Eaton 9170+Battery Charger Module
Models ASY-0652 and ASY-0675
User's Guide
®

Special Symbols
The following are examples of symbols used on the UPS or accessories to alert you to important
information:
RISK OF ELECTRIC SHOCK - Observe the warning associated with the risk of
electric shock symbol.
CAUTION: REFER TO OPERATOR'S MANUAL - Refer to your operator's manual for
additional information, such as important operating and maintenance
instructions.
This symbol indicates that you should not discard the UPS or the UPS batteries
in the trash. This product contains sealed, lead‐acid batteries and must be
disposed of properly. For more information, contact your local recycling/reuse or
hazardous waste center.
This symbol indicates that you should not discard waste electrical or electronic
equipment (WEEE) in the trash. For proper disposal, contact your local
recycling/reuse or hazardous waste center.
Eaton and Powerware are registered trademarks of Eaton Corporation or its subsidiaries and affiliates. All other
trademarks are property of their respective companies.
ECopyright 2002–2010 Eaton Corporation, Raleigh, NC, USA. All rights reserved. No part of this document may be
reproduced in any way without the express written approval of Eaton Corporation.

Eaton 9170+Battery Charger Module User's Guide S164201399 Rev E
www.eaton.com/powerquality
i
Table of Contents
1 Introduction 1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Physical Features 2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2 Installation 5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cabinet Preparation 5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
DC Cabling Between Cabinets 6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Setting DIP Switches 6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Output Current Limit 6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Periodic Float Charge 7. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Reserved Switch 7. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Battery Charger Module Installation 8. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3 Operation 9. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
UPS Cabinet Operation 9. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
External Battery Cabinet Operation 9. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Output Foldback 9. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4 Specifications 11. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
5 Troubleshooting 21. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Alarm Messages 21. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Audible Alarms and UPS Conditions 21. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Battery Charger Module Replacement 22. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Service and Support 23. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

TABLE OF CONTENTS
Eaton 9170+Battery Charger Module User's Guide S164201399 Rev E
www.eaton.com/powerquality
ii

Eaton 9170+Battery Charger Module User's Guide S164201399 Rev E
www.eaton.com/powerquality
1
Chapter 1 Introduction
The optional Battery Charger Module is designed to provide additional
current for faster recharging of uninterruptible power system (UPS)
battery modules in systems with many batteries.
NOTE To realize maximum module functionality, install Battery Charger Modules in the
UPS cabinet.
For systems with especially long runtime requirements, DIP switches on
the rear panel of the Battery Charger Module make it possible to install
the module in a specially designed external battery cabinet (ASY-0739).
The Battery Charger Module is capable of providing up to 20 amperes of
current for optimum charging, based upon the condition and number of
batteries in the system.
Examples of improved system recharge times are shown in Table 1.
Note that larger systems require at least one (or more) Battery Charger
Modules to be able to recharge the larger number of battery modules.
Table 1. Recharge Times Using Battery Charger Modules
Designed
Runtime
(Minutes)
Number of
Battery
Charger
Modules
6 kVA Capacity 12 kVA Capacity 18 kVA Capacity
Battery
Modules
Recharge
Time (Hours)
Battery
Modules
Recharge
Time (Hours)
Battery
Modules
Recharge
Time (Hours)
58
0
16
20
32
20
48
20
1 3 4 6
120 1 28 5 56 8 82 11
240
1
54
9
110
17
160
N/A
2 6 9 13
360
1
78
14
160
N/A
234
N/A
2 7 14 19
480
1
102
18
200
N/A
308
N/A
2 10 18 26
3 7 13 18

INTRODUCTION
Eaton 9170+Battery Charger Module User's Guide S164201399 Rev E
www.eaton.com/powerquality
2
Physical Features
The Battery Charger Module is similar in appearance to a power module.
The two primary differences are the front label color (light-purple for the
ASY-0652 and orange for the ASY-0675) and the current-limit DIP switch
on the rear panel of the module as shown in Figure 1. See “Setting DIP
Switches” on page 6 for more information on DIP switch functions.
The module may be installed in either the UPS cabinet (6-, 9-, and 12-slot
sizes) or a special 12-slot external battery cabinet.
On
Off
On
DIP Switch Detail
*Factory default setting
1234
Current
Limit 12
5A Off Off*
10A Off
Off15A On
On20A On
Figure 1. Battery Charger Module (Rear View)
The external battery cabinet may have input power hardwired through
rigid or flexible conduit, as shown in Figure 2, or input power may be
supplied through a plug-terminated line cord (requires the purchase of a
line cord kit). Besides input power, the external battery cabinet has a
cable or conduit connection to the UPS cabinet. It may also have a cable
or conduit to additional external battery cabinets.

INTRODUCTION
Eaton 9170+Battery Charger Module User's Guide S164201399 Rev E
www.eaton.com/powerquality
3
To UPS or Previous External
Battery Cabinet
AC Line In
To Next External Battery Cabinet
DC Disconnect Switch
Button
Figure 2. External Battery Cabinet for Charger Modules

INTRODUCTION
Eaton 9170+Battery Charger Module User's Guide S164201399 Rev E
www.eaton.com/powerquality
4

Eaton 9170+Battery Charger Module User's Guide S164201399 Rev E
www.eaton.com/powerquality
5
Chapter 2 Installation
The Battery Charger Module can be plugged into any UPS cabinet slot
above the battery modules. Battery Charger Modules may be installed in
any of the top three slots of the ASY-0739 12-slot external battery
cabinet.
NOTE Do not block the cabinet's ventilation holes on the sides or the back.
Cabinet Preparation
Follow the procedures in the UPS user's guide for:
SEquipment clearances
SInstalling the UPS cabinet and optional external battery cabinets
If additional external battery cabinets are to be used for Battery Charger
Modules, install input power wiring to each additional cabinet (see
Figure 3). Table 2 shows required wire sizes based upon the number of
Battery Charger Modules.
For each 12-slot external battery cabinet, stabilizer brackets must be
installed. If required, also install a floor anchor kit as described in the
UPS user's guide.
NOTE The ASY-0739 12-slot external battery cabinet must be wired for input power from the
utility AC power supply.
(b) Universal Power Modules
(2-wire plus ground input)
200, 208, 220, 230, and 240 Vac
(a) Split-Phase Power Modules
(3-wire plus ground input) (2 PEN)
100/200, 110/220, 120/208, 120/240, 127/220 Vac
321321
L2
L1
N
GND
L1
L2/N
GND
Figure 3. Input Power Wiring to ASY-0739 External Battery Cabinet

INSTALLATION
Eaton 9170+Battery Charger Module User's Guide S164201399 Rev E
www.eaton.com/powerquality
6
Table 2. Required Input Wiring for ASY-0739 External Battery Cabinet
Number of Charger Modules Input Circuit Breaker Rating 75°C Copper Wire Size Conductor Screw Torque
1 15A 14/12 AWG 2.3 Nm (20 lb in)
2 30A 10 AWG 2.3 Nm (20 lb in)
3 45A 8 AWG 2.8 Nm (25 lb in)
DC Cabling Between Cabinets
Refer to “Battery Cabinet Installation” in the UPS user's guide for the
procedure to connect the cable assembly between the external battery
cabinet and the UPS cabinet, or to additional external battery cabinets.
NOTE See Figure 2 on page 3 for the proper location of cabinet-to-cabinet wiring, which
must be in the second cabinet section.
Setting DIP Switches
The DIP switches on the rear panel of the Battery Charger Module are
functional only when the module is installed in an external battery
cabinet. The DIP switches control two functions: the output current
limit and a periodic float charging to equalize all battery capacities.
NOTE Set the DIP switches ONLY if the Battery Charger Module is placed in the ASY-0739
12-slot external battery cabinet. When the module is placed in the UPS cabinet, do not set
the DIP switches.
Output Current Limit
The Battery Charger Module is capable of producing up to 5A, 10A, 15A,
or 20A when installed in an external battery cabinet. Discharged
batteries must be recharged at an optimum rate, neither too quickly nor
too slowly. For optimum charging of batteries, you must set DIP
switches 1 and 2.
Follow the guidelines in Table 3 to determine the proper output current
setting and set DIP switches 1 and 2 accordingly (see Figure 4).

INSTALLATION
Eaton 9170+Battery Charger Module User's Guide S164201399 Rev E
www.eaton.com/powerquality
7
Table 3. Output Current Limit Settings
Output Current Limit Minimum Requirement DIP Switch 1 DIP Switch 2
5A 2 battery strings (7.2 Ah) Off Off*
10A 4 battery strings (14.4 Ah) On Off
15A 6 battery strings (21.6 Ah) Off On
20A 8 battery strings (28.8 Ah) On On
NOTE A battery string is made up of two battery modules.
* Factory-default setting
Off
On
1234
Figure 4. DIP Switches
Periodic Float Charge
To enable automatic float (or equalize) charging of the battery modules
every 30 days, set DIP switch 3 to ON.
NOTE Enable only one Battery Charger Module in external battery cabinets.
Reserved Switch
The function of DIP switch 4 is reserved; it should remain in the OFF
position.

INSTALLATION
Eaton 9170+Battery Charger Module User's Guide S164201399 Rev E
www.eaton.com/powerquality
8
Battery Charger Module Installation
To install the Battery Charger Modules into the UPS or external battery
cabinet:
CAUTION
A maximum, total combination of seven (7) power modules and Battery Charger Modules are
allowed in a 12-slot cabinet.
1. Remove the front cover(s) of the cabinet.
The covers have spring latches on the left and right sides that hold
them in place.
NOTE Place Battery Charger Modules above the battery modules in the UPS cabinet, or in
any of the top three slots of the ASY-0739 12-slot external battery cabinet.
2. Insert the Battery Charger Modules into the cabinet. To insert a
Battery Charger Module:
Lower the front slightly and lift the rear edge over the safety stop
on the center support rail. Keep the module handle extended until
the module is fully inserted.
Raise the Battery Charger Module handle to secure the module into
the cabinet. Be sure the handle latch snaps into place. Tighten the
thumbscrew on the handle.
3. Reinstall the front cover(s).
4. Turn on the UPS according to the UPS user's guide.

Eaton 9170+Battery Charger Module User's Guide S164201399 Rev E
www.eaton.com/powerquality
9
Chapter 3 Operation
The Battery Charger Module operates in two automatic modes:
SAs a charger module within the UPS cabinet under control of the UPS
power modules
SAs an independent charger module located in an external battery
cabinet containing battery modules for the UPS system
UPS Cabinet Operation
When the Battery Charger Module is installed in the UPS cabinet, it
communicates through a controller area network (CAN) bus with the
power modules. The power modules monitor and control the battery
charger. Alarm conditions detected by the Battery Charger Module are
logged and announced by the UPS system (refer to the UPS user's
guide). Normal output voltage is 133 Vdc.
External Battery Cabinet Operation
When the Battery Charger Module is installed in an external battery
cabinet, it has no communication path with the UPS power modules.
Therefore, it controls its own operation, independent of any system
information within the power modules.
The module output current limit is set by the rear panel DIP switches.
An audible alarm signals module status and alarm conditions (see
“Troubleshooting” on page 21). Normal output voltage is 133 Vdc.
Output Foldback
If the Battery Charger Module senses a charged-battery condition, it
folds back its output voltage to prevent overcharging system batteries.
Output current is controlled by power modules on the UPS CAN bus or
by the rear panel DIP switches.

OPERATION
Eaton 9170+Battery Charger Module User's Guide S164201399 Rev E
www.eaton.com/powerquality
10

Eaton 9170+Battery Charger Module User's Guide S164201399 Rev E
www.eaton.com/powerquality
11
Chapter 4 Specifications
Table 4. Model Specifications for Universal Power Modules (ASY-0528 and ASY-0674)
Three-Slot Cabinet
Optional
Chargers
UPS
kVA/Watts
Input Current for
200/208/220/230/240V
Output Current for
200/208/220/230/240V
Recommended
Input Service
Heat
Dissipation
NA 3/2100 14/13.5/13/12.5/12A 15/14.5/14/13/12.5A 25A 285W
(0.98 kBTU/hr)
Six-Slot Cabinet
CAUTION Do NOT install more than three power and/or battery charger modules in a 6-slot cabinet.
Optional
Chargers
UPS
kVA/Watts
Input Current for
200/208/220/230/240V
Output Current for
200/208/220/230/240V
Recommended
Input Service
Heat
Dissipation
0 3/2100 14/13.5/13/12.5/12A 15/14.5/14/13/12.5A 25A 285W
(0.98 kBTU/hr)
1 3/2100 30/29.5/29/28.5/28A 15/14.5/14/13/12.5A 40A 570W
(1.95 kBTU/hr)
2 3/2100 46/45.5/45/44.5/44A 15/14.5/14/13/12.5A 60A 860W
(2.93 kBTU/hr)
0 6/4200 28/27/26/25/24A 30/29/28/26/25A 40A 570W
(1.95 kBTU/hr)
1 6/4200 44/43/42/41/40A 30/29/28/26/25A 60A 860W
(2.93 kBTU/hr)
0 9/6300 42/40.5/39/37.5/36A 45/43.5/42/39/37.5A 60A 860W
(2.93 kBTU/hr)
Nine- and Twelve-Slot Cabinet
CAUTION Do NOT install more than seven power and/or battery charger modules in a 9- or 12-slot cabinet.
Optional
Chargers
UPS
kVA/Watts
Input Current for
200/208/220/230/240V
Output Current for
200/208/220/230/240V
Recommended
Input Service
Heat
Dissipation
0 3/2100 14/13.5/13/12.5/12A 15/14.5/14/13/12.5A 25A 285W
(0.98 kBTU/hr)
1 3/2100 30/29.5/29/28.5/28A 15/14.5/14/13/12.5A 40A 570W
(1.95 kBTU/hr)
* Maximum current rating for the cabinet size. If an additional charger is desired, it must be installed in external battery
cabinet ASY-0739.

SPECIFICATIONS
Eaton 9170+Battery Charger Module User's Guide S164201399 Rev E
www.eaton.com/powerquality
12
Table 4. Model Specifications for Universal Power Modules (ASY-0528 and ASY-0674) (continued)
Nine- and Twelve-Slot Cabinet
CAUTION Do NOT install more than seven power and/or battery charger modules in a 9- or 12-slot cabinet.
Heat
Dissipation
Recommended
Input Service
Output Current for
200/208/220/230/240V
Input Current for
200/208/220/230/240V
UPS
kVA/Watts
Optional
Chargers
2 3/2100 46/45.5/45/44.5/44A 15/14.5/14/13/12.5A 60A 860W
(2.93 kBTU/hr)
3 3/2100 62/61.5/61/60.5/60A 15/14.5/14/13/12.5A 80A 1145W
(3.90 kBTU/hr)
4 3/2100 78/77.5/77/76.5/76A 15/14.5/14/13/12.5A 100A 1430W
(4.88 kBTU/hr)
5 3/2100 94/93.5/93/92.5/92A 15/14.5/14/13/12.5A 125A 1720W
(5.85 kBTU/hr)
0 6/4200 28/27/26/25/24A 30/29/28/26/25A 40A 570W
(1.95 kBTU/hr)
1 6/4200 44/43/42/41/40A 30/29/28/26/25A 60A 860W
(2.93 kBTU/hr)
2 6/4200 60/59/58/57/56A 30/29/28/26/25A 80A 1145W
(3.90 kBTU/hr)
3 6/4200 76/75/74/73/72A 30/29/28/26/25A 100A 1430W
(4.88 kBTU/hr)
4 6/4200 92/91/90/89/88A 30/29/28/26/25A 125A 1720W
(5.85 kBTU/hr)
5 6/4200 102A* 30/29/28/26/25A 125A 1995W
(6.75 kBTU/hr)
0 9/6300 42/40.5/39/37.5/36A 45/43.5/42/39/37.5A 60A 860W
(2.93 kBTU/hr)
1 9/6300 58/56.5/55/53.5/52A 45/43.5/42/39/37.5A 80A 1145W
(3.90 kBTU/hr)
2 9/6300 74/72.5/71/69.5/68A 45/43.5/42/39/37.5A 100A 1430W
(4.88 kBTU/hr)
3 9/6300 90/88.5/87/85.5/84A 45/43.5/42/39/37.5A 125A 1720W
(5.85 kBTU/hr)
4 9/6300 102A* 45/43.5/42/39/37.5A 125A 1995W
(6.75 kBTU/hr)
* Maximum current rating for the cabinet size. If an additional charger is desired, it must be installed in external battery
cabinet ASY-0739.

SPECIFICATIONS
Eaton 9170+Battery Charger Module User's Guide S164201399 Rev E
www.eaton.com/powerquality
13
Table 4. Model Specifications for Universal Power Modules (ASY-0528 and ASY-0674) (continued)
Nine- and Twelve-Slot Cabinet
CAUTION Do NOT install more than seven power and/or battery charger modules in a 9- or 12-slot cabinet.
Heat
Dissipation
Recommended
Input Service
Output Current for
200/208/220/230/240V
Input Current for
200/208/220/230/240V
UPS
kVA/Watts
Optional
Chargers
0 12/8400 56/54/52/50/48A 60/58/56/52/50A 80A 1145W
(3.90 kBTU/hr)
1 12/8400 72/70/68/66/64A 60/58/56/52/50A 100A 1430W
(4.88 kBTU/hr)
2 12/8400 88/86/84/82/80A 60/58/56/52/50A 125A 1720W
(5.85 kBTU/hr)
3 12/8400 102/102/100/98/96A* 60/58/56/52/50A 125A 1995W
(6.75 kBTU/hr)
0 15/10500 70/67.5/65/62.5/60A 75/72.5/70/65/62.5A 100A 1430W
(4.88 kBTU/hr)
1 15/10500 86/83.5/81/78.5/76A 75/72.5/70/65/62.5A 125A 1720W
(5.85 kBTU/hr)
2 15/10500 102/99.5/97/94.5/92A* 75/72.5/70/65/62.5A 125A 1995W
(6.75 kBTU/hr)
0 18/12600 84/81/78/75/72A 90/87/84/78/75A 125A 1720W
(5.85 kBTU/hr)
1 18/12600 100/97/94/91/88A* 90/87/84/78/75A 125A 1995W
(6.75 kBTU/hr)
* Maximum current rating for the cabinet size. If an additional charger is desired, it must be installed in external battery
cabinet ASY-0739.

SPECIFICATIONS
Eaton 9170+Battery Charger Module User's Guide S164201399 Rev E
www.eaton.com/powerquality
14
Table 5. Model Specifications for Split-Phase Power Modules (ASY-0673)
Three-Slot Cabinet
Optional
Chargers
UPS
kVA/Watts
Input Current
(200V)
Output Current
(100/200V, 110/220V, 120/240V)
Recommended
Input Service
Heat
Dissipation
NA 3/2500 16A* 15A, 14A, 12.5A 25A 285W
(0.98 kBTU/hr)
Six-Slot Cabinet
CAUTION Do NOT install more than three power and/or battery charger modules in a 6-slot cabinet.
Optional
Chargers
UPS
kVA/Watts
Input Current
(200V)
Output Current
(100/200V, 110/220V, 120/240V)
Recommended
Input Service
Heat
Dissipation
0 3/2500 16A 15A, 14A, 12.5A 25A 285W
(0.98 kBTU/hr)
1 3/2500 32A 15A, 14A, 12.5A 40A 570W
(1.95 kBTU/hr)
2 3/2500 48A* 15A, 14A, 12.5A 60A 860W
(2.93 kBTU/hr)
0 6/5000 32A 30A, 28A, 25A 40A 570W
(1.95 kBTU/hr)
1 6/5000 48A* 30A, 28A, 25A 60A 860W
(2.93 kBTU/hr)
0 9/7500 48A* 45A, 42A, 37.5A 60A 860W
(2.93 kBTU/hr)
Nine- and Twelve-Slot Cabinet
CAUTION Do NOT install more than seven power and/or battery charger modules in a 9- or 12-slot cabinet.
Optional
Chargers
UPS
kVA/Watts
Input Current
(200V)
Output Current
(100/200V, 110/220V, 120/240V)
Recommended
Input Service
Heat
Dissipation
0 3/2500 16A 15A, 14A, 12.5A 25A 285W
(0.98 kBTU/hr)
1 3/2500 32A 15A, 14A, 12.5A 40A 570W
(1.95 kBTU/hr)
2 3/2500 48A 15A, 14A, 12.5A 60A 860W
(2.93 kBTU/hr)
3 3/2500 64A 15A, 14A, 12.5A 80A 1145W
(3.90 kBTU/hr)
* Maximum current rating for the cabinet size. If an additional charger is desired, it must be installed in external battery
cabinet ASY-0739.

SPECIFICATIONS
Eaton 9170+Battery Charger Module User's Guide S164201399 Rev E
www.eaton.com/powerquality
15
Table 5. Model Specifications for Split-Phase Power Modules (ASY-0673) (continued)
Nine- and Twelve-Slot Cabinet
CAUTION Do NOT install more than seven power and/or battery charger modules in a 9- or 12-slot cabinet.
Heat
Dissipation
Recommended
Input Service
Output Current
(100/200V, 110/220V, 120/240V)
Input Current
(200V)
UPS
kVA/Watts
Optional
Chargers
4 3/2500 80A 15A, 14A, 12.5A 100A 1430W
(4.88 kBTU/hr)
5 3/2500 96A 15A, 14A, 12.5A 125A 1720W
(5.85 kBTU/hr)
0 6/5000 32A 30A, 28A, 25A 40A 570W
(1.95 kBTU/hr)
1 6/5000 48A 30A, 28A, 25A 60A 860W
(2.93 kBTU/hr)
2 6/5000 64A 30A, 28A, 25A 80A 1145W
(3.90 kBTU/hr)
3 6/5000 80A 30A, 28A, 25A 100A 1430W
(4.88 kBTU/hr)
4 6/5000 96A 30A, 28A, 25A 125A 1720W
(5.85 kBTU/hr)
5 6/5000 102A* 30A, 28A, 25A 125A 1995W
(6.75 kBTU/hr)
0 9/7500 48A 45A, 42A, 37.5A 60A 860W
(2.93 kBTU/hr)
1 9/7500 64A 45A, 42A, 37.5A 80A 1145W
(3.90 kBTU/hr)
2 9/7500 80A 45A, 42A, 37.5A 100A 1430W
(4.88 kBTU/hr)
3 9/7500 96A 45A, 42A, 37.5A 125A 1720W
(5.85 kBTU/hr)
4 9/7500 102A* 45A, 42A, 37.5A 125A 1995W
(6.75 kBTU/hr)
0 12/10000 64A 60A, 56A, 50A 80A 1145W
(3.90 kBTU/hr)
1 12/10000 80A 60A, 56A, 50A 100A 1430W
(4.88 kBTU/hr)
* Maximum current rating for the cabinet size. If an additional charger is desired, it must be installed in external battery
cabinet ASY-0739.

SPECIFICATIONS
Eaton 9170+Battery Charger Module User's Guide S164201399 Rev E
www.eaton.com/powerquality
16
Table 5. Model Specifications for Split-Phase Power Modules (ASY-0673) (continued)
Nine- and Twelve-Slot Cabinet
CAUTION Do NOT install more than seven power and/or battery charger modules in a 9- or 12-slot cabinet.
Heat
Dissipation
Recommended
Input Service
Output Current
(100/200V, 110/220V, 120/240V)
Input Current
(200V)
UPS
kVA/Watts
Optional
Chargers
2 12/10000 96A 60A, 56A, 50A 125A 1720W
(5.85 kBTU/hr)
3 12/10000 102A* 60A, 56A, 50A 125A 1995W
(6.75 kBTU/hr)
0 15/12500 80A 75A, 70A, 62.5A 100A 1430W
(4.88 kBTU/hr)
1 15/12500 96A 75A, 70A, 62.5A 125A 1720W
(5.85 kBTU/hr)
2 15/12500 102A* 75A, 70A, 62.5A 125A 1995W
(6.75 kBTU/hr)
0 18/15000 96A 90A, 84A, 75A 125A 1720W
(5.85 kBTU/hr)
1 18/15000 102A* 90A, 84A, 75A 125A 1995W
(6.75 kBTU/hr)
* Maximum current rating for the cabinet size. If an additional charger is desired, it must be installed in external battery
cabinet ASY-0739.
Table 6. Model Specifications for Split-Phase Power Modules (ASY-0567)
Three-Slot Cabinet
Optional
Chargers
UPS
kVA/Watts
Input Current
(200V)
Output Current
(200V, 220V, 240V)
Recommended
Input Service
Heat
Dissipation
NA 3/2100 14A 15A, 14A, 12.5A 25A 285W
(0.98 kBTU/hr)
Six-Slot Cabinet
CAUTION Do NOT install more than three power and/or battery charger modules in a 6-slot cabinet.
Optional
Chargers
UPS
kVA/Watts
Input Current
(200V)
Output Current
(200V, 220V, 240V)
Recommended
Input Service
Heat
Dissipation
0 3/2100 14A 15A, 14A, 12.5A 25A 285W
(0.98 kBTU/hr)
* Maximum current rating for the cabinet size. If an additional charger is desired, it must be installed in external battery
cabinet ASY-0739.
