Draper Micro Projector Lift Programming manual

Overall
Height
20
5
/ 8 " Max.
12
5
/ 8 " Min.
Available
Projector/
Bracket
Height
13½" Max.
5½" Min.
Upper Section
Lift
Middle Section
Lower Section
Copyright ©2006 Draper, Inc. Form MicroProjectorLiftPlenum_Inst06 Printed in U.S.A.
Assembly/Installation Instructions
Micro Projector Lift Plenum Housing by Draper
Available space in Micro Projector Lift Plenum Housing
If you encounter any difficulties installing your Micro Projector Lift
Plenum Housing, call your dealer or Draper, Inc. in Spiceland, Indiana,
765-987-7999, fax [phone], or E-mail [email protected].
Installing Micro Projector Lift Plenum Housing
The Plenum Housing is shipped pre-assembled in its shortest position. The
height of the plenum can be adjusted by moving the screws to different mount-
ing holes in side panels.You can install the plenum housing in a pre-assembled
state or as separate components, which will require that the plenum housing be
completely disassembled prior to installation.
Please note that if the plenum is to be installed in a space where there is no
access from above the plenum, then it is recommended that the Micro projector
Lift be installed to the upper section prior to installing the plenum housing.
Please refer to drawing belowfor these instructions.
➀Install top section of plenum housing using outer four holes located on top
of upper section.
➁Attach Micro Projector Lift to upper section of plenum housing through the
inner four holes in the upper section with the
5
/ 16 " –18 x
7
/ 8 " hex head
screws,
5
/ 16 " flat washers, and lock washers provided with plenum housing.
The lock washers should be used above the plenum housing (one per
screw); the flat washers should be used between the plenum housing and
the MPL (three flat washers per screw).
➂Attach the two flat panels of the middle section across from each other
with the clinch nuts to the outside of the housing.
➃Attach the two middle section panels with the formed ends across from
one another.
➄Attach lower section of plenum housing.
➅Use 1" foil tape (roll provided with plenum housing) to cover any unused
screwholes in plenum housing.

Installing Optional Ceiling Trim Kit
The lower section of the Micro Projector Lift Plenum is available as part of a
ceiling trim kit, to finish out the ceiling opening even if a plenum housing is not
necessary. This kit consists of the lower section of the plenum housing and the
optional closure panel. Please refer to drawing belowfor these instructions.
➀Install Micro Projector Lift as previously described in these instructions.
➁Install bottom section of plenum housing in opening. This can be
accomplished by suspending with wire, or by mounting directly to the ceiling
joists (if space permits).
Ceiling tile
(by others)
Lower section of
Plenum Housing
Assembly/Installation Instructions
Micro Projector Lift Closure and Ceiling Trim Kit by Draper
If you encounter any difficulties installing your Micro Projector
Lift Closure or Ceiling Trim Kit, call your dealer or Draper, Inc. in
Spiceland, Indiana, 765-987-7999, fax [phone], or E-mail
[email protected].
Installing Ceiling Closure
If your Micro Projector Lift is equipped with a ceiling closure system, it can be
used as is, or in conjunction with a square of existing ceiling tile. Please refer to
diagram below for these instructions.
➀If installing with ceiling tile, you may need to cut tile so that its overall
dimensions are the same as (or slightly less than) the closure panel. Place
tile into trim frame. Lay closure panel on top (back side) of ceiling tile, and
tighten screws to hold in place.
➁Attach
5
/ 16 " threaded rods to pem nuts in lift pan.
➂Run unit “up” until bottom pan stops at highest position. Mark position on
5
/ 16 " rods even with ceiling level and cut rods to length (removing from
pan if convenient).
➃Run unit “down” until bottom pan stops at “show” position.
➄Attach closure to lower end of
5
/ 16 " rods by slipping into four corner slots
and secure with nuts above and belowslots.
➅Run unit “up” again to highest position. Measure distance by which panel
fails to reach required “closed” height for surrounding ceiling.
➆Run unit “down” then readjust mounting of
5
/ 16 " rods in traveling grid to raise
panel required distance.
➇Test unit operation to confirm that panel will stop in closed position just
before touching ceiling.
NOTE: Immediately upon completion of the surrounding ceiling, units should be
operated to confirm that optional ceiling closure panel stops just short of touch-
ing ceiling in closed position.
