CYP PU-103 User manual

PU-103
HDMI v1.3 to
CAT6 Transmitter
Operation Manual
PU-103

TABLE OF CONTENTS
1. Introduction.................................................................................1
2. Main Features............................................................................. 1
3. Package Contents..................................................................... 1
4. Operation Controls and Functions............................................1
4.1 Front Panel.............................................................................1
4.2 Rear Panel..............................................................................2
5. Connection and Installation...................................................... 2
6. Specifications............................................................................. 2

1. Introduction
This is the transmitter (Tx) unit of HDMI to CAT6 Solution that can extend
HDMI digital signal through CAT-6 cables. This is compatible to HDMI v1.3
specifications, a cutting edge technology which defines the support to
transfer Deep Color (12 bits/color) video and new lossless compressed
(Dolby TrueHD, Dolby Digital Plus and DTS-HD Master Audio) Digital audio,
with a bandwidth up to 225MHz. The installation of HDMI to CAT6 is easy
and quick, simply place receiver side next to your HDTV source such as a
DVD player, then place the transmitter side next to your display or CAT 6 to
CAT6 repeater unit and get all necessary cables connected and enjoy.
2. Main Features
●Compliant with HDMI 1.3, HDCP 1.1 and DVI1.1 standards.
●Supports digital video formats in Deep Color Mode at up to 36 bits
(12bits/color) and new lossless compressed (Dolby TrueHD, Dolby Digital
Plus and DTS-HD Master Audio) Digital audio .
●Supports CAT-6 cables for data/DDC transmission.
●Supports equalize and recover incoming TMDS data before re-transmitting
them with optimal quality regardless of the incoming signal quality.
●Supports high definition resolution, the input up to 1080p/12bits and output
resolution follows input. The distance table please refers to section 5.
●Support CEC function.
●Easy to install and simple to operate.
3. Package Contents
●HDMI to CAT6 Transmitter.
●5V DC power supply adaptor.
●Operation Manual.
4. Operation Controls and Functions
4.1. Front Panel
1 HDMI input: Connect the HDMI input port to the HDMI or DVI output of your
source equipment such as DVD player or set-top-box.
2 Power: Plug the 5VDC power supply into the unit and connect the
adaptor to AC wall outlet.
1
1
DC 5V
POWER
HDMI INPUT
1 2

2
1 DDC output: Connect the DDC output to the DDC input of the receiver
unit using CAT-6 cable.
2 Video output: Connect the video output to the video input of the receiver
unit using CAT-6 cable.
1 2
VIDEODDC
CAT6 OUTPUT
4.2. Rear Panel
HDMI
HDMI
HDMI LCD TV
PU-103 PU-103
DVD PLAYER
HDMI
Cable
DDC
VIDEO
HDMI
Cable
HDMI
HDMI
5. Connection and Installation
6. Specifications
Input port
Output ports
Power Supply
Dimensions (mm)
Weight(g)
Chassis Material
Silkscreen Color
Operating Temperature
1 x HDMI
1 x CAT-6 output for Video,
1 x CAT6 output for DDC
5V/2.6A DC (US/EU standards, CE/FCC/UL certified)
50(W) x 62(D) x 23(H)
90
Aluminum
Black
0°C ~ 40°C

3

2008.1.14 MPM-CH103TX-UK

PU-103
CAT6 to HDMI
Receiver
Operation Manual
PU-103

TABLE OF CONTENTS
1. Introduction.................................................................................1
2. Main Features............................................................................. 1
3. Package Contents..................................................................... 1
4. Operation Controls and Functions............................................1
4.1 Front Panel.............................................................................1
4.2 Rear Panel..............................................................................2
5. Connection and Installation......................................................2
6. Specifications............................................................................. 2

1. Introduction
This is the Receiver (Rx) unit of CAT6 to HDMI Solution that can receive the
digital signal through CAT-6 cables. This is compatible to HDMI v1.3
specifications, a cutting edge technology which defines the support to
transfer Deep Color (12 bits/color) video and new lossless compressed
(Dolby TrueHD, Dolby Digital Plus and DTS-HD Master Audio) Digital audio,
with a bandwidth up to 225MHz. The installation of CAT6 to HDMI is easy
and quick, simply place receiver side next to your CAT6 transmitter unit,
then place the CAT6 to HDMI transmitter side to your display and get all
necessary cables connected and enjoy.
2. Main Features
●Compliant with HDMI 1.3, HDCP 1.1 and DVI1.1 standards.
●Supports digital video formats in Deep Color Mode at up to 36 bits
(12bits/color) and new lossless compressed (Dolby TrueHD, Dolby Digital
Plus and DTS-HD Master Audio) Digital audio.
●Supports CAT-6 cables of variable types.
●Supports equalize and recover incoming TMDS data before re-transmitting
them with optimal quality regardless of the incoming signal quality.
●Supports high definition resolution, the input up to 1080p/12bits and output
resolution follows input. The distance table please refers to section 5.
●Support CEC function.
●Easy to install and simple to operate.
3. Package Contents
●CAT6 to HDMI Receiver.
●5V DC power supply adaptor.
●Operation Manual.
4. Operation Controls and Functions
4.1. Front Panel
1 Video input: Connect the video input to the video output of the
transmitter unit using CAT-6 cable.
2 DDC input: Connect the DDC input to the DDC output of the transmitter
unit using CAT-6 cable.
1
1
1 2
DDC
CAT6 INPUT
VIDEO

2
1 HDMI output: Connect the HDMI output port to the HDMI or DVI input of
your display.
2 Power: Plug the 5VDC power supply into the unit and connect the
adaptor to AC wall outlet.
1 2
4.2. Rear Panel
HDMI
HDMI
HDMI LCD TV
PU-103 PU-103
DVD PLAYER
HDMI
Cable
DDC
VIDEO
HDMI
Cable
HDMI
HDMI
5. Connection and Installation
6. Specifications
Input ports
Output port
Power Supply
Dimensions (mm)
Weight(g)
Chassis Material
Silkscreen Color
Operating Temperature
1 x CAT-6 input for Video, 1 x CAT6 input for DDC
1 x HDMI
5V/2.6A DC (US/EU standards, CE/FCC/UL certified)
50(W) x 62(D) x 23(H)
96
Aluminum
Black
0°C ~ 40°C
DC 5V
POWER
HDMI OUTPUT

3

2008.1.14 MPM-CH103RX-UK
