Dometic TEC Series User manual

TEC60EV
Generator
Operating manual . . . . . . . . . . . . . . . . . . . . .8
Generator
Bedienungsanleitung . . . . . . . . . . . . . . . . .27
Générateur
Notice d’utilisation . . . . . . . . . . . . . . . . . . .48
Generador
Instrucciones de uso . . . . . . . . . . . . . . . . . .70
Gerador
Manual de instruções . . . . . . . . . . . . . . . . . 91
Generatore
Istruzioni per l’uso . . . . . . . . . . . . . . . . . . . 112
Generator
Gebruiksaanwijzing. . . . . . . . . . . . . . . . . .133
Generator
Betjeningsvejledning . . . . . . . . . . . . . . . .153
Generator
Bruksanvisning. . . . . . . . . . . . . . . . . . . . . . 173
Generator
Bruksanvisning. . . . . . . . . . . . . . . . . . . . . .192
Generaattori
Käyttöohje . . . . . . . . . . . . . . . . . . . . . . . . . 211
Генератор
Инструкция по эксплуатации . . . . . . . . . 231
Generator
Instrukcja obsługi . . . . . . . . . . . . . . . . . . .253
Generàtor
Návod na obsluhu. . . . . . . . . . . . . . . . . . . 274
Generàtor
Návod k obsluze . . . . . . . . . . . . . . . . . . . . 293
Generátor
Használati utasítás. . . . . . . . . . . . . . . . . . . 313
EN
DE
FR
ES
PT
IT
NL
DA
SV
NO
FI
RU
PL
SK
CS
HU
POWER & CONTROL
TEC
TEC60EV-O-16s.book Seite 1 Montag, 5. August 2019 12:56 12

TEC60EV-O-16s.book Seite 2 Montag, 5. August 2019 12:56 12

TEC60EV
3
0V 0.0KW 12H
12.3 GEN OFF
1 2 3
4
5
1
1
2
2
TEC60EV-O-16s.book Seite 3 Montag, 5. August 2019 12:56 12

TEC60EV
4
5
3
2
1
6
4
7 8
109
3
1
2
3
4
TEC60EV-O-16s.book Seite 4 Montag, 5. August 2019 12:56 12

TEC60EV
5
1
2
5
1
6
TEC60EV-O-16s.book Seite 5 Montag, 5. August 2019 12:56 12

TEC60EV
6
12
4
3
7
0,7 – 0,8 mm0,7 – 0,8 mm
8
TEC60EV-O-16s.book Seite 6 Montag, 5. August 2019 12:56 12

TEC60EV
7
626
679 545
474
9
TEC60EV-O-16s.book Seite 7 Montag, 5. August 2019 12:56 12

EN
Explanation of symbols TEC60EV
8
Please read this instruction manual carefully before first use, and storeit in
a safe place. If you pass on the product to another person, hand over this
instruction manual along with it.
Table of contents
1 Explanation of symbols. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
2 Safety instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
3 Target group for this manual. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
4 Scope of delivery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
5 Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
6 Intended use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
7 Technical description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
8 Operating the generator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
9 Cleaning the generator. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
10 Servicing the generator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
11 Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
12 Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
13 Disposal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
14 Technical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
1 Explanation of symbols
!
!
WARNING!
Safety instruction: Indicates a hazardous situation that, if not avoided,
could result in death or serious injury.
CAUTION!
Safety instruction: Indicates a hazardous situation that, if not avoided,
could result in minor or moderate injury.
TEC60EV-O-16s.book Seite 8 Montag, 5. August 2019 12:56 12

EN
TEC60EV Safety instructions
9
A
I
2 Safety instructions
Pleaseobservetheprescribedsafetyinstructionsand stipulations from the
vehicle manufacturer and service workshops.
The manufacturer accepts no liability for damage in the following cases:
• Damage to the product resulting from mechanical influences and incorrect
connection voltage
• Alterations to the product without express permission from the manufacturer
• Use for purposes other than those described in the operating manual
In particular, the manufacturer will not be liable for any consequential damage, espe-
cially consequential damage caused by failure of the generator.
Note the following basic safety information when using electrical devices to protect
against:
• Electric shock
•Firehazards
•Injury
2.1 General safety
!WARNING! Failure to obey these warnings could result in death
or serious injury.
Health hazard
• Only use the device as intended.
• Do not make any alterations or conversions to the device.
NOTICE!
Indicates a situation that, if not avoided, can result in property damage.
NOTE
Supplementary information for operating the product.
TEC60EV-O-16s.book Seite 9 Montag, 5. August 2019 12:56 12

EN
Safety instructions TEC60EV
10
• Installation, maintenance and repairs of the generator may only be car-
ried out by qualified personnel who are familiar with the risks involved
when handling generators as well as the relevant regulations. Inade-
quate repairs may cause serious hazards. For repair service, please
contact the manufacturer's branch office in your country (see back
page).
• People (including children) whose physical, sensory or mental capac-
ities prevent them from using this device safely may not be allowed to
operate it without the supervision of a responsible adult.
Risk of asphyxiation
• Exhaust fumes contain carbon monoxide which is a highly toxic,
odourless and colourless gas. Do not inhale any exhaust fumes. Do
not leave the generator motor running in a closed garage or in a room
without windows.
Electrical shock
•Electrical devices are not toys
Keep electrical devices out of reach of children or infirm persons. Do
not allow them to use electrical devices without supervision.
!CAUTION! Failure to obey these cautions could result in minor or
moderate injury.
Health hazard
• The generator may only be used with the flap closed.
Fire hazard
• Remove all flammable materials such as petrol, paints, solvents, etc.,
from the vicinity of the generator.
• Ensure that hot parts of the generator do not come in contact with any
flammable materials.
• Only refuel the generator when it is switched off and in a well-venti-
lated area. Petrol and liquid gas are highly flammable and can
explode.
• Do not refuel the generator when the vehicle engine is running if the
tank is in the vicinity of the generator.
• If petrol is spilled, wipe it up properly and wait until the fumes have
cleared before turning on the engine.
Electrical shock
• Do not touch the generator and the cables with wet hands.
• Replace the fuses or thermo switch using only those with the same
technical data.
TEC60EV-O-16s.book Seite 10 Montag, 5. August 2019 12:56 12

EN
TEC60EV Target group for this manual
11
• Only operate the device if you are certain that the housing and the
cables are undamaged.
ANOTICE! Damage hazard
• Do not fill up the tank too full. Petrol must not be allowed to fill up to
the neck of the tank. Check the lid is on properly.
• If a welding operation has be done on the vehicle disconnect all gen-
erator cables, otherwise the electronics may be damaged.
2.2 Operating the device safely
!WARNING! Failure to obey these warnings could result in death
or serious injury.
Electrical shock
• Always disconnect the power supply when working on the device.
3 Target group for this manual
This operating manual is for the user of the generator.
4Scopeofdelivery
Designation
TEC60EV generator
Changeover relay for making priority circuits
Control panel
Silencer
Exhaust pipe
Mounting material for silencer
Connection cables
Mounting material
Installation manual
Operating manual
TEC60EV-O-16s.book Seite 11 Montag, 5. August 2019 12:56 12

EN
Accessories TEC60EV
12
5Accessories
Available as accessories (not included in the scope of delivery):
6 Intended use
The generator TEC60 EV is designed for use in motor homes, camper vans and vehi-
cles for commercial use.
The generator is not suitable for installation in water vessels.
The generator produces a pure sine wave voltage of 230 V/50 Hz which can be
connected to the consumer with a total continuous load of 6200 W.
The power quality is also suitable for sensitive consumers (such as PCs).
The generator can charge a 12 V battery.
7 Technical description
The generator consists of the following main parts (fig. 1, page 3):
• Power generator with permanent magnets (1)
•Combustionengine(2)
• Connection box (3)
•Inverter(4)
• Control panel (5)
The combustion engine (2) drives the power generator connected to it (1), which in
turn generates AC voltage.
The internal inverter (4) transforms this AC voltage into a stable voltage of 230 V and
50 Hz.
The terminals and the main switch are installed in the connection box (3) located
behind the door.
The control panel is used to operate the device (5).
The generator has an integrated battery charger for charging the connected battery.
Part designation Reference no.
PR 250133, external sealing kit 9600025375
TEC60EV-O-16s.book Seite 12 Montag, 5. August 2019 12:56 12

EN
TEC60EV Technical description
13
Control elements in the connection box
The connection box is located on the generator behind the cover.
Control elements in the control panel
The control panel is installed in the vehicle interior.
No. in
fig. 2,
page 3
Description
1 Main switch Switches the generator to standby or no
function.
2 Thermal protection of the
inverter
Activates if the inverter overheats (see chapter
“Display messages” on page 16)
No. in
fig. 3,
page 4
Description
1 Display Shows the status reports.
2 On/Off switch PSwitches the control panel on and off if the
main switch is at “I” or “1”.
Stops the generator in emergency.
3 Grey button START/STOP Starts/stops the generator if the control panel
is switched on and the main switch is at “I” or
“1”.
4 Petrol gauge Lights up if the petrol goes into reserve.
5 Oil gauge Lights up if the oil level is too low in the
engine.
TEC60EV-O-16s.book Seite 13 Montag, 5. August 2019 12:56 12

EN
Operating the generator TEC60EV
14
Displays
8 Operating the generator
A
I
8.1 Basic notes on operation
!
Please note the following basic information:
• Always check the oil level before use (chapter “Checking the oil level” on
page 18).
• Even small overloads in the long-run will cause the generator to stop.
• Leave the generator running for a few minutes after use without any consumers
before stopping it.
No. in
fig. 3,
page 4
Description
6 AC supply Actual voltage output
7 Constant output Current capacity of connected consumer
8 Operating hours Time the generator is in operation
9 DC voltage Battery charging voltage
10 Messages Status reports of the generator (see chapter
“Display messages” on page 16)
NOTICE! Damage hazard
Do not run the generator over 70 % of the maximum constant output for
the first 50 operating hours (run-in phase).
NOTE
By doing this you can prolong the service life of the generator and
optimise its output:
run the generator at a maximum of approx. 75 % of the maximum
continuous load after the run-in phase.
CAUTION! Beware of injury
Do not insert your fingers or objects into the air nozzles or the intake
grille.
TEC60EV-O-16s.book Seite 14 Montag, 5. August 2019 12:56 12

EN
TEC60EV Operating the generator
15
• Abrupt braking, accelerating and driving round bends in the vehicle can cause
problems in the generator's pump system and lead to unwanted shutdown.
• If you are not using your generator for a longer period of time, start it up at least
every 30 days and leave it running for 15 minutes or more.
8.2 Switching the generator to standby or no function
The generator can be switched to standby or no function with the main switch
(fig. 21, page 3) in the connection box.
8.3 Switching the control panel on and off
This switch on the control panel (fig. 32, page 4) is for switching the control panel
on and off.
➤Switch the control panel on with the on/off switch.
✓The display shows: GEN OFF.
The display switches off automatically after 5 minutes if the start button is not
touched within this time.
Press the start button to switch on the display again.
✓The generator can now be started.
8.4 Starting the generator
The generator can only be started if it is in standby and the control panel is switched
on.
➤Start up the generator with the grey button “START/STOP” (fig. 33, page 4).
8.5 Stopping the generator
➤Stop the generator with the grey button “START/STOP” (fig. 33, page 4).
✓The inverter shuts down immediately. The engine runs for 30 seconds to cool
down, then the engine stops too.
ANOTICE! Damage hazard
Always stop the generator with the grey button “START/STOP” to avoid
engine damages. The turn off procedure with the red button has to be
used only for emergency.
TEC60EV-O-16s.book Seite 15 Montag, 5. August 2019 12:56 12

EN
Operating the generator TEC60EV
16
8.6 Display messages
Display message
Description Generator behaviour Measures
LOW BATTERY
The battery voltage has fallen
below the minimum value for
starting up (9 V).
The generator does not start. Charge the battery.
Check OIL Level The generator continues to run. Fill up with oil (see chapter
“Checking the oil level” on
page 18).
OIL CHANGE
The number of prescribed oper-
ating hours has been reached for
changing the engine oil.
The generator continues to run. Change the oil (see chapter
“Changing the oil” on page 21),
then confirm the message by
pressing and holding down the
button START/STOP. Restart the
generator by again pressing and
holding down the button
START/STOP.
NO FUEL
The petrol in the tank is in
reserve.
The generator continues to run. Refuel.
OIL ALERT
Insufficient engine oil.
The generator stops. Fill up with oil (see chapter
“Checking the oil level” on
page 18).
GENERATOR ALERT!
General alarm message
Example: The control ring on the
throttle valve of the carburettor
(stepper motor) is faulty.
The generator stops. Check the system by referring to
the troubleshooting table.
If the problem persists, contact
the manufacturer's branch office
in your country (see back page).
OVERLOAD!
The consumers generate an
overload at the output.
The inverter switches off, there-
fore no voltage is supplied but
the engine carries on running
until it goes off.
Reduce the connected load and
start the generator again.
SHORT CIRCUIT
The consumers cause a short cir-
cuit at the output.
The inverter switches off, there-
fore no voltage is supplied but
the engine carries on running
until it goes off.
Check the connected consum-
ers then start the generator
again.
OVER TEMPERATURE
Overheating
The inverter switches off so no
voltage is supplied to cool the
generator, but the engine car-
ries on running.
Leave the engine to cool down
for a few minutes then start the
generator again.
TEC60EV-O-16s.book Seite 16 Montag, 5. August 2019 12:56 12

EN
TEC60EV Operating the generator
17
LOW POWER ENGINE
The inverter supply voltage has
dropped.
The generator stops. Reduce the connected load and
start the generator again.
Overspeed
RPM too high
The generator stops. Press the button START/STOP to
restart the generator. If the prob-
lem persists, contact the manu-
facturer's branch office in your
country (see back page).
Start failed
Example: No fuel, cold tempera-
ture, spark plug to be replaced,
dirty air filter
The generator is switched off. Press the start button to restart
the generator.
GEN CAL
Message appears when the gen-
erator is started up; it shows the
calibration phase which takes
place before each start-up. The
generator does not supply any
voltage.
The generator is running but
does not supply any voltage.
Wait a moment.
GEN WAIT
Message appears while you are
waiting for the generator to start
again.
The generator is switched off. Wait until the message has disap-
peared then attempt ignition
again.
GEN ON
The generator is operating
normally.
Normal mode –
GEN OFF The generator is idle and can be
started.
–
GEN Stop The generator is stopped. Wait a moment.
Wait Cooling The engine is running without
load to cool down the system.
Wait a moment.
Inverter lost comm The generator stops. Check the system by referring to
the troubleshooting table.
If the problem persists, contact
the manufacturer's branch office
in your country (see back page).
Display message
Description Generator behaviour Measures
TEC60EV-O-16s.book Seite 17 Montag, 5. August 2019 12:56 12

EN
Operating the generator TEC60EV
18
8.7 Checking the oil level
!
I
Always check the oil level before use. To do this, proceed as follows:
➤Open the generator flap.
➤Switch the generator to no function with the main switch (fig. 41, page 4).
➤Disconnect the positive terminal of the supply battery.
➤Take the dipstick (fig. 42, page 4) out of the filler neck (fig. 43, page 4).
➤Clean the dipstick (fig. 42, page 4) with a cloth.
➤Put the dipstick (fig. 42, page 4) back into the filler neck (fig. 43, page 4).
➤Take the dipstick (fig. 42, page 4) out of the filler neck.
Engine lost comm The generator stops. Check the system by referring to
the troubleshooting table.
If the problem persists, contact
the manufacturer's branch office
in your country (see back page).
Inverter failed The generator stops. Contact the manufacturer's
branchoffice in your country (see
back page).
Eng. Param. Error The generator stops. Contact the manufacturer's
branchoffice in your country (see
back page).
Inv. Param. Error The generator stops. Contact the manufacturer's
branchoffice in your country (see
back page).
Software Error The generator stops. Contact the manufacturer's
branchoffice in your country (see
back page).
CAUTION! Risk of injury
Hot oil can cause burns.
Only check the oil level when the generator is switched off.
NOTE
The generator must be level.
Display message
Description Generator behaviour Measures
TEC60EV-O-16s.book Seite 18 Montag, 5. August 2019 12:56 12

EN
TEC60EV Cleaning the generator
19
➤Check that the oil level is between the notch (maximum filling level) and the tip of
the dipstick.
If not, top up with more oil.
➤Put the dipstick (fig. 42, page 4) back into the filler neck (fig. 43, page 4).
➤Check that the oil level is not above the maximum level.
➤Connect the generator to the positive terminal of the supply battery.
➤Switch the generator to standby with the main switch (fig. 41, page 4).
➤Close the generator flap.
9Cleaningthegenerator
A
➤Clean the generator with a damp cloth from time to time.
➤Remove any dirt from the air vents in the generator at regular intervals. Make sure
you do not damage the grilles of the generator in the process.
10 Servicing the generator
I
10.1 Maintenance table
!
NOTICE! Damage hazard
• Do not clean the generator with a high-pressure cleaner. Exposure
to water can damage the generator.
• Do not use sharp or hard objects or cleaning agents for cleaning as
these may damage the generator.
• To clean the generator, use water with a gentle cleaning agent.
Never use petrol, diesel or solvents.
NOTE
Find your Dometic service partner on the internet:
service-location.dometic.com
WARNING!
Only have maintenance work carried out by specialist personnel who
are familiar with the relevant regulations. Inadequate maintenance may
cause serious hazards.
TEC60EV-O-16s.book Seite 19 Montag, 5. August 2019 12:56 12

EN
Servicing the generator TEC60EV
20
I
10.2 Preparing maintenance work
!
➤Open the generator flap.
➤Switch the generator to no function with the main switch (fig. 21, page 3).
➤Disconnect the positive terminal of the supply battery.
For maintenance work, you can take the generator out (fig. 5, page 5):
!
➤Undo the fastening screws (1).
➤Remove the mounting plate (2) with the generator from the housing (3).
NOTE
Have the following maintenance work performed at regular intervals or
after the specified number of operating hours, whichever is sooner.
Interval Inspection/maintenance
In the first month
or after 20 hours.
➤Change the oil.
➤Check the air filter (chapter “Servicing the air filter” on page 22).
Every 3 months or
after 50 hours.
➤Check the air filter (chapter “Servicing the air filter” on page 22).
Every 6 months or
after 100 hours.
➤Change the oil.
➤Check the spark plug (chapter “Servicing the spark plugs” on
page 23).
Once a year or
every 300 hours
➤Check the valves.
➤Check the fuel tank and fuel filter.
➤Check the vibration damper.
Every two years ➤Check the petrol supply lines.
CAUTION! Risk of injury
Note the following for all maintenance work:
• The generator must not be running.
• All the parts must be cooled down.
WARNING! Risk of injury
The mounting plate with generator is very heavy (> 70 kg) and could fall
out the housing if you take it out too far.
TEC60EV-O-16s.book Seite 20 Montag, 5. August 2019 12:56 12
