Dometic TEC 40D Operation User manual

TEC40D
Generator
Operating manual . . . . . . . . . . . . . . . . . . . . .8
Generator
Bedienungsanleitung . . . . . . . . . . . . . . . . .28
Générateur
Notice d’utilisation . . . . . . . . . . . . . . . . . . .49
Generador
Instrucciones de uso . . . . . . . . . . . . . . . . . .70
Gerador
Manual de instruções . . . . . . . . . . . . . . . . .92
Generatore
Istruzioni per l’uso . . . . . . . . . . . . . . . . . . . 113
Generator
Gebruiksaanwijzing. . . . . . . . . . . . . . . . . .134
Generator
Betjeningsvejledning . . . . . . . . . . . . . . . .155
Generator
Bruksanvisning. . . . . . . . . . . . . . . . . . . . . . 175
Generator
Bruksanvisning . . . . . . . . . . . . . . . . . . . . . 195
Generaattori
Käyttöohje . . . . . . . . . . . . . . . . . . . . . . . . . 214
Генератор
Инструкция по эксплуатации . . . . . . . . . 235
Generator
Instrukcja obsługi . . . . . . . . . . . . . . . . . . . 257
Generàtor
Návod na obsluhu. . . . . . . . . . . . . . . . . . . 278
Generàtor
Návod k obsluze . . . . . . . . . . . . . . . . . . . . 299
Generátor
Használati utasítás. . . . . . . . . . . . . . . . . . . 319
EN
DE
FR
ES
PT
IT
NL
DA
SV
NO
FI
RU
PL
SK
CS
HU
ENERGY & LIGHTING
TEC
TEC40D-O-16s.book Seite 1 Freitag, 12. August 2016 7:10 19

TEC40D-O-16s.book Seite 2 Freitag, 12. August 2016 7:10 19

TEC40D
3
2
1
3
4
5
1
3
12
4
2
TEC40D-O-16s.book Seite 3 Freitag, 12. August 2016 7:10 19

TEC40D
4
5
3
2
1
6
4
7 8
109
3
2 3 1
4
TEC40D-O-16s.book Seite 4 Freitag, 12. August 2016 7:10 19

TEC40D
5
1
2
5
OIL
O
I
L
1
2
D
B
C
A
3
4
5
1
2
6
TEC40D-O-16s.book Seite 5 Freitag, 12. August 2016 7:10 19

TEC40D
6
1
2
3
4
7
1
2
3
4
8
TEC40D-O-16s.book Seite 6 Freitag, 12. August 2016 7:10 19

TEC40D
7
765 467
490
9
TEC40D-O-16s.book Seite 7 Freitag, 12. August 2016 7:10 19

EN
TEC40D
8
Please read this instruction manual carefully before first use, and store it in
a safe place. If you pass on the product to another person, hand over this
instruction manual along with it.
Table of contents
1 Explanation of symbols. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
2 Safety instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
3 Target group for this manual. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
4 Scope of delivery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
5 Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
6 Intended use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
7 Technical description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
8 Operating the generator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
9 Cleaning the generator. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
10 Servicing the generator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
11 Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
12 Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
13 Disposal. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
14 Technical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
TEC40D-O-16s.book Seite 8 Freitag, 12. August 2016 7:10 19

EN
TEC40D Explanation of symbols
9
1 Explanation of symbols
!
!
A
I
2 Safety instructions
The manufacturer accepts no liability for damage in the following cases:
•Damage to the product resulting from mechanical influences and excess voltage
•Alterations to the product without express permission from the manufacturer
•Use for purposes other than those described in the operating manual
In particular, the manufacturer will not be liable for any consequential damage,
especially consequential damage caused by failure of the generator.
Note the following basic safety information when using electrical devices to protect
against:
•Electric shock
•Fire hazards
•Injury
2.1 General safety
DDANGER!
•Do not operate the device in spaces where danger of explosion is
present.
WARNING!
Safety instruction: Failure to observe this instruction can cause fatal or
serious injury.
CAUTION!
Safety instruction: Failure to observe this instruction can lead to injury.
NOTICE!
Failure to observe this instruction can cause material damage and impair
the function of the product.
NOTE
Supplementary information for operating the product.
TEC40D-O-16s.book Seite 9 Freitag, 12. August 2016 7:10 19

EN
Safety instructions TEC40D
10
!WARNING!
•Electrical devices are not toys
Keep electrical devices out of reach of children or infirm persons. Do
not allow them to use electrical devices without supervision.
•This device can be used by children aged 8 years or over,as well as by
persons with diminished physical, sensory or mental capacities or a
lack of experience and/or knowledge, providing they are supervised
or have been taught how to use the device safely and are aware of the
resulting risks.
•Only use the device as intended.
•Do not make any alterations or conversions to the device.
•Installation, maintenance and repairs of the generator may only be
carried out by qualified personnel who are familiar with the risks
involved when handling generators as well as the relevant regulations.
Inadequate repairs may cause serious hazards. For repair service,
please contact the manufacturer's branch office in your country
(addresses on the back page).
•Mark the area surrounding the device during maintenance work and
prevent access to areas where activation can cause perils.
•Exhaust fumes contain carbon monoxide which is a highly toxic,
odourless and colourless gas. Do not inhale any exhaust fumes. Do
not leave the generator motor running in a closed garage or in a room
without windows.
!CAUTION!
•The generator may only be used with the inspection cover closed.
•Remove all flammable materials such as petrol, paints, solvents, etc.,
from the vicinity of the generator.
•Ensure that hot parts of the generator do not come in contact with any
flammable materials.
•Only refuel the generator when it is switched off and in a well-venti-
lated area. Diesel oil is highly flammable and can explode.
•Do not refuel the generator when the vehicle engine is running if the
tank is in the vicinity of the vehicle engine.
•Wipe up spilled diesel oil properly and wait until the fumes have
cleared before turning on the engine.
•Do not touch the generator and the cables with wet hands.
•Replace the fuses using only those with the same technical data.
TEC40D-O-16s.book Seite 10 Freitag, 12. August 2016 7:10 19

EN
TEC40D Target group for this manual
11
ANOTICE!
•Do not fill up the tank too full. Fuel must not be allowed to fill up to the
neck of the tank. Check the lid is on properly.
2.2 Operating the device safely
!WARNING!
•Always disconnect the power supply when working on the device.
ANOTICE!
•Only operate the device if you are certain that the housing and the
cables are undamaged.
3 Target group for this manual
This operating manual is for the user of the generator.
4Scopeofdelivery
Description Item number
TEC40D generator 9600000116
Remote control
Exhaust pipe, 2 m
Fastening material for silencer
Connection cable
AG 102, changeover relay for making priority circuits
Fastening material
Installation manual
Operating manual
TEC40D-O-16s.book Seite 11 Freitag, 12. August 2016 7:10 19

EN
Accessories TEC40D
12
5Accessories
Available as accessories (not included in the scope of delivery):
6 Intended use
The TEC40D generator (ref. no. 9600000116) is designed for use in motor homes,
camper vans and vehicles for commercial use.
The generator is not suitable for installation in water vessels.
The generator produces a pure sine wave voltage of 230 V/50 Hz which can be
connected to the consumer with a total continuous load of 3500 W. The power
quality is also suitable for sensitive consumers (such as PCs).
The generator can charge a 12 V battery.
7 Technical description
The generator consists of the following main parts (fig. 1, page 3):
•Alternating current generator (1)
•Endothermic engine (2)
•Internal control panel (3)
•Inverter (4)
•Remote control (5)
Theendothermicengine (2) drives the alternating current generator (1)connected to
it, which in turn generates AC voltage.
The integrated inverter (4) transforms this AC voltage into a stable voltage of 230 V
and 50 Hz, which is available at the inverter terminal. The socket for the connection
cable to the control panel (5) is installed in the inverter.
The terminals and the main switch are installed in the internal control panel (3)
located behind the door.
Part designation Item number
PR 25044, external sealing kit 9102900174
TEC40D-O-16s.book Seite 12 Freitag, 12. August 2016 7:10 19

EN
TEC40D Technical description
13
The generator has an integrated battery charger for charging the connected battery.
Control elements in the control panel
The control panel is located on the generator behind the cover.
Control elements in the remote control
The remote control is installed in the vehicle interior.
No. in
fig. 2,
page 3
Description
1 Main switch Switches the generator to standby or no func-
tion.
2 Battery positive terminal Connection to the positive battery terminal.
3 Main fuse Triggers if overvoltage occurs in the inverter
4 Battery charger fuse Triggers if overvoltage occurs in the battery
charger
No. in
fig. 3,
page 4
Description
1 Display Shows the status reports.
2 On/Off switch PSwitches the control panel on and off if the
main switch is at “I” or “1”.
Stops the generator in emergency.
3 Green button START/STOP Starts/stops the generator if the control panel
is switched on and the main switch is at “I”
or “1”.
4 Fuel gauge Lights up if the diesel fuel goes into reserve.
5 Oil gauge Lights up if the oil level is too low in the
engine.
TEC40D-O-16s.book Seite 13 Freitag, 12. August 2016 7:10 19

EN
Operating the generator TEC40D
14
Displays
8 Operating the generator
A
I
8.1 Basic notes on operation
!
No. in
fig. 3,
page 4
Description
6 AC supply Actual voltage output
7 Constant output Current capacity of connected consumer
8 Operating hours Time the generator is in operation
9 DC voltage Battery voltage
10 Messages Status reports of the generator (see chapter
“Display messages” on page 16)
NOTICE!
Do not run the generator over 70 % of the maximum constant output for
the first 50 operating hours (run-in phase).
NOTE
Run the generator at a maximum of approx. 75 % of the maximum con-
tinuous load after the run-in phase.
By doing this you can prolong the service life of the generator and
maximise its efficiency.
CAUTION! Beware of injury
Do not insert your fingers or objects into the air nozzles or the intake
grille.
TEC40D-O-16s.book Seite 14 Freitag, 12. August 2016 7:10 19

EN
TEC40D Operating the generator
15
Please note the following basic information:
•When operating the generator at low temperatures (< 0 °C) you have to use
winter diesel fuel or you have to add a percentage of petrol to the diesel oil
according to the following table:
•Always check the oil level before use (chapter “Checking the oil level” on
page 18).
•Even small overloads in the long-run will cause the generator to stop.
•Leave the generator running for a few minutes after use without any consumers
before stopping it.
•Abrupt braking, accelerating and driving round bends in the vehicle can cause
problems in the generator's pump system and lead to unwanted shutdown.
•If you are not using your generator for a longer period of time, start it up at least
every 10 days and leave it running for 15 minutes or more.
8.2 Switching the generator to standby or no function
The generator can be switched to standby or no function with the main switch
(fig. 21, page 3) in the connection box.
8.3 Switching the control panel on and off
This switch on the control panel (fig. 32, page 4) is for switching the control panel
on and off.
➤Switch the control panel on with the on/off switch.
✓The display shows: GEN OFF.
The display switches off automatically after 5 minutes if the start button is not
touched within this time.
Press the start button to switch on the display again.
✓The generator can now be started.
Ambient Temperature Summer diesel Winter diesel
–10 to 0 °C 20 % –
–15 to –10 °C 30 % –
–20 to –15 °C 30 % 20 %
TEC40D-O-16s.book Seite 15 Freitag, 12. August 2016 7:10 19

EN
Operating the generator TEC40D
16
8.4 Starting the generator
The generator can only be started if it is in standby and the control panel is switched
on.
I
➤Start up the generator with the green button "START/STOP (fig. 33, page 4).
8.5 Stopping the generator
➤Stop the generator with the on/off switch (fig. 32, page 4).
If the generator does not stop: switch it off with the main switch (fig. 21,
page 3).
8.6 Display messages
NOTE
If the generator is still warm, press the start button briefly to start it; press
longer for a cold generator.
Display message
Description Generator behaviour Measures
LOW BATTERY
The battery voltage has fallen
below the minimum value for
starting up (9V).
The generator does not start. Charge the battery.
Check OIL Level The generator continues to run. Fill up with oil (see chapter
“Checking the oil level” on
page 18).
OIL CHANGE
The number of prescribed oper-
ating hours has been reached for
changing the engine oil.
The generator continues to run. Change the oil (see chapter
“Changing the oil” on page 22).
In order to reset the alarm start
up the generator by pressing
and holding down the
START/STOP button.
NO FUEL
The diesel fuel in the tank is in
reserve.
The generator continues to run. Refuel.
TEC40D-O-16s.book Seite 16 Freitag, 12. August 2016 7:10 19

EN
TEC40D Operating the generator
17
OIL TEMP PRESS
Insufficient engine oil.
Engine temperature too high.
The generator stops. Fill up with oil (see chapter
“Checking the oil level” on
page 18).
Leave the generator to cool
down for a few minutes then start
up the generator again.
GENERATOR ALERT!
General alarm message
The generator stops. Check the system by referring to
the troubleshooting table.
If the problem persists, contact
the manufacturer's branch office
in your country (addresses on the
back page).
OVERLOAD!
The consumers generate an
overload at the output.
The inverter switches off, there-
fore no voltage is supplied but
the engine carries on running
until it goes off.
Reduce the connected load and
start the generator again.
SHORT CIRCUIT
The consumers cause a short
circuit at the output.
The inverter switches off, there-
fore no voltage is supplied but
the engine carries on running
until it goes off.
Check the connected consum-
ers then start the generator
again.
OVER TEMPERATURE
The inverter temperature is too
high.
The inverter switches off, there-
fore no voltage is supplied to
cool the generator, but the
engine carries on running.
Leave the generator to cool
down for a few minutes then start
up the generator again.
LOW POWER ENGINE
The inverter supply voltage has
dropped.
The generator stops. Reduce the connected load and
start the generator again.
GEN CAL
A message appears when the
generator is started up; it shows
the calibration phase which
takes place before each start-up.
The generator does not supply
any voltage.
The generator is running but
does not supply any voltage.
Wait a moment.
GEN WAIT
A message appears while you
are waiting for the generator to
start again.
The generator is switched off. Wait until the message has disap-
peared then attempt ignition
again.
Display message
Description Generator behaviour Measures
TEC40D-O-16s.book Seite 17 Freitag, 12. August 2016 7:10 19

EN
Operating the generator TEC40D
18
8.7 Checking the oil level
!
I
Always check the oil level before use. To do this, proceed as follows:
➤Open the generator cover.
➤Switch the generator to no function with the main switch (fig. 41, page 4).
➤Disconnect the positive terminal of the supply battery.
➤Take the dipstick (fig. 42, page 4) out of the filler neck (fig. 43, page 4).
➤Clean the dipstick (fig. 42, page 4) with a cloth.
➤Put the dipstick (fig. 42, page 4) back into the filler neck (fig. 43, page 4).
➤Take the dipstick (fig. 42, page 4) out of the filler neck.
➤Check that the oil level is between the notch (maximum filling level) and the tip of
the dipstick.
If not, top up with more oil.
➤Put the dipstick (fig. 42, page 4) back into the filler neck (fig. 43, page 4).
➤Connect the generator to the positive terminal of the supply battery.
➤Switch the generator to standby with the main switch (fig. 41, page 4).
➤Close the generator cover.
GEN ON
The generator is operating nor-
mally.
Normal mode –
GEN OFF The generator is in stand-by and
can be started.
–
CAUTION!
Hot oil can cause burns.
Only check the oil level when the generator is switched off.
NOTE
The generator must be level.
Display message
Description Generator behaviour Measures
TEC40D-O-16s.book Seite 18 Freitag, 12. August 2016 7:10 19

EN
TEC40D Cleaning the generator
19
9Cleaningthegenerator
A
➤Clean the generator with a damp cloth from time to time.
➤Remove any dirt from the air vents in the generator at regular intervals. Make sure
you do not damage the grilles of the generator in the process.
NOTICE! Beware of damage
•Do not clean the generator with a high-pressure cleaner. Exposure
to water can damage the generator.
•Do not use sharp or hard objects or cleaning agents for cleaning as
these may damage the generator.
•To clean the generator, use water with a gentle cleaning agent.
Never use petrol, diesel or solvents.
TEC40D-O-16s.book Seite 19 Freitag, 12. August 2016 7:10 19

EN
Servicing the generator TEC40D
20
10 Servicing the generator
10.1 Maintenance table
!
I
WARNING!
Only have maintenance work carried out by specialist personnel who
are familiar with the relevant regulations. Inadequate maintenance may
cause serious hazards.
NOTE
Have the following maintenance work performed at regular intervals or
after the specified number of operating hours, whichever is sooner.
Interval Inspection/maintenance
In the first month
or after 50 hours.
➤Change the oil.
Every 250 hours ➤Change the oil.
➤Clean the engine's cooling system.
➤Check the valve play and screws. Adjust the valve play and tighten
the screws, if necessary.
➤Check the air filter (chapter “Servicing the air filter” on page 23).
Every 500 hours ➤Replace the air filter and fuel filter.
Once a year or
every 1000 hours
➤Clean the oil filter.
The following must be carried out by a HATZ authorised retailer or
Dometic skilled personnel:
➤Check the fuel injection pump.
➤Check the vibration damper.
TEC40D-O-16s.book Seite 20 Freitag, 12. August 2016 7:10 19
