Assembly instructions for R82 Combi frame x
MED3145
1. Remove wheels on both sides.
2. Check the correct placement for the stop pin, and that the anti-tip devices and Battery
box are removed.

2018-01-23
3. Assembly the plate (right side) according to picture.
4. Parts pair mounting set:
Item No. Part Number Qty Description
1 XSM18M 1 Nut M18 x1 low
2 405241 1 Nordlock M18 Washer
3 100 400 020 1 Spacer
4 XSM18BR 1 Washer M18
5 XSM6X30 1 Screw Round M6 x 30
6 HW056 1 Sleeve
7 MED 2004 1 Bracket
5. Assemble the extension spacer for brake pin and adjust the parking brakes.
Item No. Part Number Qty Description
1 XSM6X25 1 Screw Round M6 x 25
2 100 400 039 1 Spacer
6. Assemble the back placed battery bag.

2018-01-23
MED1204
User control with Joystick controller
7. Assemble the joystick control handle. Place the bracket 1 into the aluminum tube on
the side you want to place the joystick.
Item No. Part Number Qty Description
1 MED1203 1 Bracket plate
2 100 400 039 2 Spacer
3 XSM6BR 6 Washer Plain M6
4 XSM6X30 2 Screw Round M6 x 30
5 XA2-2615E-00 1 Plate, stopper
6 XOF-2612F-00 1 Boss
7 XSM6X35 2 Screw Round M6 x 35
8 XSM6ML 2 Nut Self-Locking M6
9 XOF-48160-00 1 Upper Holder Assembly

2018-01-23
MED1202
Attendant control with Attendant controller
8. Assemble the attendant control.
Item No. Part Number Qty Description
1 MED1200 1 Assistant controller
2 91312-06050 1 Screw Socket M6 x 50
3 92902-06200 2 Washer Plain M6
4 XA2-2612E-00 1 Clamp
5 XOD-2612K-00 1 Clamp2

2018-01-23
MED1356
Attendant control with Joystick controller
9. Assemble the attendant control with the joystick unit, see the pictures.
Item No. Part Number Qty Description
1 MED1317 1 Bracket
2 MC6SM6X35 1 Screw M6 x 35
3 XSM6X16 2 Screw M6 x 16
4 XSM6BR 3 Plain Washer M6
5 XSM6ML 2 Locknut M6
6 MED1316 1 Plate with pin
7 XOC-2612K-00 1 Clamp with thread
8 XOC-2612E-00 1 Clamp with hole
