Dancover HE94020 Operation and maintenance manual

08-06-2015
for
Heater Sumba
Manual

InfraredPatioHeater
 SafetyInstructions
andOperationManual
HE94020
 (Note:Thisproductisstrictlyprohibitedtocover)





 












Thankyouforpurchasingourproducts.Pleasereadcarefullythisinstructionbeforeusingandoperatestrictlyaccordancewiththe
instructionsandespeciallypayattentionto"ImportantSafetyInstructions".Pleasebecarefulcollectionafterreadingsoastofor
futurereference
BriefIntroduction
ThisproductisinfraredradiantheaterwithremotecontrolandIP65approved.Itisalmostunlimitedusedinoutdoor,suchasopen
bars,courtyard,plaza,station,andconstructionsiteinwinteretc.Thispatioheaterisenergy‐efficient,convenient,environmentally
friendlyandforbetterlifeetc.

ImportantSafetyInstructions
Whenusingelectricalappliances,basicsafetyprecautionsshouldalwaysbefollowedtoreducetheriskoffire,electricshock,or
injurytopersons,
includingthefollowing: .
Readallinstructionsbeforeusingthisheater
Thisheaterishotwheninuse.Toavoidburns,donotletbareskintouchhotsurfaces.Ifprovided,usehandleswhenmovingthis
heater.Keepcombustiblematerials,suchasfurniture,pillows,bedding,papers,clothesandcurtainsatleast0.9mfromthe
frontoftheheater.
Extremecautionisnecessarywhenanyheaterisusedbyornearchildrenorinvalidsandwhenevertheheaterisleftoperating
andunattended.
Alwaysunplugheaterwhennotinuse
Donotoperateanyheaterwithadamagedcordorplugoraftertheheatermalfunctions,hasbeendroppedordamagedin
anymanner.Discardheater,orreturntoauthorizedservicefacilityforexaminationand/orrepair.
Thisheaterisnotintendedforuseinbathrooms,laundryareasandsimilarlocations.Neverlocateheaterwhereitmayfall
intoabathtuborotherwatercontainer.
Donotruncordundercarpeting.Donotcovercordwiththrowrugs,runners,orsimilarcoverings.Donotroutecordunder
furnitureorappliances.Arrangecordawayfromtrafficareaandwhereitwillnotbetrippedover.
Connecttoproperlygroundedoutletsonly.
Todisconnectheater,turncontrolsoff,thenremoveplugfromoutlet.
 
Donotinsertorallowforeignobjectstoenteranyventilationorexhaustopeningasthismaycauseanelectricshockorfire,or
damagetheheater.

Topreventapossiblefire,donotblockairintakesorexhaustinanymanner.Donotuseonsoftsurfaces,likeabed,where
openingsmaybecomeblocked.
Aheaterhashotandarcingorsparkingpartsinside.Donotuseitinareaswheregasoline,paint,orflammableliquidsare
usedorstored.
Usethisheateronlyasdescribedinthismanual.Anyotherusenotrecommendedbythemanufacturermaycausefire,
electricshock,orinjurytopersons.
Alwaysplugheatersdirectlyintoawalloutlet/receptacle.Neverusewithanextensioncordorrelocatablepowertap
(outlet/powerstrip).
Checkifthevoltageindicatedonthenameplateoftheappliancecorrespondstothelocalmainsvoltagebeforeyouconnect
theappliance.
Theapplianceisnotlocatedimmediatelybelowawallsocket‐outlet.
Thecasingandthefrontcoveroftheappliancebecomeextremelyhotduringoperation.Payattentionthat,nocombustible
materialduetowindorotherenvironmentalinfluencescoversorobstructstheappliance,suchascurtains,marquees,flags,
plasticfoiletc.Donottouchtheappliance.Caution!Riskofscaldinjury!
Incaseofimproperuse,thereisariskofelectricalshockand/orfirehazard.Operationoftheappliancemustbediscontinued
andremovethemainsplugimmediately.Donottrytorepairtheappliancebyyour‐self.Pleasecontactwiththeserviceagent
orasuitablyqualifiedelectricianformaintenance.
Removetheplugfromthepoweroutletandwaituntiltheapplianceissufficientlycooledoffbeforecleaning.
Keepoutofreachofchildren.Inordertokeepchildrenfromthedangersofelectricalappliances,neverleavethem
unsupervisedwiththemachine.Consequently,whenselectingthelocationforyourmachine,dosoinsuchawaythat
childrendonothaveaccesstothemachine.Childrenbeingsupervisednottoplaywiththeappliance.
Theappliancemustonlybemountedbyanauthorizedspecialist,payingattentiontotherelevantregulationsofthepower
supplycompaniesandtheregionalconstructionregulations.

SaveTheseInstructions

Specifications

SpecificationHE94020
Voltage(V)220‐240～50Hz
Powerconsumption(W)2000W
DimensionsL×W×H(mm)556.0×130.0×185.0
Weight(kg)2.75
IP IP65
InfraredreceivingAngle60°±5°

BLUETOOTHOPERATION
A freeBluetoothAppisavailabletodownloadforthisheaterforeitheryouriPhone,iPad
orAndroiddevice. 
The 'Sunkare Heater'Appwillallowyouto connect remotelytomany heaters andcontrolthem
independently. Controlfunctions include: 
On/Off
Variableheatoutputfrom25%to100%
Timerwithautoshutoff
Passwordconnectiontoheaters
Individualheateridentificationandcontrol

To download,search for 'Sunkare 'inyourAppstoreandaddtoyour device.
RESETOPERATION
PresstheResetbuttonshortly,thepowerwillbeadjustedaccordingly(Low,Middle,High,ON/OFF)
PresstheRestbuttonforatleast4seconds,theheaterwillrestorefactorysettings

RemoteControlInstructions

ButtonGraphic Feature
UpArrowUponeheatinglevel
MaxTheheatergoesdirectlytothehighestheating
level.
DownArrowDownoneheatinglevel
On

Toswitchtheheateron:
PressON.Thepatioheaterhasasoftstart
functionof33%power.4secondsafterthe
heaterhasbeenturnedon,itwillautomatically
switchtothelastheatinglevelused.Incaseof
thefirst‐timeuse,after4secondstheheaterwill
automaticallyswitchto100%power.
Off

Toswitchtheheateroff:
PressOFF.Theheaterwillswitchtostandby
mode(thereceiverindicatorwilllightup).
Notice：
Use2piecesAAAsize1.5Vbatteriesintheremotecontrol.Removethebatterywhennotuseforlong
time,thusthelifespanofremotecontrolcanbeextended.
Choosethesamespecificationbatterywhenreplacingthebatteryinside,otherwiseitmaycause
remotecontrolnotwork,therebyaffectthenormaluseoftheheater.
Theheatercanbestillusedinnormalexceptremotecontrolfunctioniftheremotecontrolismissed
orlost.Pleasecontactserviceagentforfurtherhelpifyouneedthefunction.
Theremotecontrolfunctionmaybeoutofworkifthereisabarrierbetweentheremotecontroland
heater.
Replacingthebatteriesdulysoasnottoaffectthenormaluseofheaterandremotecontrol.






OperationInstruction
Removeallpackagematerial(includinganti‐vibrationobjectofthelamp)andchecktheappliance,supplycordandtheplug
forsignsofdamage.
Payattentiontothemountingplaceandallmountingmaterial(dowels,screws).Ensuretheyaresuitableandstableenough
formountingandlastinglyholdingoftheappliance.
Beforemounting,theminimumsafemountingdistancesandtiltanglesshowninthefiguresmustbestrictlyfollowed.
Thedistancebetweenthebottomedgeoftheapplianceandthefloormustbeatleast1.8M.Seefigure3.
Theremustbeadistanceofatleast0.25Mbetweentheapplianceandtheceilings,roofsorothercovers.Seefigure3.
Theremustbeadistanceofatleast0.5Mateachsidebetweentheapplianceandwallsorthelike.Seefigure3.
Recommendeddegreetomountingsurfaceis45°.Seefigure4.
Payattentionthat,theinstallationoftheappliancemustnotaddexcessivewindload.
Fixthemountingbrackettotheceilinglfirst.Ensurethattheplacetobeinstalledissecureandfirm.Orconnecttheappliance
tothestand.
Adjustthedesiredangleofradiationandfastenallscrews.Checkregularlythescrew'sconnection.Mechanicalbearing
pressureandoscillationduetowindorraincouldleadtoloose.
Pluginthepowersourceandoperatetheremotecontrol.Thenobserve,whetherduringthefirst10‐15minutesthe
applianceworkstrouble‐free.
Ifyoudonotuse,pleaseremovebatterysocket



Figure1:Mountingbracketandanchordowels
provided.Connectionfromthewalltotheinfrared
heater.
Figure2:Min.distancetofloor,ceilingandwall.




Figure3:Tiltangle.
 



CleaningandMaintenance

Thisapplianceconsistsofarobustandmaintenance‐freealuminiumcasingwithaprotectioncover.Nouserserviceableparts
inside.
Beforecleaning,removetheplugfromthepoweroutletandwaituntiltheapplianceissufficientlycooledoff.
Wipetheapplianceonlywithcleanandlint‐freeclothorasoftbrush.
Neveruseabrasivecleaners,scrubbingbrushesandchemicalcleanersforcleaning!
Canusealcoholtocleantheappliance.
Toprotectagainstelectricalshockanddangeroflife,donotimmersecord,plug,oranypartoftheapplianceinwateror
otherliquid.
Forheatingelementreplacement,pleasecontactthemanufactureroritsserviceagentorasimilarlyqualifiedperson.
Anyotherservice,pleasecontactwiththeserviceagentorasuitablyqualifiedelectrician.

Storage
Donotroutecordwhenheaterstorage,orheaterisnotinuse.

Disposal

InaccordancewithEuropeanDirective2001/96/EGconcerningusedelectricalandelectronicappliances(wasteelectrical
andelectronicequipment–WEEE),pleasereturnanyelectricalequipmentthatyouwillnolongerusetothecollection
pointsprovidedfortheirdisposal.
Thissymbolindicatesthattheappliancecannotbetreatedasnormaldomestictrash,butmustbehandedtoacollection
pointforrecyclingelectricandelectronicappliances.
Informationconcerningwheretheequipmentcanbedisposedofcanbeobtainedfromyourlocalauthority.
CustomerService
Repairsmustbecarriedoutbyauthorizedspecialists,thusensuringelectricalsafety.
Pleasecontactwiththeserviceagentorasuitablyqualifiedelectrician.
Improperrepairscouldleadtodangertotheuser.
Thiswarrantydoesnotcoverdamageoffailurewhichresultsfromalteration,accident,misuse,abuse,neglect,commercial
useorimpropermaintenance.
Inlinewithourpolicyofcontinuousproductdevelopmentwereservetherighttochangetheproductanddocumentation
specificationswithoutnotice.
