INSTRUCTION MANUAL
MODEL 2117-7172 Up/Downconverter
TABLE OF CONTENTS PAGE
Warranty 2
1.0 General 3
1.1 Equipment Description 3
1.2 Technical Characteristics 4
2.0 Installation 5
2.1 Mechanical 5
2.2 Front & Rear Inputs and Outputs 6
2.3 Available Options/Pinouts 7
2.4 Installation/Operation 8
2.5 Use Information 9
WARRANTY - The following warranty applies to all Cross Technologies, Inc. products.
All Cross Technologies, Inc. products are warranted against defective materials and
workmanship for a period of one year after shipment to customer. Cross Technologies,
Inc.’s obligation under this warranty is limited to repairing or, at Cross Technologies, Inc.’s
option, replacing parts, subassemblies, or entire assemblies. Cross Technologies, Inc. shall
not be liable for any special, indirect, or consequential damages. This warranty does not
cover parts or equipment which have been subject to misuse, negligence, or accident by the
customer during use. All shipping costs for warranty repairs will be prepaid by the
customer. There are not other warranties, express or implied, except as stated herein.
CROSS TECHNOLOGIES, INC.
6170 Shiloh Road
Alpharetta, Georgia 30005
[phone]
FAX [phone]
Toll Free 888-900-5588
WEB www.crosstechnologies.com
E-MAIL [email protected]
2117-7172 Manual Page 2 11/14/19

MODEL 2117-7172 Up/Downconverter
1.0 General
The 2117-7172 Up/Downconverter converts 1.95 - 2.05 GHz to 7.15 - 7.25 GHz and 7.15-7.25 GHz to 1.55 -
1.65 GHz, with non-inverting spectrums. Front panel LEDs provide indication of DC Power, External 10 MHz,
and PLL Alarm. The gain is +20 dB for the upconverter and -20 dB for the downconverter. Connectors are
Type N female for the RF output and input, BNC female for the L-band input and output and external reference
input and reference output. A three-way switch controls which 10 MHz reference is being used. In the AUTO
position, the internal reference is used unless a +3 dBm ± 3 dB, 10MHz reference signal is connected to the
external reference input. The 2117 is powered by a 100-240 ± 10% VAC power supply, and in a 1 3/4” X 19” X
19” rack mount chassis.
MODEL 2117
CROSS TECHNOLOGIES INC.
EXT
10MHZ POWERALARM
UP/DOWNCONVERTER
FRONT PANEL
AC
GND
J8
J2
EXT REF
IN REF OUT
INT EXTAUTO
S1 J112 J11
MONITOR
AND
CONTROL
15 234 6
78
9
J111
RF2 IN RF2 OUT
J102J101
RF1 OUT RF1 IN
DOWNCON UPCONV
REAR PANEL
FIGURE 1.1 Model 2117-7172 Front and Rear Panels
2117-7172
Up/Dowconverter
Block Diagram
10 MHz
To PLLs
EXT 10 M
10 M
MON
1.95 to 2.05
GHz IN
RF2 In
7.15 to 7.25 GHz BP 2.05 GHz LP
7.15 to 7.25
GHz OUT
RF2 Out
5.20 GHz
7.15 to 7.25
GHz IN
RF1 In
1.55 to 1.65
GHz OUT
RF1 Out
7.15 to 7.25 GHz BP
5.60 GHz
1.65 GHz LP
Upconverter
Dowconverter
ATT. ATT.
FIGURE 1.2 Model 2117-7172 Up/Downconverter Block Diagram
2117-7172 Manual Page 3 11/14/19

1.2 Technical Characteristics
TABLE 1.0 2117-7172 Up/Downconverter Specifications*
EQUIPMENT SPECIFICATIONS*
SPECIFICATIONS*
Input
Input Characteristics
UP
DOWN
Impedance/Return Loss 50Ω/14 dB 50Ω/14 dB
Frequency 1.95-2.05 GHz 7.15-7.25 GHz
Noise Figure, Max. 20 dB @ max gain 25 dB @ max gain
Input Level range -40 to -20 dBm -20 to 0 dBm
Output
Output Characteristics
Impedance/Return Loss 50 Ω/14 dB 50 Ω/14 dB
Frequency (GHz) 7.15-7.25 GHz 1.55-1.65 GHz
Output Level Range -20 to 0 dBm -40 to -20 dBm
1 dB comp, max gain +10 dBm -10 dBm
Mute @ 0 dBm out >50 dB N/A
Channel
Channel Characteristics
Gain, max. at Fc, fixed +20 ±2 dB -20 ±2 dB
Image Rejection >60 dBC >60 dBC
Spurious, Inband, sig. rel. <-50 dBC, 0dBm <-50 dBC, -5dBm
Spurious, Inband, sig. ind. <-50 dBC, Gmax <-50 dBC, Gmax
S
p
urious, Out of band
<-50 dBm, Gmax <-50 dBm, Gmax
2 tone 4MHz; Max -10 ea <-50 dBC,Gmax <-50 dBC,Gmax
Frequency Resp. band ±1.5 dB ±1.5 dB
Frequency Resp. 40 MHz ± 0.5 dB ± 0.5 dB
Frequency Sense non-inverting non-inverting
LO Characteristics
LO Frequency Downconverter -5.60 GHz; Upconverter - 5.20 GHz
Frequency Accuracy ± 0.01 ppm max over temp internal reference; external reference input
10 MHz Level +3 dBm, ± 3dB, 75 ohms, External In or Internal out
-110-100-85-80-70
1MHz100kHz10kHz1kHz100 MHz
dBC/Hz
Phase Noise
@
Fre
q
(
Hz
)
Controls, Indicators
INT/AUTO/EXT Switch Selects internal or external 10 Mhz (rear panel DP3T switch)
Ext 10 MHz Yellow LED, indicates external 10 MHz reference selected
PLL Alarm Red LED, External contact closure
Power Green LED
Other RF1 In, RF2 Out N-Type (female), 50Ω
RF1 Out, RF2 In BNC, 50Ω, female (see TABLE 2.2 for other options)
10 MHz Connectors BNC (female), 75Ωconnector; works with 50Ωor 75Ω
Alarm Connector DB9, female - NO or NC contact closure on Alarm
Size 19 inch Standard Chassis 1.75”high X 14.0” deep
Power 100-240 ± 10% VAC, 47-63 Hz, 50 watts maximum
Options
Connector Options See TABLE 2.2
*+10˚C to +40˚C; Specifications subject to change without notice.
2117-7172 Manual Page 4 11/14/19

2.0 Installation
2.1 Mechanical - The 2117-7172 consists of one RF PCB housed in a 1 RU (1 3/4 inch high) by 14 inch deep
chassis. A switching, ± 12, +24, +5 VDC power supply provides power for the assemblies. The 2117-7172 can
be secured to a rack using the 4 holes on the front panel. Figure 2.0 shows how the 2117-7172 is assembled.
1
PS IN
PIN 1, +12 VDC
PIN 2, +5 VDC
PIN 3, +5 VDC
PIN 4, GROUND
PIN 5, GROUND
PIN 6, -12 VDC
PIN 7, +24 VDC
PIN 8, +24 VDC
POWER
SUPPLY
FIGURE 2.0 2117-7172 Mechanical Assembly
2117-7172 Manual Page 5 11/14/19

2.2 Rear Panel Input/Output Signals - Figure 2.1 shows the input and output connectors on the rear panel.
INT AUTO EXT
GND
J102
AND
MONITOR
CONTROL
J8
J2 - EXT 10 MHz INPUT
BNC (Female), 75Ωinsert
external 10 MHz reference
here
(
3 dBm
± 3 dB)
J11 - ALARM
DB9 (Female)
connector.
See table 2.1
1
5 23
4
6
78
9
J14 - Ethernet Connection
RJ45 Ethernet Connector
(option -W8, 18, W28).
J8-10 MHz OUTPUT
BNC (Female), 75Ω
J101- RF1 OUTPUT
BNC (Female), 50Ω
1.55 to 1.65 GHz
-40 to -20 dbm si
g
nal
J102 - RF1 IN
N-Type Female, 50Ω
7.15 to 7.25 GHz
-20 to 0 dbm max. signal
J112-RF2 OUT
N-Type Female, 50Ω
7.15 to 7.25 GHz,
-20 to 0 dBm max signal.
See table 2.2 for other
connection options.
J14 S1
S1 - 10MHz SWITCH
3 position switch INT selects 10MHz
ref. Auto selects internal10MHZ ref.
unless a 0 dBm ± 3 dB 10 MHz
signal is inserted on J2 EXT selects
external 10MHz reference from J2.
J2 J101 J111 UPCON
J112
J111-RF2 IN
1.95 to 2.05 GHz
-40 to -20 dbm
max in
p
ut si
g
nal
RF2 IN
RF2 OUT
J11
RF1 IN
DOWNCON
J102
RF1 OUT
EXT REF
IN RF
OUT
AC
AC INPUT
100-240 VAC, 47-60 Hz
Uses 2 amp Slow Blo,
5mm fuse.
Shown below (Option P48) - Rear Panel Input/Output Signals
with Option P48, 48 VDC nominal 36-72 VDC, 2.5A maximum.
INT AUTO EXT
GND
J102
AND
MONITOR
CONTROL
J8
1
5 23
4
6
78
9
36 TO 72 VDC
• •
• •
DC INPUT
1
23
4
J14 S1 J2 J101 J111 UPCON
J112
RF2 IN
RF2 OUT
J11
RF1 IN
DOWNCON
J102
RF1 OUT
EXT REF
IN RF
OUT
DS2 - ALARM LED
Lights RED when PLL
comes out of lock.
DS1 - POWER LED A
Lights GREEN when DC voltage is
present from AC power supply.
DS3 - EXT 10MHZ LED
Lights YELLOW when external
10MHz reference is active.
POWER
EXT
10MHZ ALARM
FIGURE 2.2 2117-7172 Front Panel Controls and Indicators
2117-7172 Manual Page 6 11/14/19

TABLE 2.1 JJ11
TABLE 2.1 J11 Pinouts (DB9)
Pin Function
1 Not Used
2 Not Used
3 Not Used
4 Not Used
5GND
6 Alarm Relay: Common
7 Alarm Relay: Normally Open
8 Not Used
9 Alarm Relay: Normally Closed
TABLE 2.3 DDC1
TABLE 2.3 DC1 Pinouts
Pin# Function
1 Minus DC input
2NC
3 Plus DC input
4NC
Shell Ground
FIGURE 2.1 2117-7172 Rear Panel I/Oʼs FIGURE 2.3 2117-7172 DC1 Pinouts
TABLE 2.2 Available Options
P48 = 48 V DC Power Supply
R = Redundant AC Power Supply
Available Connector Options
NF 50ΩN-Type (RF), 75ΩF-Type (L-Band)
N50ΩN-Type (RF), 75ΩBNC (L-Band)
NN 50ΩN-Type (RF), 50ΩN-Type (L-Band)
SS 50ΩSMA (RF), 50ΩSMA (L-Band)
FIGURE 2.2 2117-7172 Available Options
AC Fuse - 2 amp slow blow (Type T),
5 mm X 20 mm
FUSE DRAWER
SPARE FUSE
~
INPUT
100-240± 10%VA
C
47-63 Hz
2A MAX
FUSE
TYPE T 2A GDC
250 VOLT
FOR 100 - 240 V~
~
FIGURE 2.3 Fuse Location and Spare Fuse
2117-7172 Manual Page 7 11/14/19

2.4 Installation / Operation
2.4.2 Installing and Operating the 2117-7172 Downconverter
1.) Connect a -20 dBm to -0 dBm signal to RF1 7.15 to 7.25 GHz INPUT, J102 (Figure 2.1).
2.) Connect the, RF1 OUT, J101 to the external equipment.
3.) Connect 100-240 ± 10% VAC, 47 - 63 Hz to AC connector on the back panel.
4.) Be sure DS1 (green, DC Power) is on and DS2 (red, Alarm) is off (Figure 2.2).
5.) Select either INT (for internal 10MHz ref), AUTO (for internal 10MHz ref UNLESS a external
10MHz, 0 dBm signal is connected to J2), or EXT (for external 10MHz, 0 dBm ref that is inserted
at J2) on rear panel switch S1 (Figure 2.1).
6.) If EXT is selected or AUTO is selected and there is a 10MHz, 0 dBm signal at J2,
check that DS3 (yellow, Ext 10 MHz) is on (Figure 2.2).
7.) Check that a 10MHz, 0 dBm ±3 dB signal is present at the 10 MHz REF OUTPUT (J8)
(Figure 2.1).
8.) AC Fuse - The fuse is a 5 mm X 20 mm, 2 amp slow blow (Type T) and is inserted in the far slot
in the drawer below the AC input as shown in Figure 2.3. There is a spare fuse in the near slot.
If a fuse continues to open, the power supply is most likely defective.
2.4.3 Installing and Operating the 2117-7172 Upconverter
1. Connect 1.95 to 2.05 GHz -40 dBm to -20 dBm signal to RF2 IN, J111 (Figure 2.1).
2. Connect the RF2 OUTPUT, J112, to the external equipment.
3. Connect 100-240 ±10% VAC, 47 - 63 Hz to AC connector on the back panel.
4. Be sure DS1 (green, DC Power) is on and DS2 (red, Alarm) is off (Figure 2.2).
5. Select either INT (for internal 10MHz ref), AUTO (for internal 10MHz ref UNLESS a external 10MHz,
3 dBm signal is connected to J2), or EXT (for external 10MHz, 3 dBm ref that is inserted at J2) on rear
panel switch S1 (Figure 2.1).
6. If EXT is selected or AUTO is selected and there is a 10MHz, 3 dBm signal at J2, check that DS3
(yellow, Ext 10MHZ) is on (Figure 2.2).
7. Check that a 10MHz, 3 dBm ±3 dB signal is present at the 10MHZ REF OUTPUT (J8) (Figure 2.1).
8. AC Fuse - The fuse is a 5 mm X 20 mm, 2 amp slow blow (Type T) and is inserted in the far slot in the
drawer below the AC input as shown in Figure 2.3. There is a spare fuse in the near slot. If a fuse
continues to open, the power supply is most likely defective.
Use Information
2117-7172 Manual Page 8 11/14/19

A.Rack-Mounting - To mount this equipment in a rack, please refer to the installation instructions
located in the user manual furnished by the manufacturer of your equipment rack.
B. Mechanical Loading - Mounting of equipment in a rack should be such that a hazardous condition
does not exist due to uneven weight distribution.
C.Elevated Operating Ambient Temperature - If installed in a closed or multi-unit rack assembly,
the operating ambient temperature of the rack may be greater than room ambient temperature.
Therefore, consideration should be given to Tmra. (Maximum Recommended Ambient Temperature)
D. Reduced Air Flow - Installation of the equipment in a rack should be such that the amount of air flow
required for safe operation of the equipment is not compromised. Additional space between units
may be required.
E. Circuit Overloading - Consideration should be given to the connection of the equipment to the supply
circuit and the effect that overloading of circuits could have on over current protection and supply wiring.
Appropriate consideration of equipment name plate rating should be used when addressing this concern.
F. Reliable Earthing - Reliable earthing of rack-mounted equipment should be maintained.
Particular attention should be given to supply connections other than direct connection to the
Branch (use of power strips).
G. Top Cover - There are no serviceable parts inside the product so, the Top Cover should not be removed.
If the Top Cover is removed the ground strap and associated screw MUST BE REINSTALLED
prior to Top Cover screw replacement. FAILURE TO DO this may cause INGRESS and/or EGRESS
emission problems.
2117-7172 Manual Page 9 11/14/19

CROSS TECHNOLOGIES, INC.
6170 Shiloh Road
Alpharetta, Georgia 30005
[phone]
FAX [phone]
Toll Free 888-900-5588
WEB www.crosstechnologies.com
E-MAIL [email protected]
2117-7172 Manual Page 10 11/14/19
