and Right Key LED Color as well as controls for turning each of
the LEDs Off.
Touch Back to return to the “Key Backlight Settings” screen, then touch Back to
return to the “Display Settings” screen. Touch Back again to return to the “Panel
Setup Options” screen.
TPMC-3SMD On the TPMC-3SMD, the “Display Settings” screen, shown in the illustration below,
provides controls for LCD Brightness and Keypad Backlight Brightness. There is
also a Key Wake Options button to access the “Key Wake Options” screen, shown
at the bottom of page 7 and a Key Color Selection button to access the
TPMC-3SMD’s “LED Color Settings” screen, shown in the illustration at the top of
the following page.
TPMC-3SMD “Display Settings” Screen
Configuration Guide – DOC. 7269A Isys®2.8” Touch Screens: TPMC-3SM & TPMC-3SMD •9

Wall Mount & Designer Touch Screens Crestron TPMC-3SM & TPMC-3SMD
TPMC-3SMD “LED Color Settings” Screen
The TPMC-3SMD’s “LED Color Settings” screen provides control for selection of
Left Key LED Color and Right Key LED Color (i.e., the White button turns the LED
on) as well as controls for turning each of the LEDs Off.
Touch Back to return to the “Display Settings” screen, then touch Back to return to
the “Panel Setup Options” screen.
System Messages Disabled/Enabled
On the “Panel Setup Options” screen, the System Messages Disabled button toggles
between this state and System Messages Enabled, allowing you to turn system
messages on or off. By default, system messages are disabled.
About
On the “Panel Setup Options” screen, touch About to display the “About the
TPMC-3SM” (or “About the TPMC-3SMD”) screen. This screen displays
information about the firmware and operating system versions in your unit.
Touch Back to return to the “Panel Setup Options” screen.
10 •Isys®2.8” Touch Screens: TPMC-3SM & TPMC-3SMD Configuration Guide – DOC. 7269A

Crestron TPMC-3SM & TPMC-3SMD Wall Mount & Designer Touch Screens
Diagnostics
On the “Panel Setup Options” screen, touch Diagnostics to display the “Diagnostics”
screen, shown in the following illustration.
“Diagnostics” Screen
The “Diagnostics” screen displays information about the Total RAM and Free RAM
in your TPMC-3SM or TPMC3SMD. It also provides Keypad Test, Touch Test and
Display Test Patterns buttons to access the “Keypad Test”, touch test and “Test
Patterns” screens, respectively.
Keypad Test
From the “Diagnostics” screen, touch Keypad Test to display the “Keypad Test”
screen, shown in the illustration below.
“Keypad Test” Screen
The “Keypad Test” screen can be used to test the function of the four hard key push
buttons below the screen and the two backlit buttons on either side of the top of the
Configuration Guide – DOC. 7269A Isys®2.8” Touch Screens: TPMC-3SM & TPMC-3SMD •11

Wall Mount & Designer Touch Screens Crestron TPMC-3SM & TPMC-3SMD
screen. When a button is pressed, its corresponding indication on the screen will
light. Touch Back to return to the “Diagnostics” screen.
Touch Test
From the “Diagnostics” screen, touch Touch Test to display the touch test screen,
shown in the illustration below.
Touch Test Screen
The touch test screen contains a Calibrate button to initiate touch screen calibration
and a Return button to return to the “Diagnostics” screen.
During touch screen calibration, a crosshair will appear at the center of the screen.
Touch the center of the crosshair, which will then move to the lower right part of the
screen. Touch the center of the crosshair and it will move to another part of the
screen. Continue touching the center of the crosshair until calibration is complete.
NOTE: When touching the screen during calibration, be as accurate as possible.
Use the tip of a capped pen or the eraser end of a pencil.
12 •Isys®2.8” Touch Screens: TPMC-3SM & TPMC-3SMD Configuration Guide – DOC. 7269A

Crestron TPMC-3SM & TPMC-3SMD Wall Mount & Designer Touch Screens
Display Test Patterns
From the “Diagnostics” screen, touch Display Test Patterns to display the “Test
Patterns” screen, shown in the illustration below.
“Test Patterns” Screen
The “Test Patterns” screen contains buttons for selecting the different available test
patterns: Display Color Bars, Display Vertical Lines, Display Gray Scale,
Display Grid Pattern and Display Test Pattern. Touch Back to return to the
“Diagnostics” screen, then touch Back to return to the “Panel Setup Options” screen.
User Project Mode Off/On
NOTE: TPMC-3SM only; this is not applicable to the TPMC-3SMD.
On the “Panel Setup Options” screen, the User Project Mode Off button toggles
between this state and User Project Mode On. User Project Mode Off is the
default state for using the TPMC-3SM with the Fusion RV™ Interface. For more
information, refer to the latest version of the TPMC-3SM Fusion RV Interface Guide
(Doc. 7268), which is available from the Crestron®Web site at
www.crestron.com/manuals.
Save & Exit
On the “Panel Setup Options” screen, touch Save & Exit to save all settings, exit the
setup screens and return to the main project.
Configuration Guide – DOC. 7269A Isys®2.8” Touch Screens: TPMC-3SM & TPMC-3SMD •13

Crestron Electronics, Inc. Configuration Guide – DOC. 7269A
15 Volvo Drive Rockleigh, NJ 07647 (2032521)
Tel: 888.CRESTRON 12.11
Fax: [phone] Specifications subject to
www.crestron.com change without notice.
