Heater Bermuda
Manual

INFRAREDPATIOHEATER 

SafetyInstructions
andOperationManual


HE94000




















Introduction
Yourinfraredheaterisheatinginthewayofradiation(noneedformedium)soyourinfraredheateriseffective.Becauseitdoesn’t
needtoheattheambientair(medium),itisgoodtobeusedintheopen‐airaswell.

ImportantSafetyInstructions

Whenusingelectricalappliances,basicsafetyprecautionsshouldalwaysbefollowedtoreducetheriskoffire,electricshock,or
injurytopersons,etc.
Readthroughtheoperationandassemblyinstructionsconscientiouslybeforeoperatingtheappliance.
Besuretokeepthemanualinasafeplaceforfuturereference.Ifyoupasstheapplianceon,passontheinstructionstoo.

Readallinstructionsbeforeusingthisheater
Thisheaterishotwheninuse.Toavoidburns,donotletbareskintouchhotsurfaces.Ifprovided,usehandleswhenmoving
thisheater.Keepcombustiblematerials,suchasfurniture,pillows,bedding,papers,clothesandcurtainsatleast0.9mfrom
thefrontoftheheater.
Thisapplianceisnotintendedforusebypersons(includingchildren)withreducedphysical,sensoryormentalcapabilities,or
lackofexperienceandknowledge,unlesstheyhavebeengivensupervisionorinstructionconcerninguseoftheapplianceby
apersonresponsiblefortheirsafety.
Turnofftheelectricity,removetheplugfromtheoutletwhennotinuse

Donottrytorepairbyyourselfwhenitisbroken(suchascord,plugetc),pleasecontacttheserviceagent.
Iftheapplianceislocatedinbathroom,laundryareasandsimilarlocations.Makesuretheplugisnotinthecircumstanceor
takethenecessaryprotectionmeasurestopreventelectricleakageoftheplug
Donotruncordundercarpeting.Donotcovercordwiththrowrugs,runners,orsimilarcoverings.Donotroutecordunder
furnitureorappliances.Arrangecordawayfromtrafficareaandwhereitcannotbetrippedover.
Connecttoproperlygroundedoutletsonly.Todisconnectheater,turncontrolstooff,thenremoveplugfromoutlet.
Aheaterhashotandarcingorsparkingpartsinside.Donotuseitinareaswheregasoline,paint,orflammableliquidsare
usedorstored.
Usethisheateronlyasdescribedinthismanual.Anyotherusenotrecommendedbythemanufacturermaycausefire,
electricshock,orinjurytopersons.
Alwaysplugheatersdirectlyintoawalloutlet/receptacle.Trynotusewithanextensioncordorrelocatablepowertap
(outlet/powerstrip).Evenuse,makesurethecurrentcarryingcapacityandratedvoltagecorrespondtotherelative
regulation
Checkifthevoltageindicatedonthenameplateoftheappliancecorrespondstothelocalmainsvoltagebeforeyouconnect
theappliance.
Theapplianceisnotlocatedimmediatelybelowawallsocket‐outlet.
Thecasingandthefrontcoveroftheappliancebecomeextremelyhotduringoperation.Payattentionthat,nocombustible
materialduetoWindorotherenvironmentalinfluencescoversorobstructstheappliance,suchascurtains,marquees,flags,
plasticfoiletc.Donottouchtheappliance.Caution!Riskofscaldinjury!
Incaseofimproperuse,thereisariskofelectricalshockand/orfirehazard.Operationoftheappliancemustbediscontinued
andremovethemainsplugimmediately.Donottrytorepairtheappliancebyyour‐self.Pleasecontactwiththeserviceagent
orasuitablyqualifiedelectricianformaintenance
Removetheplugfromthepoweroutletandwaituntiltheapplianceissufficientlycooledoffbeforecleaning.
Keepoutofreachofchildren.Inordertokeepchildrenfromthedangersofelectricalappliances,neverleavethem
unsupervisedwiththemachine.Consequently,whenselectingthelocationforyourmachine,dosoinsuchawaythat
childrendonothaveaccesstothemachine.Childrenbeingsupervisednottoplaywiththeappliance.
Theappliancemustonlybemountedbyanauthorizedspecialist,payingattentiontotherelevantregulationsofthepower
supplycompaniesandtheregionalconstructionregulations.
SAVETHESEINSTRUCTIONS







OPERATIONINSTRUCTION
Foradditionalprotectiontheinstallationofaresidualcurrentdevice(RCD)isadvisable.
Removeallpackagematerial(includinganti‐vibrationobjectofthelamp)andchecktheappliance,supplycordandtheplug
forsignsofdamage.
Payattentiontothemountingplaceandallmountingmaterial(dowels,screws).Ensuretheyaresuitableandstableenough
formountingandlastinglyholdingoftheappliance.
Beforemounting,theminimumsafemountingdistancesandtiltanglesshowninthefiguresmustbestrictlyfollowed.
1. Thedistancebetweenthebottomedgeoftheapplianceandthefloormustbeatleast1.8M.
2. Theremustbeadistanceofatleast0.2Mbetweentheapplianceandtheceilings,roofsorothercovers.
3. Theremustbeadistanceofatleast0.5Mateachsidebetweentheapplianceandwallsorthelike.Seefigure2.
4. Recommendeddegreetomountingsurfaceis45°.Seefigure3.
Payattentionthat,theinstallationoftheappliancemustnotaddexcessivewindload.
Fixthemountingbracketonthewallfirst.Ensurethattheplacetobeinstalledissecureandfirm.Orconnecttheapplianceto
thestand.
Theheatersarealsowidelyusedunderparasolwiththehelpofparasolbrackets
Adjustthedesiredangleofradiationandfastenallscrews.Checkregularlythescrews’connection.Mechanicalbearing
pressureandoscillationduetowindorraincouldleadtoloose.
Pluginthepowersource.Thenobserve,whetherduringthefirst10‐15minutestheapplianceworkstrouble‐free.


Figure1:Mountingbracket(wall
bracket)andanchordowelsprovided.
Connectionfromthewalltothe
infraredheater.
Figure2Min.distancetofloor,
ceilingandwall

Figure3:Tiltangle





CleaningandMaintenance
Thisapplianceconsistsofarobustandmaintenance‐freestainlesssteel，aluminiumcasingandaprotectioncover.Nouser
serviceablepartsinside.
Beforecleaning，removetheplugfromthepoweroutletandwaituntiltheapplianceissufficientlycooledoff.
Wipetheapplianceonlywithcleanandlint‐freeclothorasoftbrush.
Neveruseabrasivecleaners,scrubbingbrushesandchemicalcleanersforcleaning!
Canusealcoholtocleantheappliance.
Toprotectagainstelectricalshockanddangeroflife,donotimmersecord,plug,oranypartoftheapplianceinwaterorother
liquid.
Forheatingelementreplacement，pleasecontactthemanufactureroritsserviceagentorasimilarlyqualifiedperson.
anyotherservicecontactwiththeserviceagentorasuitablyqualifiedelectrician.

STORAGE
Donotroutecordwhenheaterstorage,orheaterisnotinuse.

Disposal
InaccordancewithEuropeanDirective2002/96/EGconcerningusedelectricalandelectronicappliances(wasteelectrical
andelectronicequipment–WEEE),pleasereturnanyelectricalequipmentthatyouwillnolongerusetothecollection
pointsprovidedfortheirdisposal.
Thissymbolindicatesthattheappliancecannotbetreatedasnormaldomestictrash,butmustbehandedtoacollection
pointforrecyclingelectricandelectronicappliances.
Informationconcerningwheretheequipmentcanbedisposedofcanbeobtainedfromyourlocalauthority.




Specifications
SpecificationHE94000
Voltage(V)220‐240V～50Hz
Power(W)2000W
Dimensions
W×H×D(m)545.0×100.0×160.0
Weight(kg)2.5

CustomerService
Repairsmustbecarriedoutbyauthorizedspecialists,thusensuringelectricalsafety.Pleasecontactwiththeserviceagentora
suitablyqualifiedelectrician.
Improperrepairscouldleadtodangertotheuser.
Thiswarrantydoesnotcoverdamageoffailurewhichresultsfromalteration,accident,misuse,abuse,neglect,commercialuseor
impropermaintenance.
Inlinewithourpolicyofcontinuousproductdevelopmentwereservetherighttochangetheproductanddocumentation
specificationswithoutnotice.
