Spectrum/VMAX2/Plus4 Series
Electric/Motorized Projection Screen
User Guide

Rev. 091709-JA
www.elitescreens.com [e-mail]
Im
p
ortant safet
y
and warnin
g
p
recautions
1. Be sure to read this user guide before use and follow the procedures below.
Please retain this manual for future reference.
To avoid any damage, do not use in conjunction with any accessories not recommended by the
manufacturer. Handle the device carefully during transportation to avoid damage.
To ensure safe and reliable operation, direct connection to a properly grounded power source is
advised.
The power outlet supplying power to the unit should be close to the unit and easily accessible.
Do not install the device on uneven or inclined surfaces.
Do not put heavy objects on the power cord and position it properly to avoid creating a trip obstacle.
Never overload the power cord to prevent an electric shock or fire.
Guard the device from any liquid or foreign objects to avoid electrical shock or fire due to loose
contact or short circuit.
There are no user serviceable parts in the device. Do not attempt to disassemble this device by
yourself. No one except authorized technicians can open this device to make repairs.
Make sure the power source this device is connected to has a continuous power flow.
If there is a need to use an extension cord, make sure the cord has the same equal rating as the
appliance to avoid overheat.
Do not handle the power plug when your hands are wet or your feet are in contact with water.
2. Do not use this device under the following circumstances:
Disconnect the power cord under the conditions of heavy rain, wind, thunder or lighting.
Avoid direct sunshine, rain shower or moisture.
Keep away from fire sources and high temperature to prevent this device from overheating.
Cut off the power supply first before transportation or maintenance.
Fully disconnect from the power supply when screen is not in use for a long period of time, as should
be done with any other electric household appliance. .
To avoid possible injury and/or an electric shock, do not attempt to use the screen if there is obvious damage or
if there are any evident broken parts

Rev. 091709-JA
www.elitescreens.com [email protected]
W
arning
Accessories for S
p
ectrum an
d
VMAX2
Bubble level
Eye receiver
(Optional for Spectrum)
When using your IR remote,
always be sure to point your
remote at the IR receiver.
2 x AAA Batteries
Wall
b
ox switch
Red12V Green 0V
5-12 volt trigger cable
N
ote: Contact your reseller for optional
accessories or visit shop.elitescreens.com
f
or accessories purchase.
RFremote
(Optional for Spectrum)
IR remote
Individual modifications to this product are prohibited and will void the warranty. Please contact Elite
Screens Customer Service for any questions.
NOTE:
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to
Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful interference in a residential
installation. This equipment generates and can radiate radio frequency energy and, if not installed and used
in accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this equipment
does harmful interference to radio or television reception, which can be determined by turning the equipment
off and on, the user is encouraged to try to correct the interference by one or more of the following measures.
9Reorient or relocate the receiving antenna of the device which may be causing interference
9Increase the separation between the screen and the device’s receiver
9Connect the equipment into a different power outlet than the device

Rev. 091709-JA
www.elitescreens.com in[email protected]om
2. For the best support of your screen, it is ideal to secure your screen into the studs of your house's internal
framework. If studs are not available, use hollow anchors for mounting your wall- screws in drywall. If you
are installing in a concrete structure, use the concrete bolts for securing your screen into concrete walls.
(Always consult a professional installer or hardware professional to ensure that the proper screws and/or
anchors are used)
3. Ensure tha
t
b
oth brackets are in perfec
t
level alignmen
t
with one anothe
r
. Use wall/ceiling wood
screws tosecure to the wood studs.Usehollow wall anchors if mountingin drywall.
4. Position a washer to the head of the wall-screw. The washers give added stability by enabling the screw
t
o
remain firmly anchored to the wall.
5. The screen casing is designed to accept the wall screws directly. If not using the Optional L- brackets
b
e sure
to position the washer between the head of the wall-screw and the anchor slots on the screen’s casing
1. Select the location for your screen. Ensure that it is within a reasonable proximity from you
r
power source.
Be sure to allow for a reasonable angle of projection.
1. Using a tape measure, mark the keyholes that are located at the back of the screen's casing end cap.
2. After marking the area and predrilled hole, insert the screw and leave at least 1/8” of an inch from the wall
to mount the screen. (Fig. 1)
Regardless of mounting method, screen should
b
e securely supported so tha
t
vi
b
ration or pulling on
the viewing surface will not cause casing to become loose or fall. Installer must insure that fasteners
used are of adequate strength and suitable for the mounting surface chosen.
PRE INSTALLATION
1. Carefully unpack the screen
2. Always handle the screen in a leveled position on a clean surface.
3. In order to protect the screen from exposure to stains, keep the screen out of contact with
foreign particles such as dust, sawdust, and/or liquids.

Rev. 091709-JA
www.elitescreens.com [e-mail]
O
pt
i
onal
i
nstallat
i
on method us
i
ng a cha
i
n to hang the screen
f
rom the ce
i
l
i
ng
Fig.2
Fi
g
. 1

Rev. 091709-JA
www.elitescreens.com [e-mail]
12-V Tri
gg
er
The VMAX2 and Spectrum Screens have the capability of using a 12-Volt Trigger.
To Projector
Red DC12V
Green
0V
Video Pro
j
ection Interface
12-VoltTriggerAssembly
Diag
r
am A
Wall-mounted 3-way-switch
1. Bubble Level: Included with the installation package is a
small bubble level that can be useful in determining if the
screen is
p
erfectl
y
level when installin
g
.
Dia
g
ram B
Bubble Level
2. Below is the RF remote with a range of 100 Ft.
(Radio Frequency)
Note: When you get the optional RF, you should
follow the instruction and adjust the code.
Infrared “Eye” Sensor with
IR Remote Control
3. Below is the IR remote (Infra Red) with a
range of 15 Ft.
(Infra Red)
N
ote: The light on this remote does not turn on
when the buttons are depressed unlike the RF
remote.
Radio Frequency Remote Control Infrared Remote Control

Rev. 091709-JA
www.elitescreens.com [e-mail]
FAQ’S
1.
Q
: Wh
y
does m
y
screen no lon
g
er function?
A: There are a few
p
ossible thin
g
s
y
ou could check:
I.)Make sure your wall plug has power and that the screen is properly plugged in.
II.) Please check the fuse to y our screen. (Call Tech support for location of fuse)
III.) If screen works well with the line switch but not with the remote control, make sure the remote control has good
batteries in it.
IV.) Our electric screens with a tubular motor installed are equipped with a Thermal relay. This would include all
Home (2, 3), Tension (1, 2, 3) series, and VMAX screens with a diagonal size above 180". This feature will
automatically shut off screen in the event the motor becomes too hot, preventing overheating of the motor. To
correct this, let screen alone for 10-15 minutes and try again.
2. Q: How is the screen material cleaned?
A: The screen material can be cleaned with mild soap and water.
3. Q: What type of batteries do the remote controls require?
A: The IR and RF remote controls use AAA alkaline batteries
4. Q: Can you manually pull down the screen?
A: No, manually pulling down the screen will damage the electronic motor rolling system.
5. Q: How could I setup my Screens IR receiver to work with my learning remote control system?
Do you have any IR codes I can use to achieve this?
A: Our IR remote controls have been evaluated and entered in to the databases of some Universal remote control
manufacturers. Please contact the manufacturer of your remote to inquire about your remotes ability to function with
ours. If they have not evaluated our remote control then the following list of Binary codes will be used for most remote
setups.
For Spectrum, VMAX2 (Plus), Home2(3) and Tension2(3) Series
Up: 1111 0000 0001
Stop: 1111 0000 0010
Down: 1111 0000 0100
6. Q: What is the gain on the matte white screen material?
A: The matte white material has a gain of 1.1. For detailed specs, info please check our web-site for more detail
N
ote: For more U
p
date FAQ,
p
lease visit www.elitescreens.com

Rev. 091709-JA
www.elitescreens.com [email protected]om
Warranty Policy
•Two (2) year warranty on parts and labor from defects in workmanship from purchase
dateasfollows.
•Eachpartywillberesponsibleforonewayshippingduringthewarrantyreturnperiod.
•DOA(DefectiveonArrival):Mustbereportedwithin7businessdaysofreceipt. 
•AnRMA(ReturnMerchandiseAuthorization)numbermustbeissuedinordertoprocessareplacementor
authorizeawarrantyrepair.  EliteScreenswillreplacetheDOA(DefectiveonArrival)unitwithabrandnew
replacement*(seeexceptionsbelow)aftertheDOAunitisreceivedand/orconfirmeddefective.Oncethe
productisreceived,EliteScreenswillsendoutanew*unittothecustomerbygroundservice(subjectto
inventoryavailability).Shouldaproblembereportedafterthe7‐daygraceperiod,theitemmustbeshipped
tousforwarrantyrepair.
•MissingPartsmustbereportedwithinthe7‐day(DOA)graceperiod. Ifreportedafter7days,customer
will only be responsible for shipping and handling fees. If reported after 30 days of receipt, customer is
responsibleforcostofthepartsandshipping&handlingfees.
•DONOTreturnanyunauthorizeditemstoEliteScreens,astheywillberefusedatshipper’sexpense.The
RMAnumbermustbeincludedontheoutsidelabelofyourshippingboxandshippingdocuments.Our
warehouseisnotauthorizedtoacceptreturnswithoutanRMAnumberontheshippinglabel.RMA
numbersarevalidfor45daysfromtheissueddate.
*A new or refurbished replacement will be sent out to the customer depending on the type of purchase (new
or refurbished) or based on stock availability.
For Warranty and Service requests please fill out a RMA /Service Form at:
http://www.elitescreens.com/service_formhtm.
Please Visit this link for full Warranty information:
http://www.elitescreens.com/service.htm
For Customer Service and Technical questions, please contact Elite Screens at:
