Crosswater Berea 11-02-T User manual

15121412-A
11-02-T-PC
11-02-T-SN
11-02-T-PN
11-02-T-BZ
15121412-A 4
Applicable Standards/Codes
Installation Dimensions
IAPMO certified to meet or exceed the following:
• ASME A112.18.1/CSA B125.1
• Uniform Plumbing Code
• National Plumbing Code of Canada
• ADA Compliant
5 1/8
3 1/4
2 1/82 1/2
3 29/32
7 5/8
9
3/4-14 NPT
19" Max 19" Max
1 15/32
1 1/16-1 9/16
Berea Deck Tub Faucet
Trim 11-02-T
Installation Instructions
Before beginning installation, check for any damage
that may have occurred during transport.
Note: Damage claims cannot be made during or
after installation.
For ease of installation you will need:
 To read the installation instructions completely before beginning.
 To read all warnings, care, and maintenance information.
Anti-scald protection is the responsibility of the installer and
according to applicable codes.

11-02-T 11-02-T-PC
11-02-T-SN
11-02-T-PN
11-02-T-BZ
Installation Instructions
15121412-A 2 15121412-A3
Replacement Parts
NO. Description Part NO.
1 Washer, Key and Aerator 9Q1110PL
2 Handle Assembly(cold) 9Q1125
3 Handle Assembly(hot) 9Q1124
4 Set Screw & Allen Key 9Q1350NT
2
1
4
3
 Only use a soft, dampened sponge or cloth to clean and polish the fixture.
 Wipe fixtures and the immediate areas clean and rinse completely with water immediately after installation and after
applying any cleaner.
 If you are using a cleaning compound on or close to the product, please test the compound on a hidden area of the
trim to ensure it will not damage the finish.
 Do not allow cleaners to soak anywhere on the product.
Cleaning Instructions
123
Remove the mud guards from the
spout nipple assembly, the hot and
cold valves.
4
Place the spout washer under the
spout and install spout on spout
nipple assembly. Be sure the spout is
firmly resting on the deck and secure
the spout. Secure the spout with the
setscrew.
Place the “O” ring over the cold valve.
Align the handle and place the handle
and escutcheon assembly into the
valve. Secure the assembly by turning
the escutcheon clockwise. Repeat for
hot valve.
Turn water supply on.
5
Remove the aerator with the supplied
key. Turn the faucet handles on full
for one minute to flush debris.
6
Re-install the aerator with key.
7
Installation complete.

11-02-T-PC
11-02-T-SN
11-02-T-PN
11-02-T-BZ
Installation Instructions
15121412-A 2 15121412-A3
Replacement Parts
NO. Description Part NO.
1 Washer, Key and Aerator 9Q1110PL
2 Handle Assembly(cold) 9Q1125
3 Handle Assembly(hot) 9Q1124
4 Set Screw & Allen Key 9Q1350NT
2
1
4
3
Rinse away any traces of soap and gently dry with a clean, soft cloth after each use. Rinse completely with water and
dry any overspray. This will maintain the finish and avoid water spotting.
To remove mineral deposits, use a 50/50 solution of white vinegar and water. Do not allow the solution to soak on the
product.
Simichrome Polish® contains a protective film to enhance maintenance and is helpful in preventing water spot buildup.
Follow instructions to ensure optimum results.
Never use an abrasive material such as a brush or scouring pad to clean the surface. The use of abrasive cleaners,
cleansers or disinfectants will alter the surface finish and void the warranty.
Do not allow certain materials such as toothpaste, cologne, shaving cream, nail polish remover, vinegar, wine, drain
and glass cleaners to remain on the surface. Prolonged contact will alter surface finishes and void the warranty.
We DO NOT recommend using any household cleaners as many can cause damage to the finish.
Please see the website for care instructions for specific finishes.
Cleaning Instructions
123
Remove the mud guards from the
spout nipple assembly, the hot and
cold valves.
4
Place the spout washer under the
spout and install spout on spout
nipple assembly. Be sure the spout is
firmly resting on the deck and secure
the spout. Secure the spout with the
setscrew.
Place the “O” ring over the cold valve.
Align the handle and place the handle
and escutcheon assembly into the
valve. Secure the assembly by turning
the escutcheon clockwise. Repeat for
hot valve.
Turn water supply on.
5
Remove the aerator with the supplied
key. Turn the faucet handles on full
for one minute to flush debris.
6
Re-install the aerator with key.
7
Installation complete.
11-02-T

Series # 11
TRIM ONLY
Deck Tub Set Trim
11-02-T-PC
11-02-T-SN
11-02-T-PN
11-02-T-BZ
15121412-A
Installation Instructions
15121412-A 4
Applicable Standards/Codes
Installation Dimensions
For easy installation of your faucet you will need:
 To read all the installation completely before beginning.
 To read all warnings, care, and maintenance information.
IAPMO certified to meet or exceed the following:
• ASME A112.18.1/CSA B125.1
• Uniform Plumbing Code
• National Plumbing Code of Canada
• ADA Compliant
5-1/8
3-1/42-1/82-1/2
3-7/8"
7-5/8
9
3/4-14 NPT
19" Max 19" Max
1-1/2"
1" - 1-1/2"
11-02-T
Warranty - This Crosswater London product is covered by a limited lifetime warranty. For full details, terms and conditions please visit our website.
For further information contact:Crosswater London, 393 Fortune Blvd., Milford, MA 01757
Toll free number: 844-XWATER-1 (844-992-8371) tel: [phone] fax: [phone]
www.crosswaterlondon.com
email: [e-mail]
Issue date: 18112019
