Elba EBO9810S Installation and operating instructions

8-FUNCTION
OVENS
Instructions for the use - Installation advices
KEEP IN A SAFE PLACE
Before operating this oven,
please read these instructions carefully

2
Dear Customer,
Thank you for having purchased and given your preference to our
product.
The safety precautions and recommendations within this booklet
are for your own safety and that of others. They will also provide
a means by which to make full use of the features offered by your
appliance.
Please preserve this booklet carefully. It may be useful in future,
either to yourself or to others in the event that doubts should arise
relating to its operation.
This appliance must be used only for the task it has explicitly
been designed for, that is for cooking foodstuffs. Any other form
of usage is to be considered as inappropriate and therefore dan-
gerous.
The manufacturer declines all responsibility in the event of dam-
age caused by improper, incorrect or illogical use of the appliance.
DECLARATI N F CE C NF RMITY
– This oven has been designed to be used only for cooking. Any other use (such as
heating a room) is improper and dangerous.
– This oven has been designed, constructed, and marketed in compliance with:
- safety requirements of EEC Directive “Low voltage” 2006/95
- safety requirements of EEC Directive “EMC” 89/336;
- requirements of EEC Directive 93/68.
IMP RTANT INF RMATI N F R C RRECT DISP SAL F THE PR DUCT IN
ACC RDANCE WITH EC DIRECTIVE 2002/96/EC.
At the end of its working life, the product must not be disposed of as
urban waste. It must be taken to a special local authority differentiat-
ed waste collection centre or to a dealer providing this service.
Disposing of a household appliance separately avoids possible nega-
tive consequences for the environment and health deriving from inap-
propriate disposal and enables the constituent materials to be recov-
ered to obtain significant savings in energy and resources. As a
reminder of the need to dispose of household appliances separately,
the product is marked with a crossed-out wheeled dustbin.

3
IMP RTANT PRECAUTI NS AND REC MMENDATI NS
– After having unpacked the appliance, check to ensure that it is not damaged.
If you have any doubts, do not use it and contact the store from where you pur-
chased it.
– Packing materials (i.e. plastic bags, polystyrene foam, nails, packing straps, etc.)
should not be left around within easy reach of children, as these may cause serious
injuries.
– Do not attempt to modify the technical characteristics of the appliance as it may
become dangerous to use.
– Do not carry out cleaning or maintenance operations on the appliance without hav-
ing previously disconnected it from the electric power supply.
– If you should decide not to use this appliance any longer (or decide to substitute an
older model), before disposing of it, it is recommended that it be made inoperative
in an appropriate manner in accordance to health and environmental protection reg-
ulations, ensuring in particular that all potentially hazardous parts be made harmless,
especially in relation to children who could play with old appliances.
IMP RTANT PRECAUTI NS AND REC MMENDATI NS F R USE F ELECTRICAL
APPLIANCES
Use of any electrical appliance implies the necessity to follow a series of fundamen-
tal rules. In particular:
– ever touch the appliance with wet hands or feet;
– do not operate the appliance barefooted;
– do not allow children or disabled people to use the appliance without your supervi-
sion.
The manufacturer cannot be held responsible for any damages caused by improper,
incorrect or unreasonable use of the appliance.
USING THE VEN F R THE FIRST TIME
You are advised to carry out the following operations:
– Assemble the interior of the oven as described under the heading “Cleaning and
maintenance”
– Switch the empty oven O at maximum temperature for about two hours to elimi-
nate traces of grease and smell from the components.
– Let the oven cool down, switch off the electrical supply, then clean the inside of the
oven with a cloth soaked in water and neutral detergent and dry thoroughly.

4
Control panel 1
Fig. 1.1
A
U
T
O
P
A
U
T
O
6-71
251
9-10-111
12-131
43
2
2
43
43
43
2
81 2
43
Fig. 1.2
Fig. 1.3
Fig. 1.4
Fig. 1.5

5
C NTR L PANEL
1. Oven thermostat knob
2. Function selector knob
3. Power on indicator lamp
4. Oven temperature indicator lamp
5. Electronic programmer
6. Electronic clock/end cooking timer
7. Electronic clock
8. Clock and timer with “Touch-Control” keys
9. Clock programmer (start-end)
10. Electric clock with alarm
11. Electric clock
12. Timer (120’ cut-off)
13. 60’ alarm
GREASE FILTER (some models only)
– A special screen is provided at the back of the oven to catch grease particles, main-
ly when meat is being roasted (see page 29).
– When baking pastry etc. this filter should be removed.
– Always clean the filter after cooking as any solid residues on it might adversely affect
the oven performance.

6
GENERAL FEATURES
As its name indicates, this is an oven
that presents particular features from an
operational point of view.
In fact, it is possible to insert 8 differ-
ent programs to satisfy every cooking
need.
The 8 positions, thermostatically con-
trolled, are obtained by 4 heating ele-
ments which are:
- Lower element 1300 W
- Upper element 1000 W
- Grill element 2000 W
- Circular element 2200 W
N TE:
Upon first use, it is advisable to oper-
ate the oven at the maximum tempera-
ture (thermostat knob on position 225)
for 60 minutes in the position and
to eliminate possible traces
of grease on the heating elements.
Repeat the operation for another 15
minutes with the grill element on as
explained in the chapters GRILLI G and
USE OF THE GRILL.
WA NING:
The door is hot, use the handle.
During use the appliance becomes hot.
Care should be taken to avoid touch-
ing heating elements inside the oven.
Attention: the oven door becomes
very hot during operation.
Keep children away.
How to use the oven 2
PERATING PRINCIPLES
Heating and cooking in the 8-FU C-
TIO oven are obtained in the following
ways:
a. by normal convection
The heat is produced by the upper
and lower heating elements.
b. by forced convection
A fan sucks in the air contained in the
oven, which circulates it through the
circular heating element and then
forced back into the oven by the fan.
Before the hot air is sucked back
again by the fan to repeat the
described cycle, it envelops the food
in the oven, provoking a complete
and rapid cooking. It is possible to
cook several dishes simultaneously.
c. by semi-forced convection
The heat produced by the upper and
lower heating elements is distributed
throughout the oven by the fan.
d. by radiation
The heat is radiated by the infra red
grill element.
e. by radiation and ventilation
The radiated heat from the infra red
grill element is distributed throughout
the oven by the fan.
f. by ventilation
The food is defrosted by using the
fan only function without heat.

7
THERM STAT KN B (fig. 2.1)
To turn on the heating elements of the
oven, set function selector knob to the
required position and the thermostat
knob to the desired temperature.
To set the temperature, turn the ther-
mostat control knob indicator mark to
the required temperature.
The elements will turn on or off auto-
matically which is determined by the
thermostat.
The operation of the heating elements is
signalled by a light placed on the con-
trol panel.
Fig. 2.2Fig. 2.1
FUNCTI N SELECT R KN B (fig. 2.2)
Rotate the knob clockwise to set the
oven to one of the following functions:
VEN LIGHT
By turning the function selector knob to
this setting, the oven light will illuminate
in the oven cavity
.
The oven light will operate on all select-
ed functions.
TRADITI NAL C NVECTI N
C KING
The upper and lower heating elements
are switched on.
The heat is diffused by natural convec-
tion and the temperature must be reg-
ulated between 50°C and MAX position
with the thermostat knob.
It is necessary to preheat the oven
before introducing the foods to be
cooked.
Recommended for:
For foods which require the same cook-
ing temperature both internally and
externally, i. e. roasts, spare ribs,
meringue, etc.

8
GRILLING
The infra-red heating element and the
rotisserie motor are switched on. The heat
is diffused by radiation.
Use with the oven door closed and
the thermostat knob must be regulated
between 50°C and 200°C max.
For correct use see chapter “USE OF THE
GRILL” and “USE OF THE ROTISSERIE”
Always grill with the oven door
closed.
Recommended for:
Intense grilling action for cooking with the
rotisserie; browning, crisping, “au gratin”,
toasting, etc.
VENTILATED GRILL C KING
The infra-red grill and the fan are on.
The heat is mainly diffused by radiation
and the fan then distributes it through-
out the oven.
The temperature must be regulated
between 50°C and 200°C max with the
thermostat knob.
It is necessary to preheat the oven for
about 5 minutes.
For correct use see chapter “GRILLI G
A D AU GRATI .
Always grill with the oven door
closed.
Recommended for:
For grill cooking when a fast outside
browning is necessary to keep the juices
in, i. e. veal steak, steak, hamburger,
etc.
L WER HEATING ELEMENT
In this position only the lower element is
switched on.
Heat is distributed by natural convec-
tion. The temperature can be set
between 50 and MAX position.
Recommended for:
To complete cooking of dishes that
require higher temperature at the bottom.
UPPER HEATING ELEMENT
In this position only the upper element is
switched on.
Heat is distributed by natural convec-
tion. The temperature can be set
between 50 and MAX position.
Recommended for:
To complete cooking of dishes that
require higher temperature at the top.
C NVECTI N C KING WITH
VENTILATI N
The upper and lower heating elements
and the fan turn on.
The heat coming from the top and bot-
tom is diffused by forced convection.
The temperature must be regulated
between 50°C and MAX position with
the thermostat knob.
Recommended for:
For foods of large volume and quantity
which require the same internal and
external degree of cooking; for ex: rolled
roasts, turkey, legs, cakes, etc.

9
DEFR STING FR ZEN F DS
Only the oven fan is on.
To be used with the thermostat knob in
the off “●” position because the other
positions have no effect.
The defrosting is done by simple venti-
lation without heat.
Recommended for:
To rapidly defrost frozen foods; 1 kilo-
gram requires about one hour.
The defrosting times vary according to
the quantity and type of foods to be
defrosted.
H T AIR C KING
The circular element and the fan are on.
The heat is diffused by forced convec-
tion and the temperature must be reg-
ulated between 50°C and MAX position
with the thermostat knob.
It is not necessary to preheat the oven.
Recommended for:
For foods that must be well done on the
outside and tender or rare on the inside,
i. e. lasagna, lamb, roast beef, whole
fish, etc.
The external parts of the oven
become hot during operation.
Keepchildren well out of reach.
C KING ADVICE
STERILIZATI N
Sterilization of foods to be conserved, in
full and hermetically sealed jars, is done
in the following way:
a. Set the switch to position .
b. Set the thermostat knob to position
185 °C and preheat the oven.
c. Fill the grill pan with hot water.
d. Set the jars into the grill pan making
sure they do not touch each other
and the door and set the thermostat
knob to position 135 °C.
When sterilization has begun, that is,
when the contents of the jars start to
bubble, turn off the oven and let cool.
REGENERATI N
Set the switch to position and the
thermostat knob to position 150° C.
Bread becomes fragrant again if wet
with a few drops of water and put into
the oven for about 10 minutes.
R ASTING
To obtain classical roasting, it is neces-
sary to remember:
– that it is advisable to maintain a tem-
perature between 180 and 200 °C.
– that the cooking time depends on the
quantity and the type of foods.

10
C KING DIFFERENT DISHES AT
THE SAME TIME
With the function selector in position
, the ventilated oven allows you to cook
different types of food at the same time.
Fish, cakes and meat can be cooked
together without the smells and flavours
mixing.
The only precautions required are the
following:
– The cooking temperatures must be as
close as possible with a maximum dif-
ference of 20° - 25°C between the dif-
ferent foods.
– Different dishes must be placed in the
oven at different times according to
the cooking time required for each
one. This type of cooking obviously
provides a considerable saving on
time and energy.
GRILLING AND “AU GRATIN”
Grilling may be done by selecting
grill+fan setting with the function
selector knob, because the hot air com-
pletely envelops the food that is to be
cooked.
Set the thermostat knob between 50°C
and 200°C max and after having pre-
heated the oven, simply place the food
on the grid.
Close the door and let the oven oper-
ate until grilling is done.
Adding a few dabs of butter before the
end of the cooking time gives the gold-
en “au gratin” effect.
Grilling with the oven door closed.
It is recommended that you do not
grill for longer than 30 minutes at any
one time.
Attention: the oven door becomes
very hot during operation.
Keep children away.
USE F THE GRILL
Set the switch to position and the
thermostat knob between 50°C and
200°C max.
Leave to warm up for approximately 5
minutes with the door closed.
Introduce the food to be cooked, posi-
tioning the rack as close to the grill as
possible.
The dripping pan should be placed
under the rack to catch the cooking
juices and fats.
Grilling with the oven door closed.
Grilling with the oven door closed and
do not for longer than 30 minutes at
any one time.
Attention: the oven door becomes
very hot during operation.
Keep children away.
