Heater Borneo
Manual

InfraredPatioHeater
 SafetyInstructions
andOperationManual

 HE94010 






















ThankyouforpurchasingfromHeatOutdoors.Pleasereadtheseinstructionscarefullybeforeusingyourheater,andpayspecial
attentiontothe"ImportantSafetyInstructions".ThisproductisaninfraredradiantheaterwitharemotecontrolandisIP65
approvedforfulloutdooruse.
ImportantSafetyInstructions
Whenusingelectricalappliances,basicsafetyprecautionsshouldalwaysbefollowedtoreducetheriskoffire,electricshock,or
injurytopersons,etc.Readallinstructionsbeforeusingthisheater
Keepcombustiblematerials,suchasfurniture,pillows,bedding,papers,clothesandcurtainsatleast0.9mfromthefrontof
theheater.
Thisapplianceisnotintendedforusebypersons(includingchildren)withreducedphysical,sensoryormentalcapabilities,or
lackofexperienceandknowledge,unlesstheyhavebeengivensupervisionorinstructionconcerninguseoftheapplianceby
apersonresponsiblefortheirsafety.
Turnofftheelectricity,removetheplugfromtheoutletwhennotinuse.
Donottrytorepairbyyourselfifitisbroken(suchascord,plugetc),pleasecontacttheserviceagentformaintenance.
Donotrunpowercordundercarpeting.Donotcovercordwiththrowrugs,runners,orsimilarcoverings.Donotroutecord
underfurnitureorappliances.Arrangecordawayfrombusyareasandwhereitcannotbetrippedover.
Connecttoproperlyearthedoutletsonly.Todisconnectheater,turnsocketoff,thenremoveplug.
 
Aheaterhashotandarcingorsparkingpartsinside.Donotuseitinareaswheregasoline,paint,orflammableliquidsare
usedorstored.
 
Usethisheateronlyasdescribedinthismanual.Anyotherusenotrecommendedbythemanufacturermaycausefire,
electricshock,orinjurytopersons.
Alwaysplugheatersdirectlyintoawallplug,fusedspurorpurposemadecontroller.Donotusetheheaterwithacoiled
cableorextensionlead.


Checkifthevoltageindicatedonthenameplateoftheappliancecorrespondstothelocalmainsvoltagebeforeyouconnect
theappliance.
Theapplianceisnottobelocateddirectlybelowanelectricalwallsocket.
Thecasingandthefrontcoveroftheappliancebecomeextremelyhotduringoperation.Payattentionthat,nocombustible
materials(duetowindorotherenvironmentalinfluences)coversorobstructstheappliance,suchascurtains,marquees,
flags,plasticfoiletc.
Donottouchtheappliance.Caution!Riskofscaldinjury!
Incaseofimproperuse,thereisariskofelectricalshockand/orfirehazard.Operationoftheappliancemustbediscontinued
andremovethemainsplugimmediately.Donottrytorepairtheappliancebyyourself.Pleasecontactwiththeserviceagent
orasuitablyqualifiedelectricianformaintenance.
Removetheplugfromthepoweroutletandwaituntiltheapplianceissufficientlycoolbeforecleaning.
Keepoutofreachofchildren.Inordertokeepchildrenfromdangers,neverleavethemunsupervisedwiththeheater.
Consequently,whenselectingasuitablelocation,dosoinsuchawaythatchildrendonothaveeasyaccess.
Specifications

Voltage(V)220‐240～50Hz
Powerconsumption(W)2000W
DimensionsL×W×H(mm)574.0×100.0×145.0
Weight(kg)2.8
IP IP65
InfraredreceivingAngle60°±5°
Thecontroldistance(M)6
Batterytype 2xAAAsize1.5V

RemoteControlInstructions

ButtonGraphic Feature
UpArrowUponeheatinglevel
MaxTheheatergoesdirectlytothehighestheating
level.
DownArrowDownoneheatinglevel
On

Toswitchtheheateron:
PressON.Thepatioheaterhasasoftstart
functionof33%power.4secondsafterthe
heaterhasbeenturnedon,itwillautomatically
switchtothelastheatinglevelused.Incaseof
thefirst‐timeuse,after4secondstheheaterwill
automaticallyswitchto100%power.
Off

Toswitchtheheateroff:
PressOFF.Theheaterwillswitchtostandby
mode(thereceiverindicatorwilllightup).

Notice：
Use2piecesAAAsize1.5Vbatteriesintheremotecontrol.Removethebatterywhennotuseforlong
time,thusthelifespanofremotecontrolcanbeextended.
Choosethesamespecificationbatterywhenreplacingthebatteryinside,otherwiseitmaycause
remotecontrolnotwork,therebyaffectthenormaluseoftheheater.
Theheatercanbestillusedinnormalexceptremotecontrolfunctioniftheremotecontrolismissed
orlost.Pleasecontactserviceagentforfurtherhelpifyouneedthefunction.
Theremotecontrolfunctionmaybeoutofworkifthereisabarrierbetweentheremotecontroland
heater.
Replacingthebatteriesdulysoasnottoaffectthenormaluseofheaterandremotecontrol.




OperationInstructions
Removeallpackagingmaterial(includinganti‐vibrationpackagingonthelamp)andchecktheappliance,supplycordandplug
forsignsofdamage.
Beforemounting,notetheminimumsafemountingdistancesandtiltanglesasshowninthebelowmustbestrictlyfollowed.
Thedistancebetweenthebottomedgeoftheapplianceandthefloormustbeatleast1.8M.Seefigure3.
Theremustbeadistanceofatleast0.2Mbetweentheapplianceandtheceiling,rooforothercovers.Seefigure3.
Theremustbeadistanceofatleast0.5Mateachsidebetweentheapplianceandwallsorthelike.Seefigure3.
Recommendedangletomountingsurfaceis45°.Seefigure4.
Fixthemountingbracketonthewallfirst.Ensurethattheplacetobeinstalledissecureandfirm.Orconnecttheapplianceto
asuitablefloorstand.
Adjustthedesiredangleandtightenthehexboltonthehinge.Regularlythescrews’fixing.Mechanicalpressuresand
oscillationduetowindorraincancauseyourfixingtoworkloose.
Plugintoasuitablepowersourceandoperatetheviatheremotecontrolhandset
Whennotinuseforlongperiods,itisadvisabletoremovethebatteries


Figure1:Mountingbracket(wallbracket)and
anchordowelsprovided.Connectionfromthewall
totheinfraredheater.
Figure2:Connectionfromthestandtothe
infraredheater.Thestandshallbepurchased
separately.


Figure3:Min.distancetofloor,ceilingandwall.Figure4:Tiltangle




CleaningandMaintenance

Thisapplianceismanufacturedfromrobustandmaintenance‐freealuminiumwithaprotectivecover.Therearenouser
serviceablepartsinside.
Beforecleaning,removetheplugfromthepoweroutletandwaituntiltheapplianceissufficientlycooledoff.
Wipetheapplianceonlywithcleanandlint‐freeclothorasoftbrush.
Neveruseabrasivecleaners,scrubbingbrushesandchemicalcleanersforcleaning!
Toprotectagainstelectricalshockanddangertolife,donotimmersethecord,plug,oranypartofthisheaterinwaterorany
otherliquid.
Forheatingelementreplacement，pleasecontactthemanufactureroritsserviceagentorasimilarlyqualifiedperson.
Foranyotherrepairs,pleasecontactthesalesagentorasuitablyqualifiedelectrician.

Disposal

InaccordancewithEuropeanDirective2001/96/EGconcerningusedelectricalandelectronicappliances(wasteelectrical
andelectronicequipment–WEEE),pleasereturnanyelectricalequipmentthatyouwillnolongerusetothecollection
pointsprovidedfortheirdisposal.
Thissymbolindicatesthattheappliancecannotbetreatedasnormaldomestictrash,butmustbehandedtoacollection
pointforrecyclingelectricandelectronicappliances.
Informationconcerningwheretheequipmentcanbedisposedofcanbeobtainedfromyourlocalauthority.
CustomerService
Thiswarrantydoesnotcoverdamageoffailurewhichresultsfromalteration,accident,misuse,abuse,neglect,commercial
useorimpropermaintenance.
Inlinewithourpolicyofcontinuousproductdevelopmentwereservetherighttochangetheproductanddocumentation
specificationswithoutnotice.

