Decon wheel XLT Nordic User manual

2020-04-23
Assembly instructions for XLT Nordic/ Power
MED3027
1. Remove wheels and hubsleevers on both sides.
2. Check the correct placement for the stop pin.

2020-04-23
Placement on Boxer frame. Placement on U and V frame
1. Assembly the plate (right side) according to picture.
Parts pair mountingset for one side:
Item No. Part Number Qty Description
1 MED2000 1 Bracket
2 100 400 017 1 Spacer
3 HW069 1 Hubsleever M16x1/12,7
4 405239 1 Nordlock Washer
5 XSM16FJ 1 Singlecoil Washer M16
6 100 400 007 1 Spacer
7 XSM8ML 1 Locknut M8
8 XSM16M 1 Nut M16
9 XSM8BR 1 Plain Washer M8
10 XSM8X25 1 Screw M8 x 25
11 100 400 004 1 Spacer
12 300011 or 300023 1 Plate
Boxer frame Part Number: 300011
U and V frame
Part Number: 300023

2020-04-23
2. Assemble the under placed battery bag or if have order a Lithium battery place the
battery holder as the picture bellow.
Note!
Lithium battery is not possible to mount on the Box frame (XLT Nordic).
Assemble instructions for MEM5014 on wheelchairs
Item No. Part Number Qty Description
1 MEM5002 1 Hoop
2 MEM5003 4 Clamp
3 XSFM5X12 2 Screw Countersunk M5 x12
4 XSM5ML 2 Nut Self-Locking M5
5 XSSM8X20 4 Bolt Round-Square M8 x20
6 XSM8ML 4 Nut Self-Locking M8
7 MED5001 Rev3 1 Battery plate eDrive/ eMove
8 XSFM6X12 4 Screw Countersunk M6 x12
9 XSM6ML 4 Nut Self-Locking M6
10 MEM5011 1 Bracket
11 350070 1 Clamp tipping lever
3. Special assemble for the battery box under the wheelchairs.

2020-04-23
Joystick for user
Item No. Part Number Qty Description
1 XOC-48160-B0 1 Upper holder assembly2
2 XSM6X30 2 Screw M6 x 30
3 XSM6BR 4 Plain washer M6
4 XSM6ML 4 Locknut M6
5 XSM6X20 2 Screw M6 x 20
6 MED1502 1 Bracket
7 MED1501 1 Bracket

2020-04-23
Attendant control with joystick (left and right side)
MED1409
Item No. Part Number Qty Description
1 MED1317 1 Bracket
2 XSM6X35 1 Screw M6 x 35
3 XSM6X16 2 Screw M6 x 16
4 XSM6BR 3 Plain Washer M6
5 XSM6ML 3 Locknut M6
6 MED1316 1 Plate with pin
7 Xklamma2 1 XClamp2
8 100 400 044 1 Spacer
Move this
too the
other side,
if you
assemble
the joystick
on the left
side.

2020-04-23
Alternative attendant control (only right side)
Item No. Part Number Qty Description
1 XSM6TG 1 Thorn Washer 6,4
2 Xklamma2 1 XClamp2
3 XSM6X20 1 Screw M6 x 20
4 XSM6BR 1 Plain Washer 6,4
5 MED1200 1 Attendant control

2020-04-23
Åtdragningsmoment / Tightening torque
Metriska grovgängor, stål.
Metric coarse threads, steel.
Gänga / Thread
Åtdragningsmoment / Tightening torque
M3
1,2 Nm
M4
3 Nm
M5
6 Nm
M6
10 Nm
M8
25 Nm
M10
50 Nm
M12
85 Nm
Navhylsor.
Sleeves.
Gänga / Thread
Åtdragningsmoment / Tightening torque
M16x1
30 Nm
M18x1
40 Nm
