CYP PU-515PLTX-1H User manual

PU-515PLTX-1H
HDBaseT™ LITE Transmitter with simultaneous HDMI output
(HDMI, IR & RS-232 with POC, up to 60m)
OPERATION MANUAL

SAFETY PRECAUTIONS
Please read all instructions before attempting to unpack, install or
operate this equipment and before connecting the power supply.
Please keep the following in mind as you unpack and install this
equipment:
•Always follow basic safety precautions to reduce the risk of fi re,
electrical shock and injury to persons.
•To prevent fi re or shock hazard, do not expose the unit to rain,
moisture or install this product near water.
• Never spill liquid of any kind on or into this product.
• Never push an object of any kind into this product through any
openings or empty slots in the unit, as you may damage parts
inside the unit.
• Do not attach the power supply cabling to building surfaces.
• Use only the supplied power supply unit (PSU). Do not use the PSU
if it is damaged.
• Do not allow anything to rest on the power cabling or allow any
weight to be placed upon it or any person walk on it.
• To protect the unit from overheating, do not block any vents or
openings in the unit housing that provide ventilation and allow for
suffi cient space for air to circulate around the unit.
REVISION HISTORY
VERSION NO. DATE DD/MM/YY SUMMARY OF CHANGE
VR0 10/01/14 Preliminary Release

CONTENTS
1. Introduction............................................ 1
2. Applications........................................... 1
3. Package Contents ................................ 1
4. System Requirements............................ 1
5. Features.................................................. 2
6. Operation Controls and Functions....... 3
6.1 Front Panel ........................................3
6.2 Rear Panel.........................................4
6.3 IR Cable Pin Assignment..................5
6.4. D-Sub 9-Pin Defi nitions ....................5
7. Connection Diagram ............................ 6
8. Specifi cations ........................................ 7
8.1 CAT5e/6/7 Cable Specifi cation .....8
9. Acronyms ............................................... 8

1
1
1. INTRODUCTION
The PU-515PLTX-1H Transmitter allows uncompressed HDMI signals and
to be transmitted over a Single CAT5e/6/7 cable. This device allows
the distribution of Video, Audio, Power over Cable (PoC), RS-232 and
2-way IR control functionality over the same CAT5e/6/7 cable. These
combined HDMI and control signals can be transmitted up to lengths
of 60 metres. This variant of the PU-515PL-TX Transmitter has a
simultaneous HDMI output enabling a local HDMI display to be
connected whilst simultaneously distributing the signals over a single
CAT5e/6/7 to a compatible HDBaseT Receiver.
2. APPLICATIONS
• Household entertainment sharing and control
• Lecture room display and control
• Showroom display and control
• Meeting room presentation and control
• Classroom display and control
3. PACKAGE CONTENTS
• HDMI over HDMI & CAT5e/6/7 Transmitter
•IR Blaster x 1
• 3.5mm Phone Jack to RS-232 Cable
• 24V DC Power Adaptor
• Operation Manual
4. SYSTEM REQUIREMENTS
• Source equipment with HDMI output connector
• Display TV/Monitor with HDMI input connector
• HDMI over CAT5e/6/7 Receivers with industry CAT5e/6/7 cables

2
2
5. FEATURES
Note:
1. This system was tested with CAT6/23AWG cables, results may vary
with cables of a different specification.
2. Displaying HDMI 4Kx2K resolution require the standard 4Kx2K HDMI
cable and display in order for proper image displaying.
3. This device obtain the last memory function therefore, the device
will use last CAT5e/6/7 output port's EDID when CAT5e/6/7 output is
not connected to a display after power cycling.
The unit will detect CAT5e/6/7 output's EDID when it obtain a 4Kx2K
EDID and send out the signal accordingly to other output ports. If
the CAT5e/6/7 output is without a 4Kx2K's EDID the unit will detect
all output's EDID and send out the signal that all outputs can
accept.
• HDCP 2.2 Compliant
• HDMI, HDCP, & DVI compliant
• Supports all v1.4 HDMI resolutions plus 4k.
• Supports uncompressed video/audio up to 10.2Gbps
• Simultaneous HDMI and CAT5e/6/7 outputs
• Supports resolutions VGA~WUXGA, 480i~1080p, 4K UHD@24/25/30Hz
(RGB 4:4:4 & YUV 4:2:2), 4K UHD@ 60Hz (YUV 4:2:0),
4K/2K@24/25/30Hz (RGB 4:4:4 & YUV 4:2:2) and 4K/2K@ 60Hz (YUV
4:2:0) dependent upon the output display’s EDID settings)
• Supports LPCM 7.1CH, Dolby TrueHD, Dolby Digital Plus and DTS-HD
Master Audio transmission (32-192kHz sample rate)
• Supports distances up to 60 meters through CAT5e/6/7 cables
• Supports 3D signals

3
3
6. OPERATION CONTROLS AND FUNCTIONS
6.1 Front Panel
HDMI OUT HDMI IN RS232 IN
HDMI to CAT5e/6 with IR/RS232 Transmitter
1 2 3
1HDMI OUT:
Connect to HDMI display for instant image display or cascade
with another family type Transmitter. The unit will detect CAT5e/6/7
output's EDID when it obtain a 4Kx2K EDID and send out the signal
accordingly to other output ports. If CAT5e/6/7 output is without a
4Kx2K's EDID the unit will detect all output's EDID and send out the
signal that all outputs can accept.
This device obtain the last memory function therefore, the device
will use the last CAT5e/6/7 output port's EDID when CAT5e/6/7
output port is not connected after power cycling.
2HDMI IN:
Connect with source equipment such as DVD/Blu-ray or PS3
player.
3RS-232 IN:
Connect to a PC/Laptop or RS-232 enabled device (with supplied
3.5mm Phone Jack to D-Sub 9-Pin female adaptor) to transmit of
RS-232 commands.

4
4
6.2 Rear Panel
POWER
DC 24V
CAT5e/6 OUT
IR 1
BLASTER USB LINK
IR 2
EXTENDER
1 2 3 4 5 6 7
1POWER LED:
Once the power supply is connected the LED will illuminate.
2DC 24V:
Plug the 24V DC power supply into the unit and connect the
adaptor to an AC outlet.
3IR 1 BLASTER:
Connect with the supplied IR Blaster to blast out the IR signal
received from the Receiver side. Place the IR Blaster in direct line-
of-sight of the equipment to be controlled.
4IR 2 EXTENDER:
Connect with the supplied IR Extender to receive IR signal from
Transmitter side and blast out at Receiver side. Ensure that remote
controller being used is within the direct line-of-sight of the IR
Extender.
5USB:
This slot is reserved for fi rmware update only.
6LINK LED:
This LED will illuminate when both the input source and output
display signals are connected through CAT cable. When it blinks
regularly it states the display is NOT sending signals to Receiver but
the Transmitter and Receiver are linked and if it blink irregularly it
states an error has occurred.
7CAT5e/6/7 OUT:
Connect this port to CAT5e/6/7 to HDMI Receiver with CAT5e/6/7
cable to extend the signal up to 60m.

5
5
6.3 IR Cable Pin Assignment
3
1
3
1
2
2
Power 3.3 V
IR Blaster Signal
NC
IR Signal
Power 3.3 V
Grounding
IR Extender
IR Blaster
6.4. D-Sub 9 Pin Defi nitions
Pin Defi ne TX / RX
1 N/C
2TxD/RxD
3RxD/TxD
4 NC
5 GND
6 NC
7 NC
8 NC
9 NC

6
6
7. CONNECTION DIAGRAM
POWER
DC 24V
CAT5e/6 OUT
IR 1
BLASTER USBLINK
IR 2
EXTENDER
HDMI OUTHDMI IN RS232 IN
HDMI to CAT5e/6 with IR/RS232 Transmitter
IR BLASTER
1.5m
60°
IR RECEIVER
7m
3m 3m
60°
m
CAT5e/6 In
Link
IR1 Extender
IR2 Blaster
Power
Blu-ray or PS3 Player
3D TV/Display
HDMI
HDMI
3D TV/Display
PC
RS-232 Cable

7
7
8. SPECIFICATIONS
Video Bandwidth 340Mbps/10.2Gbps
Input ports 1 x HDMI,
1 x 3.5mm Phone Jack for RS-232,
1 x IR IN,
1 x USB (Service only)
Output ports 1 x HDMI,
1 x IR OUT,
1 x CAT5e/6/7
Resolution Up to 4Kx2K (3840x2160@24/25/30Hz/4096x
2160@24Hz)
HDMI Input & Output
Cable Distance
Up to 10m@8 or12-bit 1080p
CAT5e/6/7 Output
Cable Distance
Up to 60 m
IR Frequency 30~50kHz
Power Supply 24V / 1.25A DC (US/EU standards, CE/FCC/
UL certifi ed)
Dimensions 102 mm(W) x 102 mm(D) x 25 mm(H)/
Jacks Excluded
102 mm(W) x 110 mm(D) x 25 mm(H)/
Jacks Included
Weight 244 g
Chassis Material Metal
Silkscreen Color Gray
ESD Protection Human body model:
±8kV (air-gap discharge)
±4kV (contact discharge)
Operating Temperature 0°C ~ 40°C
Storage Temperature -20˚C ~ 60˚C / -4 ˚F ~ 140 ˚F
Relative Humidity 20 ~ 90% RH (non-condensing)
Power Consumption 6.3W
Black

8
8
8.1 CAT5e/6/7 Cable Specifi cation
Cable
Type
Range Pixel clock
rate
Video Data
Rate
Supported Video
CAT5e/6/7 60 m <=225 MHz <=5.3 Gbps
(HD Video)
Up to 1080p, 60 Hz, 36
bits, 3D (data rates
lower than 5.3 Gbps
or below 225MHz
TMDS clock)
40 m >225 MHz > 5.3 Gbps
(Ultra HD
Video)
4K2K, 30Hz video
formats
CAT6/7 60 m >225 MHz > 5.3 Gbps
(Ultra HD
Video)
4K2K, 30Hz video
formats
9. ACRONYMS
ACRONYM COMPLETE TERM
4Kx2K 3840x2160 / 4096x2160
DTS Digital Theater System
EDID Extended Display Identification Data
HDCP High-bandwidth Digital Content Protection
HDMI High-Definition Multimedia Interface
HDTV High-Definition Television

CYP (UK) Ltd., Unit 7, Shepperton Business Park, Govett Avenue, Shepperton,
Middlesex, TW17 8BA
Tel: [phone] | Fax: [phone]
Email: [email protected]
www.cypeurope.com
VR0
