Kingston pergola
Assembly & installation Instructions
General Information:
»Read through carefully before beginning assembly.
»When assembling components, place on a clean, flat,
non-abrasive surface to avoid scratches.
»In the event of missing or defective parts, please call our
customer service department directly at 1-877-258-6020
Tools required:
»Cordless Drill with #2 phillips bit
»Hammer
»Tape Measure
»Shovel
»Post Hole Digger (recommended)
»Ladder/Step stool (recommended)
Part # Description (Box Number) Qty
14” sq. x 93” Post (1) 4
21½” x 5½“ x 106” Lower Support (2) 2
31½” x 5½“ x 106” Upper Support (2) 5
4⅞” x 1½” x 106” Top Rail (2) 7
51½” Upper Support Bracket (3) 6
64” sq. New England Post Cap (3) 4
76⅛” Support Rail End Cap (3) 14
830” U-channel Ground Anchor (1) 4
9Hardware Kit (includes): (3)
PVC Glue Can 1
⅞” x 1½” Top Rail Cap 14
2” Kappet Screw 48
1¼” Kappet Screw 35
¾” Kappet Screw 24
Kappet Screw Caps 107
1” Self-tapping White-head Screws 8
Parts List:
FIGURE 1
Product dimensions &
Part identification

Lay out one lower support (part 2).
[Lower support has six pilot
holes drilled in top edge]
Using ¾” kappet screws, fasten
three upper support brackets (part
5) to lower support. Snap kappet
screw caps over screw heads.
Insert ends of lower support
through bottom routed holes of
two posts (part 1).
Do not screw together at this
time.
REPEAT steps 1 and 2 using
remaining lower support, upper
support brackets and posts.
Insert ends of two upper supports
(part 3) through top routed holes
of posts.
[Upper support have seven equally
spaced pilot holes drilled in top edge]
Do not screw together at this
time.
1
2
3

Lay two top rails (part 4) onto
upper supports. To set width of
pergola, line up outer most holes
of top rails with outer most pilot
holes of upper supports. Using
1¼” kappet screws, fasten top
rails to upper supports. Snap
kappet screw caps over screw
heads.
Using 2” kappet screws, screw
together all posts and supports.
Snap kappet screw caps over
screw heads.
Slide three remaining upper sup-
ports through upper support
brackets, underneath top rails.
4
5
6

Using 1¼” kappet screws, fasten
top rails to upper supports. Snap
kappet screw caps over screw
heads.
[This will center remaining upper supports]
Using ¾” kappet screws,
fasten upper support
brackets to upper supports.
Snap kappet screw caps
over screw heads.
Using 1¼” kappet screws, fasten
remaining top rails (part 4) to
upper supports. Snap kappet
screw caps over screw heads.
Using included PVC glue, glue
post caps (part 6) to top of posts.
Glue support end caps (part 7) to
ends of upper and lower sup-
ports. Glue top rail caps to ends
of top rails.
7
8
9

PERGOLA INSTALLATION
Option 1
Slide one 30” steel u-channel ground anchor
(part 8) into bottom of each post. Slide
ground anchor about 12 inches into post,
leaving 18 inches for in-ground. Using 1”
self-tapping white-head screw fasten post
to ground anchor.
Using product dimension drawings
(figure 1), dig holes approximately 18 inches
deep. Set pergola in holes and level. Back
fill with soil removed from holes. For
permanent installation fill with cement.
Option 2
Using product dimension drawings
(figure 1), pound ground anchors into
ground according to dimensions. When
pounding into ground, use block of wood to
prevent ground anchor from bending.
Slide pergola over ground anchors. Using
1” self-tapping white-head screw fasten
post to ground anchor.
Option 3
Using product dimension layout drawings
(figure 1), dig holes 18” deep according to
dimensions. Fill with cement and place
ground anchors in wet cement. Be sure that
ground anchors are straight and in
accordance with dimension in figure 1.
Allow cement to dry. NOTE: There is very
little room for error with this installation
method.
Slide pergola over ground anchors. Using
1” self-tapping white-head screw fasten
post to ground anchor.
