DINUY RE DMS 001 User manual

INSTRUCTIONS MANUAL
CONSTANT LIGHT CONTROLLER
& MOTION DETECTOR
for 1/10VDC ELECTRONIC BALLASTS
RE DMS 001
2DESCRIPTION
3WORKING
RE DMS 001
Constant Light Control
ON / OFF
· Flush ceiling mounting.
· Built in LED  Which is lighted upon detecting movement.
· 1/10VDC output  For dimmable electronic ballasts.
· Possibility of extending the coverage area of motion detection with
extra sensors (only AUTO mode).
Technical Specifications
· Power supply: 230V~ 50Hz
· Consumption: 2W
· Load type: 80 dimmable 1/10V
DC electronic ballasts
· Relay operating voltage: 250V
AC
· Relay cutout capacity: 16A
· Max. absorption current: 500mA
· Max. injection current: 40mA
· Coverage: 360º and
Æ 6m max. at 2,4m high
· Time delay: AUTO mode: 10min ~ 30min
MOV mode: 5sec ~ 10min
· Number of motion sensors: Up to 15 units
(14 x DM SEN T03) - Only in Automatic mode
· Sensor dimensions:
Æ65mm
· Control dimensions: 107 x 53 x 34mm
· Weight: 205g
· Protection degree: IP20 according to EN60529
· Operating temperature: 0ºC ~ +40ºC
· Storage temperature: -10ºC ~ +45ºC
· Connection terminals: Wires of up to 6mm
2
cross section
· According to: EN60730
It consists in a constant light control for installations with fluorescent
lamps, associated to 1/10V dimmable electronic ballasts.
These type of systems are usually used in offices, conference halls,
hotels,...
Consists of 2 elements:
Sensor:
- Flush ceiling sensor, just like a 65mm diameter halogen lamp.
- With built-in brigthness sensor and motion detector.
- RJ12 connector.
- Four settings:
· Mode selector: Automatic (constant light control + motion detection),
only constant light control or only motion detection (see point 5A).
· Switch-off % level setting (see point 5B).
· Time delay setting (see point 5C).
· Programming setting (see point 5D).
Control:
- Can be mounted over the false ceiling, connected to the sensor.
- 1/10VDC output signal for dimmable electronic ballasts.
- Incorporates a relay which disconnects physically the ballasts. It
allows to switch-off completely the lamps.
Extra motion sensor DM SEN T03:
- Extra motion sensor that can extend the coverage area.
Attention! Only for AUTO mode.
- RJ12 connector that allows quick and easy installation.
B. Installation procedure:
Before doing the wiring disconnect the mains supply in order to
do the installation without voltage.
C. Wiring diagrams:
C.1. Installation using K relay (L' output)
Doing this wiring, the fluorescents will be physically disconnected when
dimming level reaches a value lower than the 10%.
C.2. Installation without K relay (L' output)
Doing this wiring, the fluorescents will keep turned-on to its minimum
level when the regulation signal reaches to its lowest value (enough
natural light).
The user sets the desired light level and the system dims the ballasts in
order to maintain the brightness level.
The system can operate with or without motion detection. If this
function is activated, the system will begin to run as soon as motion is
detected and it will continue working until the selected time finishes.
If motion detection is not applied, the system will allways run whereas
it is supplied.
The RE DMS 001 can also work as only motion detector with the
Corridor function (adjustable switch-off level %).
4INSTALLATION
AND WIRING
A. Select a appropiate location:
Depending on the use and operation mode:
- If the constant light control is used:
Distribute the installation by zones depending on the daylight.
In each clearly differentiated area it should be installed a sensor/control.
In case of making use of both functions (motion detection and constant
light control) it is necessary to fulfill the above-cited requirements.
If the current is highest than 16A, it will be
necessary to build in a contactor at L' output.
C.3. Installation of an auxiliary switch to turn-off manually
It is possible to install an auxiliary switch to turn on/off manually the
system. At installations, for example, with the movement detection
function cancelled, this swith will allow to turn on/off the system
voluntarily at any time.
Access to the terminals:
Easy installation on false ceilings. It is only necessary 48mm height, if
the orifice has a diameter of 68mm:
and 60mm height if the orifice is 55mm.
2,4M
Install the sensor over the place that is desired to take as brightness
reference (normally the desk).
In order to get an optimal operation of the system, the sensor should be
installed at a distance of 2 ~ 3m from the window.
Avoid placing the sensor over dark surfaces (dark furniture or carpets)
or highly reflecting (polished tables and floors).
Avoid pointing light onto the sensor (sunray, reflexions of windows or
mirrors, lamps focused to the sensor,...).
- Installation criteria for optimal performance of motion detection:
Install the sensor taking into account the range of vision or detection
area.
Nota: after supplying the dimmer the lamps will turn-on to its
maximum level. The system is self-regulate to the adjusted light
level with some inertia.
This inertia last, approximately, 10min, from the maximum level
(100%) to the minimum (<10%).
Considering that motion detector responds temperature changes,
please avoid next conditions:
- Avoid pointing the sensor towards areas or objects whose surfaces
are highly reflective or are subject to rapid temperature changes.
- Avoid mounting the sensor near heat sources, such as heating vents,
air conditioners, dryers, vents or lights.
- Avoid directing the sensor towards light sources.
- Avoid aiming the sensor towards objects, which may move by wind,
such as curtains, small trees or bushes.
Switch
1CHARACTERISTICS
LATERAL VIEW TOP VIEW
4 elements
· Insert the two long spring-fixing clips into the hole and once
released they will keep adjusted automatically.
· Adjust the position of the sensor. Be sure that bottom of sensor is
tightly stacked on the ceiling.
Note
L
L
N
+
-
L
N
L
L
N
+
-
L
N
L
L
N
+
-
L
N
BALLAST
FLUORESCENT TUBE
BALLAST
FLUORESCENT TUBE
BALLAST
FLUORESCENT TUBE
BALLAST
FLUORESCENT TUBE
BALLAST
FLUORESCENT TUBE
BALLAST
FLUORESCENT TUBE
LN
+-
LN
+-
LN
+-
LN
+-
LN
+-
LN
+-
RE DMS 001
RE DMS 001
RE DMS 001

5SETTINGS AND
WORKING TEST
C.4. Installation with extra motion sensors (only AUTO mode)
Is possible to extend the coverage area of motion detection by
installing up to 14 extra motion sensors (DM SEN T03).
A. OPTIONAL Programming day and night lighting setpoints
(only for AUTO and REG modes)
The system is calculated to achieve an adequate lighting,
approximately 500 - 600Luxes, on the desk in a standard
installation. If the results obtained with the factory settings are
not the desired please adjust the setpoints "day" and "night" by
following the steps detailed below.
Allows setting the desired brightness level in the installed place.
For programming, two points must be set: day and night.
A.1. At night or with the room in the dark:
- Install according to the above connection diagrams, and place the
sensor in its location.
- Supply the device.
- Wait for 1 minute until the sensor is stabilized.
- Turn LUX control knob to   position. The sensors red LED flickers
intermittently. The lamps will be switched-on at maximum.
- Place the sensor in its position and get away from it around 4 - 5m.
- Wait for 1 minute. The lamps and the sensors red LED will be
switched-off. At this moment, the device has memorized the
brightness target value for the maximum switching-on.
- Finally, set the LUX control knob in the middle.
A.2. During the day and under normal conditions and with the
desired daylight:
- Wait for 1 minute until the sensor is stabilized.
- Turn LUX control knob to   position. The sensors red LED
flickers intermittently. The lamps will be switched-off.
- Place the sensor in its position and get away from it around 4 - 5m.
- Wait for 1 minute. The lamps and the sensors red LED will be
switched-off. At this moment, the device has memorized the
brightness target value for the switching-off.
- Finally, set the LUX control knob in the middle.
E. Motion detection Test and LED Function
The LED can be used to show whether the load is switched-on or off
when doing the working tests:
1. Aim the sensor towards the area to be covered.
2. Adjust TIME knob at - position. In this mode each detection is a
time delay of a 10sec on.
3. Turn-on the device.
4. Wait for more than 1 minute for becoming stabilized.
5. Walk from outside to inside of the coverage area until the detection
is done.
6. Adjust the head of the sensor to change the coverage area. Remind
not pointing the head towards a light focus.
7. Repeat steps 5 and 6 until reaching the desired detection area.
6REMOTE CONTROL
CO REG R05
When unlocking te remote control, it does not indicate the mode in
which the sensor is. Is necessary to press the mode key you wish to
activate.
E94HDIC7
The RE DMS 001 has 4 knobs to do the different settings:
A. Working mode: Automatic (Constant Light Control + Motion
Detection), only Constant Light Control or only Motion Detection
- AUTO: constant light control depending on the daylight with the
motion detection function.
- REG: constant light control depending on the daylight without the
motion detection function.
- MOV: only motion detection despite daylight and dimming. It is
possible to set the switch-off level % (Corridor function - point
5B).
In this mode, the LUX setting knob must be in the middle and it
does not admit extra motion sensors (DM SEN T03).
B. Switch-Off setting %. Corridor Function
This setting is only operative working in motion detection function
(MOV).
It allows setting the dimming level when the lamps are in stand-by,
without any movement. It can be set between 0% (-) and 50% (+).
C. Delay time setting (TIME) and TEST mode (-)
With this knob is set the delay time after a motion detection.
This time can be adjusted between:
- AUTO mode: 10 ~ 30min.
- MOV mode: 5sec ~ 10min. TEST mode (-) is not available.
If the knob is adjusted at minimum (-) it is selected TEST mode. This
mode is helpful at the moment of doing the detection tests for as it
decreases the connection time to only 10sec. In this mode, and for
10sec, it could be also tested if the dimming of the lamps is working.
For that, and with daylight, if the sensor is covered with the hand, it
would be possible to check that the light of the lamps increases and at
the moment of moving away the hand the light of the lamps will
decreases step by step.
This setting is not important working in REG mode because the motion
detection does not work.
Is possible to control the device via the infrared remote control
CO REG R05. It will allow programming the day and night light points
without the need to access to the roof and dim the lamps manually at
any moment. It is only valid for AUTO or REG modes.
It has 3 working modes:
- Programming mode Prog: sets the brightness target values (day
and night).
- Automatic mode AUTO or REG: automatic dimming depending on
the daylight.
- Manual mode: allows switching and dimming manually the lamps
with the remote control.
A. Programming mode Prog
A.1. At night or with the room in the dark
- Turn on the lamps with the "ON" key and dim them to the desired
level. This will be the maximum level to which it will turn on the lamps.
- Wait 30 seconds without blocking the light received by the sensor.
- Switch to programming mode by pressing the "Prog" key and without
pointing to the sensor. By pressing the key, the LED on the remote
control will light indicating that it is in this mode.
- Press the " " key pointing to the sensor. Thus, the night point is
configured.
KEY FUNCTION
Lock
The remote control is Locked and will not
respond to pressed keys. Thus are avoided
unintentional keystrokes and also contributes to
saving battery.
Unlock
The control is Unlocked responding to
keystrokes. If no keys are pressed for 30sec the
remote control goes into Lock mode.
Manual Dimming
Keeping pressed these keys is possible to dim
manually the lamps.
Night setting
Is memorized the daylight level below which the
luminaires remain on.
ON at Maximum
The lamps are turned-on at its maximum level.
Automatic mode
Auto mode is selected. The lamps are regulate
automatically according to the desired light level
and the daylight.
Programming mode
Enters into programming mode to set the points
for day and night lighting.
Day setting
Is memorized the daylight level below which the
luminaires remain off.
Manual ON / OFF
Is forced permanent ON or OFF manually.
Reset
Allows to reset the factory settings (day and night
points).
Battery LED
This LED stays on while the keyboard is
unlocked and constantly flashes to indicate that
the battery is running low.
A.2. During the day and under normal conditions and with the
desired daylight
- If the lamps are on, force them off by pressing the "OFF" key.
- Wait 30 seconds without blocking the light received by the sensor.
- Switch to programming mode by pressing the "Prog" key and without
pointing to the sensor. By pressing the key, the LED on the remote
control will light indicating that it is in this mode.
- Press the " " key pointing to the sensor. Thus, the day point is
configured.
- Finally, press the "Auto" key pointing to the sensor to switch to
automatic mode.
The RE DMS 001 indicates that the points have been stored (day and
night) by three flashings of the red LED.
B. Automatic mode Auto
In this mode, the LED of the sensor will light only after detecting motion.
The lamps will be self-regulated depending on the set brightness level
and the daylight.
C. Manual Mode
In this mode, the LED of the sensor will be on permanently.
It has several buttons for manual control: Dimming Up/Down, ON, OFF
and Maximum ON.
C/Auzolan 2, 20303 Irún (SPAIN)
Tel.: [phone] / [e-mail] / www.dinuy.com
L
L
N
+
-
L
N
DM SEN T03
BALLAST
FLUORESCENT TUBE
LN
+-
RE DMS 001
TIME
A
U
T
O
R
E
G
M
O
V
LUX
