Decon wheel Sorg Jump User manual

2021-09-03
Assembly instructions for Sorg Jump, Vector
MED3190
1. Remove wheels and sleeves on both sides.
2. Check the correct placement for the stop pin, and check that the battery box
and anti-tip devices are removed. Use the wheelchairs original tip-devices.

2021-09-03
3. Assembly the plate (right side) according to pictures.
Parts pair mounting set for one side:
ITEM PART NUMBER QTY DESCRIPTION
1 MED2000 1 Bracket
2 405241 1 Nordlock Washer M18
3 HW084 1 Sleeve
4 100 400 008 1 Spacer
5 100 400 016 1 Spacer
6 Vector Spacer 1 Not included (recycled from the wheelchair)
7 100 400 013 1 Spacer
8 XSM8X35 1 Screw Rounded M8 X 35
9 XSM8ML 1 Nut Self-Locking M8
10 XSM18M 1 Nut M18 low
4. Adjust side covers and brakes.
5. Assemble the back placed battery bag.
40-50 Nm
19,5-28,5 Nm

2021-09-03
Assemble the Joystick on Side cover with armrest
ITEM PART NUMBER QTY DESCRIPTION
1 XOC-48160-B0 1 SwingAway Bracket
2 MED1500 1 Bracket
3 XSM6X16 2 Screw Round M6 x16
4 XSM6BR 2 Plain Washer M6
5 XSM6ML 2 Lock Nut M6
6 MED1320 1 Bracket
7 NJF1022 1 Ball pin with pin
8 X0F-48160-D00 1 Sliding bracket assembly

2021-09-03
MED1209
Assembly instructions for Joystick as an Attendant control
Item No. Part Number Qty Description
1 MED1317 1 Bracket
2 XSM6X25 1 Screw M6 x 25
3 XSM6BR 3 Plain Washer M6
4 XSM6LM 3 Locknut M6
5 XSM6X20 2 Screw M6 x 20
6 MED1316 1 Plate with pin
7 8500-1042-01 1 Clamp dia. 20mm
8 100 400 039 1 Spacer

2021-09-03
MED1210
Assembly instructions for Attendant control
Item No. Part Number Qty Description
1 XSM6BRTG 1 Thorn Washer M6
2 XSM6X20 1 Screw Round M6 x 20
3 8500-1042-01 1 Clamp dia. 20mm

2021-09-03
Åtdragningsmoment / Tightening torque
Metriska grovgänga, stål.
Metric coarse thread, steel.
Gänga / Thread
Åtdragningsmoment / Tightening torque
M3
1,2 Nm
M4
3 Nm
M5
6 Nm
M6
10 Nm
M8
25 Nm
M10
50 Nm
M12
85 Nm
Navhylsor.
Sleeves.
Gänga / Thread
Åtdragningsmoment / Tightening torque
M16x1
30 Nm
M18x1
40 Nm
