DTS XR2000 BEAM User manual

GB
Made in Italy
XR2000 BEAM
User’s Manual Rel 1.4
D.T.S. Illuminazione srl - ITALY
http://www.dts-lighting.it

Le informazioni contenute in questo documento sono state attentamente redatte e controllate. Tuttavia
non è assunta alcuna responsabilità per eventuali inesattezze. Tutti i diritti sono riservati e questo
documento non può essere copiato, fotocopiato, riprodotto per intero o in parte senza previo consenso
scritto della D.T.S .
DTS si riserva il diritto di apportare senza preavviso cambiamenti e modifiche estetiche , funzionali o di
design a ciascun proprio prodotto. D.T.S non assume alcuna responsabilità sull’uso o sull’applicazione dei
prodotti o dei circuiti descritti.
The information contained in this publication has been carefully prepared and checked. However, no
responsibility will be taken for any errors. All rights are reserved and this document cannot be copied,
photocopied or reproduced, in part or completely, without prior written consent from D.T.S.
D.T.S. reserves the right to make any aesthetic, functional or design modifications to any of its products
without prior notice. D.T.S. assumes no responsibility for the use or application of the products or circuits
described herein.
Les informations contenues dans le présent manuel ont été rédigées et contrôlées avec le plus grand
soin. Nous déclinons toutefois toute responsabilité en cas d'éventuelles inexactitudes. Tous droits
réservés. Ce document ne peut être copié, photocopié ou reproduit, dans sa totalité ou partiellement,
sans le consentement préalable de .
se réserve le droit d'apporter toutes modifications et améliorations esthétiques, fonctionnelles ou
de design, sans préavis, à chacun de ses produits. décline toute responsabilité sur l'utilisation ou
sur l'application des produits ou des circuits décrits.
D.T.S
D.T.S.
D.T.S.
Las informaciones contenidas en este documento han sido cuidadosamenteredactadas y
controladas. Con todo, no se asume ninguna responsabilidad por eventuales inexactitudes.
Todos los derechos han sido reservados y este documento no puede ser copiado, fotocopiado
o reproducido, total o parcialmente, sin previa autorizaciónescrita de
se reserva el derecho a aportar sin previo aviso cambios y modificaciones de carácter
estético, funcional o de diseño a cada producto suyo. no se asume responsabilidad de
ningún tipo sobre la utilización o sobre la aplicació
n de los productos o de los circuitos descritos.
D.T.S.
D.T.S.
D.T.S.
ARC 1200
XR2000 BEAM
2

ARC 1200
INDEX:
1- SYMBOLS 4
2- GENERAL WARNING 4
3- GENERAL WARRANTY CONDITION 4
4- TECHNICAL FEATURES 5
5- ACCESSORIES 7
6- IMPORTANT SAFETY INFORMATION 8
6.1 Fire prevention
6.2 Prevention of electric shock
6.3 Protection against ultraviolet radiation
6.4 Safety
6.5 Level of protection against the penetration of solid and liquid objects
7- MOUNTING THE LAMP 9
7.1 Lamp alignment
8- VOLTAGE AND FREQUENCY 10
9- INSTALLATION 10
9.1 Safety cable
9.2 Protection against liquids
9.3 Movement
9.4 Risk of fire
9.5 Forced ventilation
9.6 Ambient temperature
10- MAINS CONNECTION 11
10.1 Protection
11- DMX SIGNAL CONNECTION 12
11.1 DMX Addresses
11.2 Selecting the DMX address
12- FIRMWARE UPDATING 13
13- DISPLAY FUNCTIONS 14
14- ERROR MESSAGES 17
15- HIDDEN MENU 18
16- PAN & TILT SPEED 19
17- FANS SPEED 19
18- OPENING THE PROJECTOR HOUSING 20
19- REPLACING GOBOS 20
20- PERIODIC CLEANING 21
20.1 Lenses and reflectors
20.2 Fans and air passages
21- PERIODIC CONTROLS
22- DMX PROTOCOL 22
23- 8 MOTORS CONTROL CARD 34
24- PAN & TILT CARD 35
25- CABLES RESEND CARD
26- DISPLAY CARD
27- LAMP ON-OFF CONTROL CARD
28- ROTATING GOBO WHEEL 36
29- COLOUR WHEEL 1 37
30- MORE GOBOS PROVIDED IN THE PACK AS STANDARD ACCESSORIES 38
3XR2000 BEAM

ARC 1200
1- SYMBOLS
Graphic symbols used on this manual
2- GENERAL WARNING
Read the instruction contained in this user manual carefully, as they give important information
regarding safety during installation , use and maintenance.
The device is not for domestic use and must be installed by a qualified electrician or experienced
person.
Always disconnect the device from the mains before replacing the lamp.
The lamp must be replaced if it has been damaged or deformed by prolonged use or overheating.
The device must always be equipped with an efficient ground connection.
3- GENERAL WARRANTY CONDITIONS
The unit is guaranteed for 24 months from the date of purchase against manufacturing material defects.
THIS SYMBOL INDICATES A HOT SURFACE
THIS SYMBOL INDICATES ELECTRIC SHOCK RISK
THIS SYMBOL INDICATES GENERAL RISK
THIS SYMBOL MEANS “DO NOT PLACE THE UNIT ON
INFLAMMABLE SURFACES”
2M THIS SYMBOL INDICATES THE MINIMUM DISTANCE TO
BE KEPT BETWEEN THE DEVICE AND THE LIT OBJECT
4
F
THIS SYMBOL MEANS “RADIATION FROM THIS LAMP
CAN CAUSE DAMAGE TO EYES AND SKIN”
!
UV
XR2000 BEAM

ARC 1200
4- TECHNICAL FEATURES
Lamp
Lamp: Philips MSR Gold 700/2 Fastfit
Automatic switching ON of lamp in case of accidental switching OFF.
Lamp ON/OFF via DMX; Reset via DMX.
Optical group
XR2000 BEAM is a new compact moving head with an extremely high light power, projecting a parallel
and very concentrated beam.
With its new lens unit, XR2000 BEAM generates a luminosity of an incredible 150,000 Lux at 5 metres,
using only a 700 W lamp, giving an exceptional balance between performance and power consumption.
XR2000 BEAM is designed for a wide range of professional applications, like concerts, shows, tours and
big events.XR2000 BEAM ensures in fact great flexibility in use, because in a single projector it
incorporates a range of functions normally available only on different units (long-throw projectors with
high-power lamps, PAR 64 ACL, moving heads).XR2000 BEAM offers:
* Exceptional light power (150,000 Lux at 5 metres);
* The capacity to project a highly condensed and intense beam of light even over great distances, thanks
to the high efficiency of the new lens;
* Variety of colours (linear CMY synthesis + wheel with 7 colours);
* Customizable gobo wheel;
* Insertable linear frost filter (soft edge);
* Fast and uniform Pan and Tilt movements.
The XR2000 BEAM is also the ideal light for a vast range of applications in which quiet operation is a
priority, thanks to its silent ventilation system and silent pan/tilt operation.
The 16 bit Pan/Tilt mechanism features an exclusive Super Speed function, and a locking system with
recessed buttons. Access to every feature of the internal menu is simple and direct, thanks to the new
user interface featuring a LCD backlit graphic display (128 x 64).
XR2000 BEAM
(Cod. 03.MB001.EB.L)
• Electronic ballast 90-245V 50/60 Hz • Black finish
150.000 Lux at 5 m (5,5°beam angle)
Dichroic glass reflector
Dimmer / shutter / strobo
Linear dimmer
Shutter
Strobe from 0,85 flash/sec to 10 flash/sec
Colours
CMY colour synthesis system + colour wheel (7 colours + open) with linear selection for perfect 2-colour
beams
Colour change with blackout sync; rainbow effect
Gobos
1 customizable rotating gobo wheel (7 gobos); extractable gobo holders
Gobo change with synchronized blackout
Gobo scrolling; Gobo shake
Frost
Frost filter (soft edge)
5XR2000 BEAM

4- TECHNICAL FEATURES
Pan / Tilt
DMX channels
Connections
4 XLR connectors (3-pole In and Out; 5-pole In and Out) by Neutrik
POWERCONN connector by Neutrik
Power supply
Electronic ballast: 90 - 260 V (50/60 Hz)
Power consumption: 820 W
Standard accessories
2 x “C” GQuick clamps with “fastlock” connection
Thermal
Operating ambient temperature: -10° / 40°
Weight
37 Kg
Pan 540°(3,9 sec.); Tilt 270°(2,6 sec.); 16-bit resolution
Super Speed function; extremely smooth and precise movements even at the highest speeds
Pan / Tilt locking system with recessed buttons
Automatic Pan/Tilt repositioning in case of knocks
21(default) or 16 DMX channels
Internal operating system updatable via DMX
Interface
LCD backlit graphic display (128x64)
Power saving mode (the lamp dims to 50% six seconds after shutter closure)
ARC 1200
6XR2000 BEAM

4- TECHNICAL FEATURES
Dimensions
5- ACCESSORIES
As standard
•1 x MSR Gold 700/2 Fastfit lamp
•1 x POWERCONN male cable connector (cod. 0520P014)
•1 x XLR 5 Pins male cable connector (cod. 0508B028)
•1 x XLR 5 Pins female cable connector (cod. 0508B027)
•5 x Metal Gobos
•2 x “C” Clamp GQUICK with “Fast Lock” connection 1/4 turn (max. load. 80Kg) (cod. 0521A014)
• User’s manual
Optional (on request)
• Double Professional Flight case; compartment for lamps and accessories, swivel wheels, cover with
hinges with-stay, dishes on cover for piling, 8 handles (2 each side) (cod. 0521C038)
• Raincover for XR2000 base (top) (cod. 03.MA009)
• Raincover for XR2000 base (bottom) (cod. 03.MA010)
• Embedding flange for XR2000 (visible display) (cod. 03.MA008)
• Embedding flange for XR2000 (no visible display) (cod. 03.MA007)
• Wireless DMX receiver card (cod. 03.LA.012)
• “C”Clamp G60 black (max. load 50Kg) (cod. 0521A004)
• “C”Clamp G60 chrome (max. load. 50Kg) (cod. 0521A004.20)
• “C”Clamp GQUICK with “Fast Lock”connection 1/4 turn (max. load. 80Kg) (cod. 0521A014)
• “C”Clamp G100 black / professional (max. load. 200Kg) (cod. 0521A015)
• Omega clamp with “Fast Lock”connection 1⁄4 turn
• Safety wire (3mm x 60 cm), ring spring catch, max. capacity load 60Kg (cod. 0521A010)
Unit Dimensions (LxWxH)
510x510x775mm
Weight: 37 Kg
Packaging Dimensions (LxWxH)
610 x 540 x 720 mm
Weight: 42 Kg
ARC 1200
7XR2000 BEAM

6- IMPORTANT SAFETY INFORMATION
6.1 Fire prevention:
MSR Gold 700 Fastfit lamp
The use of any other alternative lamp is not recommended and will null and void the fixture's warranty.
-Never locate the fixture on any flammable surface.
-Minimum distance from flammable materials: 1.5 MT.
-Minimum distance from the closest illuminable surface: 2 MT.
-Replace any blown or damaged fuses only with those of identical value. Refer to the wiring diagram if
there is any doubt.
-Connect the projector to mains power via a thermal magnetic circuit breaker.
6.2 Prevention of electric shock:
-High voltage is present inside the unit. Unplug the unit prior to performing any function which involves
touching the inside of the moving head, including lamp replacement.
-The level of technology inherent in the requires the assistance of specialised personnel
for all servicing. Please refer to an authorised DTS service centre.
-A good earth connection is essential for proper functioning of the projector.
-Never connect the unit without proper earth connection.
-The fixture should be located in places with a good air ventilation.
6.3 Protection against ultraviolet radiation:
-Never turn on the lamp if any of the lenses, filters or ABS covering are damaged. Their respective
shielding functions will only operate efficiently if they are in perfect working order.
-Never look directly the lamp when it is on.
6.4 Safety:
-The projector should always be installed with bolts, clamps and other tools that are capable of
supporting the weight of the unit.
-Always use a second safety cable to sustain the weight of the unit in case of the failure of the main
fixing point.
-The external surface of the unit, at various points, may exceed 70°C. Never handle the unit until at
least 10 minutes have elapsed since the lamp was turned off.
-Always replace the lamp if any physical damage is evident.
-Never install the fixture in an enclosed area lacking sufficient air flow. The ambient temperature should
not exceed 40°C.
-A hot lamp may explode, so always wait for at least 10 minutes prior to attempting to replace the lamp.
-Always wear suitable hand protection when handling the lamp.
6.5 Level of protection against the penetration of solid and liquid objects:
-The projector is classified as an ordinary appliance and its protection level against the penetration of
solid and liquid objects is IP 20.
For outdoor use, D.T.S. reccomend the use of the dedicated raincovers:
•
•
XR2000 BEAM uses a PHILIPS /2
XR2000 BEAM
Raincover for XR2000 base (top) (cod. 03.MA009)
Raincover for XR2000 base (bottom) (cod. 03.MA010)
ARC 1200
2M
8
F
!
!
UV
XR2000 BEAM

7- MOUNTING THE LAMPS
Warning: Switch off the unit before replacing the lamp.
1) Using a screwdriver, loose the 3 screws A, B, C, (photo 1) and remove the metal cover .
2) Insert the lamp (photo2).
3) Rotate the lamp 1/4 turn clockwise (photo 3 and 4).
The lamp used on XR2000 BEAM is made in quartz glass and should be handled with care. Always
follow the instructions supplied in the lamp's packaging. Never touch the glass directly but use the tissue
provided in the lamp's packaging. The lamp socket is not symmetrical.
DO NOT USE UNDUE FORCE ON THE GLASS. In case of difficulty, read again the instructions and repeat
the procedure.
4) Replace the metal cover and tighten the screws A,B,C, which were previously removed.
WARNING: Never look directly at the lamp when it’s lit.
Discharge lamps emits UV rays; radiation from this lamp can cause damage to eyes and skin.
7.1 Lamp alignment
Attention: we recommend to align the lamp in the optical system to avoid overheating of the dichroic
filters and other components inside the unit. The lamp alignment is also essential to obtain the
maximum unifirmity and luminous performance by the projection.
3 adjusters X, Y and
Z (photo 5)
you will have an evenly projected light beam, with no shadows or
zones wich are brighter than others.
Philips MSR Gold 700/2 Fastfit
Power 700W
Luminous flux 50,000 lm
Colour temperature 7.500°K
Lampbase PGJX50
Rated life 750 hours
PGJX50
1) Mount the fixture in an orientation so that it may be squarely projected onto a smooth white surface
no less than 3 meters away. 2) Using a console or the menu system, focus an open (white) beam onto
the surface and observe the beam. 3) Using a phillips-head screw driver, rotate the
until you achieve a uniform flat field.
When the lamp is correctly optimized,
ARC 1200
Photo 2Photo 1 Photo 4Photo 3
Photo 5
9
Lamp
Alignment
UV
XR2000 BEAM

8- VOLTAGE AND FREQUENCY
The XR2000 BEAM with electronic ballast can operate at 90-260 VOLT 50 or 60 Hz.
9- INSTALLATION
XR2000 BEAM may be either floor or ceiling mounted.
For floor mounting installations, the XR2000 BEAM is supplied with four rubber mounting feet on the
base.
For ceiling mounted installations, we reccomend the use of appropriate clamps to fix the unit to the
mounting surface.
The supporting structure from which the unit is hung should be capable of bearing the weight of the
unit, as should any clamps used to hung it. The structure should also be sufficiently rigid so as not to
move or shake whilst the XR2000 BEAM is moving.
Eight 1/4 turn Fast Locks connections placed in the base of the units allow to fix the XR2000 BEAM in
any position, by using the two Fast Lock ‘C’ clamps provided in the box.
.
9.1- Safety cable
We recommend the use of a safety cable or chain connected to the XR2000 BEAM and to the suspension
truss in order to avoid the fixture accidentally falling should the main fixing point fail. Make sure that the
iron cable or chain can bear the weight of the entire unit.
You may attach the safety chain to the two holes (A) located on the base of the fixture, as shown in the
picture below.
9.2- Protection against liquids
The projector contains electric and electronic components which should under no circumstances come
into contact with oil, water or any other liquid. The proper unit functioning would be compromised
should this occur.
ARC 1200
10
A
XR2000 BEAM

9.3- Movement
The projector has a maximum movement of 540° for Pan and 270° for Tilt. DO NOT place any
obstructions in the path of the projector's movement.
9.4- Risk of fire
Each fixture produces heat and must be installed in a well-ventilated place. The minimum recommended
distance from flammable material is 1 MT.
Minimum distance from the object being illuminated is 2 MT.
9.5- Forced ventilation
You will note, on inspection, that the unit features various air inlets and cooling fans located on both the
base and head of the fixture. These should, under no circumstances, be blocked or obstructed whilst the
projector is in operation.
Doing so could cause the fixture to seriously overheat thereby compromising its proper operation.
9.6- Ambient temperature
The projector should never be installed in places that lack a constant air flow. The ambient temperature
should NOT exceed 40°C.
10- MAINS CONNECTION
XR2000 BEAM with electronic ballast operate at 90-260 VOLT 50-60 Hz.
Prior to connecting the unit to your mains supply,
ensure that the model in your possession correctly matches
the mains supply available. For connection purposes,
ensure that your plug is capable of supporting 8 amps at 230V,
Or16 amps at 100-120 V
Strict adherence to regulatory norms is strongly recommended.
10.1- Protection
The use of a thermal magnetic circuit breaker is recommended for each XR2000 BEAM.
A good earth connection is essential for the correct operation of the projector.
540°
270°
ARC 1200
11
2M
F
!
WARNING
Do not place any object in the path
of the projector’s movement
!
XR2000 BEAM
Electronic ballast
90-260V 50 / 60Hz

11- DMX SIGNAL CONNECTION
The unit operates using the digital DMX 512 (1990) signal. Connection between the mixer and the
projector or between projectors must be carried out using a two pair screened ø 0.5 mm cable and a XLR
5 or 3 pins connector. Ensure that the conductors do not touch each other. Do not connect the cable
ground to the XLR chassy
The plug housing must be isolated. Connect the mixer signal to the DMX IN projector plug and connect it
to the next projector by connecting the DMX OUT plug on the first projector to the DMX IN plug of the
second one.
This way, all the projectors are cascade connected.
NB. If the display showing the DMX address flashes, then one of the following errors has occurred:
- DMX signal not present
- DMX address not valid
- DMX reception problem
For Installations where long distance DMX cable connections are needed, we suggest to use a DMX
terminator.
The DMX terminator is a male XLR 3-5 pins connector with a 120 ohm resistor
Between pin 2 and 3.
The DMX terminator must be plugged into the last unit (DMX out panel connector) of the DMX line.
1
2
3
5
4
OUT
120 ohm
PIN 3
PIN 2
PLACE A 120 OHM RESISTOR BETWEEN PIN 2
AND 3 OF A MALE XRL CONNECTOR AND PLUG IT
INTO THE DMX OUT PANEL CONNECTOR OF THE
LAST UNIT CONNECTED TO THE DMX LINE
ARC 1200
12 XR2000 BEAM
5
3
4 2
11=GND
2=DATA-
3=DATA+
CONTROLLER
S TA N D A R D
D M X 5 1 2

11.1-DMX Addresses
XR2000 BEAM can be controlled with 21 (default) or 16 DMX channels.
If you want to use the unit in 21 channels, set the following addresses on the mixer:
Projector 1 A001
Projector 2 A022 If you want to select the next projector, just add “21”
11.2-Selecting the DMX address
1) Press the UP-DOWN key until you reach the required DMX channel. The numbers on the display will
start to flash (but the new DMX address hasn't yet been set).
2) Press ENTER to confirm your selection. The numbers on the display will stop flashing and the
projector is now setted to the new DMX address.
TRICKS:
if you keep pushed the UP or DOWN keys, the channels are calculated more quickly and you get a
faster selection.
XR2000 BEAM
Projector 3 A043
….. A….
projector 6 A106
12 FIRMWARE UPDATING
Warning:
This procedure require a base knolewge of computer applications and Windows
Hyperterminal program.
To update the software version of the you need:
D.T.S. RED BOX interface (D.T.S. Code: 03.LA.008).
USB-DMX Drivers for the D.T.S. RED BOX interface .
(The drivers and the installation procedure are available in our web site www.dts-lighting.it)
‘Updating the software version’
Please follow the procedure below to perform the update:
1. Install the D.T.S. RED BOX USB-DMX driver on the PC you will use to update the unit software.
2. Connect the D.T.S. RED BOX interface to the PC by using a USB cable.
3. Connect the D.T.S. RED BOX interface to the fixture by using a DMX cable.
4. Download the new software version into the unit by using Windows Hyperterminal program.
It will be possible to download the software from the reserved area of D.T.S. web site:
www.dts-lighting.it.
Please refer to an authorised DTS service centre.
ARC 1200
13
!
XR2000 BEAM

ARC 1200
14 XR2000 BEAM
MAINS
Electronic ballast
90-260V 50 / 60Hz
DMX IN
DMX OUT
DISPLAY
MENU
ENTER DOWN
UP
13- DISPLAY FUNCTIONS
DISPLAY FUNCTIONS
The XR2000 BEAM display panel shows all the available functions . Using these functions, it is
possible to change some of the parameters and add some functions. Changing the DTS setting
can vary the functions of the unit so that it does not respond to the DMX 512 used to control it.
Carefully follow the instructions below before carrying out any variations or selections.
NOTE: the symbol shows which key has to be pushed to obtain the desired function.
DMX IN
DMX OUT
FUSE 16A T 5X20
PAN DIRECTION
NORMAL
MENU ENTER DOWN UP
Pan Direction
Up-Down Up-DownENTER
PAN DIRECTION
This menu allows to set the Pan
movement.
Normal or Reversed
Pan movement Normal or Reversed
Default = Normal ENTER
Menu
TILT DIRECTION
NORMAL
MENU ENTER DOWN UP
Tilt Direction
Up-Down Up-DownENTER
TILT DIRECTION
This menu allows to set the Pan
movement.
Normal or Reversed
Tilt movement Normal or Reversed
Default = Normal ENTER
Menu
PAN TILT SPEED
4
MENU ENTER DOWN UP
Pan Tilt Speed
Up-Down Up-DownENTER
PAN TILT SPEED
Pan Tilt Speed control (1-4)
Pan Tilt Speed control
Default = 4 ENTER
Menu

ARC 1200
15 XR2000 BEAM
13- DISPLAY FUNCTIONS
MENU ENTER DOWN UP
Display
Up-Down Up-DownENTER Display Flip
ON THE GROUND (Default)
SUSPENDED
ENTER
Menu
DISPLAY FLIP / STAND BY / CONTRAST
Display Flip:
Reverses display's reading depending on the
mounting position
(On the ground or suspended).
Display Standby:
To turn off the display (after 5 seconds)
Or leave it always on.
Display Contrast:
Display contrast regulation (1-16)
FLIP
FLIP
ON THE GROUND
DISPLAY
MENU ENTER DOWN UP
FLIP
STANDBY
OFF
DISPLAY
MENU ENTER DOWN UP
FLIP
CONTRAST
8
DISPLAY
Display Standby
OFF = Display Standby disabled
(Default)
ON = Display goes OFF after 5
seconds
ENTER
Display Contrast
1-16 (Default = 8)
DMX MODE
21 channels
MENU ENTER DOWN UP
DMX Mode
Up-Down Up-DownENTER DMX mode
21 channels (Default)
16 channels
ENTER
Menu
DMX MODE
To select DMX mode :
21 channels or 16 channels
ENTER
ENTER
ENTER
BY DMX = ON / OFF via DMX (default)
ALWAYS ON = Forced ON
ALWAYS OFF = Forced OFF
RESET COUNTER = Lamp life time
reset
LAMP ADJUST =
To adjust the lamp
with no mixer connected.
It’s possible to set the parameters for
PAN-TILT and ZOOM
FLIP
LAMP
FLIP
LAMP
ADJUST
UP
UP
DOWN
DOWN
ENTER
ENTER
MENU
MENU
Up-DownENTER
LAMP
Lamp always ON, always OFF,
lamp ON-OFF selectable via DMX
And lamp life time reset
ADJUST
To adjust the lamp with no mixer
connected.
It’s possible to set the parameters for
PAN-TILT and ZOOM
Lamp
Up-Down
Menu
BY DMX

ARC 1200
XR2000 BEAM
13- DISPLAY FUNCTIONS
RESET
ENABLED
MENU ENTER DOWN UP
Reset
Up-Down Up-DownENTER ENABLED = Reset via DMX enabled
(Default)
DISABLED = Reset via DMX disabled
NOW = Unit motors reset
ENTER
Menu
RESET
Reset via DMX ENABLED / DISABLED
and unit reset
BY DMX
CMY BLACKOUT
ON
MENU ENTER DOWN UP
CMY Blackout
Up-Down Up-DownENTER ON = Blackout enabled (Default)
OFF = Blackout disabled ENTER
Menu
CMY BLACKOUT
CMY filters blades inserted at 100% if the dimmer
remain closed for more than 5 seconds.
By activating this function, it will be possible to
reduce substantially any visible light reflection
coming out from the front lens when dimmer is
closed.
SYSTEM INFO
LAMP LIFE:0000H STRIKE:001
UNIT LIFE: 0010H
8M R.20
PT R.19
MODEL: XR2000 BEAM
MENU ENTER DOWN UP
System info
Up-Down Up-DownENTER SYSTEM INFO
Lamp life time, lamp strikes, unit life
time, 8 motors card software
version, Pan&Tilt card software
version and unit model
ENTER
Menu
SYSTEM INFO
Lamp life time, lamp strikes, unit life time, 8
motors card software version, Pan&Tilt card
software version and unit model
Reserved
Up-Down Up-DownENTER Pan Lock = Lock the Pan to the
desired value
Tilt Lock = Lock the Tilt to the
desired value
Pan Free = Remove power to Pan
motor
Tilt Free = Remove power to Tilt
motor
System Reboot = Unit Reboot
without needing of turning OFF the
unit
ENTER
Menu
RESERVED
Pan lock-Tilt lock
Pan free-Tilt free
System Reboot
(Code = 100)
RESERVED
000
MENU ENTER DOWN UP
ENTER CODE
PAN LOCK
NO
MENU ENTER DOWN UP
FAN SPEED
5
MENU ENTER DOWN UP
Fan Speed
Up-Down Up-DownENTER Fan speed control
1-5 (Default = 5) ENTER
Menu
FAN SPEED
Fan Speed control
GOBO ROTATION
OFF
MENU ENTER DOWN UP
Gobo Rotation
Up-Down Up-DownENTER ON
OFF = (Default) ENTER
Menu
GOBO ROTATION
Gobo rotation control the Rotating speed of gobo During gobo scrolling
16

Default
Up-Down Up-DownENTER Default
To restore main settings ENTER
Menu
DEFAULT
To restore main settings
DEFAULT
SURE?
MENU ENTER DOWN UP
RESTORE MAIN SETTINGS
DEFAULT
RESTORE MAIN SETTINGS
MENU ENTER DOWN UP
PRESS ENTER TO CONFORM
PRESS MENU TO CANCEL
14- ERROR MESSAGES
13- DISPLAY FUNCTIONS
MENU ENTER DOWN UP
ERROR
COLOUR WHEEL
MENU ENTER DOWN UP
ERROR
CYAN
MENU ENTER DOWN UP
ERROR
MAGENTA
MENU ENTER DOWN UP
ERROR
YELLOW
MENU ENTER DOWN UP
ERROR
PAN
MENU ENTER DOWN UP
ERROR
TILT
MENU ENTER DOWN UP
ERROR
INTERNAL BUS
MENU ENTER DOWN UP
ERROR
DMX ADDRESS
COLOUR WHEEL
POSITION ERROR
CYAN POSITION
ERROR
MAGENTA POSITION
ERROR
YELLOW POSITION
ERROR
PAN REPOSITIONING
ENCODER ERROR
TILT REPOSITIONING
ENCODER ERROR
COMMUNICATION
PROBLEM BETWEEN 8
MOTORS CARD AND
PAN&TILT CARD
DMX ADDRESS
ERROR
MOTORS TEST
Motors Test Motors Test
ALL ,PAN, TILT, DIMMER, SHUTTER,
COLOUR WHEEL, CYAN, MAGENTA,
YELLOW and FROST.
ENTER
Up-Down Up-DownENTER
Menu
TEST MODE
Full test and single function test. ALL
MENU ENTER DOWN UP
ARC 1200
XR2000 BEAM
17

15- HIDDEN MENU
For technical personnel only.
To operate this menu:
-Connect the projector to the DMX controller (DMX SIGNAL MUST BE CORRECTLY RECEIVED)
- Reset the XR2000 BEAM (reset from the MENU, not from the DMX controller!).
- While reset is running, press the MENU and ENTER keys at the same time.
PAN ALIGNMENT
To align Pan position
TILT ALIGNMENT
To align Tilt position
SHUTTER ALIGNMENT
To align Shutter blades
GOBO WHEEL INDEX ALIGNMENT
To align Gobo wheel Index
CYAN ZERO ALIGNMENT
Cyan zero position setting
FROST ALIGNMENT
To align Frost
ELECTRONIC
CALIBRATION OF THE
MOTORS
RESET EEPROM.
RESET ALL SETTINGS
TO 128 VALUE
EXIT FROM HIDDEN
MENU
CALIBRATION
PAN
MENU ENTER DOWN UP
MOTORS ALIGNMENT
134
DEFAULT CAL
MENU ENTER DOWN UP
SET ALL MOTORS AT 128
EXIT TO MAIN
MENU ENTER DOWN UP
Calibration mode
CALIBRATION
PAN
MENU ENTER DOWN UP
MOTORS ALIGNMENT
134
CALIBRATION
TILT
MENU ENTER DOWN UP
MOTORS ALIGNMENT
167
CALIBRATION
SHUTTER
MENU ENTER DOWN UP
MOTORS ALIGNMENT
145
CALIBRATION
GOBO INDEX
MENU ENTER DOWN UP
MOTORS ALIGNMENT
141
CALIBRATION
FROST
MENU ENTER DOWN UP
MOTORS ALIGNMENT
85
CALIBRATION
CYAN ZERO
MENU ENTER DOWN UP
MOTORS ALIGNMENT
162
FAN SPEED WHEN
DIMMER CLOSED
FANS SPEED
MENU ENTER DOWN UP
ONLY AT MIN LAMP POWER
3
LAMP POWER WHEN
DIMMER CLOSED
MIN LAMP POW.
MENU ENTER DOWN UP
1=65% 100=100%
10
GOBO WHEEL ALIGNMENT
To align Gobo wheel
CALIBRATION
GOBO
MENU ENTER DOWN UP
MOTORS ALIGNMENT
151
COLOUR WHEEL ALIGNMENT
To align Colour wheel
CALIBRATION
COLOUR WHEEL
MENU ENTER DOWN UP
MOTORS ALIGNMENT
151
ARC 1200
XR2000 BEAM
18

16- PAN & TILT SPEED (default: 4)
17- FAN SPEED ( default: 5)
You can set the PAN and TILT motors at high speed on your XR2000 BEAM.
Press menu until you see PAN TILT SPEED.
Press ENTER and select a speed with UP-DOWN (there are 4 speeds). Confirm by pressing ENTER.
Fan speed regulation makes it possible to reduce fan noise. However, the ambient temperature must be
less than 35° C.
ARC 1200
19 XR2000 BEAM
CYAN PATH ALIGNMENT
Cyan excursion setting
MAGENTA ZERO ALIGNMENT
Magenta zero position setting
YELLOW ZERO ALIGNMENT
Yellow zero position setting
Calibration mode
CALIBRATION
CYAN PATH
MENU ENTER DOWN UP
MOTORS ALIGNMENT
134
CALIBRATION
MAGENTA ZERO
MENU ENTER DOWN UP
MOTORS ALIGNMENT
167
CALIBRATION
YELLOW ZERO
MENU ENTER DOWN UP
MOTORS ALIGNMENT
141
MAGENTA PATH ALIGNMENT
Magenta excursion setting
CALIBRATION
MAGENTA PATH
MENU ENTER DOWN UP
MOTORS ALIGNMENT
151
YELLOW PATH ALIGNMENT
Yellow excursion setting
CALIBRATION
MENU ENTER DOWN UP
MOTORS ALIGNMENT
121
YELLOW PATH

18- OPENING THE PROJECTOR HOUSING
It is possible to inspect the inside of the projector by removing the cover as indicated below.
ATTENTION
REMOVE MAINS POWER PRIOR TO ACCESSING THE PROJECTOR’S INTERNAL COMPONENTS.
2) Loosen the 2 screws which fix the head covers (photo 2) .
3) Once unscrewed, simply lift the covers to access the internal components (photo 3).
19- REPLACING GOBOS
XR2000 BEAM uses a mechanical system which allows the fixture's gobos to be removed without the use
of special tools. Replacement gobos should be made of either heat resistant glass or metal.
An ever-increasing range of gobos is available from your DTS sales network.
Gobo dimensions are as follows:
ø external (ED) = 27.9 mm
ø of image with defined edge (ID) = 24 mm
thickness = from 0.2 to 4 mm (see catalogue)
1) Using a screwdriver, loose the 3 screws A, B, C, (photo 1) and remove the metal cover .
Photo 2 Photo 3
ARC 1200
Load with coated surface toward the light source.
Max thickness
Coated side
When an object is held up the coated side of the glass gobo there
is no space between the object and its reflection.
Uncoated side
When an object is held up the uncoated side of the glass gobo
there is a space between the object and its reflection.
Coated side
Uncoated side
ED
ID
4 mm
XR2000 BEAM
Photo 1
20
