dji M30 User manual

DJI Matrice 30 Series Dock Version
User Guide
v1.0

Introduction
DJITM MATRICE TM 30 Series Dock Version aircraft can be linked to DJI Dock Version. With DJI FlightHub 2, it can be
used to perform automated operations remotely.
In the Box
Aircraft* ×1
with microSD card inserted
Screws and Tools ×1 1671 Propeller ×2 1671 Propeller ×2
CW CCW
* The M30 Dock Version and M30T Dock Version are equipped with different cameras. Refer to the actual product
purchased. This guide uses the M30T aircraft as an example.
Preparing the Aircraft
Make sure the propellers are securely mounted and not damaged or deformed and that
there are no foreign objects in or on the motors or propellers.
Make sure the lenses of the vision systems, gimbal cameras, FPV camera, the glass of the
infrared sensors, and the auxiliary lights are clean and not blocked in any way, and the
protective stickers are removed.
Make sure the waterproof rubber port covers are correctly in place and securely sealed.
1. Unfold the frame arms on both sides in the same way. Make sure the frame arm folded buttons pop out so
that the frame arms are locked firmly.
2. Make sure the gimbal camera is facing forward laterally.
3. Insert two TB30 batteries (purchased separately). Make sure the battery release toggles are in the same
position as shown in the diagram.

4. Press and then press and hold the power button to power on/off the aircraft. The power indicator glows
solid after the aircraft is powered on.
Push the battery release toggles outward to remove TB30 batteries.
Make sure to push and hold the frame arm folding button and fold the arms in before
transporting the aircraft separately.
When transporting the unpacked dock, make sure to remove the aircraft from the dock for
separate transportation.
Linking to the Dock
The aircraft and the dock require activation before use for the first time. An internet
connection is required for the remote controller during activation.
When the dock is connecting to the remote controller and the dock cover is opening
using DJI Pilot 2, make sure to keep a safe distance from the dock cover movement
mechanism to avoid injury. Press any of the emergency stop buttons on the dock to stop
the dock covers from opening, if necessary.
When the dock cover needs to be closed after the aircraft is placed in the dock, it is
recommended to close the cover in the app or on FlightHub 2. Before closing the dock
covers (including manual closing), make sure to move the two blades for each motor to
be at 90°with each other in order to avoid breaking the propellers when closing the
dock cover.
1. Open the dock electrical cabinet door. Use the USB-C cable included in the Dock Bundle to connect the USB-C
port of the remote controller to the USB-A port of the dock electrical cabinet.
2. Power on the remote controller, run DJI Pilot 2, and follow the prompts to complete the activation for the
aircraft.
3. Make sure the driving rods on the landing pad are pulled back, the aircraft heading is consistent with the
arrow mark on the landing pad, and the aircraft is placed on the landing pad. Move the two blades for
each motor to be at 90°with each other to complete the configuration, as shown in the diagram. Make sure
to close the dock cover in the app.
4. Dock Onsite Debugging in DJI Pilot 2 provides the aircraft status and operations such as charging aircraft.

Usage
Scan the QR code or go to the address to watch the tutorial videos and read the related manuals such as the Safety Guidelines, User
Manual and Installation and Setup Manual. Make sure to understand the safety precautions and learn more aircraft information.
Disclaimer and Warning
By using this product, you signify that you have read, understand, and accept the terms and conditions of this
guideline and all instructions at www.dji.com/dock.
EXCEPT AS EXPRESSLY PROVIDED IN AFTER-SALES SERVICE POLICIES AVAILABLE AT
HTTPS://WWW.DJI.COM/SERVICE/POLICY, THE PRODUCT AND ALL MATERIALS AND CONTENT AVAILABLE
THROUGH THE PRODUCT ARE PROVIDED "AS IS" AND ON "AS AVAILABLE BASIS" WITHOUT WARRANTY OR
CONDITION OF ANY KIND. This product is not intended for children.
Specifications
Operating Temperature -20°to 50°C (-4°to 122°F)
Video Transmission System O3 Enterprise
Operating Frequency 2.4000-2.4835 GHz, 5.170-5.250 GHz; 5.725-5.850 GHz

Transmitter Power (EIRP)
Max Transmission Distance 15 km (FCC), 8 km (CE/SRRC/MIC)
Power Supply Using external battery
Compatible Battery Model TB30 Intelligent Flight Battery
