Rugged Tablet
BASIC OPERATION GUIDE
DT300Q
INTRODUCTION
Thank you for acquiring the DT300Q, part of DT Research’s line of tablets. Featuring a slim yet robust
enclosure, the DT300Q with 8” TFT display is powered by the Intel® Atom™ quad-core or Qualcomm
octa-core processor, offering optimal combinations of performance and power savings. The DT300Q is
available with Microsoft® Windows® or Android operating system. The software operating system features
web browser, client/ server computing software, media player, accessories, and applications support.
PACKAGE CONTENTS
•One DT300Q with Battery Pack and Handstrap
•AC-DC Power Adapter with Power Cord
•Basic Operation Guide
* If your DT300Q contains camera or barcode scanner, please refer to the Tablet Modules Basic Operation
Guide for detailed operation.

DT300Q:
Input/ Output Ports Button Functions
A
Headphone Jack
BUTTON
ACTION
B
USB Port
1
power button
C
DC Power Input
2
Programmable Button without the
scanner module As Scanner Trigger
when equipped with the scanner
module
D
Back Camera (optional on DT380CR)
3
Battery Latch
E
Barcode Scanner (optional)
2

Power/Battery LED Status:
•Blue indicates the battery is 25% to 100% charged
•Blinking blue indicates the battery is charging
•Orange indicates that the battery is between 11% to 25%
•Blinking Orange indicates that the battery is below 10%
PRECAUTIONS
•Always exercise care when operating and handling the DT300Q.
•Do NOT apply excessive pressure to the display screen.
•Avoid prolonged exposure of the display panel to any strong heat source. Wherever possible, the DT300Q
should face away from direct light to reduce glare.
•If the AC-DC power adapter is used to recharge or power the tablet, do NOT use any AC-DC adapter other
than the one provided or acquired from the manufacturer or its partners.
•In the unlikely event that smoke, abnormal noise, or strange odor is present, immediately power off the
DT300Q and disconnect all power sources. Report the problem to your device provider immediately.
•Never attempt to disassemble the DT300Q, as this will void the warranty.
BASIC FEATURES
The DT380CR/ DT380Q wireless tablet integrates a bright and multi-touch display, one USB port, and
embedded networking elements such as wireless LAN and Bluetooth. The DT300Q is complemented by a
suite of accessories, including battery gang charger, and charging cradles, for a comprehensive user
experience.
A DT300Q typically integrates an 802.11ac wireless LAN (WLAN) adapter that may connect to other wireless
devices or access points. If your DT300Q does not come with such a network adapter, please consult your
device provider to establish the desired network connectivity.
3

OPERATION
Powering ON and OFF
To activate the DT300Q, push and quickly release the Power Button. The display will come on in a few
seconds. To put the DT300Q in Standby mode, push and quickly release the Power Button. To turn the
DT300Q off for extended storage, power off safely using any software function that “shuts down computer”
provided in the software operating system.
NOTE:
The battery pack shipped with your tablet may be low in power—please use the AC-DC adapter with
the DT300Q when setting up for the first time to fully charge the battery pack.
NOTE:
When the battery pack is charging, the blue-colored Battery LED should blink slowly. If plugging in the
AC-DC adapter does not trigger this blinking activity and the LED stays dark, the battery pack(s) may
have been drained substantially. Try unplugging/ replugging the AC-DC adapter to the DT300Q a few
times to activate the charging process.
NOTE:
To conserve power, use (push and quick release) the Power Button to put the tablet in “Standby”
mode while not in use. Pushing briefly on the same button will wake up the system within seconds.
NOTE:
For DT380CR, avoid using the Power Button (“hold 4+ seconds” feature) to turn off the tablet—this
form of hardware shutdown is intended to be a means of recovery from lockups, and not as normal
operation.
4

Start Up
If the power up (from Standby mode or otherwise) is successful, the appropriate interface will be displayed
after a launch sequence of several seconds. The wireless LAN connection may take 10-15 seconds to be
established.
Configuring the Mobile Tablet
The DT300Q may be configured using the utilities and methods dictated by the software operating system.
The DT300Q should be configurable for various properties such as user profiles, network features, and several
system elements.
Wireless Networking
Wireless LAN
The DT300Q is often delivered with an embedded (user-inaccessible) 802.11ac WLAN adapter equipped with
a hidden custom antenna.
• Through the support of typical WLAN adapters, the DT300Q should be able to detect all 802.11 access
points in the vicinity for you to select the access point of your choice for connection.
• The SSID and WEP/WPA/WPA2 (if enabled) parameters on the DT300Q and the access points have to
match. The SSID is case-sensitive and it is recommended that you enable WEP/WPA/WPA2 encryption (or
advanced alternatives) for secure access.
•When WEP/WPA/WPA2 is enabled, you may need to consult your network administrator or your
networking equipment literature to properly configure associated settings such as Authentication mode,
etc.
•Refer to the access point operating manuals for setting up the 802.11 access points.
Bluetooth
The Bluetooth configuration application is enabled from the Windows System Tray or from the Android
Settings APP. Follow the instructions and options provided within the application to configure and invoke
Bluetooth connectivity with the corresponding peripherals.
5

USING THE MOBILE TABLET
Peripherals Support
Through its USB port, the DT300Q supports a wide range of USB-based peripherals. These peripherals are
applicable for software installation, applications storage, data storage, and system software recovery and
updates.
For More Support
Users can download the Tablet Modules Basic Operation Guides from the DT Research website.
To Hold the Tablet
Left hand: grip the left back side of the tablet with your left hand
four index fingers, with thumb resting on the top of the back side
of the tablet and palm securely against the back.
Right hand: grip the right back side of the tablet with your right
hand four index fingers, with thumb resting on the top of the back
side of the tablet and palm securely against the back.

6
Specifications:
DT300Q
DT380CR
System
CPU
Qualcomm Octa-Core, 2.0GHz
Intel® Atom™ Quad Core, 1.44GHz (up to 1.92GHz)
RAM
4GB
4GB
Storage
64GB flash
128GB flash
Operating System
Android 9.0
Microsoft® Windows® 10 IoT Enterprise
Display
8” LED-backlight, high-brightness (850 nits) capacitive touch screen
Display Resolution
1920 x 1200
1920 x 1200
Network Interface
Wi-Fi 802.11ac, 2.4GHz/ 5GHz dual band; Bluetooth 4.2 LE
Fan/ Fanless
Fanless
Fanless
Control Switch and
Buttons
1 power button and 1 trigger buttons
1 power button and 1 trigger buttons
Speaker
Built-in Speaker
Built-in Speaker
I/O Ports
USB port
1 (USB 3.0)
1 (USB 3.0)
Audio Jack
1 (3.5mm)
1 (3.5mm)
DC-in
1
1
SD Slot
1 micro SD card slot
1 micro SD card slot
Mechanical
AC/DC Adapter
Input: 100 –240V AC; Output: 12V DC, 5A
Input: 100 –240V AC; Output: 12V DC, 5A
Battery Pack
Hot swappable battery, 3.7V, 8800mAh
Hot swappable battery, 3.7V, 8800mAh
Enclosure
ABS + PC plastics and magnesium-aluminum alloy
Dimensions (H x W x D)
5.7 x 8.3 x 0.8 in/ 145.4 x 210 x 20.4 mm
5.7 x 8.3 x 0.8 in/ 145.4 x 210 x 20.4 mm
Weight
1.99 lbs/ 900 g
1.99 lbs/ 900 g
Environmental
Operating Temperature
Operation: 32°F to 122°F (-0°C to 50°C); Storage: -4°F to 140°F (-20°C to 60°C)
Humidity
0% –90% non-condensing
0% –90% non-condensing

FCC Regulatory Compliance
Warning: changes or modifications not expressly approved by the party responsible for compliance
could void the user’s authority to operate the equipment.
Note: This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates, uses
and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
-- Reorient or relocate the receiving antenna.
-- Increase the separation between the equipment and receiver.
-- Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
-- Consult the dealer or an experienced radio/TV technician for help.
RF Exposure Compliance
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled
environment.
The device has been tested for use against the body with 0mm separation in Specific Absorption
Rate (SAR) testing.
User must follow the specific operating instructions for satisfying RF exposure compliance.
This transmitter must not be co-located or operating in conjunction with any other antenna or
transmitter.
Supplier's Declaration of Conformity
47 CFR § 2.1077 Compliance Information
Unique Identifier Trade Name: , Model No.: SC600TA
Responsible Party –U.S. Contact Information
DT Research, Inc.
2000 Concourse Drive, San Jose, CA 95131
http://www.dtresearch.com
FCC Compliance Statement
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)
This device may not cause harmful interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
DT Research, Inc.
2000 Concourse Drive, San Jose, CA 95131 http://www.dtresearch.com
Copyright © 2020, DT Research, Inc. All Rights Reserved.
