Dynojet POWER COMMANDER III User manual

i209-411i209-411 www.powercommander.com 2003-2007 Kawasaki VN1600 - PCIII USB - 1
2003-2007 Kawasaki VN1600
Installation Instructions
Dynojet Research 2191 Mendenhall Drive North Las Vegas, NV 89081 [phone] www.powercommander.com
Parts List
1Power Commander
1USB Cable
1CD-ROM
1Installation Guide
1Power Adapter
2Power Commander Decals
2 Dynojet Decals
2 Velcro®Strip
1Alcohol Swab
You can also download the Power
Commander software and latest maps
from our web site at:
www.powercommander.com
The ignition MUST be turned
OFF before installation!
PLEASE READ ALL DIRECTIONS BEFORE STARTING INSTALLATION
Button Adjustment Display
Faceplate Buttons
USB Port
Expansion Port

1 Remove the main seat and the
passenger seat.
2Remove the fuel tank
Note: The installation can be done
without removing the fuel tank
but it may be easier to have it
removed
3 To remove the fuel line squeeze
the sides of the connector
(Fig. A). Disconnect the two
electrical connectors.
4Loosen the four bolts holding on
the left hand side cover (Fig. B).
5Route the PCIII harness between
the tray and the frame (Fig. C).
Fig. AFig. B
Fig. C
i209-411 www.powercommander.comi209-411 www.powercommander.com 2003-2007 Kawasaki VN1600 - PCIII USB - 2
Disconnect these lines
Squeeze this line to remove
Loosen these bolts
PCIII harness

6Continue routing the PCIII har-
ness towards the front of the
bike. Route underneath the
frame and towards the left hand
side of the rear cylinder
(Fig. D).
7Continue routing the PCIII har-
ness along the frame towards the
front of the bike. Locate the
stock connector for the throttle
bodies (Fig. E).
8Unplug this connector.
9Plug the connectors from the
PCIII in-line of the stock con-
nector (Fig. F).
Fig. DFig. E
Fig F
i209-411 www.powercommander.comi209-411 www.powercommander.com 2003-2007 Kawasaki VN1600 - PCIII USB - 3
Unplug this connector
PCIII harness
Stock connectors
PCIII connectors

10 Attach the ground wire from the
PCIII to the negative side of the
battery.
11 Install the PCIII under the left
hand side cover. You can use
the supplied velcro to attach it in
place.
Note: If you have a California model it
is best to velcro the unit to the
front portion of the side cover.
Fig. GFig. H
i209-411 www.powercommander.comi209-411 www.powercommander.com 2003-2007 Kawasaki VN1600 - PCIII USB - 4
PCIII ground wire
Fig. J
