Crestron TSW-550/750/1050
5”/7”/10.1” Touch Screens
Configuration Guide

The specific patents that cover Crestron products are listed at patents.crestron.com.
Crestron, the Crestron logo, and Rava are either trademarks or registered trademarks of Crestron Electronics, Inc. in the United States and/or other
countries. Other trademarks, registered trademarks, and trade names may be used in this document to refer to either the entities claiming the marks and
names or their products. Crestron disclaims any proprietary interest in the marks and names of others. Crestron is not responsible for errors in
typography or photography.
This document was written by the Technical Publications department at Crestron.
©2013 Crestron Electronics, Inc.

Crestron TSW-550/750/1050 5”/7”/10.1” Touch Screens
Configuration Guide – DOC. 7366C Contents •i
Contents
5”/7”/10.1” Touch Screens: TSW-550/750/1050 1
Access the Setup Screens........................................................................................................... 1
Configure the Touch Screen ......................................................................................................3
Ethernet Setup ............................................................................................................. 3
IP Table Setup .............................................................................................................4
Audio Setup .................................................................................................................6
Display Setup .............................................................................................................. 7
Standby Timeout ......................................................................................................... 7
Diagnostics ..................................................................................................................8
About ......................................................................................................................... 11
Save & Exit ............................................................................................................... 11

Crestron TSW-550/750/1050 5”/7”/10.1” Touch Screens
Configuration Guide – DOC. 7366C 5”/7”/10.1” Touch Screens: TSW-550/750/1050 •1
5”/7”/10.1” Touch Screens:
TSW-550/750/1050
Access the Setup Screens
The “Setup” menu is the starting point for configuring the TSW-550, TSW-750 and
TSW-1050 touch screens from Crestron®.
NOTE: If no project has been loaded or if an invalid project has been loaded, the
touch screen defaults to the “Setup” menu.
The setup screens enable basic configuration procedures prior to regular operation of
the touch screen.
During regular operation of the touch screen, there are two ways to activate the setup
functions:
1. Place a button on the project main page and assign the reserved join number
(17242) that activates setup.
2. Press hard keys 1, 2, 3 and 4, to the right of the touch screen display, in
sequence twice (i.e., press 1, 2, 3, 4, 1, 2, 3, 4) within a five second period.
Button Numbering
4
3
2
1
The “Setup” menu is displayed.

5”/7”10.1” Touch Screens Crestron TSW-550/750/1050
2•5”/7”/10.1” Touch Screens: TSW-550/750/1050 Configuration Guide – DOC. 7366C
“Setup” Menu
The “Setup” menu is comprised of buttons for Ethernet Setup, IP Table Setup,
Audio Setup, Display Setup,Standby Timeout and Diagnostics. In addition, there
is an About button that provides information about the touch screen and a Save &
Exit button. The functions of each are detailed in the next section of this guide.

Crestron TSW-550/750/1050 5”/7”/10.1” Touch Screens
Configuration Guide – DOC. 7366C 5”/7”/10.1” Touch Screens: TSW-550/750/1050 •3
Configure the Touch Screen
Ethernet Setup
On the “Setup” menu, touch Ethernet Setup to display the “Ethernet Setup” menu.
“Ethernet Setup” Menu
The “Ethernet Setup” menu displays the touch screen’s Mac and IP Address, Subnet
Mask, Def Router, Primary DNS, Secondary DNS, Hostname and Domain. There are
controls for turning DHCP On or Off as well as a Static IP Settings button, which
provides access to controls which allow editing of these settings. This screen also
contains a Link indicator to show the status of the Ethernet connection.
Touch Static IP Settings to display the “Ethernet Setup – Static IPs” screen.
“Ethernet Setup – Static IPs” Screen
To edit the Static IP Address, Static Subnet Mask, Static Default Router, Preferred
DNS or Alternate Preferred DNS, touch the button directly under the label for the
entry to edit. The on-screen numeric keypad opens.

5”/7”10.1” Touch Screens Crestron TSW-550/750/1050
4•5”/7”/10.1” Touch Screens: TSW-550/750/1050 Configuration Guide – DOC. 7366C
On-Screen Numeric Keypad
Use the keypad to make the new entry. Touch the “x” in the text field to clear any
previous entry. Touch to delete the last digit. Touch Save to save a new entry
or to return to the “Ethernet Setup – Static IPs” screen.
After new settings have been saved, touch Reboot to Apply Changes on the
“Ethernet Setup – Static IPs” screen to reboot the touch screen, so the new settings
can take effect.
If not making any changes, touch to return to the “Ethernet Setup” menu.
Touch again to return to the “Setup” menu.
IP Table Setup
On the “Setup” menu, touch IP Table Setup to display the “Ethernet Setup – IP
Table” menu.
“Ethernet Setup –IP Table” Menu

Crestron TSW-550/750/1050 5”/7”/10.1” Touch Screens
Configuration Guide – DOC. 7366C 5”/7”/10.1” Touch Screens: TSW-550/750/1050 •5
The “Ethernet Setup – IP Table” menu displays up to four IP table settings, each of
which has an Online indicator. To add or edit an entry, touch the Add/Edit button to
its left. The “Ethernet Setup – Edit IP Table Entry” screen is displayed.
“Ethernet Setup –Edit IP Table Entry” Screen
Touch the field below CIP ID to display the on-screen hex keypad.
On-Screen Hex Keypad
Use the keypad to make the new entry. Touch the “x” in the text field to clear any
previous entry. Touch to delete the last digit. Touch Save to save a new entry
or to return to the “Ethernet Setup – Edit IP Table Entry” screen.
Touch the field below IP Address/Hostname to display the on-screen keyboard.

5”/7”10.1” Touch Screens Crestron TSW-550/750/1050
6•5”/7”/10.1” Touch Screens: TSW-550/750/1050 Configuration Guide – DOC. 7366C
On-Screen Keyboard
Use the keyboard to make the new entry. Touch Cancel to return to the “Ethernet
Setup – Edit IP Table Entry” screen. Touch the “x” in the text field to clear any
previous entry. Touch to delete the last digit. Touch Save to save a new entry
and return to the “Ethernet Setup – Edit IP Table Entry” screen.
On the “Ethernet Setup – Edit IP Table Entry” screen, touch Save Entry to save the
current entry or Delete Entry to clear it.
If not making any changes, touch to return to the “Ethernet Setup –IP
Table” menu.
Touch again to return to the “Setup” menu.
Audio Setup
On the “Setup” menu, touch Audio Setup to display the “Audio Setup” screen.
“Audio Setup” Screen
The “Audio Setup” screen provides controls for muting (or unmuting) the audio,
adjusting level for both Master Volume and Media Volume, as well as a control for

Crestron TSW-550/750/1050 5”/7”/10.1” Touch Screens
Configuration Guide – DOC. 7366C 5”/7”/10.1” Touch Screens: TSW-550/750/1050 •7
playing a test .wav file. The Media Volume controls adjust H.264 streaming media
level in relation to the Master Volume controls.
Touch to return to the “Setup” menu.
Display Setup
On the “Setup” menu, touch Display Setup to enter the “Display Setup” screen.
“Display Setup” Screen
The “Display Setup” screen provides controls for LCD (Screen) Brightness and On
and Off controls for Hard Key Wakes LCD.
Touch to return to the “Setup” menu.
Standby Timeout
On the “Setup” menu, touch Standby Timeout to display the “Standby Timeout”
screen.
“Standby Timeout” Screen

5”/7”10.1” Touch Screens Crestron TSW-550/750/1050
8•5”/7”/10.1” Touch Screens: TSW-550/750/1050 Configuration Guide – DOC. 7366C
The “Standby Timeout” screen provides controls to adjust standby timeout from 0 to
120 minutes.
Touch to return to the “Setup” menu.
Diagnostics
On the “Setup” menu, touch Diagnostics to display the “Diagnostics” menu.
“Diagnostics” Menu
The “Diagnostics” menu displays the CPU temperature, Available Memory and
contains controls to run a Keypad Test, Touch Test,Rava Test and Mic Test. In
addition there are controls to initiate touch screen calibration and to open various test
screens. These are explained in the paragraphs that follow.
Keypad Test
On the “Diagnostics” menu, touch Keypad Test to display the “Diagnostics –
Keypad Test” screen.
“Diagnostics – Keypad Test” Screen

Crestron TSW-550/750/1050 5”/7”/10.1” Touch Screens
Configuration Guide – DOC. 7366C 5”/7”/10.1” Touch Screens: TSW-550/750/1050 •9
The “Diagnostics - Keypad” screen can be used to test the function of the hard key
push buttons on the right side of the screen. When a button is pressed, its
corresponding indication on the screen lights.
Touch to return to the “Diagnostics” menu.
Touch Test
On the “Diagnostics” menu, touch Touch Test to display the touch test screen.
Touch Test Screen
The touch test screen can be used to test the function of the screen. When a location
button (the “x” buttons or the “o” button) is touched, its indication on the screen
lights. This screen also contains a Calibrate button to initiate touch screen
calibration.
During touch screen calibration, a crosshair appears at the center of the screen.
Touch the center of the crosshair, which then moves to the upper left part of the
screen. Touch the center of the crosshair and it moves to another part of the screen.
Continue touching the center of the crosshair until calibration is complete.
NOTE: When touching the screen during calibration, be as accurate as possible.
Touch to return to the “Diagnostics” menu.
Calibrate
On the “Diagnostics” menu, touch Calibrate to initiate the screen calibration
procedure. Refer to “Touch Test” above for details.

5”/7”10.1” Touch Screens Crestron TSW-550/750/1050
10 •5”/7”/10.1” Touch Screens: TSW-550/750/1050 Configuration Guide – DOC. 7366C
Test Patterns
On the “Diagnostics” menu, touch Test Patterns to display the “Diagnostics - Test
Patterns” screen.
“Diagnostics - Test Patterns” Screen
The “Diagnostics - Test Patterns” screen contains buttons for selecting the different
available test patterns: Display Color Bars, Display Vertical Lines, Display Gray
Scale, Display Grid Pattern and Display Test Pattern.
Touch to return to the “Diagnostics” menu.
Rava Test
On the “Diagnostics” menu, touch Rava Test to display the “Diagnostics – Rava”
screen.
“Diagnostics - Rava” Screen
The “Diagnostics - Rava” screen provides controls for testing the use of Crestron’s
Rava™ SIP Intercom with the TSW-550/750/1050. They can be used to test projects
and settings. If the intercom works but the project does not, there is an issue with the
project; if the intercom does not work, there is an issue with the settings.

Crestron TSW-550/750/1050 5”/7”/10.1” Touch Screens
Configuration Guide – DOC. 7366C 5”/7”/10.1” Touch Screens: TSW-550/750/1050 •11
Touch to return to the “Diagnostics” menu.
Mic Test
On the “Diagnostics” menu, touch Mic Test to begin a microphone test. The touch
screen records audio for five seconds and then plays back the recorded sound.
The built-in microphone (located in the lower right corner of the touch screen) will
be used to record your voice and play it back to confirm the microphone is
functioning. When playback is finished, the display returns to the “Diagnostics”
menu.
Touch to return to the “Setup” menu.
About
On the “Setup” menu, touch About to display the “About” screen.
“About” Screen
The “About” screen displays information about the touch screen, including the
currently loaded firmware and operating system versions.
Touch to return to the “Setup” menu.
Save & Exit
On the “Setup” menu, touch Save & Exit to save all settings, exit the setup screens
and return to the main project.
