Dometic DSP212 User manual

DSP 212, DSP 224, DSP 412, DSP 424
Sine wave inverter
Installation and Operating Manual. . . . . . . . 8
Sinus-Wechselrichter
Montage- und Bedienungsanleitung . . . . .22
Onduleur sinusoïdal
Instructions de montage et de service . . . .36
Convertidor de ondas seno
Instrucciones de montaje y de uso . . . . . . . 51
Conversor sinusoidal
Instruções de montagem e manual de
instruções . . . . . . . . . . . . . . . . . . . . . . . . . . .66
Inverter sinusoidale
Istruzioni di montaggio e d’uso . . . . . . . . . 81
Sinus ondulator
Montagehandleiding en
gebruiksaanwijzing . . . . . . . . . . . . . . . . . . .96
Sinus ensretter
Monterings- og betjeningsvejledning . . . 111
Sinus växelriktare
Monterings- och bruksanvisning . . . . . . .125
Sinus vekselretter
Monterings- og bruksanvisning . . . . . . . .139
Sinus -vaihtosuuntaaja
Asennus- ja käyttöohje . . . . . . . . . . . . . . .153
Przetwornica sinusoidalna
Instrukcja montażu i obsługi . . . . . . . . . . .182
Sínusový menič napätia
Návod na montáž a uvedenie
do prevádzky. . . . . . . . . . . . . . . . . . . . . . . 197
Sinusový měnič
Návod k montáži a obsluze . . . . . . . . . . . 211
Szinuszos inverter
Szerelési és használati útmutató . . . . . . . 225
Inverter sa sinusnim valom
Upute za montažu i uporabu . . . . . . . . . . 240
Sinüs dalga invertör
Montaj ve Kullanım Kılavuzu. . . . . . . . . . . 254
Sinusni pretvornik
Navodilo za montažo in uporabo . . . . . . 268
Invertor cu undă sinusoidă
Instrucţiuni de montaj şi operare . . . . . . . 282
Инвертор със синусоидална вълна
Инструкция за монтаж
и експлоатация . . . . . . . . . . . . . . . . . . . . . 297
Siinuslaine inverter
Paigaldus- ja kasutusjuhend. . . . . . . . . . . 312
Μετατροπέας inverter
ημιτονοειδούς κύματος
Οδηγίες τοποθέτησης και χειρισμού. . . 326
Sinusiniųbangųinverteris
Montavimo ir naudojimo vadovas . . . . . . 342
Sinusoidālāviļņa strāvas
pārveidotājs
Uzstādīšanas un lietošanas rokasgrāmata356
EN
DE
FR
ES
PT
IT
NL
DA
SV
NO
FI
PL
SK
CS
HU
HR
TR
SL
RO
BG
ET
EL
LT
LV
ENERGY & LIGHTING
SINEPOWER
DometicDSP200-400_IOM_4445102437_EMEA16_xxxx-xx-xx.book Page 1 Monday, July 31, 2023 3:00 PM

© 2023 Dometic Group. The visual appearance of the contents of this manual is
protected by copyright and design law. The underlying technical design and the
products contained herein may be protected by design, patent or be patent
pending. The trademarks mentioned in this manual belong to Dometic Sweden AB.
All rights are reserved.
DometicDSP200-400_IOM_4445102437_EMEA16_xxxx-xx-xx.book Page 2 Monday, July 31, 2023 3:00 PM

DSP 212, DSP 224, DSP 412, DSP 424
3
12
3
1
DSP 2xx
DSP 4xx
1
2 3 4
5
1
2 3 4
5
6
6
7
2
DometicDSP200-400_IOM_4445102437_EMEA16_xxxx-xx-xx.book Page 3 Monday, July 31, 2023 3:00 PM

DSP 212, DSP 224, DSP 412, DSP 424
4
5 cm
5 cm
3
4x
1.
2.
3.
1.
2.
BA
C
4
DometicDSP200-400_IOM_4445102437_EMEA16_xxxx-xx-xx.book Page 4 Monday, July 31, 2023 3:00 PM

DSP 212, DSP 224, DSP 412, DSP 424
5
CLICK
1.
2.
Ø 21 mm
15 A
DC
1.
DSP 2xx
5
rd
bk
2.
3. 1.
DSP 4xx
DSP412: 50 A
DSP424: 25 A
≤ 2m
≤ 2m
6
DometicDSP200-400_IOM_4445102437_EMEA16_xxxx-xx-xx.book Page 5 Monday, July 31, 2023 3:00 PM

DSP 212, DSP 224, DSP 412, DSP 424
6
1.
2.
7
A
B
A
B
DSP 4xx
8
DometicDSP200-400_IOM_4445102437_EMEA16_xxxx-xx-xx.book Page 6 Monday, July 31, 2023 3:00 PM

DSP 212, DSP 224, DSP 412, DSP 424
7
9
50
126
187,5
0
DometicDSP200-400_IOM_4445102437_EMEA16_xxxx-xx-xx.book Page 7 Monday, July 31, 2023 3:00 PM

EN
Explanation of symbols DSP 212, DSP 224, DSP 412, DSP 424
8
Please read these instructions carefully and follow all instructions, guidelines, and warnings included in this product manual in order to ensure
that you install, use, and maintain the product properly at all times. These instructions MUST stay with this product.
By using the product, you hereby confirm that you have read all instructions, guidelines, and warnings carefully and thatyou understand and
agree to abide by the terms and conditions as set forth herein. You agree to use this product only for the intended purpose and application
and in accordance with the instructions, guidelines, and warnings as set forth in this product manual as well as in accordance with all appli-
cable laws and regulations. A failure to read and follow the instructions and warnings set forth herein may result in an injury to yourself and
others, damage to your product or damage to other property in the vicinity. This product manual, including the instructions, guidelines, and
warnings, and related documentation, may be subject to changes and updates. For up-to-date product information, please visit
documents.dometic.com.
Table of contents
1 Explanation of symbols. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
2 General safety instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
3 Scope of delivery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
4 Intended use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
5 Technical description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
6 Fitting the inverter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
7 Connecting the inverter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
8 Using the inverter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
9 Cleaning and caring for the inverter. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
10 Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
11 Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
12 Disposal. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
13 Technical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
1 Explanation of symbols
D
!
DANGER!
Safety instruction: Indicates a hazardous situation that, if not avoided,
will result in death or serious injury.
WARNING!
Safety instruction: Indicates a hazardous situation that, if not avoided,
could result in death or serious injury.
DometicDSP200-400_IOM_4445102437_EMEA16_xxxx-xx-xx.book Page 8 Monday, July 31, 2023 3:00 PM

EN
DSP 212, DSP 224, DSP 412, DSP 424 General safety instructions
9
A
I
2 General safety instructions
2.1 General safety
This product is only suitable for the intended purpose and application in accordance
with these instructions.
This manual provides information that is necessary for proper installation and/or
operation of the product. Poor installation and/or improper operating or mainte-
nance will result in unsatisfactory performance and a possible failure.
The manufacturer accepts no liability for any injury or damage to the product
resulting from:
• Incorrect assembly or connection, including excess voltage
• Incorrect maintenance or use of spare parts other than original spare parts
provided by the manufacturer
• Alterations to the product without express permission from the manufacturer
• Use for purposes other than those described in this manual
Dometic reserves the right to change product appearance and product
specifications.
Note the following basic safety information when using electrical devices to protect
against:
• Electric shock
•Firehazards
•Injury
NOTICE!
Indicates a situation that, if not avoided, can result in property damage.
NOTE
Supplementary information for operating the product.
DometicDSP200-400_IOM_4445102437_EMEA16_xxxx-xx-xx.book Page 9 Monday, July 31, 2023 3:00 PM

EN
General safety instructions DSP 212, DSP 224, DSP 412, DSP 424
10
2.2 General safety
DDANGER!
• In the event of fire, use a fire extinguisher which is suitable for electrical
devices.
!WARNING!
• Only use the device as intended.
• Ensure that the red and black terminals never come into contact.
• Disconnect the device from the mains:
– Before cleaning and maintenance
– Before changing a fuse
• If you disassemble the device:
– Detach all connections
– Make sure that no voltage is present at any of the inputs and out-
puts
• The device may not be used if the device itself or the connection cable
are visibly damaged.
• If this power cable for this device is damaged, it must be replaced by
the manufacturer, customer service or a similarly qualified person in
order to prevent safety hazards.
• This device may only be repaired by qualified personnel. Inadequate
repairs may cause serious hazards.
• This device can be used by children aged 8 years or over, as well as by
persons with diminished physical, sensory or mental capacities or a
lack of experience and/or knowledge, providing they are supervised
or have been taught how to use the device safely and are aware of the
resulting risks.
•Electrical devices are not toys.
Always keep and use the appliance out of the reach of children.
• Children must be supervised to ensure that they do not play with the
device.
DometicDSP200-400_IOM_4445102437_EMEA16_xxxx-xx-xx.book Page 10 Monday, July 31, 2023 3:00 PM

EN
DSP 212, DSP 224, DSP 412, DSP 424 General safety instructions
11
ANOTICE!
• Before start-up, check that the voltage specification on the type plate
is the same as that of the power supply.
• Ensure that other objects cannot cause a short circuit at the contacts
of the device.
• Never pull the plug out of the socket by the connection cable.
• Store the device in a dry and cool place.
2.3 Safety when installing the device
DDANGER!
• Never mount the device anywhere where there is a risk of gas or dust
explosion.
!CAUTION!
• Ensure that the device is standing firmly.
The device must be set up and fastened in such a way that it cannot tip
over or fall down.
ANOTICE!
• Do not expose the device to a heat source (such as direct sunlight or
heating). Avoid additional heating of the device in this way.
• Set up the device in a dry location where it is protected against splash-
ing water.
2.4 Safety when connecting the device electronically
DDANGER! Danger of electrocution
• If you are working on electrical systems, ensure that there is somebody
close at hand who can help you in emergencies.
!WARNING!
• Never connect more than one consumer device to the inverter. If you
connect more than one device, a short circuit may occur.
• Make sure that the lead has a sufficient cross-section.
• Lay the cables so that they cannot be damaged by the doors or the
bonnet.
Crushed cables can lead to serious injury.
DometicDSP200-400_IOM_4445102437_EMEA16_xxxx-xx-xx.book Page 11 Monday, July 31, 2023 3:00 PM

EN
General safety instructions DSP 212, DSP 224, DSP 412, DSP 424
12
!CAUTION!
• Lay the cables so that they cannot be tripped over or damaged.
ANOTICE!
• Use ductwork or cable ducts if it is necessary to lay cables through
metal panels or other panels with sharp edges.
•Donot lay the 230 V mains cable and the 12 V DC cable in the same
duct.
•Donot lay the cable so that it is loose or heavily kinked.
• Fasten the cables securely.
• Do not pull on the cables.
2.5 Operating the device safely
DDANGER! Danger of electrocution
• Do not touch exposed cables with your bare hands. This applies espe-
cially when operating the device from the AC mains.
!WARNING!
• Only use the device in closed, well-ventilated rooms.
!CAUTION!
•Donot operate the device
– In salty, wet or damp environments
– In the vicinity of corrosive fumes
– In the vicinity of combustible materials
– In areas where there is a danger of explosions.
• Before starting the device, ensure that the power supply line and the
plug are dry.
• Always disconnect the power supply when working on the device.
• Please observe that parts of the device may still conduct voltage even
if the fuse has blown.
• Do not disconnect any cables when the device is still in use.
ANOTICE!
• Make sure the air inlets and outlets of the device are not covered.
• Ensure good ventilation.
DometicDSP200-400_IOM_4445102437_EMEA16_xxxx-xx-xx.book Page 12 Monday, July 31, 2023 3:00 PM

EN
DSP 212, DSP 224, DSP 412, DSP 424 Scope of delivery
13
3Scopeofdelivery
4 Intended use
!
The wave inverter converts direct current into a 230 V AC supply of 50 Hz:
•12 Vg:DSP212, DSP412
•24 Vg:DSP224, DSP424
Rechargeable devices with USB interface can be charged via the USB port (5 V,
2000 mA).
This device is exclusively intended for vehicle use.
5 Technical description
The inverters can be operated wherever a DC connection is available:
•12 Vg:DSP212, DSP412
•24 Vg:DSP224, DSP424
The output voltage corresponds to the household voltage from the socket (pure sine
wave, THD < 5%).
Please observe the values for constant output power and peak output power as
indicated in chapter “Recycling packaging material” on page 19. Never connect
devices that have a higher power requirement.
No. in
fig. 1,
page 3
Designation
1 Sine wave inverter
2 Holder
3 Fixing screws
– Operating manual
WARNING!
Never use the inverter on vehicles where the positive terminal of the
battery is connected to the chassis.
DometicDSP200-400_IOM_4445102437_EMEA16_xxxx-xx-xx.book Page 13 Monday, July 31, 2023 3:00 PM

EN
Technical description DSP 212, DSP 224, DSP 412, DSP 424
14
I
The inverter has various protective mechanisms.
•Overvoltage shutdown: The inverter shuts itself off when the voltage exceeds
the cut-off value. It restarts when the voltage returns to the restart value.
•Undervoltage shutdown: The inverter shuts itself off when the voltage sinks
below the cut-off value. It restarts when the voltage rises to the restart value.
•Excess temperature shutdown: The inverter switches off when the tempera-
ture inside the device or the temperature on the cooling element exceeds a cut-
off value. It restarts when the voltage rises to the restart value.
•Overloading and short circuit shutdown: The LED on the inverter indicates
an operating fault when an excess load is connected or a short circuit has
occurred.
I
5.1 Control elements
5.2 Connections
I
NOTE
Note when connecting devices with an electrical drive (such as power
drills and refrigerators), that they often require more power than is
indicated on the type plate.
NOTE
The individual values are found in the chapter “Recycling packaging
material” on page 19.
No. in
fig. 2,
page 3
Description
1 Main switch: Switches the device on and off
2 Status LED: See chapter “Status indications” on page 17
NOTE
The version for continental Europe is depicted.
DometicDSP200-400_IOM_4445102437_EMEA16_xxxx-xx-xx.book Page 14 Monday, July 31, 2023 3:00 PM

EN
DSP 212, DSP 224, DSP 412, DSP 424 Fitting the inverter
15
6 Fitting the inverter
6.1 Mounting instructions
When selecting the installation location, observe the following instructions:
• The inverter can be mounted horizontally or vertically.
• The inverter must be installed in a place that is protected from moisture.
• The inverter may not be installed in the presence of flammable materials.
• The inverter may not be installed in a dusty environment.
• The place of installation must be well ventilated. A ventilation system must be
available for installations in small, enclosed spaces. The minimum clearance
around the inverter must be at least 5 cm (fig. 3, page 4).
• The air intake on the underside or the air outlet on the back of the inverter must
remain clear.
• For ambient temperatures higher than 40 °C (such as in engine or heating
compartments, or direct sunlight), the inverter‘s maximal output load is reduced.
Thereby the inverter may shut down due to overload.
• The device must be installed on a level and sufficiently sturdy surface.
A
6.2 Mounting the inverter
➤Mount the inverter as shown (fig. 4, page 4).
No. in
fig. 2,
page 3
Description
3 USB connection
4 AC outlet
5 DC plug
6 Fan (backside)
7DSP412, DSP424 only: Connection for external switch
NOTICE!
Before drilling any holes, make sure that no electrical cables or other
parts of the vehicle can be damaged by drilling, sawing and filing.
DometicDSP200-400_IOM_4445102437_EMEA16_xxxx-xx-xx.book Page 15 Monday, July 31, 2023 3:00 PM

EN
Connecting the inverter DSP 212, DSP 224, DSP 412, DSP 424
16
7 Connecting the inverter
!
A
➤Connect the inverter as shown:
– Connecting the battery:
DSP212, DSP224: fig. 5, page 5
DSP412, DSP424: fig. 6, page 5
– Connecting load: fig. 7, page 6
Connect external switch to turn device on and off (DSP412, DSP424 only)
I
➤Connect the external switch as shown (fig. 8, page 6).
8 Using the inverter
!
WARNING!
Never connect more than one consumer device to the inverter. The
connection of more than one device must be executed by an electrically
qualified person complying with the local requirements for protection
against electric shock.
NOTICE!
• Incorrect polarity will blow an internal fuse which has to be replaced
by the Dometic service. Additionally the electronics may be dam-
aged.
• Make sure that the inverter is operated with the following voltage
only:
– DSP212, DSP412: 12 Vg
– DSP224, DSP424: 24 Vg
NOTE
The inverter is switched on when the external or the main switch
(fig. 21, page 3) is switch on. If the inverter shall be controlled via
external switch only, the main switch has to be switch to position “0”.
CAUTION!
When connecting the load observe the applicable regulations.
DometicDSP200-400_IOM_4445102437_EMEA16_xxxx-xx-xx.book Page 16 Monday, July 31, 2023 3:00 PM

EN
DSP 212, DSP 224, DSP 412, DSP 424 Cleaning and caring for the inverter
17
8.1 Switching on the inverter
➤Switch the inverter on by pressing the switch (fig. 21, page 3) on the device
(position “I”) …
➤… or (DSP412, DSP424 only) switch on the inverter using the external switch
(optional).
✔The blue Status LED lights up (fig. 22, page 3).
✔The power consuming device is supplied with voltage.
Charging the device via the USB port
I
➤Connect the device to the USB port as shown (fig. 9, page 7).
8.2 Status indications
The blue LED (fig. 22, page 3) shows the operating condition of the inverter.
9 Cleaning and caring for the inverter
A
➤Occasionally clean the cooling device interior and exterior with a damp cloth.
➤Make sure that the air inlet and outlet vents on the device are free of any dust and
dirt, so that heat can be released and the device is not damaged.
NOTE
Also observe the operating manual of the device you want to charge via
the USB port.
Display Input voltage
Constantly lit Normal mode
Long flash, short interruption Inverter overheated/Overload
Quick flash Overvoltage/Undervoltage
Off Other fault
NOTICE! Damage hazard
• Never clean the cooling device under running water or in dish water.
• Do not use abrasive cleaning agents or hard objects during cleaning
as these can damage the cooling device.
DometicDSP200-400_IOM_4445102437_EMEA16_xxxx-xx-xx.book Page 17 Monday, July 31, 2023 3:00 PM

EN
Troubleshooting DSP 212, DSP 224, DSP 412, DSP 424
18
10 Troubleshooting
!
I
The LED (fig. 22, page 3) indicates the fault:
11 Warranty
The statutory warranty period applies. If the product is defective, please contact your
retailer or the manufacturer's branch in your country (see dometic.com/dealer).
WARNING!
Do not open the device. You risk sustaining an electric shock by doing
this.
NOTE
If you have detailed questions on the specifications of the inverter
please contact the manufacturer (addresses on the back of the instruc-
tion manual).
LED display Cause Remedy
Quick flash Input voltage is too high Check the input voltage and reduce it.
Input voltage too low The battery needs recharging.
Check the cables and connections.
Long flash, short
interruption
Overheating Switch off the inverter and the consumer.
Wait 5 to 10 minutes and switch the inverter
on again without any electric consumers.
Reduce the load and make sure the inverter
has better ventilation. Then switch the con-
sumer back on.
Excessive load Switch off the inverter and remove the
consumer.
Then switch the inverter back on without the
consumer. If no excessive load is now shown,
then there is a short circuit in the consumer or
the total load was higher than the power
specified on the data sheet.
Check the cables and connections.
Off Other fault Contact the service.
DometicDSP200-400_IOM_4445102437_EMEA16_xxxx-xx-xx.book Page 18 Monday, July 31, 2023 3:00 PM

EN
DSP 212, DSP 224, DSP 412, DSP 424 Disposal
19
For repair and warranty processing, please include the following documents when
you send in the product:
• A copy of the receipt with purchasing date
• A reason for the claim or description of the fault
Note that self-repair or non-professional repair can have safety consequences and
might void the warranty.
12 Disposal
Recycling products with non-replaceable batteries, rechargeable batter-
ies or light sources
Recycling packaging material
13 Technical data
The following technical data applies to all inverters:
➤Iftheproduct containsanynon-replaceable batteries, rechargeable batteries
or light sources, you don't have to remove them before disposal.
➤If you wish to finally dispose of the product, ask your local recycling center or
specialist dealer for details about how to do this in accordance with the appli-
cable disposal regulations.
➤The product can be disposed free of charge.
➤Place the packaging material in the appropriate recycling waste bins wher-
ever possible.
Output voltage: 230 Vw± 10 %, pure sine wave (THD < 5%)
Output frequency: 50 Hz ± 0,5 Hz
Maximum efficiency: >90 %
Heat dissipation: temperature and load controlled fan
Ambient temperature at operation: 0 °C to +50 °C
Ambient temperature for storage: –30 °C to +70 °C
Air humidity: 0 – 95%, non-condensing
Testing/certification:
9
DometicDSP200-400_IOM_4445102437_EMEA16_xxxx-xx-xx.book Page 19 Monday, July 31, 2023 3:00 PM

EN
Technical data DSP 212, DSP 224, DSP 412, DSP 424
20
DSP212 DSP412 DSP224 DSP424
Ref. no.: 9600002603
9600003593
9600002541
9600003595
9600002540
9600003594
9600002542
9600003596
Rated input voltage: 12 V g24 V g
Input voltage range: 10 – 16.5 Vg20 – 33 Vg
Rated load: 150 W 350 W 150 W 350 W
Maximum power for 1 min: 170 W 400 W 170 W 400 W
Surge power for 1 s: 300 W 700 W 300 W 700 W
Idle current consumption: <0,6 A <0,4 A <0,6 A <0,4 A
Dimensions W x L x H: fig. 0, page 7
Weight: 1.1 kg 1.2 kg 1.1 kg 1.2 kg
