Boomerbeast
User Manual
Deluxe and Ultimate

About Daymak
Daymak is one of Canada’s largest Alternative Vehicle providers. We design, engineer, man-
ufacture, import and repair everything from recreational dirt scooters, go-karts and elec-
tric golf cars to alternative transportation solutions such as e-scooters and gas scooters.
Our electric scooters represent an energy-ecient and eco-friendly alternative for people
who need to get around the city. They greatly increase the practicality of scooter transpor-
tation in urban centres. Costing only a few cents to charge, an e-scooter can make city life
more convenient and much less expensive.
While there are many new Green technologies that are still in their infancy, electric scoot-
ers have been developing over the last 40 years or more. E-scooter technology has been
dramatically rened since the introduction of the rst custom-conversion scooters. Today,
electric scooters are a supremely reliable and aordable means of transportation.
Daymak is constantly developing new eco-friendly alternative transportation strategies,
led by its own Research and Development department in Toronto, Canada. We are always
improving our products. Our innovative in-house engineering and quality testing provide
customers with many new kinds of reliable, eco-friendly vehicles, designed to help change
the lives of our customers and the world.
Daymak warranties, services, and stocks parts for everything it sells. We support our prod-
ucts.
Please feel free to visit our website. You’ll nd the latest in cool transportation solutions,
support for the products you’ve purchased and contact information.

Safety
When operating the Boomerbeast please make sure you adhere to the following:
Always check your mirrors and blind spots when operating through trails.
Turn on headlights when in need of additional visibility.
Make sure that your battery power is su󰀩cient before you go out to ride
Do not ride with more than 1 passenger
Do not over charge the battery by leaving the charger in the charging port. Once the
battery is fully charged remove the charger immediately.
Do not try to operate the unit while charging.
Do not let anyone uner the age of 16 years old operate this vehicle.
Do not operate this unit up extreme inclines to avoid tipping.
Do not make sharp / abrupt turns at high speeds to avoid tipping.
Do not operate under the inuence of any use of drugs or alcohol
Do not operate on public roads
Do not operate at excessive speeds.
Do not completely submerge the unit in water

4
Scooter Part Diagrams
Diagram 1: The Boomerbeast Electric Scooter
1. Controller
2. Throttle
3. Tablet Charging Port
4. Tablet / Mount
5. Ignition
6. Mirrors
7. Seat
8. Rack
9. Tires
10. Ball Hitch
11. Motor (rear)
12. Battery
13. Charging Port
14. Motor (front) [Ultimate Only]
15. Shocks
16. Turn Signals
17. Headlights
18. Brakes

5
Boomer Beast Operation
Mounting your tablet
The Boomerbeast comes wiht a tablet mount that allows you to attach a tablet that gives you speed,
distance travelled and allows you to congure the performance infront of you.
The Mounting brackets come with 4 pieces.
Piece A Piece B Piece C Piece D
Instructions
To start take Piece A and put it around the handlebar as seen here:
Take Piece B and put it through the screws and hold it in place
where you want the table to rest.

6
Take the two pieces from Piece C and screw each
one on the screws tightly to lock the tablet holder
in place.
Take the Piece D, and align the four holes to match
the four pegs from Piece B. Once they are in, push
either up or down (depending on where you
mounted it) until it clicks into place. Adjust the
tablet width to the size you need and ip down
the lever on the back to lock that into place.
Slide in the tablet and you are
ready to go!
On the right side of the handle bar you will nd a tablet
charging port with a rubber covered. Use this to charge
your tablet.
*Please Note* The Boomerbeast must be in the ON po-
sition and the charger port must be set to 1. To disable
power to the charging port set this to 0

7
Boomer Beast Operation (cont’d)
Turning on your unit
Ignition - The Boomerbeast comes with an ignition that you must put your key into to turn on.
1) Wheel Lock - To put it into position 1 put the key into
the ignition slot and turn left as far as you can go. Once
you cannot turn any more, turn the handlebars of the
Beast to the left, then push the key further into the ignition
and turn to the left again. Once in this position your tire
will be locked perpendicular to the bike making it harder
to steal. Reverse this process to release the wheel lock
2) OFF - Put the key into this position to turn o the unit.
3) ON - Put the key into this position to turn on the unit.
*Please note* The unit does not need to have the Tablet
on for it to be running, so do not leave the Boomerbeast
on unattended for risk of injury.
Connecting your Tablet to your Unit
Connecting via Bluetooth
Turn on your tablet with the signle button on the right hand side and hold it for 3 seconds. Once it has turned
on click on the Daymak Drive Bluetooth App.

8
The Boomerbeast can be connected to via bluetooth to increase torque range and more.
Once the App is open, it will show you a list of the nearby bluetooth devices as well as the Front
and rear motor. Connect to the motor. For the rst time you connect, it will require you to input a
password: 12345678.
*Please note* To connect to the unit the Boomerbeast must be set to the ON position (see
Turning on your unit)
Once you have done that, a speedometer will show up and you are ready to go!
For more information on the Daymak Drive App, please refer to the quick guide seen here:
http://daymak.com/manuals/Daymak%20Drive%20Manual.pdf
Please note the Boomerbeast Beast Ultimate has two con-
trollers, so any changes to e󰀨ect one motor, will not e󰀨ect the
other.

9
Boomer Beast Operation (cont’d)
Driving your unit
Once you have your Boomerbeast set up and connected. It’s time to ride!
Right Handlebar
1) Throttle - Turn this toward you to engage the motor
and to propell the unit forward. Do this very slowly at
rst until you get the feel of how quickly it goes.
2) Lights - Set this into one of 3 positions
Rightmost position - All lights are o
Middle position - Rear running lights are on
Leftmost position - All lights are on
3) Reverse Switch - Hold this button down while turn-
ing the throttle to go in reverse
Left Handlebar
1) Motor Power - Choose from Rear Wheel Drive or All
Wheeled Drive. Set it to 1 For just rear wheels, and set it
to 2 for all wheels. (Ultimate only)
2) Turn Signals - Slide this switch to the right when
signaling to turn right. And left when signaling to turn
left. Press the white button in the middle once the turn
is complete.
3) Horn - Press this button to activate the horn.

10
Brakes
On both sides of the handlebar there are brake levers
as seen on the right. To engage the brakes, pull the
brake lever towards you.
The right brake lever activates the front brakes
The left brake lever activates the rear brakes
Brake lock
To engage the brake lock, rst pull the
brake lever towards you as you would nor-
mally engage the brakes.
Then push the knob seen here behind the
brake lever . To release it pull the small
latch that surrounds the button back and
pull the brake lever again to its normal po-
sition
Boomerbeast Brake Disc
