Daymak Roadstar User manual

Roadstar
User Manual

2
About Daymak
Daymak is one of Canada’s largest Alternative Vehicle providers. We design, engineer,
manufacture, import and repair everything from recreational dirt bikes, go-karts and
electric golf cars to alternative transportation solutions such as e-bikes and gas scooters.
Our electric bicycles represent an energy-ecient and eco-friendly alternative for people
who need to get around the city. They greatly increase the practicality of bicycle transpor-
tation in urban centres. Costing only a few cents to charge, an e-bike can make city life
more convenient and much less expensive.
While there are many new Green technologies that are still in their infancy, electric bicycles
have been developing over the last 40 years or more. E-bike technology has been dramat-
ically rened since the introduction of the rst custom-conversion bicycles. Today, electric
bicycles are a supremely reliable and aordable means of transportation.
Daymak is constantly developing new eco-friendly alternative transportation strategies,
led by its own Research and Development department in Toronto, Canada. We are always
improving our products. Our innovative in-house engineering and quality testing provide
customers with many new kinds of reliable, eco-friendly vehicles, designed to help change
the lives of our customers and the world.
Daymak warranties, services, and stocks parts for everything it sells.
We support our products.
Please feel free to visit our website. You’ll nd the latest in cool transportation solutions,
support for the products you’ve purchased and contact information.

3
Safety / Riding Precautions
For your safety, please ensure the following:
- check both right and left brake levers, and that the brake sensors shut o power to the
motor
- check the air pressure of both front and rear tires. The correct P.S.I. is listed on each tire.
- check both left and right turn signals and taillights work properly before riding
- check and make sure that your mirrors are tightened and allow for maximum visibility
- make sure that your battery power is sucient before you go out to ride
- additional passengers should always wear a helmet
- periodically charge the unit when not in use for long periods of time
- if you bring your charger, avoid shaking / rattling charger while riding
- do not over charge the battery by leaving the charger in the charging port. Once the
battery is fully charged remove the charger immediately.
- do not try to operate the unit while charging
- do not let anyone uner the age of 16 years old operate this vehicle
- do not make sharp / abrupt turns at high speeds to avoid tipping
- do not operate under the inuence of any use of drugs or alcohol
- do not completely submerge the unit in water
- do not operate in harsh weather conditions
- observe all trac rules, and do not operate in areas where motorized vehicles are not
allowed.
For any questions or concerns please call
1-800-649-9320 or visit www.daymak.com

4
Introduction
E-Scooters
Riding an electric scooter is a great way to hop around town conveniently and cheaply.
E- Bikes represent a natural progression in the development of urban transportation.
Using only small amounts of electricity, e-scooters have the potential to radically reduce
the amount of pollution in our cities. As well, they are very quiet, so they do not add to the
high levels of noise pollution which we often take for granted. They are easy, and usually
free to park. They are unobtrusive and highly practical additions to the urban landscape.
E-scooters are also inexpensive. They (currently) require no registration, no insurance, no
licence and do not incur parking charges. As well, compared to internal combustion en-
gines, the engines in electric vehicles have fewer moving parts and require far less main-
tenance.
Your Daymak e-scooter is the result of Daymak’s years of experience, the highly trained
technical skills of our sta and careful, ongoing design work by our engineers. We hope
you enjoy using this product and welcome any feedback that you may have.
New Laws
Most provinces in Canada, most states in the U.S.A, the United Kingdom and many Euro-
pean countries have new laws that permit cyclists to use electric motors to assist the reg-
ular operation of bicycles. Please check with your provincial or state government to learn
about your local laws.
Liability
Daymak does not assume any liability for damages, loss of prots, or claims from third
parties due to improper use of this product. Daymak does not assume any liability for dam-
ages due to problems with the product resulting from service by a third party that is not
certied by Daymak.
The information in this guide may be subject to change without notice. For the latest infor-
mation available, please contact your local Daymak dealer or visit our website.
We have taken all possible measures to ensure the accuracy and completeness of the in-
formation in this guide. However, if you do nd anything missing, incomplete or wrong, do
not hesitate to contact us.

5
Scooter Overview
Roadstar
This diagram illustrates the various parts of your mobility scooter. Please note that many of these parts are
not user-serviceable and should be repaired only by trained professionals. This is especially true of the elec-
trical systems and the mechanical components.
1. Throttle
2. Brakes
3. Headlight
4. Turn Signals
5. Front Tire
6. Floor Panel
7. Charge Port
8. Rear Tire
9. Seat
10. Carrying Case
11. Mirrors
12. Parking Brake
11
10
9
8
7
6
5
4
3
2
2
1
12

6
Instrument Overview
This diagram displays the instrument cluster and function switches needed for operation. Take note of each
switch and and familiarize yourself with all the functions described below. If any of the switches appear to
be malfunctioning, do NOT ride the unit until all functions work as intended.
1. Handgrip
2. Headlight High/Low Beam
3. Turn Signal Switch
4. Horn
Left Side Function Switches Right Side Function Switches
5. Speed Knob (Top Speed)
6. Throttle
7. Speed Switch (Torque)
8. Taillight / Headlight Switch
9. Forward / Reverse Switch
98
7
6
5
4
3
2
1
Function Switches Description
Headlight High / Low Beam - can only be activated when the Headlight (8) is on
Turn Signal Switch - push to the left or right, and press in the middle to turn o󰀨 signal
Horn - activates the horn
Throttle - turn away from you to accelerate, release and turn towards you to decelerate
Speed Switch - limits to lower torque on 1, moderate torque on 2, and maximum torque on 3
Forward / Reverse Switch - push to the left position for forward, to the right position for reverse
Taillight / Headlight Switch - right position leaves taillight and headlight o󰀨, middle position turns on
the taillight, and left position turns on the headlight and taillight
10. Speed Indicator
11. Trip Odometer
12. Battery Indicator
The speedometer provides information
about the current state of your e-bike.
Before starting on your trip, ensure that
the battery and voltage indicator indi-
cates enough power to cover the distance
required. When the turn signals and or
headlights are activated, icons on the dis-
play will also inform you that they are on.
Display Overview

7
Smart Key Overview
This diagram displays the smart key and its functions. Take note of what each function does and take care
not to damage either the key or the fob, as they are both required to fully unlock your e-scooter. If the key is
broken or the fob is malfunctioning, call your nearest Daymak dealer for service troubleshooting.
Key Fob Functions
1. Lock
2. Unlock
3. Panic
4. Keyless Start
43
12
Key Fob Function Description
Lock - press once to arm the alarm on your e-scooter. A conrmation sound will turn on after arm-
ing the system. Any load change or signicant movement of the e-scooter will cause the alarm to
ring when the system is armed.
Unlock - press once to disarm the alarm. A conrmation sound will turn on after disarming the
system. Note that the keyless start will not engage unless the alarm system is disarmed.
Panic - press once to engage the alarm system. A constant, blaring sound will turn on. Press the
unlock button to turn o󰀨 the alarm system.
Keyless Start - rst make sure to press the unlock button once before engaging. Press the key-
less start button twice. The e-scooter’s LCD display and systems should turn on and the e-scoot-
er will be functional. If the e-scooter is turned on using keyless start, inserting the key and turning
it to the left will not turn o󰀨 the system. The only way to turn o󰀨 the e-scooter after engaging the
keyless start is to press the unlock button.

8
Engaging Parking Brake
Underneath throttle there will be a small bar with a black nub covering it. This is to engage the parking
brake. To activate it, rst pull the rear brake caliper until it cannot go any further back.
Next, push the black nub up towards the handlebar to engage the rear brake lock.
Release the brake caliper and its set!
To disengage the parking brake, simply grab the rear brake caliper and pull it towards you again and the
parking brake will disengage and the bar will pop back out
Pull brake handle towards handlebar and push in the black nub
seen in the gures above and to the right.

9
FM Radio / MP3 Player
This diagram displays the FM Radio / MP3 Player, located in the center of the dashboard console.
1
2
3
4
5
6
1) Power - Press this button once to turn on the sound system and set it to MP3, once more to set it to
radio and once more to turn it o.
2) Volume Down - Press this button to turn down the volume.
3) Seek / Previous Song - In Radio mode, press this to seek a lower frequency station. In MP3 mode it will
play the previous song.
4) Volume Up - Press this button to turn up the volume.
5) Seek / Next Song - In Radio mode, press this to seek a higher frequency station. In MP# mode it will play
the next song.
6) Play / Pause - Press once to either play music, or pause the music that is currently playing
Connecting your smartphone to your speakers.
Press the Power button once until the light under MP3 is showing. Go to your smart phone and go to your
bluetooth settings. *Please note bluetooth must be turned on, on your smart phone.*
Click on the device that is called - GB - Bluetooth.
You are now connected to your unit and will be able to play music directly from your smart phone!

10
Riding Instructions
This guide assumes that you already know how to ride a standard mobility scooter. Before
you try to ride an electric scooter, you should be very familiar with controlling a normal
mobility scooter.
Caution
If you do not have experience operating a mobility scooter, turn down the speed and prac-
tice on a wide open area before embarking on a long trip.
Important Notes
• Obey the Law. Be sure to follow all provincial and city trac laws. This includes
obeying stop signs, checking carefully when turning, and riding defensively.
• Stay Sober. Never ride your scooter while intoxicated. An e-scooter is capable of
relatively fast speeds, and you should always be in control of it.
• Share the Road. Be careful in mixed trac. When on bicycle paths, traveling near
pedestrians, or on recreational trails, try to be polite and courteous to those using
the paths with you.
Items to Carry with the Mobility Scooter
It is a good idea to carry the following items with you at all times when you ride your mo-
bility scooter.
• The charger, to charge the scooter in case the battery power runs out
• A cover, to protect your e-scooter from the weather if you are to park it for long
periods of time

11
Inspecting your Mobility Scooter
Always inspect your mobility scooter before you ride it, to make sure its safety features are
operating properly. Many accidents can be avoided with routine inspections. Once you
are comfortable with your mobility scooter, you will be able to detect small changes in the
way it feels. If anything changes between uses, make sure to have it properly examined.
Also, be sure to listen for changes in the sounds your mobility scooter makes over time.
Any mechanical or power issues may have eects on the sounds the scooter makes.
Holding the Handlebars
Place your ngers over the brake levers, using the palms of your hand and your thumbs
to wrap around and under the handlegrips. Doing this allows you to activate the brakes
easily, by squeezing your hand, in case you have to stop quickly. This is the safe way to
control your mobility scooter.
Turning your Mobility Scooter On and O
To turn on your mobility scooter, insert the key into the “ignition”, located just below the
dash board, and turn the key to the right. When your e-scooter is activated, the power
indicator will light and the battery charge indicator will jump, showing you how much
power your e-scooter has. To turn o the mobility scooter, simply turn the key to the left,
and remove the key.
Warning
When you activate the mobility scooter, the electrical system becomes live. Do not try to
aect changes to the mobility scooter (such as removing the battery or repairing electri-
cal components) while the mobility scooter is activated. Turn the mobility scooter o and
remove the key before you attempt to access any of the electrical components. Also, the
battery carries a signicant electric charge and can injure people if not treated properly
and with respect.
Accelerating and Decelerating
The throttle is found on the right-side hand grip on the handlebars. Turn the grip forward
(away from you) to accelerate. To decelerate, release the grip (turn it towards you). Don’t
over-rotate the accelerator, as this could damage the battery and electrical components.
Warning
Do not activate the accelerator until you are seated on the mobility scooter and are ready
to accelerate. The mobility scooter can easily escape from your control, possibly injuring
you or others, and the mobility scooter may be damaged by being crashed.

12
Stopping
Your mobility scooter has two sets of brakes, at the front and at the rear. The levers at-
tached to the handlebars, on the left and right, activate the brakes. Pull the levers toward
you to activate the brakes.
You can use both brakes to come to a stop more quickly, or you can use one of the brakes
to come to a gentle stop, depending on your riding needs at the moment.
When the brakes are activated, the power to the engine is automatically turned o, until
you release the brakes. This allows you to stop safely.
Safety Tips
• When you are traveling in wet weather, water may cause your brakes to function
less eciently because it reduces friction between the brake pads and the wheels.
Take care to slow down and give yourself more room to stop or slow if necessary.
• It is a good idea to have your brakes and brake pads checked regularly. The brake
pads will eventually wear down through friction, and after signicant use will have
to be replaced.
The Horn
The mobility scooter has a horn. There are horn buttons on the left side of the function
switches on the handlebar. Simply press it to activate the horn.
Turning Signal Lights
Your mobility scooter has turn signal lights. The turn signal activator is on the left handle-
bar. Push it left or right to activate it to indicate that you are turning in the appropriate
direction, and press the middle of the button to turn it o.
Lights
The headlight and taillight are useful features when you are riding at night or in dark ar-
eas. They radically improve your safety in mixed trac. The switch is located on the right
handlebar. The lights on your mobility scooter consume some electricity. Keeping them on
may reduce the maximum distance you can travel on one charge by about 5%.

13
Riding in Wet Weather
Your mobility scooter is designed to function in wet conditions, such as when it is raining.
However, because the motor is on the rear wheel, it is easy to slip when moving at high
speeds. If it is very wet, be sure to avoid high speeds.
The Motor and Water
Your mobility scooter is not designed to be immersed in water. Always ensure that the
water level does not go above the middle of the tire, to prevent water from getting inside
the motor.
Water in the motor can cause short-circuits and may damage the electrical systems in your
mobility scooter.
Riding in Cold Weather
Your mobility scooter is designed to operate year-round. However, in very cold conditions
or when there is a lot of snow or slush on the ground, it is possible for the motor in the
mobility scooter to get wet or for the brakes to function less eciently, just as can happen
in wet weather. Below 10 degrees Celsius, the battery will not work as well as it would in
warmer temperatures. While Lithium-Ion batteries perform better than Lead-Acid batter-
ies in temperature extremes, both will experience reduced performance in cold tempera-
tures.
Also, riding the mobility scooter in cold temperatures may require you to replace the bat-
tery sooner rather than later.

14
Thank you for choosing Daymak
