DEMA Nitro Plus User manual









I-1205
Rev. B-43
Overv
i
The DEMA
®
dish machin
e
Warni
n
816
ew
®
Nitro Plus i
s
e
s. The unit is
n
gs
Installat
i
bynatio
n
regulati
o
installat
i
Allinstal
devices.
codesin
tee.
ALWAYS
W
3/23/2
0
Ware
W
s
a digital war
e
triggered by a
i
onofDEMAp
n
al,city,coun
t
o
nsrequireth
a
on.Forquesti
o
lationsmustc
Apressurein
d
thestateof
W
W
EARPROTEC
0
18
DEM
A
W
ash C
h
e
wash dispens
e
ware wash m
a
roductsmust
m
t
y,parish,pro
v
a
tacertifiede
l
o
ns,contacta
o
nformtoloc
a
d
icatingteeis
t
W
isconsinand
a
TIVECLOTHIN
G
A
Nitro
h
emical
e
r designed to
a
chine. The Ni
t
m
eetallappli
c
v
incialorothe
r
l
ectricalcontr
a
certifiedelect
a
lplumbingco
t
obeinstalled
a
nyotherstat
e
G
ANDEYEWE
A
Plus
Dispen
s
dispense clea
n
t
ro Plus is pro
g
c
ableelectrical
r
agencies.Iti
s
a
ctororengin
e
rician.
desandusea
p
withexisting
f
e
thatrequires
ARWHENW
O
Page
s
ing
n
ing chemicals
g
rammed via t
h
codesandre
g
s
possiblethat
e
erperformth
p
provedbackf
f
aucetsaccord
theuseofap
O
RKINGWITH
C
1 of 13
into ware wa
s
h
e front panel.
g
ulationsesta
b
electricalcod
e
eelectrical
lowpreventio
n
ingtolocalpl
u
ressureindica
t
C
HEMICALPR
O
s
h and
b
lished
e
sand
n

u
mbing
t
ing
O
DUCTS.

I-1205
Rev. B-43816 Page 2 of 13
3/23/2018
Note:Left to Right- 1st Position Detergent,
2nd Position Rinse, 3rd Position Sanitizer
L = Liquid (pump)
D = DRY (solenoid valve)
Liquid or Dry Chemical Product
Nitro Plus
Base Unit
Nitro Express Models
Nitro Plus can be built in a number of configurations. The following applies to all systems.
Prewired with power, trigger and probe cables.
Mounting bracket assembled to the Nitro Plus and ready to use.
Appropriate installation kit items that include, fittings, tubing, etc. (see Packout Kitsection)
NP.DLL.TI
Trigger Device
T = Trigger Board
M = Magnetic Field Sensor
Packing Kit List
NitroPlusInstallationKit
Part
Number
Description
Qty/Model
NP.DL.T
NP.LL.T
NP.DLL.T
NP.LLL.T
904.8TRinseCheckValve(StainlessSteel) 1  1  1  1 
904.8KYSanitizerCheckValve(Kynar) 1  1 
80.55LiquidDetergentBulkheadFitting 1  1 
58.5DryDetergentBulkheadFitting 1  1 
C.12VIKConductivityProbe(FlipProbe) 1  1  1  1 
25.68.201/4"ODLDPETubing‐20ft 1  1  1  1 
100.12.SV1VinylRinseTube‐16ft 1  1  2  3 
81.312.1SplitPickupTubeStiffener 1  2  2  3 
81.182.11/4"x1/4"Push‐OnFittings(forpump) 2  4  4  6 
81.16.1TieWraps8"Long 5  5  8  8 
I‐1205InstructionSheet 1  1  1  1 
Strain Relief
System will come with strain relief for the
wiring that is exiting the enclosure.
Systems that do have the "I" come
with a 1/2" conduit.

I-1205
Rev. B-43816 Page 3 of 13
3/23/2018
Operational Requirements
For Indoor Use Only
Main Powe
r
100 VAC – 250 VAC 50/60 Hz 1.5 A
Trigger Signals 20V – 500V 50/60 Hz 200mA
Motors/Solenoid Valves 24VDC
Detergent Pump Rate 10oz/min (300ml/min)
Rinse/Sanitizer Pump Rate 0.5oz/min (15ml/min)
Operating Temp 4-30°C 40-100°F
Case Material ABS
Weight 3.8 kg 8.5 lbs
Max. Altitude 2000 M 6500 ft
Environmental Temp 0-40°C 32-104°F
Installation Category II
Pollution Category II
The integrity and operational characteristics of this unit are not guaranteed outside the above
mentionedparameters.Useofthisunitoutsideoftheseparametersnullifieswarranty.
Overall Size
Sanitizer Rinse Detergent
