ONE TOP MILK XP POWDER with BEV AIR FRIDGE
HIGH VOLUME SUPER AUTOMATIC ESPRESSO MACHINE
ESPRESSO MACHINE SPECIFICATIONS
High volume fully automac espresso machine with
touchscreen user interface and stainless steel 18-gram
patented brew group. Includes dual grinders made by
Ding™. Machine made of stainless steel and ABS plasc and
features an easy 3-step automac daily cleaning program,
thanks to its patented technology which rinses the enre
milk system with cold water and air. The ONE features the
patented stainless steel brewing group with advanced sealing
technology which requires less maintenance visits and reduces
the cost of ownership.
REFRIGERATOR SPECIFICATIONS
Versale, compact (29” depth) models with stainless
steel work tops and refrigerated storage of food products.
Heavy-duty construcon includes stainless steel on front,
sides, door(s) and grille. Stainless steel 2 1/2” thick work
top with 4” high removable backsplash. Cabinet back
and boom are galvanized steel. Interior liner is made of
anodized aluminum for longer lasng corrosion protecon.
Interior thermometer is standard. Doors are mounted to
the cabinet on self-closing, cartridge style hinges with 120°
stay-open feature. Interior arrangement includes 2 steel wire
epoxy-coated shelves behind each door, adjustable in 1/2”
increments.
Refrigeraon system ulizes R134a refrigerant metered by a
capillary tube system. Automac (non-electric) condensate
evaporator is standard. Interior forced air system, with high
humidity evaporator coils, provides the ideal environment
for food preservaon. Cartridge style door hinges provide a
posive seal. Wired for connecon to 115/60/1 phase, 15
amps.
ESPRESSO MACHINE STANDARD FEATURES
• Standard 5.7” touchscreen graphic display in full color user
interface enables up to 48 drink selecons
• Single milk pump system
• Beverage Air under the counter workstaon fridge with milk
delivery hose access
• Powder Module enables machine to deliver up to two types of
powder, for example, chocolate for mocha and hot chocolate
• Centralized hot water
• Americano bypass enables machine to deliver authenc
Americanos into a single cup
• Lowest cost of ownership of any fully automac with milk
• Premium espresso brewing
• Stainless steel 18-gram patented brewing technology
• Dual grinders by Ding™
• Made of stainless steel and ABS plasc
• Single component two-piece dispensing outlet for easy cleaning
• Daily milk cleaning cycle only requires operator to add detergent
• 2-year parts warranty
ESPRESSO MACHINE OPTIONS
Mul-Drink SW Touchscreen: Industrial color touchscreen with a
create-a-drink soware features over 1000 drink possibilies (Self-
adjusng grinder, Automac spout, and Cold foam not available with
Mul-Drink Soware)
iSteam: Intelligent steam wand automacally froths milk and shuts
o at programmed temperature
Self-adjusng Grinder: Automacally adjusts the coee grind size to
compensate for environmental changes
Automac Spout: Automacally adjusts the delivery spout to the
correct cup size
Under Counter Grounds Chute: chute that diverts ground coee to
under the counter waste container; not available when an under the
counter fridge is installed directly under the machine
External Hot Water Outlet: Hot water delivered through a separate
outlet to the right of the drink spout
Mul-Milk: Add to any fridge conguraon to deliver two types of
milk
Extension Card: Required for self-adjusng grinder, automac
spout or cold foam. Only 1 card is needed when purchasing opons
together
Locks Package: Locks for hopper, grounds drawer, and fridge
Credit Card Reader: Credit card reader for self-service payment,
mounted on a side 6” housing unit; when powder module is also
purchased, credit card is mounted unto the powder module
ESPRESSO MACHINE STANDARD ACCESSORIES
• Plasc grounds bin container
• One month supply of daily cleaning products
• Milk container
• Container for daily cleaning
• User manual
• Foot extensions
ESPRESSO MACHINE DATA SPECIFICATIONS
• Weight: 126 lbs (machine) 28 lbs
• Power Supply: 208 - 220 V (machine)
• Power Rang: 6700 W (machine)

SPACE REQUIREMENTS
Allow 1.5” of clearance on all sides of the machine.
Allow space to ll bean hoppers from the top 4” minimum
12” preferred.
Allow 24” x 5” of space for in-line lter. Filter can be
mounted behind the machine or under the counter.
SERVICE CONNECTIONS
ELECTRICAL CONNECTIONS:
Espresso Machine
Voltage Range: 208 - 220 V
Was: 6700
Circuit Size: 30 Amps
Suggested Receptacle: NEMA L6-30R
Bev Air Fridge & Powder Module
Voltage: 110 V
Was: 200
Circuit Size: 15 Amps
Suggested Receptacle: 5-15R GFI
PLEASE NOTE: Egro coee machines do not use a neutral
line. A dedicated ground wire is required.
Power can be installed under or above the counter. Please
allow 3.5” - 4” of space for the plug, especially when
placing power above the counter and behind the machine.
WATER CONNECTION:
Dedicated cold water access line with standard female
3/8” NPT ng and manual shut-o valve within 4‘ of the
machine.
DRAIN REQUIREMENTS:
Open gravity drain with minimum 2“ I.D. within 4’ of the
machine.
WATER QUALITY STATEMENT:
The fact that water is potable is no guarantee that it is
suitable for espresso machines. Your water supply must be
within these general guidelines:
SUPPLY PRESSURE: 30-70 psi
HARDNESS: 2-4 GPG*
*17.1 ppm = 1 grain of hardness
Water entering the espresso machine should have a water hardness level
of 2-3 GPG at all mes. If the water supply is not within this range, a
dedicated water soener is required for the espresso machine to operate
correctly over me.
NEMA L6-30R
Suggested Receptacle
for Espresso Machine
CSpecSheetONETOPMILKXPPOWDERwithBEVAIRFRIDGEv4December12,201612:37PM
Rancilio Group North America ǀ 1340 Internaonale Parkway #200 ǀWoodridge, IL 60517 ǀ Ph: [phone] ǀ www.ranciliogroupna.com
ONE TOP MILK XP POWDER with BEV AIR FRIDGE
HIGH VOLUME SUPER AUTOMATIC ESPRESSO MACHINE
BEV-AIR WTR 27A-SR DIMENSIONS
COUNTERTOP REQUIREMENTS
Width: 18” Depth: 23” Height: 31” Weight: 154 lbs
UNDER COUNTERTOP REQUIREMENTS
Width: 27” Depth: 34.5”
Depth with
door open
90ᵒ: 54”
Height: 35.6” Weight: 160 lbs
SHIPPING DIMENSIONS AND WEIGHT
Length: 36” Width: 36” Height: 32” Weight: 315 lbs

CSpecSheetONETOPMILKXPPOWDERwithKS9FRIDGEv4December12,20162:04PM
Rancilio Group North America ǀ 1340 Internaonale Parkway #200 ǀWoodridge, IL 60517 ǀ Ph: [phone] ǀ www.ranciliogroupna.com
ONE TOP MILK XP POWDER with KS9 FRIDGE
HIGH VOLUME SUPER AUTOMATIC ESPRESSO MACHINE
ESPRESSO MACHINE SPECIFICATIONS
High volume fully automac espresso machine with
touchscreen user interface and stainless steel 18-gram
patented brew group. Includes dual grinders made by
Ding™. Machine made of stainless steel and ABS plasc and
features an easy 3-step automac daily cleaning program,
thanks to its patented technology which rinses the enre
milk system with cold water and air. The ONE features the
patented stainless steel brewing group with advanced sealing
technology which requires less maintenance visits and reduces
the cost of ownership. Milk is pumped from the KS9 Top Milk
fridge. Make Cappuccinos and Laes with the push of one
buon. Includes the ability to set dierent milk temperatures
and textures for each drink.
ESPRESSO MACHINE STANDARD FEATURES
• Standard 5.7” touchscreen graphic display in full color user
interface enables up to 48 drink selecons
• Single milk pump system
• Automac milk frothing and delivery with a push of a buon
• Top Milk fridge (KS9) 6.5 liter (1.7 gallons) countertop fridge ts
perfectly on the le side of the machine
• Set dierent milk temperatures and textures for each drink
• Powder Module enables machine to deliver up to two types of
powder, for example, chocolate for mocha and hot chocolate
• Centralized hot water
• Americano bypass enables machine to deliver authenc
Americanos into a single cup
• Lowest cost of ownership of any fully automac with milk
• Premium espresso brewing
• Stainless steel 18-gram patented brewing technology
• Dual grinders by Ding™
• Made of stainless steel and ABS plasc
• Single component two-piece dispensing outlet for easy cleaning
• Daily milk cleaning cycle only requires operator to add detergent
• 2-year parts warranty
ESPRESSO MACHINE OPTIONS
Mul-Drink SW Touchscreen: Industrial color touchscreen with a
create-a-drink soware features over 1000 drink possibilies (Self-
adjusng grinder, Automac spout, and Cold foam not available with
Mul-Drink Soware)
iSteam: Intelligent steam wand automacally froths milk and shuts
o at programmed temperature
Self-adjusng Grinder: Automacally adjusts the coee grind size to
compensate for environmental changes
Automac Spout: Automacally adjusts the delivery spout to the
correct cup size
Under Counter Grounds Chute: chute that diverts ground coee to
under the counter waste container; not available when an under the
counter fridge is installed directly under the machine
External Hot Water Outlet: Hot water delivered through a separate
outlet to the right of the drink spout
Mul-Milk: Add to any fridge conguraon to deliver two types of
milk
Extension Card: Required for self-adjusng grinder, automac
spout or cold foam (Only 1 card is needed when purchasing opons
together)
Cold Milk Foam: Delivers amazingly stable cold foam for unique
drinks (Not available with any conguraon that includes Mul-Milk
or under the counter conguraons)
Locks Package: Locks for hopper, grounds drawer, and fridge
Credit Card Reader: Credit card reader for self-service payment,
mounted on a side 6” housing unit; when powder module is also
purchased, credit card is mounted unto the powder module
ESPRESSO MACHINE STANDARD ACCESSORIES
• Plasc grounds bin container
• One month supply of daily cleaning products
• Milk container
• Container for daily cleaning
• User manual
• Foot extensions
POWDER MODULE FEATURES
• Two 2.6 lbs powder hoppers
• Perfect for a variety of water soluble powders
• Use chocolate powder for mochas at the touch of a
buon
• Requires only 6” of counter space
ESPRESSO MACHINE DATA SPECIFICATIONS
• Weight: 126 lbs (machine) 28 lbs (powder module) 64
lbs (KS9 fridge)
• Power Supply: 208 - 220 V (machine) 110v (powder
module) 110v (KS9 fridge)
• Power Rang: 6700 W (machine) 200 W (powder
module) 200 W (KS9 fridge)

SPACE REQUIREMENTS
Allow 1.5” of clearance on all sides of the machine.
Allow space to ll bean hoppers from the top 4” minimum
12” preferred.
Allow 24” x 5” of space for in-line lter. Filter can be
mounted behind the machine or under the counter.
SERVICE CONNECTIONS
ELECTRICAL CONNECTIONS:
Espresso Machine
Voltage Range: 208 - 220 V
Was: 6700
Circuit Size: 30 Amps
Suggested Receptacle: NEMA L6-30R
KS9 Fridge & Powder Module
Voltage: 110 V
Was: 200
Circuit Size: 15 Amps
Suggested Receptacle: 5-15R GFI
PLEASE NOTE: Egro coee machines do not use a neutral
line. A dedicated ground wire is required.
Power can be installed under or above the counter. Please
allow 3.5” - 4” of space for the plug, especially when
placing power above the counter and behind the machine.
WATER CONNECTION:
Dedicated cold water access line with standard female
3/8” NPT ng and manual shut-o valve within 4‘ of the
machine.
DRAIN REQUIREMENTS:
Open gravity drain with minimum 2“ I.D. within 4’ of the
machine.
WATER QUALITY STATEMENT:
The fact that water is potable is no guarantee that it is
suitable for espresso machines. Your water supply must be
within these general guidelines:
SUPPLY PRESSURE: 30-70 psi
HARDNESS: 2-4 GPG*
*17.1 ppm = 1 grain of hardness
Water entering the espresso machine should have a water hardness level
of 2-3 GPG at all mes. If the water supply is not within this range, a
dedicated water soener is required for the espresso machine to operate
correctly over me.
NEMA L6-30R
Suggested Receptacle
for Espresso Machine
CSpecSheetONETOPMILKXPPOWDERwithKS9FRIDGEv4December12,20162:04PM
Rancilio Group North America ǀ 1340 Internaonale Parkway #200 ǀWoodridge, IL 60517 ǀ Ph: [phone] ǀ www.ranciliogroupna.com
POWDER MODULE SPECIFICATIONS
Powder Module allows the management of a great number of
beverages in powder form. It is an external device posioned
on the right-hand side of the machine and consists of two
hoppers that may be used with one type of powder or may
operate independently with dierent water soluble powders.
For example, vanilla powder may be used for vanilla avored
drinks or chai powder for chai laes and teas.
ONE TOP MILK XP POWDER with KS9 FRIDGE
HIGH VOLUME SUPER AUTOMATIC ESPRESSO MACHINE
POWDER MODULE
TOTAL COUNTERTOP REQUIREMENTS
Width: 30” Depth: 23” Height: 31” Weight: 218 lbs
SHIPPING DIMENSIONS AND WEIGHT
Length: 36” Width: 36” Height: 32” Weight: 222 lbs

CSpecSheetONETOPMILKXPPOWDERwithUSEYOUROWNUTCFRIDGEv4December12,20162:20PM
Rancilio Group North America ǀ 1340 Internaonale Parkway #200 ǀWoodridge, IL 60517 ǀ Ph: [phone] ǀ www.ranciliogroupna.com
ONE TOP MILK XP POWDER with USE YOUR OWN UTC FRIDGE
HIGH VOLUME SUPER AUTOMATIC ESPRESSO MACHINE
ESPRESSO MACHINE SPECIFICATIONS
High volume fully automac espresso machine with
touchscreen user interface and stainless steel 18-gram
patented brew group. Includes dual grinders made by
Ding™. Machine made of stainless steel and ABS plasc and
features an easy 3-step automac daily cleaning program,
thanks to its patented technology which rinses the enre
milk system with cold water and air. The ONE features the
patented stainless steel brewing group with advanced sealing
technology which requires less maintenance visits and reduces
the cost of ownership.
POWDER MODULE SPECIFICATIONS
Powder Module allows the management of a great number of
beverages in powder form. It is an external device posioned
on the right-hand side of the machine and consists of two
hoppers that may be used with one type of powder or may
operate independently with dierent water soluble powders.
For example, vanilla powder may be used for vanilla avored
drinks or chai powder for chai laes and teas.
MILK PUMP UNIT
The Milk Pump Unit is an external unit that can be placed
in any under-the-counter refrigerator that has top access
holes. It includes all the necessary components to pump
milk to the machine for authenc laes, cappuccinos and
more. It includes milk tubes to be inserted into fresh milk
gallons or other containers. It is designed to be placed on the
refrigerator shelf with the milk placed beneath it.
ESPRESSO MACHINE STANDARD FEATURES
• Standard 5.7” touchscreen graphic display in full color user
interface enables up to 48 drink selecons
• Single milk pump system
• Powder Module enables machine to deliver up to two types of
powder, for example, chocolate for mocha and hot chocolate
• Centralized hot water
• Americano bypass enables machine to deliver authenc
Americanos into a single cup
• Lowest cost of ownership of any fully automac with milk
• Premium espresso brewing
• Stainless steel 18-gram patented brewing technology
• Dual grinders by Ding™
• Made of stainless steel and ABS plasc
• Single component two-piece dispensing outlet for easy cleaning
• Daily milk cleaning cycle only requires operator to add detergent
• 2-year parts warranty
ESPRESSO MACHINE OPTIONS
Mul-Drink SW Touchscreen: Industrial color touchscreen with a
create-a-drink soware features over 1000 drink possibilies (Self-
adjusng grinder, Automac spout, and Cold foam not available with
Mul-Drink Soware)
iSteam: Intelligent steam wand automacally froths milk and shuts
o at programmed temperature
Self-adjusng Grinder: Automacally adjusts the coee grind size to
compensate for environmental changes
Automac Spout: Automacally adjusts the delivery spout to the
correct cup size
Under Counter Grounds Chute: chute that diverts ground coee to
under the counter waste container; not available when an under the
counter fridge is installed directly under the machine
External Hot Water Outlet: Hot water delivered through a separate
outlet to the right of the drink spout
Mul-Milk: Add to any fridge conguraon to deliver two types of
milk
Extension Card: Required for self-adjusng grinder, automac
spout or cold foam. Only 1 card is needed when purchasing opons
together
Locks Package: Locks for hopper, grounds drawer, and fridge
Credit Card Reader: Credit card reader for self-service payment,
mounted on a side 6” housing unit; when powder module is also
purchased, credit card is mounted unto the powder module
ESPRESSO MACHINE STANDARD ACCESSORIES
• Plasc grounds bin container
• One month supply of daily cleaning products
• Milk container
• Container for daily cleaning
• User manual
• Foot extensions
ESPRESSO MACHINE DATA SPECIFICATIONS
• Weight: 126 lbs (machine) 28 lbs (powder module)
• Power Supply: 208 - 220 V (machine) 110v (powder
module)
• Power Rang: 6700 W (machine) 200 W (powder
module)

SPACE REQUIREMENTS
Allow 1.5” of clearance on all sides of the machine.
Allow space to ll bean hoppers from the top 4” minimum
12” preferred.
Allow 24” x 5” of space for in-line lter. Filter can be
mounted behind the machine or under the counter.
SERVICE CONNECTIONS
ELECTRICAL CONNECTIONS:
Espresso Machine
Voltage Range: 208 - 220 V
Was: 6700
Circuit Size: 30 Amps
Suggested Receptacle: NEMA L6-30R
Powder Module
Voltage: 110 V
Was: 200
Circuit Size: 15 Amps
Suggested Receptacle: 5-15R GFI
PLEASE NOTE: Egro coee machines do not use a neutral
line. A dedicated ground wire is required.
Power can be installed under or above the counter. Please
allow 3.5” - 4” of space for the plug, especially when
placing power above the counter and behind the machine.
WATER CONNECTION:
Dedicated cold water access line with standard female
3/8” NPT ng and manual shut-o valve within 4‘ of the
machine.
DRAIN REQUIREMENTS:
Open gravity drain with minimum 2“ I.D. within 4’ of the
machine.
WATER QUALITY STATEMENT:
The fact that water is potable is no guarantee that it is
suitable for espresso machines. Your water supply must be
within these general guidelines:
SUPPLY PRESSURE: 30-70 psi
HARDNESS: 2-4 GPG*
*17.1 ppm = 1 grain of hardness
Water entering the espresso machine should have a water hardness level
of 2-3 GPG at all mes. If the water supply is not within this range, a
dedicated water soener is required for the espresso machine to operate
correctly over me.
NEMA L6-30R
Suggested Receptacle
for Espresso Machine
CSpecSheetONETOPMILKXPPOWDERwithUSEYOUROWNUTCFRIDGEv4December12,20162:20PM
Rancilio Group North America ǀ 1340 Internaonale Parkway #200 ǀWoodridge, IL 60517 ǀ Ph: [phone] ǀ www.ranciliogroupna.com
ONE TOP MILK XP POWDER with USE YOUR OWN UTC FRIDGE
HIGH VOLUME SUPER AUTOMATIC ESPRESSO MACHINE
TOTAL COUNTERTOP REQUIREMENTS
Width: 18” Depth: 23” Height: 31” Weight: 154 lbs
SHIPPING DIMENSIONS AND WEIGHT
Length: 36” Width: 36” Height: 32” Weight: 222 lbs
MILK PUMP UNIT DIMENSIONS
Front ngs are for tubes
going to milk container
Side hole is for wiring and
tubing going to the
espresso machine

C Spec Sheet ONE TOP MILK XP with BEV AIR FRIDGE v4 December 12, 2016 2:06 PM
ONE TOP MILK XP with BEV AIR FRIDGE
HIGH VOLUME SUPER AUTOMATIC ESPRESSO MACHINE
ESPRESSO MACHINE SPECIFICATIONS
High volume fully automac espresso machine with
touchscreen user interface and stainless steel 18-gram
patented brew group. Includes dual grinders made by
Ding™. Machine made of stainless steel and ABS plasc and
features an easy 3-step automac daily cleaning program,
thanks to its patented technology which rinses the enre
milk system with cold water and air. The ONE features the
patented stainless steel brewing group with advanced sealing
technology which requires less maintenance visits and reduces
the cost of ownership.
REFRIGERATOR SPECIFICATIONS
Versale, compact (29” depth) models with stainless
steel work tops and refrigerated storage of food products.
Heavy-duty construcon includes stainless steel on front,
sides, door(s) and grille. Stainless steel 2 1/2” thick work
top with 4” high removable backsplash. Cabinet back
and boom are galvanized steel. Interior liner is made of
anodized aluminum for longer lasng corrosion protecon.
Interior thermometer is standard. Doors are mounted to
the cabinet on self-closing, cartridge style hinges with 120°
stay-open feature. Interior arrangement includes 2 steel wire
epoxy-coated shelves behind each door, adjustable in 1/2”
increments.
Refrigeraon system ulizes R134a refrigerant metered by a
capillary tube system. Automac (non-electric) condensate
evaporator is standard. Interior forced air system, with high
humidity evaporator coils, provides the ideal environment
for food preservaon. Cartridge style door hinges provide a
posive seal. Wired for connecon to 115/60/1 phase, 15
amps.
ESPRESSO MACHINE STANDARD FEATURES
• Standard 5.7” touchscreen graphic display in full color user
interface enables up to 48 drink selecons
• Single milk pump system
• Beverage Air under the counter workstaon fridge with milk
delivery hose access
• Centralized hot water
• Americano bypass enables machine to deliver authenc
Americanos into a single cup
• Lowest cost of ownership of any fully automac with milk
• Premium espresso brewing
• Stainless steel 18-gram patented brewing technology
• Dual grinders by Ding™
• Made of stainless steel and ABS plasc
• Single component two-piece dispensing outlet for easy cleaning
• Daily milk cleaning cycle only requires operator to add detergent
• 2-year parts warranty
ESPRESSO MACHINE OPTIONS
Mul-Drink SW Touchscreen: Industrial color touchscreen with a
create-a-drink soware features over 1000 drink possibilies (Self-
adjusng grinder, Automac spout, and Cold foam not available with
Mul-Drink Soware)
iSteam: Intelligent steam wand automacally froths milk and shuts
o at programmed temperature
Self-adjusng Grinder: Automacally adjusts the coee grind size to
compensate for environmental changes
Automac Spout: Automacally adjusts the delivery spout to the
correct cup size
Under Counter Grounds Chute: chute that diverts ground coee to
under the counter waste container; not available when an under the
counter fridge is installed directly under the machine
External Hot Water Outlet: Hot water delivered through a separate
outlet to the right of the drink spout
Mul-Milk: Add to any fridge conguraon to deliver two types of
milk
Extension Card: Required for self-adjusng grinder, automac
spout or cold foam. Only 1 card is needed when purchasing opons
together
Locks Package: Locks for hopper, grounds drawer, and fridge
Powder Module: Enables machine to deliver up to two types of
powder, for example, chocolate for mochas and hot chocolate
Credit Card Reader: Credit card reader for self-service payment,
mounted on a side 6” housing unit; when powder module is also
purchased, credit card is mounted unto the powder module
ESPRESSO MACHINE STANDARD ACCESSORIES
• Plasc grounds bin container
• One month supply of daily cleaning products
• Milk container
• Container for daily cleaning
• User manual
• Foot extensions
ESPRESSO MACHINE DATA SPECIFICATIONS
• Weight: 126 lbs (machine) 28 lbs
• Power Supply: 208 - 220 V (machine)
• Power Rang: 6700 W (machine)

SPACE REQUIREMENTS
Allow 1.5” of clearance on all sides of the machine.
Allow space to ll bean hoppers from the top 4” minimum
12” preferred.
Allow 24” x 5” of space for in-line lter. Filter can be
mounted behind the machine or under the counter.
SERVICE CONNECTIONS
ELECTRICAL CONNECTIONS:
Espresso Machine
Voltage Range: 208 - 220 V
Was: 6700
Circuit Size: 30 Amps
Suggested Receptacle: NEMA L6-30R
Bev Air Fridge
Voltage: 110 V
Was: 200
Circuit Size: 15 Amps
Suggested Receptacle: 5-15R GFI
PLEASE NOTE: Egro coee machines do not use a neutral
line. A dedicated ground wire is required.
Power can be installed under or above the counter. Please
allow 3.5” - 4” of space for the plug, especially when
placing power above the counter and behind the machine.
WATER CONNECTION:
Dedicated cold water access line with standard female
3/8” NPT ng and manual shut-o valve within 4‘ of the
machine.
DRAIN REQUIREMENTS:
Open gravity drain with minimum 2“ I.D. within 4’ of the
machine.
WATER QUALITY STATEMENT:
The fact that water is potable is no guarantee that it is
suitable for espresso machines. Your water supply must be
within these general guidelines:
SUPPLY PRESSURE: 30-70 psi
HARDNESS: 2-4 GPG*
*17.1 ppm = 1 grain of hardness
Water entering the espresso machine should have a water hardness level
of 2-3 GPG at all mes. If the water supply is not within this range, a
dedicated water soener is required for the espresso machine to operate
correctly over me.
NEMA L6-30R
Suggested Receptacle
for Espresso Machine
C Spec Sheet ONE TOP MILK XP with BEV AIR FRIDGE v4 December 12, 2016 2:06 PM
Rancilio Group North America ǀ 1340 Internaonale Parkway #200 ǀWoodridge, IL 60517 ǀ Ph: [phone] ǀ www.ranciliogroupna.com
ONE TOP MILK XP with BEV AIR FRIDGE
HIGH VOLUME SUPER AUTOMATIC ESPRESSO MACHINE
BEV-AIR WTR 27A-SR DIMENSIONS
COUNTERTOP REQUIREMENTS
Width: 12” Depth: 23” Height: 31” Weight: 126 lbs
UNDER COUNTERTOP REQUIREMENTS
Width: 27” Depth: 34.5”
Depth with
door open
90ᵒ: 54”
Height: 35.6” Weight: 160 lbs
SHIPPING DIMENSIONS AND WEIGHT
Length: 36” Width: 36” Height: 32” Weight: 315 lbs

ESPRESSO MACHINE STANDARD ACCESSORIES
• Plasc grounds bin container
• One month supply of daily cleaning products
• Milk container
• Container for daily cleaning
• User manual
• Foot extensions
ESPRESSO MACHINE DATA SPECIFICATIONS
• Weight: 126 lbs (machine) 64 lbs (KS9 fridge)
• Power Supply: 208 - 220 V (machine) 110v (KS9 fridge)
• Power Rang: 6700 W (machine) 200 W (KS9 fridge)
ONE TOP MILK XP with KS9 FRIDGE
HIGH VOLUME SUPER AUTOMATIC ESPRESSO MACHINE
ESPRESSO MACHINE SPECIFICATIONS
High volume fully automac espresso machine with
touchscreen user interface and stainless steel 18-gram
patented brew group. Includes dual grinders made by
Ding™. Machine made of stainless steel and ABS plasc and
features an easy 3-step automac daily cleaning program,
thanks to its patented technology which rinses the enre
milk system with cold water and air. The ONE features the
patented stainless steel brewing group with advanced sealing
technology which requires less maintenance visits and reduces
the cost of ownership. Milk is pumped from the KS9 Top Milk
fridge. Make Cappuccinos and Laes with the push of one
buon. Includes the ability to set dierent milk temperatures
and textures for each drink.
ESPRESSO MACHINE STANDARD FEATURES
• Standard 5.7” touchscreen graphic display in full color user
interface enables up to 48 drink selecons
• Single milk pump system
• Automac milk frothing and delivery with a push of a buon
• Top Milk fridge (KS9) 6.5 liter (1.7 gallons) countertop fridge ts
perfectly on the le side of the machine
• Set dierent milk temperatures and textures for each drink
• Centralized hot water
• Americano bypass enables machine to deliver authenc
Americanos into a single cup
• Lowest cost of ownership of any fully automac with milk
• Premium espresso brewing
• Stainless steel 18-gram patented brewing technology
• Dual grinders by Ding™
• Made of stainless steel and ABS plasc
• Single component two-piece dispensing outlet for easy cleaning
• Daily milk cleaning cycle only requires operator to add detergent
• 2-year parts warranty
ESPRESSO MACHINE OPTIONS
Mul-Drink SW Touchscreen: Industrial color touchscreen with a
create-a-drink soware features over 1000 drink possibilies (Self-
adjusng grinder, Automac spout, and Cold foam not available with
Mul-Drink Soware)
iSteam: Intelligent steam wand automacally froths milk and shuts
o at programmed temperature
Self-adjusng Grinder: Automacally adjusts the coee grind size to
compensate for environmental changes
Automac Spout: Automacally adjusts the delivery spout to the
correct cup size
Under Counter Grounds Chute: chute that diverts ground coee to
under the counter waste container; not available when an under the
counter fridge is installed directly under the machine
External Hot Water Outlet: Hot water delivered through a separate
outlet to the right of the drink spout
Mul-Milk: Add to any fridge conguraon to deliver two types of
milk
Extension Card: Required for self-adjusng grinder, automac
spout or cold foam (Only 1 card is needed when purchasing opons
together)
Cold Milk Foam: Delivers amazingly stable cold foam for unique
drinks (Not available with any conguraon that includes Mul-Milk
or under the counter conguraons)
Locks Package: Locks for hopper, grounds drawer, and fridge
Powder Module: Enables machine to deliver up to two types of
powder, for example, chocolate for mochas and hot chocolate
Credit Card Reader: Credit card reader for self-service payment,
mounted on a side 6” housing unit; when powder module is also
purchased, credit card is mounted unto the powder module
OPTIONAL COLD MILK FOAM

SPACE REQUIREMENTS
Allow 1.5” of clearance on all sides of the machine.
Allow space to ll bean hoppers from the top 4” minimum
12” preferred.
Allow 24” x 5” of space for in-line lter. Filter can be
mounted behind the machine or under the counter.
SERVICE CONNECTIONS
ELECTRICAL CONNECTIONS:
Espresso Machine
Voltage Range: 208 - 220 V
Was: 6700
Circuit Size: 30 Amps
Suggested Receptacle: NEMA L6-30R
KS9 Fridge
Voltage: 110 V
Was: 200
Circuit Size: 15 Amps
Suggested Receptacle: 5-15R GFI
PLEASE NOTE: Egro coee machines do not use a neutral
line. A dedicated ground wire is required.
Power can be installed under or above the counter. Please
allow 3.5” - 4” of space for the plug, especially when
placing power above the counter and behind the machine.
WATER CONNECTION:
Dedicated cold water access line with standard female
3/8” NPT ng and manual shut-o valve within 4‘ of the
machine.
DRAIN REQUIREMENTS:
Open gravity drain with minimum 2“ I.D. within 4’ of the
machine.
WATER QUALITY STATEMENT:
The fact that water is potable is no guarantee that it is
suitable for espresso machines. Your water supply must be
within these general guidelines:
SUPPLY PRESSURE: 30-70 psi
HARDNESS: 2-4 GPG*
*17.1 ppm = 1 grain of hardness
Water entering the espresso machine should have a water hardness level
of 2-3 GPG at all mes. If the water supply is not within this range, a
dedicated water soener is required for the espresso machine to operate
correctly over me.
NEMA L6-30R
Suggested Receptacle
for Espresso Machine
C Spec Sheet ONE TOP MILK XP with KS9 FRIDGE v4 December 12, 2016 11:23 AM
Rancilio Group North America ǀ 1340 Internaonale Parkway #200 ǀWoodridge, IL 60517 ǀ Ph: [phone] ǀ www.ranciliogroupna.com
ONE TOP MILK XP with KS9 FRIDGE
HIGH VOLUME SUPER AUTOMATIC ESPRESSO MACHINE
KS9 TOP MILK FRIDGE
KS9 TOP MILK FRIDGE SPECIFICATIONS
The KS9 Fridge ts perfectly beside the EGRO ONE machine or can be
placed under the counter to save counter space. A milk container is
included with the KS9 Fridge, milk may be poured into this container
for maximum benets. This container holds 1.7 gallons of milk and
contains a sensor to allow the machine to automacally determine
milk levels. Alternavely, a standard 1-gallon milk container may be
used if milk sensing is not needed.
TOTAL COUNTERTOP REQUIREMENTS
Width: 24” Depth: 23” Height: 31” Weight: 190 lbs
SHIPPING DIMENSIONS AND WEIGHT
Length: 36” Width: 36” Height: 32” Weight: 222 lbs

CSpecSheetONETOPMILKXPwithUSEYOUROWNUTCFRIDGEv4December12,20162:20PM
Rancilio Group North America ǀ 1340 Internaonale Parkway #200 ǀWoodridge, IL 60517 ǀ Ph: [phone] ǀ www.ranciliogroupna.com
ONE TOP MILK XP with USE YOUR OWN UTC FRIDGE
HIGH VOLUME SUPER AUTOMATIC ESPRESSO MACHINE
ESPRESSO MACHINE SPECIFICATIONS
High volume fully automac espresso machine with
touchscreen user interface and stainless steel 18-gram
patented brew group. Includes dual grinders made by
Ding™. Machine made of stainless steel and ABS plasc and
features an easy 3-step automac daily cleaning program,
thanks to its patented technology which rinses the enre
milk system with cold water and air. The ONE features the
patented stainless steel brewing group with advanced sealing
technology which requires less maintenance visits and reduces
the cost of ownership.
MILK PUMP UNIT
The Milk Pump Unit is an external unit that can be placed
in any under-the-counter refrigerator that has top access
holes. It includes all the necessary components to pump
milk to the machine for authenc laes, cappuccinos and
more. It includes milk tubes to be inserted into fresh milk
gallons or other containers. It is designed to be placed on the
refrigerator shelf with the milk placed beneath it.
ESPRESSO MACHINE STANDARD FEATURES
• Standard 5.7” touchscreen graphic display in full color user
interface enables up to 48 drink selecons
• Single milk pump system
• Centralized hot water
• Americano bypass enables machine to deliver authenc
Americanos into a single cup
• Lowest cost of ownership of any fully automac with milk
• Premium espresso brewing
• Stainless steel 18-gram patented brewing technology
• Dual grinders by Ding™
• Made of stainless steel and ABS plasc
• Single component two-piece dispensing outlet for easy cleaning
• Daily milk cleaning cycle only requires operator to add detergent
• 2-year parts warranty
ESPRESSO MACHINE OPTIONS
Mul-Drink SW Touchscreen: Industrial color touchscreen with a
create-a-drink soware features over 1000 drink possibilies (Self-
adjusng grinder, Automac spout, and Cold foam not available with
Mul-Drink Soware)
iSteam: Intelligent steam wand automacally froths milk and shuts
o at programmed temperature
Self-adjusng Grinder: Automacally adjusts the coee grind size to
compensate for environmental changes
Automac Spout: Automacally adjusts the delivery spout to the
correct cup size
Under Counter Grounds Chute: chute that diverts ground coee to
under the counter waste container; not available when an under the
counter fridge is installed directly under the machine
External Hot Water Outlet: Hot water delivered through a separate
outlet to the right of the drink spout
Mul-Milk: Add to any fridge conguraon to deliver two types of
milk
Extension Card: Required for self-adjusng grinder, automac
spout or cold foam. Only 1 card is needed when purchasing opons
together
Locks Package: Locks for hopper, grounds drawer, and fridge
Powder Module: Enables machine to deliver up to two types of
powder, for example, chocolate for mocha and hot chocolate
Credit Card Reader: Credit card reader for self-service payment,
mounted on a side 6” housing unit; when powder module is also
purchased, credit card is mounted unto the powder module
ESPRESSO MACHINE STANDARD ACCESSORIES
• Plasc grounds bin container
• One month supply of daily cleaning products
• Milk container
• Container for daily cleaning
• User manual
• Foot extensions
ESPRESSO MACHINE DATA SPECIFICATIONS
• Weight: 126 lbs (machine)
• Power Supply: 208 - 220 V (machine)
• Power Rang: 6700 W (machine)
OPTIONAL MULTI-DRINK TOUCHSCREEN

SPACE REQUIREMENTS
Allow 1.5” of clearance on all sides of the machine.
Allow space to ll bean hoppers from the top 4” minimum
12” preferred.
Allow 24” x 5” of space for in-line lter. Filter can be
mounted behind the machine or under the counter.
SERVICE CONNECTIONS
ELECTRICAL CONNECTIONS:
Espresso Machine
Voltage Range: 208 - 220 V
Was: 6700
Circuit Size: 30 Amps
Suggested Receptacle: NEMA L6-30R
PLEASE NOTE: Egro coee machines do not use a neutral
line. A dedicated ground wire is required.
Power can be installed under or above the counter. Please
allow 3.5” - 4” of space for the plug, especially when
placing power above the counter and behind the machine.
WATER CONNECTION:
Dedicated cold water access line with standard female
3/8” NPT ng and manual shut-o valve within 4‘ of the
machine.
DRAIN REQUIREMENTS:
Open gravity drain with minimum 2“ I.D. within 4’ of the
machine.
WATER QUALITY STATEMENT:
The fact that water is potable is no guarantee that it is
suitable for espresso machines. Your water supply must be
within these general guidelines:
SUPPLY PRESSURE: 30-70 psi
HARDNESS: 2-4 GPG*
*17.1 ppm = 1 grain of hardness
Water entering the espresso machine should have a water hardness level
of 2-3 GPG at all mes. If the water supply is not within this range, a
dedicated water soener is required for the espresso machine to operate
correctly over me.
NEMA L6-30R
Suggested Receptacle
for Espresso Machine
CSpecSheetONETOPMILKXPwithUSEYOUROWNUTCFRIDGEv4December12,20162:20PM
Rancilio Group North America ǀ 1340 Internaonale Parkway #200 ǀWoodridge, IL 60517 ǀ Ph: [phone] ǀ www.ranciliogroupna.com
ONE TOP MILK XP with USE YOUR OWN UTC FRIDGE
HIGH VOLUME SUPER AUTOMATIC ESPRESSO MACHINE
TOTAL COUNTERTOP REQUIREMENTS
Width: 12” Depth: 23” Height: 31” Weight: 126 lbs
SHIPPING DIMENSIONS AND WEIGHT
Length: 36” Width: 36” Height: 32” Weight: 222 lbs
MILK PUMP UNIT DIMENSIONS
Front ngs are for tubes
going to milk container
Side hole is for wiring and
tubing going to the
espresso machine
