2HORUS

HORUS
DESCRIPTION
HORUS is a compact LED downlight designed for inset ceiling installation.
HORUS features a light body with tilting movement and it’s ideal for lighting and colouring objects and
surfaces with a homogeneous projection in different application, such as clubs, restaurants, public and
commercial spaces, houses of worship, etc.
HORUS is available with distinct types of LEDs: FULL COLOUR, RGB, RGBA, WHITE+AMBER,
WHITE 3200°K, WHITE 4500°K, WHITE 6000°K.
LED technology
HORUS FULL COLOUR: 15 x 3W Full Colour LEDs;
HORUS RGBA 54: 54 x 1W P4 LEDs (12 x Red, 15 x Green, 15 x Blue, 12 x Amber)
HORUS RGBA 48: 48 x 1W P4 LEDs (12 x Red, 12 x Green, 12 x Blue, 12 x Amber)
HORUS RGB: 36 x 1W P4 LEDs (12 x Red, 12 x Green, 12 x Blue)
HORUS WHITE+AMBER 36: 36 x 1W P4 LEDs (24 x White, 12 x Amber)
HORUS WHITE+AMBER 54: 54 x 1W P4 LEDs (42 x White, 12 x Amber)
HORUS WHITE 3200°K (48 x 3200°K White LEDs)
HORUS WHITE 4500°K (48 x 4500°K White LEDs)
HORUS WHITE 6000°K (48 x 6000°K White LEDs)
Linear colour temperature: 2800°K - 6500°K
No infrared emission; no ultraviolet emission
LEDs average lifespan: 100.000 hours
Optical units
3 lenses sets available (Spot, Medium flood, Wide flood)
Control
Via any DMX lighting console (Z1 PLUS or Z8 Power supply / LED controller needed )
Movement
FIXED or ADJUSTABLE (Movement on horizontal axis + / - 15°)
Protection
IP20
Construction
HORUS is made on aluminium
Power supply
Dedicated Z1 PLUS / Z8 power supplies / LED controllers
Z-LIGHT range on-off power supplies
Power consumption
65W (HORUS FULL COLOUR, HORUS WHITE 48 LEDs)
80W (HORUS RGBA 54 LEDs, HORUS WHITE + AMBER 54 LEDs)
Connections
8 poles plug-in screw terminals + cable length 1 m (HORUS all models)
Weight
2,8 Kg
DIMENSIONS
3

HORUS
WIRING DIAGRAMS
HORUS is provided with 8 poles plug-in screw terminals + cable length 1 m (HORUS all models)
ACCESSORIES
• Lenses set Spot (HORUS FULL COLOUR) (Code 03.LK.066)
• Lenses set Medium flood (HORUS FULL COLOUR) (Code 03.LK.067)
• Lenses set Wide flood (HORUS FULL COLOUR) (Code 03.LK.068)
• Lenses set Spot (HORUS RGBA / WHITE+AMBER) (Code 03.LK.024)
• Lenses set Medium flood (HORUS RGBA / WHITE+AMBER) (Code 03.LK.025)
• Lenses set Wide flood (HORUS RGBA / WHITE+AMBER) (Code 03.LK.026)
• Z1 PLUS IP20 Power supply / LED controller (Code 03.LA.009.P)
• Z8 IP20 Power supply / LED controller plug-in screw terminals outputs (Code 03.LA.080.V2)
• Z-LIGHT range on-off power supplies also available
IMPORTANT SAFETY INFORMATION
Fire prevention:
Never locate the fixture on any flammable surface.
Minimum distance from flammable materials: 10 cm
Safety:
The external surface of the unit may exceed 50°C, never handle the unit until at least 5 minutes
have elapsed since the unit was turned off.
Never install the unit in an enclosed area lacking sufficient air flow.
The ambient temperature should not exceed 40°C and should not be lower than -10°C.
Pin 1 = RED +
Pin 2 = RED -
Pin 3 = GREEN +
Pin 4 = GREEN -
Pin 5 = BLUE +
Pin 6 = BLUE -
Pin 7 = AMBER +
Pin 8 = AMBER -
The maximum distance between Z1 PLUS IP20 Power supply / LED controller and the HORUS LED
PROJECTOR (all models) should not exceed 100 meters.
The maximum distance between Z8 IP20 Power supply / LED controller and the HORUS
HORUS should not exceed 100 meters.
The maximum distance between Z8 IP20 Power supply / LED controller and the HORUS
should not exceed 50 meters.
WHITE+AMBER, RGBA
FULL
COLOUR
8 poles plug-in screw terminals
on board (HORUS all models)
4
1---------PIN---------8

HORUS
WIRING CONNECTIONS
IMPORTANT:
The maximum number of HORUS LED PROJECTOR connectable to the Z1 PLUS IP20 Power
supply / LED controller is 1 piece.
The maximum distance between Z1 PLUS IP20 Power supply / LED controller and the HORUS LED
PROJECTOR (all models) should not exceed 100 meters.
Never plug in a HORUS LED PROJECTOR when the power supply is turned on.
5
R+
1R-
2G+
OUTPUT
3G-
4B+
5
Z1 PLUS IP20
LED Controller
Code 03.LA.009.P
B-
6A+
7A-
8
Pin 1 = RED +
Pin 2 = RED -
Pin 3 = GREEN +
Pin 4 = GREEN -
Pin 5 = BLUE +
Pin 6 = BLUE -
Pin 7 = AMBER +
Pin 8 = AMBER -
1---------PIN---------8

6HORUS
WIRING CONNECTIONS
IMPORTANT:
The maximum number of HORUS LED PROJECTOR connectable to the Z8 IP20 Power
supply / LED controller is 1 piece each LED output (8 pcs totally).
The maximum distance between Z8 IP20 Power supply / LED controller and the HORUS
HORUS should not exceed 100 meters.
The maximum distance between Z8 IP20 Power supply / LED controller and the HORUS
should not exceed 50 meters.
Never plug in a HORUS LED PROJECTOR when the power supply is turned on.
WHITE+AMBER / RGBA
FULL COLOUR
A-
8
A+
7
B-
OUTPUT
6
B+
5
G-
Z8 IP20 LED Controller
(Plug-in screw terminals outputs)
Code 03.LA.080.V2
4
G+
3
R-
2
OUTPUT 2
OUTPUT 3
OUTPUT 4
OUTPUT 5
R+
1
A-
8
A+
7
B-
OUTPUT
6
B+
5
G-
4
G+
3
R-
2
R+
1
8 poles plug-in screw terminals
on board (HORUS all models)
1---------PIN---------8

RECESSED INSTALLATION
7HORUS
FIXING SPRINGS

HORUS MODELS
03.LDB093.03.F10 HORUS ADJ FULL COLOR SPOT lenses White finish
03.LDB093.03.F25 HORUS ADJ FULL COLOR MEDIUM flood lenses White finish
03.LDB093.03.F40 HORUS ADJ FULL COLOR WIDE flood lenses White finish
03.LDB093.03.T10 HORUS ADJ RGBA 54LED SPOT lenses White finish
03.LDB093.03.T25 HORUS ADJ RGBA 54LED MEDIUM flood lenses White finish
03.LDB093.03.T40 HORUS ADJ RGBA 54LED WIDE flood lenses White finish
03.LDB093.03.W10 HORUS ADJ WA 54LED SPOT lenses White finish
03.LDB093.03.W25 HORUS ADJ WA 54LED MEDIUM flood lenses White finish
03.LDB093.03.W40 HORUS ADJ WA 54LED WIDE flood lenses White finish
03.LDB094.03.F10 HORUS FIX FULL COLOR SPOT lenses White finish
03.LDB094.03.F25 HORUS FIX FULL COLOR MEDIUM flood lenses White finish
03.LDB094.03.F40 HORUS FIX FULL COLOR WIDE flood lenses White finish
03.LDB094.03.T10 HORUS FIX RGBA 54LED SPOT lenses White finish
03.LDB094.03.T25 HORUS FIX RGBA 54LED MEDIUM flood lenses White finish
03.LDB094.03.T40 HORUS FIX RGBA 54LED WIDE flood lenses White finish
03.LDB094.03.W10 HORUS FIX WA 54LED SPOT lenses White finish
03.LDB094.03.W25 HORUS FIX WA 54LED MEDIUM flood lenses White finish
03.LDB094.03.W40 HORUS FIX WA 54LED WIDE flood lenses White finish
03.LDB096.03.T10 HORUS ADJ RGB 36LED SPOT lenses White finish
03.LDB096.03.T25 HORUS ADJ RGB 36LED MEDIUM flood lenses White finish
03.LDB096.03.T40 HORUS ADJ RGB 36LED WIDE flood lenses White finish
03.LDB096.03.W10 HORUS ADJ WA 36LED SPOT lenses White finish
03.LDB096.03.W25 HORUS ADJ WA 36LED MEDIUM flood lenses White finish
03.LDB096.03.W40 HORUS ADJ WA 36LED WIDE flood lenses White finish
03.LDB097.03.T10 HORUS FIX RGB 36LED SPOT lenses White finish
03.LDB097.03.T25 HORUS FIX RGB 36LED MEDIUM flood lenses White finish
03.LDB097.03.T40 HORUS FIX RGB 36LED WIDE flood lenses White finish
03.LDB097.03.W10 HORUS FIX WA 36LED SPOT lenses White finish
03.LDB097.03.W25 HORUS FIX WA 36LED MEDIUM flood lenses White finish
03.LDB097.03.W40 HORUS FIX WA 36LED WIDE flood lenses White finish
03.LDB143.03.W10 HORUS ADJ 3200°K 48LED SPOT lenses White finish
03.LDB143.03.W25 HORUS ADJ 3200°K 48LED MEDIUM flood lenses White finish
03.LDB143.03.W40 HORUS ADJ 3200°K 48LED WIDE flood lenses White finish
03.LDB144.03.W10 HORUS ADJ 4500°K 48LED SPOT lenses White finish
03.LDB144.03.W25 HORUS ADJ 4500°K 48LED MEDIUM flood lenses White finish
03.LDB144.03.W40 HORUS ADJ 4500°K 48LED WIDE flood lenses White finish
03.LDB145.03.W10 HORUS ADJ 6000°K 48LED SPOT lenses White finish
03.LDB145.03.W25 HORUS ADJ 6000°K 48LED MEDIUM flood lenses White finish
03.LDB145.03.W40 HORUS ADJ 6000°K 48LED WIDE flood lenses White finish
03.LDB146.03.W10 HORUS FIX 3200°K 48LED SPOT lenses White finish
03.LDB146.03.W25 HORUS FIX 3200°K 48LED MEDIUM flood lenses White finish
03.LDB146.03.W40 HORUS FIX 3200°K 48LED WIDE flood lenses White finish
03.LDB147.03.W10 HORUS FIX 4500°K 48LED SPOT lenses White finish
03.LDB147.03.W25 HORUS FIX 4500°K 48LED MEDIUM flood lenses White finish
03.LDB147.03.W40 HORUS FIX 4500°K 48LED WIDE flood lenses White finish
03.LDB148.03.W10 HORUS FIX 6000°K 48LED SPOT lenses White finish
03.LDB148.03.W25 HORUS FIX 6000°K 48LED MEDIUM flood lenses White finish
03.LDB148.03.W40 HORUS FIX 6000°K 48LED WIDE flood lenses White finish
8HORUS

9HORUS
NOTES

10 HORUS
NOTES

11 HORUS
NOTES
