Decon wheel Kuschall K Series User manual

2019-10-09
Page: 1
Assembly instructions for Küschall K-Serie, K-Serie G3
with Vario-Ax rear axle
MEM6179P and MEM6180P
1. Remove the wheels.
2. Check the correct placement for the eMove with axle Ø12,7 x 51 with
Part number: XOE-2530E-C0 and Spacers with Part number: XOC-25383-00 and Stop
pins are assembled with Part Numbers: 290000, 300001 and XSM8ML.
9
10

2019-10-09
Page: 2
3. Place the wheelchair on the side. Loosen the stop screws (1) that holds the bearing (4)
for the hub sleeve (3). Loosen the adjustment screw (2) for the hub sleeve. Now can
you remove parts (3 and 4). See the picture on top.
4. Now the most important with having the wheelchair on its side. Because when you
assemble the bracket, you have to replace the screw (5) that holds the anti-tip devise.
Carefully remove this screw (5), because its placed into a spacer inside the tube.
This spacer rely wants to move.
2
4
3
1
1
5

2019-10-09
Page: 3
5. Assembly parts 3,4,5,7 and 8 together and when the rest of the parts. Do not forget to
fasten the stop screws on the rear axle tube.
Parts pair mounting set for (right side):
Item No. Part Number Qty Description
1 100 400 039 1 Spacer
2 100 400 020 1 Spacer
3 HW069 1 Sleeve M16x1/12,7
4 XSM16M 1 Nut M16X1 Low
5 405239 1 Nordlock Washer
6 XSM6X40 1 Screw Round M6 x 40
7 100 400 057 1 Spacer
8 310022 1 Bracket
9 XOC-25383-00 1 Spacer 12,7
10 93440-120520 1 Circlip
Note! If you only order the mounting set, the axle, axle spacer and the circlip are not
included, for replacement see the service manual
6. Assemble the back placed battery bag.
