Digital Monitoring Products, Inc. | 1134 Installation and Programming Guide 1
Annunciators
An onboard programmable piezo provides
local annunciation at the 1134. You can
also connect a variety of switched ground
annunciators to the 1134 for remote
annunciation.
Indicator LEDs
The 1134 provides three indicator LEDs:
• RELAY (red) turns on for the same
duration as the door strike relay.
• WIEGAND (yellow) turns on for one
second to indicate receipt of valid input.
• SURVEY (red) indicates signal strength
to the wireless receiver.
The 1134 Wireless Access Control Module allows you to use the powerful, built in access
control capability of DMP Panels using smartcard, proximity, mag stripe, or biometric
readers, or other compatible authentication devices. The 1134 includes the following
features:
Power Supply
The 1134 operates at 12/24VDC from
the power supply supporting a door’s
magnetic lock or door-strike.
Warning: To avoid the risk of
equipment damage, do not exceed
750mA total output current for
zones connected to the module.
Zone Terminals
Zones 1 - 4 on the 1134 can be
programmed for a variety of burglary or
access control applications.
ABOUT THE 1134

2 1134 Installation and Programming Guide | Digital Monitoring Products, Inc.
Form C Relay
The 10Amp Form C relay draws up to
35mA of current. Refer to “Wire the
Access Control Lock” and “Isolation Relay
(optional)” in this document for more
information.
Programming Connection
The 1134 also provides a keypad
programming connection that allows
you to use a standard DMP LCD keypad
for initial setup. Programming can be
completed using a keypad connected
to the 1134 or from XR150/XR550 Series
panels.
Dry/Wet Contact
Apply 12 VDC power from the module
directly to the door relay (WET setting)
or connect the relay to a separate power
supply (DRY setting).
Built-In LED Survey
The 1134provides survey LED capability
that allows one person to confirm
communication with the panel and
receiver while the cover is removed.

Digital Monitoring Products, Inc. | 1134 Installation and Programming Guide 3
PCB FEATURES
Figure 1: PCB Features
1234 5 6 7 810 11 12 13 14
9
LC ASRED WHTGRN BLK Z1 Z2 Z3 Z4RA GND GND
NC
C
NO
SURVEY
WIEGAND
RELAY
PROG
RESET TAMPER
DISABLE
SURVEY
GND
DRY
WET
LED
Survey
Button
Piezo
Wiegand
Inputs
Status
Indicator
Outputs
Zones
Reset
Tamper
LED
Indicators
Keypad
Programming
Header
Power
Supply
Door
Relay
Terminal
Dry/Wet
Contact

4 1134 Installation and Programming Guide | Digital Monitoring Products, Inc.
PROGRAM THE 1134
Refer to the panel programming guide as needed.
1. Reset the panel.
2. At the keypad, enter 6653 (PROG) to access the PROGRAMMER menu.
Device Setup
1. In DEVICE SETUP, press CMD until you get to DEVICE NO: -.
2. Enter a DEVICE NO:- and press CMD.
3. Enter a DEVICE NAME and press CMD.
4. (XT30/XT50 only) Select YES when WIRELESS? displays.
5. Select DOOR for DEVICE TYPE and press CMD.
6. (XR150/XR550 only) Select WLS at COMM TYPE and press CMD.
Note: Panel version 191 or higher software is required.
7. Enter the eight-digit SERIAL# that starts with 14 (SN1) and press CMD.
8. Enter the SUPRVSN TIME and press CMD.

Digital Monitoring Products, Inc. | 1134 Installation and Programming Guide 5
Zone Information
1. In ZONE INFORMATION, enter the wireless ZONE NO: - and press CMD.
2. Enter the ZONE NAME and press CMD.
3. Select the ZONE TYPE and press CMD.
4. At NEXT ZN?, select NO.
5. Select YES when WIRELESS? displays.
6. Enter the eight-digit SERIAL# that starts with 08 (SN2) and press CMD.
7. Enter the CONTACT number being used.
8. Enter the SUPRVSN TIME and press CMD.
9. At the NEXT ZN? prompt, select YES and continue to program up to three more
zones. Additional zones must be entered sequentially. See Table 1.
Panel Zones
XT30/XT50,
XTLplus,
& XTLtouch
The zone numbers begin with the 1134 address and are followed by the particular
zone from the 1134. For example, an 1134 at keypad address 4 would provide
zones 41, 42, 43, and 44.
XR150 Zone numbers are valid from 500-599.
Zones must still be programmed sequentially (i.e. 551, 552, 553, and 554).
XR550 Zone numbers are valid from 500-999.
Zones must still be programmed sequentially (i.e. 551, 552, 553, and 554).
Table 1: Zone Information

6 1134 Installation and Programming Guide | Digital Monitoring Products, Inc.
INSTALL THE 1134
1Select a Location
1. With the cover removed, hold the module in the desired location.
2. Press the survey button to send a signal to the panel and determine if
communication is confirmed or faulty.
Confirmed: For each press of the survey button, the transmitter LED
blinks immediately on and immediately o. The LED remains o when
the transmitter is synced with the panel. Repeat this test to confirm five
separate consecutive LED blinks. Any indication otherwise means proper
communication has not been established.
Faulty: If communication is faulty, the transmitter LED remains on for
about 8seconds or flashes multiple times in quick succession.
3. If the transmitter is not communicating with the panel, start by confirming
that it is correctly wired and programmed, then look for items that might
cause interference such as large metal objects or electronic equipment.
Relocate the transmitter or receiver until the LED confirms clear
communication.
