Delta DVP04TC-S User manual

http://www.delta.com.tw/industrialautomation/
5011620601-T4E1
2005-06-20
DVP04TC-S
Thermocouple Sensors
Instruction Sheet
1
WARNING
Always read this manual thoroughly before using the DVP04TC-S.
In order to avoid electric shock, do not touch the terminals or conduct any maintenance while power is
applied to the PLC. Never open the PLC. Only qualified Delta personell should conduct any internal
electrical work on the PLC.
This is an OPEN-TYPE device and must be placed in an environment away from high temperatures, high
humidity, exceessive vibration, corrosive gases, liquids, airborne dust, and metallic particles when installed
in an enclosure.
Do not apply AC power to any of the input/output terminals, this will cause permanent damage to the
DVP04TC-S. Do NOT touch terminals when power on.
Make sure that the DVP-04TC is properly grounded , to avoid any electromagnetic noise.
2
INTRODUCTION
2.1Model Explanation and Peripherals
Thank you for choosing DELTA’s DVP Series PLC. The DVP04TC-S allows the connection of four
thermocouple sensors (Type J.K.R.S.T). The DVP04TC-S series can read/write the data by using commands
FROM / TO via DVP-PLC SS/SA/SX/SC MPU program. There are 49 CR (Control Register) in each module
and 16 bits per register.
DVP04TC-S thermocouple sensor can update software version by RS-485. Power supply and main
processing units are sold separately.
The DVP04TC-S works with both Centigrade and Fahrenheit. The input resolution for Centigrade is 0.1
degrees and for Fahrenheit is 0.18 degrees.
Nameplate Explanation
PLCmodel
Input power Supply Spec.
Analog Input /Output Module Spec.
Barcode, series and version
MODEL¡G
POWER INPUT¡G
THERMOCOUPLES¡G
04TC-S0T5020001VX.X
24Vdc 2W
MADE IN XXXXXX
RESOLUTION¡G 14 BITS
TYPE J ,K , R , S, T
Model Explanation
Serial Number
Model
S: for SS/SA /SX/SCseries MPU
XA: Analog input/output mixed module
ProductSeries
Input + Output points
Model type
AD: Analog input module
DA: Analog output module
PT: Platinum temperature sensors (PT-100)
TC: Thermocouple sensors (Type )
Production series
Production week
Production year (2005)
Production place (Taoyuan)
Serial number of version
Production Model
RT: Resistor Thermocouple(NTC)
2.2Product Profile and Outline
90.00
4.00
3.00
25.20
1
2
3
4
60.00
5
6
7
8
9
3
10
L+
L-
SLD
C
H
1
C
H
2
C
H
3
C
H
4
11
12
13
3.4
90.00
60.00
3.00
14
●
L+
L-
L+
L-
L+
L-
SLD
SLD
SLD
●
●
●
●
●
Unit:mm
1. Status indicator (Power, RUN and ERROR) 8. Expansion port
2. Model Number 9. Expansion Clip
3. DIN rail clip 10. DIN rail location (35mm)
4. I/O terminals 11. RS-485 Communication port
5. I/O point indicator 12. Expansion Clip
6. Expansion hole of the expansion unit mounting
pins
13. DC Power input
7. Specification Label 14. Expansion port
2.3External wiring
CH1
CH4
DC/DC
5V
AG
+15V
-15V
AG
24+
24-
SLD
L-
L+
SLD
L-
L+
Converter
System
Class 3 Grounding
(100 of less)
terminal of
power module
Shielded*1
*2
*3
Shielded*1
Grounding
Thermocouple
+
-
100
MUX
Cold-junction
Compensation
Thermocouple
+
-
Note 1: Use only the wires that are supplied with your thermocouple sensor. Tighten PLC terminal screws to a
torque of 1.95 kg-cm (1.7 in-lbs).
Note 2: Terminal SLD is a grounding location for noise suppression.
Note 3: Please connect terminal of power supply module and terminal of DVP04TC-S thermocouple
sensors module to system earth ground.
Warning: DO NOT connect wires to the No Connection ( ) terminals. Use copper conductor only, 60/75℃
2.4 Terminals of analog module
DVP04AD-S DVP02DA-S DVP04DA-S DVP04PT-S DVP04TC-S DVP06XA-S DVP08RT-S
V+
I+
COM
FG
V+
I+
COM
FG
I+
COM
FG
V+
I+
COM
FG
V+
V+
I+
COM
FG
V+
I+
COM
FG
V+
I+
COM
FG
V+
I+
COM
FG
I+
COM
FG
V+
I+
COM
FG
V+
L+
L-
FG
FG
I-
L+
L-
I-
L+
L-
FG
FG
I-
L+
L-
I-
L+
L-
SLG
L+
L-
SLG
L+
L-
SLG
L+
L-
SLG
V+
I+
COM
V+
I+
COM
I+
COM
V+
I+
COM
V+
V+
I+
COM
V+
I+
COM
L+
L-
L-
L-
L+
L+
L-
L+
L+
L-
L-
L-
L+
L+
L-
L+
3
STANDARD SPECIFICATIONS
3.1Function Specifications
Platinum Temperature Module (04TC) Centigrade (°C) Fahrenheit (°F)
Power supply voltage 24 VDC(20.4VDC~28.8VDC) ( –15%~+20%)
Analog input channel 4 channels per module
Sensors type J-type K-type R-type S-type T-type thermocouple
Temperature input range
J type : -100℃~700℃
K type : -100℃~1000℃
R type : -10℃~1700℃
S type : -10℃~1700℃
T type : -100℃~350℃
J type : -148℉~1292℉
K type : -148℉~1832℉
R type : -14℉~3092℉
S type : -14℉~3092℉
T type : -148℉~662℉
Digital conversion range
J type : K-1000~K7000
K type : K-1000~K10000
R type : K-100~K17000
S type : K-100~K17000
T type : K-1000~K3500
J type : K-1480~K12920
K type : K-1480~K18320
R type : K-140~K30920
S type : K-140~K30920
T type : K-1480~K6620
Resolution 14 bits(0.1°C) 14 bits(0.18°F)
Overall accuracy ±0.5% of full scale of 25°C(77°F), ±1% of full scale during 0~55°C
(32~131°F)
Response time 350 ms ×channels
Isolation Method Isolation between digital and analog circuitry. There is no isolation
between channels.
Digital data format 2’s complement of 16-bit, (13 Significant Bits)
Average function Yes (CR#2~CR#5 may be set and the range is K1~K4096)
Self diagnostic function Yes
Communication mode (RS-485)
MODBUS ASCII/RTU Mode. Communication baud rate of 4800 / 9600 /
19200 / 38400 / 57600 / 115200. For ASCII mode, date format is 7Bits,
even, 1 stop bit (7 E 1). For RTU mode, date format is 8Bits, even, 1 stop
bit (8 E 1). The RS-485 is disabled when the DVP04AD-S is connected in
series to an MPU.
Connection to a DVP-PLC MPU in
series
When DVP04-TC modules are connected to an MPU, the modules are
numbered from 0 – 7. 0 is the closest to the MPU and 7 is the furthest.
The Maximum number of modules is 8 modules and they do not occupy
any digital I/O points of the MPU.
3.2 Other Specification
Power Specification
Maximum Power Consumption 2W at 24 VDC (20.4VDC~28.8VDC) ( -15 % ~ +20 %)
Environment Condition
Environment Condition Follow the DVP-PLC MPU.
4
CR (CONTROLLED REGISTER)
DVP-04TC platinum temperature sensors
Explanation
CR
No.
RS-485
Parameter
address
Latched Register name b15 b14 b13 b12 b11 b10 b9 b8 b7 b6 b5 b4 b3 b2 b1 b0
#0
H 4096
○R Model type System used,. DVP-04TC model code = H 8B
#1
H 4097
○R/W Thermocouple type
Reserved CH4 CH3 CH2 CH1
Example: Setting of CH1
1. b2~b0: set (0,0,0) to use J-type
2. b2~b0: set (0,0,1) to use K-type
3. b2~b0: set (0,1,0) to use R-type
4. b2~b0: set (0,1,1) to use S-type
5. b2~b0: set (1,0,0) to use T-type
#2
H 4098
○R/W CH1 average number The number of readings used for “average” temperature on channels
CH1~CH4.
Setting range is K1~K4096 and factory setting is K10.
#3
H 4099
○
R/W
CH2 average number
#4
H 409A ○
R/W
CH3 average number
#5 H 409B ○R/W CH4 average number
#6 H 409C ╳R CH1 average degrees(°
C)
Average degrees for channels CH1~CH4. (unit: 0.1 degrees C)
#7
H 409D ╳
R
CH2 average degrees(
°
C)
#8
H 409E ╳
R
CH3 average degrees(
°
C)
#9
H 409F ╳
R
CH4 average degrees(°
C)
#10 H 40A2 ╳R CH1 average degrees(°F)
Average degrees for channels CH1~CH4. (unit: 0.1 degrees F)
#11
H 40A3
╳R CH2 average degrees(°F)
#12
H 40A4
╳
R
CH3 average degrees(
°
F)
#13
H 40A5
╳
R
CH4 average degrees(
°
F)
#14 H 40A8 ╳R
Present temperature of
CH1 (°C)
Present temperature of channels CH1~CH4. (unit: 0.1 degrees C)
#15 H 40A9 ╳R Present temperature of
CH2 (°C)
#16 H 40AA ╳R Present temperature of
CH3 (°C)
#17 H 40AB ╳R Present temperature of
CH4 (°C)
#18
Reserved
#19 H 40AE ╳R Present temperature of
CH1 (°F)
Present temperature of channels CH1~CH4. (unit: 0.1degrees F)
#20 H 40AF ╳R Present temperature of
CH2 (°F)
#21 H 40B0 ╳R
Present temperature of
CH3 (°F)
#22 H 40B1 ╳R
Present temperature of
CH4 (°F)
#23
Reserved
#24
H 40AE
○
R CH1 OFFSET Value
Adjust offset value of channels CH1~CH4. The range is -1000~+1000 and
factory setting is K0. (unit: 0.1 degrees C)
#25
H 40AF
○
R
CH2 OFFSET Value
#26
H 40B0
○
R
CH3 OFFSET Value
#27 H 40B1 ○
R
CH4 OFFSET Value
#28~#29
Reserved
#30
H 40B4
╳R Error status Data register stores the error status, refer to fault code chart for details.
#31 H 40B5 ○
R/W
Communication address
setting
RS-485 communication address.
Setting range is 01~255 and factory setting is K1
#32
H 40B6 ○
R/W
Communication baud
rate setting
Communication baud rate (4800, 9600, 19200, 38400, 57600 and 115200 bps).
b0: 4800 bps (bit/sec).
b1: 9600 bps (bit/sec). (factory setting)
b2: 19200 bps (bit/sec).
b3: 38400 bps (bit/sec).
b4: 57600 bps (bit/sec).
b5: 115200 bps (bit/sec).
b6~b13: Reserved.
b14: switch between low bit and high bit of CRC code (only for RTU mode)
b15: RTU mode.
#33 H 40B7 ○R/W Reset to factory setting
b15
b14
b13
b12
b11
b10
b9
b8
b7
b6
b5
b4
b3
b2
b1
b0
Definition of ERR
LED
CH4
CH3
CH2
CH1

Example: Setting of CH1
1. b0 Reserved
2. b1 Reserved
3. b2: Set to 1 and PLC will be reset to factory settings.
Definition of ERR LED: b12~b15=1111(factory settings)
1. b12 corresponds to CH1: when b12=1, scale exceeds the range, ERR LED
flashes.
2. b13 corresponds to CH2: when b13=1, scale exceeds the range, ERR LED
flashes.
3. b14 corresponds to CH3: when b14=1, scale exceeds the range, ERR LED
flashes.
4. b15 corresponds to CH4: when b15=1, scale exceeds the range, ERR LED
flashes.
#34
H 40B4
○
R
Software version
Display software version in hexadecimal. Example: H 010A = version 1.0A.
#35~#48
System used
○means latched.
╳means not latched.
R means can read data by using FROM command or RS-485.
W means can write data by using TO command or RS-485.
Explanation:
1. CR#0: The PLC model type.
2. CR#1: Used to set the working mode of four channels (CH1~CH4). There are 2 modes (J-type and K-type)
for each channel and allow to set separately. For example, If you want to set CH1~CH4 as CH1: mode 0
(b2~b0=000), CH2: mode 1(b5~b3=001), CH3: mode 0(b8~b6=000) and CH4: mode 1(b11~b9=001), you
should set CR#1 to H0208. The higher bits (b12~b15) will be reserved and the factory setting is H0000.
3. CR#2 ~ CR#5: Used to set the number of input readings used for the average temperature calculation. The
available range is K1~K4096 and factory setting is K10. (Note: When PLC sets average times via TO/DTO
instructions, please use rising-edge/falling-edge detection instruction (such as LDP and LDF) to get correct
average times.)
4. CR#6 ~ CR#9: The average temperature (°C). The average temperature is calculated using multiple
temperature readings. Example: If CR#2 is 10, the temperature in CR#6 will be the average of the last 10
readings on CH1.
5. CR#10 ~ CR#13: The average temperature (°C). The average temperature is calculated using multiple
temperature readings. Example: If CR#2 is 10, the temperature in CR#12 will be the average of the last
10 readings on CH1.
6. CR#14 ~ CR#17: display present temperature (°C) of CH1~CH4 input signal.
7. CR#18, CR#23, CR#28, CR#29 are reserved.
8. CR#19 ~ CR#22: display present temperature (°F) of CH1~CH4 input signal.
9. CR #24 ~ CR #27: display offset value of channels CH1~CH4. The range is -1000~+1000 and unit is 0.1
degrees C. The definition of OFFSET is Actual temperature = temperature measured by DVP-04TC –
OFFSET value.
10. CR#30 is a fault code register. Refer to the following chart.
Fault description Content b15~b8 b7 b6 b5 b4 b3 b2 b1 b0
Power source abnormal K1(H1)
Reserved
0 0 0 0 0 0 0 1
Analog input value error K2(H2) 0 0 0 0 0 0 1 0
Setting mode error K4(H4) 0 0 0 0 0 1 0 0
Offset/Gain error K8(H8) 0 0 0 0 1 0 0 0
Hardware malfunction K16(H10) 0 0 0 1 0 0 0 0
Digital range error K32(H20) 0 0 1 0 0 0 0 0
Average times setting error K64(H40) 0 1 0 0 0 0 0 0
Command error K128(H80) 1 0 0 0 0 0 0 0
Note: Each fault code will have corresponding bit (b0~b7). Two or more faults may happen at the same time. 0
means normal and 1 means fault occurs.
11. CR#31: RS-485 communication address. Setting range is 01~255 and factory setting is K1.
12. CR#32: RS-485 communication baud rate: 4800, 9600, 19200, 38400, 57600 and 115200. b0:4800bps,
b1:9600bps (factory setting), b2:19200bps, b3:38400 bps, b4:57600 bps, b5:115200 bps, b6~b13:
Reserved, b14: switch between low bit and high bit of CRC code (only for RTU mode) b15: ASCII / RTU
mode. For ASCII mode, date format is 7Bits, even, 1 stop bit (7 E 1). For RTU mode, date format is 8Bits,
even, 1 stop bit (8 E 1).
13. CR#33: Used to reset the settings of CR registers to factory defaults.
14. CR#34: software version.
15. CR#35~ CR#48: Reserved for internal system use.
16. The corresponding parameters address H 4096~H 40C7 of CR#0~CR#48 may provide users to read/write
data via RS-485 communication.
a) Communication baud rate: 4800, 9600, 19200, 38400, 57600, 115200 bps.
b) Communication format: ASCII mode is 7Bit, even bit, 1 stop bit (7 E 1). Communication format of
RTU mode is 8Bit, even bit, 1 stop bit (8 E 1).
c) Function code: 03H—read data from register. 06H—write a WORD into register. 10H—write many
WORDs into register.
5
TEMPERATURE/DIGITAL CHARACTERISTIC CURVE
Temperature mode: (Centigrade/Fahrenheit)
J-type thermocouple sensors
[phone])
-1000(-1480)
+700-100
Digital Output
Temperature Input
CC
F)
(-148 F)
(+1292
K-type thermocouple sensors
+10000(18320)
-1000(-1480)
+1000-100 CC
Temperature Input
Digital Output
(-148 F) (-1832 F)
R/S-type thermocouple sensors
+17000(30920)
-100(-140)
+1700-10
Digital Output
Temperature Input
C C
F)
(-14 F)
(+3092
T-type thermocouple sensors
[phone])
-1000(-1480)
+350-100
Digital Output
Temperature Input
CC
F)
(-148 F)
(+662
6
INITIAL PLC START-UP
LED display:
1. Upon power-up, the ERROR LED will light for 0.5 seconds the POWER LED will light continuously.
2. No errors= POWER LED on and ERROR LED off.
Low Voltage error (lower than 19.5V), ERROR LED will blink continuously till the power supply rises above
19.5V.
3. DVP04TC-S connected to PLC MPU in series = RUN LED on MPU will be lit and A/D LED or D/A LED should
blink.
4. After receiving the first RS-485 command the A/D LED or D/A LED will blink.
5. If the input or output exceeds the upper or lower bounds, then the ERROR LED will blink.
Example:
M1000
FROM K0
= H8B D0
TO K0
FROM K0
FROM K0
FROM K0
FROM K0
END
M1002
Explanation:
Reading the model type of expansion module K0 (should be H8B for DVP04TC-S model type).
The averaging number for CH1~CH4 will be D10~D13.
If the model type is DVP04TC-S. Reading the average temperature (°C) of CH1~CH4 (4 data) from
CR#6~CR#9 and save them into D20~D23.
Reading the average temperature (°F) of CH1~CH4 (4 data) from CR#10~CR#13 and save them into
D24~D27.
Reading the present temperature (°C) of CH1~CH4 (4 data) from CR#14~CR#17 and save them into
D30~D33.
Reading the present temperature (°F) of CH1~CH4 (4 data) from CR#19~CR#22 and save them into D34~D37.
7
RELATED INSTRUCTIONS EXPLANATION
API
FROM
Read special module CR data
78
D
P
Explanations:
m1: number of special module (m1=0~7). m2: CR number of special module that will be read. D: address for saving
reading data. n: data number for reading once.
Example:
Writing special module #0 of CR#24 into D0 and special module #0 of CR#25 into D1. only write two data once
(n=2).
X10 FROM K0 K24 D0 K2
API
TO
Special module CR data write
79 D P
Explanations:
m1: number of special module (m1=0~7). m2: CR number of special module that will be wrote in. S: data to write in
CR. n: data number to write in once.
Example:
Using 32-bit instruction DTO to write D11 and D10 into special module#0 of CR#3 and CR#2. only write a data once
(n=1).
X11 DTO K0 K2 D10 K1
The rule of instruction operand:
1. m1: number of special module. The special module closest to the ELC controller will be assigned 0, the next
closest will be assigned 1, etc. for a total of 8 modules(0~7).
2. m2: number of CR. Built-in of 48 groups of 16-bit memory of special module are called CR (Control Register).
Each CR uses decimal digits (#0~#48).
CR #10 CR #9
Upper 16-bit Lower16-bit
Specified CR number
D0
D1
D2
D3
D4
D5
CR #5
CR #6
CR #7
CR #8
CR #9
CR #10
D0
D1
D2
D3
D4
D5
CR #5
CR #6
CR #7
CR #8
CR #9
CR #10
Specified device Specified CR Specified device Specified CR
16-bit command when n=6 32-bit command when n=3
3. In PB models, flag M1083 is not provided. When the FROM/TO instruction is executed, all interrupts (including
external or internal interrupt subroutines) will be disabled. All interrupts will be executed after the FROM/TO
instruction is completed. The, FROM/TO instruction can also be executed in an interrupt subroutine.
4. The function of the flag M1083 (FROM/TO mode) provided in PC/PA/PH models:
a. When M1083=OFF, FROM/TO instruction is executed, all interrupts (including external or internal
interrupt subroutines) will be disabled. All interrupts will be executed after FROM/TO instruction is
completed.
b. When M1083=ON, if an interrupt occurs while the FROM/TO instruction has been programmed, The
FROM/TO instruction will be interrupted to execute the interrupt. The FROM/TO instruction cannot be
executed in the interrupt subroutine.
