DTS DONUT 6 User manual

DONUT 6
USER’S MANUAL rel. 1.0 GB

2
Le informazioni contenute in questo documento sono state attentamente redatte e
controllate. Tuttavia non è assunta alcuna responsabilità per eventuali inesattezze.
Tutti i diritti sono riservati e questo documento non può essere copiato, fotocopiato,
riprodotto per intero o in parte senza previo consenso scritto della D.T.S .
D.T.S. si riserva il diritto di apportare senza preavviso cambiamenti e modifiche
estetiche , funzionali o di design a ciascun proprio prodotto. D.T.S non assume alcuna
responsabilità sull’uso o sull’applicazione dei prodotti o dei circuiti descritti.
The information contained in this publication has been carefully prepared and
checked. However, no responsibility will be taken for any errors. All rights are
reserved and this document cannot be copied, photocopied or reproduced, in part or
completely, without prior written consent from D.T.S.
D.T.S. reserves the right to make any aesthetic, functional or design modifications to
any of its products without prior notice. D.T.S. assumes no responsibility for the use or
application of the products or circuits described herein.
Les informations contenues dans le présent manuel ont été rédigées et contrôlées
avec le plus grand soin. Nous déclinons toutefois toute responsabilité en cas
d'éventuelles inexactitudes. Tous droits réservés. Ce document ne peut être copié,
photocopié ou reproduit, dans sa totalité ou partiellement, sans le consentement
préalable de D.T.S.
D.T.S. se réserve le droit d'apporter toutes modifications et améliorations esthétiques,
fonctionnelles ou de design, sans préavis, à chacun de ses produits. D.T.S. décline
toute responsabilité sur l'utilisation ou sur l'application des produits ou des circuits
décrits.
Las informaciones contenidas en este documento han sido cuidadosamente
redactadas y controladas. Con todo, no se asume ninguna responsabilidad por
eventuales inexactitudes. Todos los derechos han sido reservados y este documento
no puede ser copiado, fotocopiado o reproducido, total o parcialmente, sin previa
autorización escrita de D.T.S.
D.T.S. se reserva el derecho a aportar sin previo aviso cambios y modificaciones de
carácter estético, funcional o de diseño a cada producto suyo. D.T.S. no se asume
responsabilidad de ningún tipo sobre la utilización o sobre la aplicación de los
productos o de los circuitos descritos.

3
INDEX:
1- SYMBOLS.................................................................................................................4
2- GENERAL WARNING ..............................................................................................4
3- GENERAL WARRANTY CONDITIONS....................................................................4
4- TECHNICAL FEATURES .........................................................................................5
5- ACCESSORIES ........................................................................................................6
6- IMPORTANT SAFETY INFORMATION....................................................................7
6.1 Fire prevention......................................................................................................7
6.2 Prevention of electric shock..................................................................................7
6.3 Safety...................................................................................................................7
6.4 Maintenance.........................................................................................................8
6.5 Waste Electrical and Electronic Equipment directive............................................8
7- CONNECTIONS........................................................................................................9
8- CONNECTIONS DIAGRAM....................................................................................10

4
1- SYMBOLS
Graphic symbols used on this manual:
THIS SYMBOL INDICATES A HOT SURFACE
THIS SYMBOL INDICATES ELECTRIC
SHOCK RISK
THIS SYMBOL INDICATES GENERAL RISK
THIS SYMBOL INDICATES THE MAXIMUM
OPERATING AMBIENT TEMPERATURE
THIS SYMBOL INDICATES THE MINIMUM
DISTANCE FROM THE ILLUMINATED OBJECTS
THIS SYMBOL MEANS “DO NOT STARE
AT THE OPERATING LIGHT SOURCE”
THIS SYMBOL INDICATES
PHOTOBIOLOGICAL SAFETY
THIS SYMBOL INDICATES THE EUROPEAN
COMMUNITY DIRECTIVE 2012/19/EU ON
WASTE ELECTRICAL AND ELECTRONIC
EQUIPMENT (WEEE)
2- GENERAL WARNING
Read the instruction contained in this user manual carefully, as they give important
information regarding safety during installation, use and maintenance.
The unit is not for household use and must be installed by a qualified electrician or
experienced person.
3- GENERAL WARRANTY CONDITIONS
The unit is guaranteed for 36 months from the date of purchase against manufacturing
material defects.
The warranty covers defects in materials and workmanship. The warranty is not
appliable where a defect is caused by misuse or unauthorised repair of the product.
Any functional or/and physical modification of the product is not allowed.
!

5
4- TECHNICAL FEATURES
Product codes:
03.DN004.F08 DONUT 6 FC Ultra-Narrow lenses
03.DN004.F10 DONUT 6 FC Narrow lenses
03.DN004.F25 DONUT 6 FC Medium lenses
03.DN004.F40 DONUT 6 FC Wide lenses
Output
6 Full Color (RGBW) LEDs
Lumens: 2400 @ 700mA
LED lifespan: 50.000 hours (70% lumen output)
Optical group
4 lenses sets available: Ultra-Narrow, Narrow, Medium, Wide
Color generation
16 million colors
Wide palette of pure uniform whites with variable linear color temperature (2700K -
8000K)
Power supply
External PSU @ 48Vdc:
DRIVENET 28C DIN
DRIVENET 28 EZ / 416 / 832 (full range 100-240Vac 50-60 Hz)
DRIVENET 1664 (range 180-240Vac 50-60 Hz)
External PSU @ 24Vdc:
DRIVENET 28C DIN
DRIVENET 832 24Vdc (full range 100-240Vac 50-60 Hz)
DRIVENET 1664 24Vdc (full range 100-240Vac 50-60 Hz)
Power consumption: 60W max
Connections
End-stripped 8-pole cable (5 m length)
Operating temperature
-20° / 40°C
Physical
IP68
IK protection degree: IK09
Housing: Bronze / Stainless steel
Weight: 5.7 Kg
Certifications

6
DIMENSIONS
5- ACCESSORIES
Optional (on request)
●8-pole underwater cable (code 0509C123)
●HUB-IP20 Screw terminals 1 IN / 3 OUT (code 03.LA.131)
● HUB-IP56 Screw terminals 1 IN / 3 OUT (code 03.LA.131.IP56)

7
6- IMPORTANT SAFETY INFORMATION
6.1 Fire prevention:
Minimum distance from the closest illuminable surface: 0,5 m.
6.2 Prevention of electric shock:
Class II LED product according to standard IEC 60598-1.
6.3 Safety:
Risk group 2 product according to IEC 62471.
CAUTION. Do not look directly into the light output. May be harmful to the eyes and
skin.
Do not stare at the operating light source.
The unit is not for household use and must be installed by a qualified electrician or
experienced person.
LEDs are not replaceable.
The external surface of the unit may exeed 50°C; never handle the unit until at least
5 minutes have elapsed since the unit was turned off.
Never install the unit in an enclosed area lacking sufficient air flow.
The ambient temperature should not exeed 40°C.
Refer to local norms in case of underwater installation. Max immersion depth: 2 m.
6.4 Maintenance:
DONUT is made on Bronze and 316 Stainless Steel.
Bronze:
Bronze is a durable material with strong anti-corrosion properties.
Bronze can be easily scratched or marred with improper care and it oxidizes if not
periodically maintained. Routine cleaning and polishing are required in order to
maintain the brilliance of the surface.
Always wear clean gloves when handling the unit, direct contact with bare hands may
cause a fast oxidation of the handled surface.
Do not expose the unit to air contaminants as heavy exhaust or solvent fumes.
Do not use cleaning or polishing products containing harsh chemicals (ammonia or
chlorine) or abrasive chemicals.
Do not use any cleaning towels that are abrasive. Use only microfiber towels. If unsure
about the suitability of a product for cleaning bronze, contact DTS.
Maintenance period can vary depending on water quality and environment conditions.
!
!

8
6.4 Maintenance:
316 Stainless Steel:
316 Stainless Steel is a durable material with strong anti-corrosion properties. With
proper care and maintenance, it will maintain an optimal appearance over a long
service life.
Exposure to high-saline environments, chlorides, abrasive chemicals, or carbon steel
will diminish its anti-corrosion properties and increase the risk of damage.
Always wear clean gloves when handling the unit.
Do not weld, cut, drill or grind carbon steel near the unit before installation. Resulting
particles will contaminate and rust stainless steel.
Do not clean stainless steel in direct sunlight or excessive temperatures.
Do not use cleaning products containing chlorides (i.e. hydrochloric acid) or other
abrasive chemicals. Do not use high-pressure cleaners.
If unsure about the suitability of a product for cleaning stainless steel, contact DTS.
Routine cleaning with soap and water is usually sufficient to maintain the corrosion
resistance and appearance of 316 Stainless Steel. Use a soft nylon brush to remove
any accumulated dirt.
Wash with mild soap or detergent, then rinse in clean water and wipe dry with a soft
cloth.
If signs of corrosion appear, clean immediately. To avoid progression of damage,
identify and address problems as early as possible.
Heavy damage includes structural compromises such as visible dents, cracks, breaks
and rust that can undermine the integrity of a product. Heavily damaged products
should be removed from service until a repair or replacement can be made. To prevent
worsening of damage, any significant rust should be removed as soon as possible.
If any parts are broken or missing, contact DTS to determine the availability of
replacements. Replace any screw only by 316 stainless steel screws. To replace cable
or gaskets, contact DTS. Maintenance period can vary depending on water quality and
environment conditions.
6.5 Waste Electrical and Electronic Equipment (WEEE) directive:
The machine, accessories and packaging should be sorted for environmental-friendly
recycling.
For EC countries: according to the European Directive 2012/19/EU for Waste
Electrical and Electronic Equipment and its implemetation into national right,
luminaires that are no longer usable must be collected separately and disposed of in
an environmentally correct manner.
!

9
7- CONNECTIONS
DONUT 6 FC is provided with end-stripped 8-pole cable (5 m length).
The maximum distance between DRIVENET PSU and DONUT 6 FC unit should
not exceed 100 meters.

10
8- CONNECTION DIAGRAMS
The maximum number of DONUT 6 FC connectable to each output of the DRIVENET
28 EZ / 416 / 832 / 1664 is 2 pcs serial wired.
The maximum distance between DRIVENET PSU and last DONUT 6 FC unit of the
line should not exceed 100 meters.

11
8- CONNECTION DIAGRAMS
The maximum number of DONUT 6 FC connectable to each output of the DRIVENET
832 or 1664 24Vdc is 1 piece.
The maximum distance between DRIVENET PSU and DONUT 6 FC unit should not
exceed 100 meters.

12
